Parts for Kitchenaid KD2661-3: 01 - Color Variation Parts

This porcelain enamel finish restores the factory color and smooth, glossy surface to compatible ranges and cooktops, improving appearance and protecting underlying metal from wear and staining. What it does

• Replaces worn, chipped, or faded enamel finish to make the appliance look like new
• Provides a durable, heat-resistant surface that resists stains and everyday wear
• Matches the OEM "Empire Red" color for a cohesive, factory-correct appearance
• Helps protect the underlying metal from corrosion and further cosmetic damage

• One porcelain enamel finish (Empire Red)

• Disconnect power and gas before starting any repair
• Removal of trim, screws, or panels may be required; follow the appliance's OEM service instructions
• Handle with care to avoid chipping the enamel during installation

This motor housing is the outer mounting and protective enclosure for the appliance motor, finished in white to match the cabinet. It provides a secure support for the motor and helps isolate noise and vibration. What it does:

• Supports and secures the motor assembly in the appliance
• Protects the motor from debris and contact with moving components
• Helps reduce motor noise and vibration through stable mounting
• Resolves symptoms like excessive vibration, rubbing noises, or misaligned motor mounting

• One motor housing (white)

• Disconnect power to the appliance before starting any repair
• Typical installation requires removing panels and either the drum or motor access components; follow OEM instructions
• Handle housing edges carefully and retain all mounting hardware for reassembly

This Onyx black finish panel restores the appliance's exterior appearance with a factory-style color-matched surface for a clean, uniform look. Ideal for replacing a worn or mismatched decorative panel. What it does:

• Provides a color-matched exterior surface to restore cosmetic appearance
• Covers scratches, chips, or discoloration on the appliance trim or door area
• Replaces a damaged or faded decorative panel without changing function
• Keeps visible surfaces consistent with the appliance's Onyx black finish

• High-level cosmetic replacement; basic hand tools may be required
• Follow OEM instructions for removal and reattachment to avoid damaging adjacent parts
• Handle with care to avoid scratching the finish during installation
• Disconnect power before servicing

This planetary gear assembly transfers motor torque through the gearcase to drive the appliance's rotating components, restoring proper drive function and reducing abnormal noises. It's a direct-fit replacement designed to match OEM form and fit. What it does

• Transfers motor rotation through the gear train to the driven components (basket/agitator/drum) so the appliance can spin or agitate as intended
• Replaces worn or damaged gears that can cause grinding, clunking, slipping, or loss of drive
• Restores proper gear mesh to reduce vibration and abnormal operating noise
• Helps eliminate intermittent or complete loss of rotational motion caused by stripped or broken gear teeth

• One planetary gear assembly as shown

• Disconnect power before beginning service to avoid electrical shock
• Installation requires basic hand tools and access to the gearbox/drive housing; follow the OEM service manual for disassembly/reassembly procedures
• Inspect surrounding seals, bearings and fasteners for wear and replace as needed to prevent recurring damage

This planetary gear assembly transfers motor torque through the gearbox to drive the appliance's internal mechanism, restoring proper gear-driven motion and reducing slipping or grinding during operation. What it does:

• Re-meshes the motor output into the gearbox so driven components rotate smoothly
• Helps eliminate symptoms like noisy gearing, uneven movement, or loss of drive
• Restores proper gear engagement when worn or damaged planetary gears cause slipping
• Works as the internal gear cluster that distributes torque to downstream parts

• High-level replacement: remove power and access the gearbox or motor housing; replace the worn planetary assembly with the matching unit
• Use proper tools and follow the appliance service manual for disassembly/reassembly to avoid damaging seals or fasteners
• If gears were damaged, inspect mating gears, bearings, and shafts for wear before reassembly
• Dispose of damaged gears properly;

This planetary gear assembly transfers motor torque into the agitator/drive mechanism so the appliance can rotate or agitate correctly. It replaces a worn or damaged planetary gear to restore normal drive motion and reduce noise. What it does

• Converts motor output into the rotational motion used by the drive/agitator system
• Stops slipping or inconsistent rotation when gear teeth are worn
• Reduces grinding, clunking, or excessive noise caused by a failing gear
• Helps prevent further damage to the gearcase by replacing a stripped or broken gear

• Disconnect power and water before starting any repair
• Installation may require access to the gearcase or agitator; follow OEM service instructions
• Use appropriate hand tools and retain any fasteners for reassembly

This planetary gear assembly transfers motor torque through the drive system to enable the washer's agitation and/or spin functions. Replacing a worn planetary restores reliable rotation and reduces noise caused by damaged gears. What it does:

• Drives the washer's agitator/drum by transferring motor power through the gear train
• Restores normal agitation and spinning when worn gears cause slipping or no movement
• Stops or reduces grinding, knocking, or unusual gear noise originating from the gearbox
• Works as the internal gearset inside the transmission/gearcase to maintain proper drivetrain operation

• Always disconnect power to the appliance before starting any repair
• Access typically requires removing the washer cabinet or transmission cover; follow OEM service instructions
• Support the drum/transmission and use appropriate tools to avoid further damage

This planetary is the replacement internal gear assembly that helps transfer motor motion to the agitator/impeller for proper wash action. It restores drivetrain engagement so the washer can agitate and spin more effectively. What it does:

• Replaces a worn or damaged planetary gear assembly that causes weak or no agitation/spinning
• Transmits motor torque to the transmission and agitator/impeller for normal wash cycles
• Can address symptoms like intermittent agitation, loud grinding noises, or slipping during cycles
• Fits into the transmission/gearcase as a direct replacement when the original planetary fails

• Inspect surrounding seals and gears during replacement
• Disconnect power and water supply before beginning any repair
• Use proper tools and follow OEM diagram for correct orientation and torque; avoid forcing parts to prevent damage
• Replace any worn fasteners or gaskets found during installation

This planetary assembly restores the mixer's planetary mixing action by linking the gearcase to the beater shaft. It replaces a worn or damaged lower hub to deliver smooth, consistent attachment rotation. Finish: imperial gray.

• Drives the beater/attachment shaft with true planetary motion
• Transfers power from the internal gear train to the attachments
• Helps maintain proper alignment of the lower hub
• Resolves: beater not turning, slipping, grinding/clunking from the front, or visible wobble/damage at the planetary hub

• Disconnect power; remove bowl and attachments before service
• Protect the finish; remove the drip ring to access the retaining pin
• Drive out the planetary retaining pin, slide off the old assembly, and align/install the new one
• Seat the pin fully and verify smooth rotation before reassembly and testing

The Planetary is an OEM part for Whirlpool stand mixers. This part holds the beater and ensures it rotates around the bowl to mix ingredients thoroughly. The planetary mechanism allows for consistent and even mixing by moving the beater in a planetary motion, which covers the entire bowl.

Causes of a bad planetary can include regular wear and tear, heavy use, or mechanical failure within the gears.

Symptoms of a bad planetary include:

• Beater not rotating properly
• Unusual noises during operation
• The mixer head wobbling or shaking
• Inconsistent mixing results

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Color: Metallic Chrome

The Planetary Assembly is an OEM replacement part for Kitchenaid stand mixers. It is the central component that transmits rotational power from the motor to the mixing attachment through an intricate system of gears.

Causes of a bad planetary assembly can include worn gears that no longer mesh properly, broken or missing gear teeth from overloading, or a failed bearing.

Symptoms of a bad planetary assembly include:

• Slipping or jumping of gears during mixing
• Grinding or scraping noises
• Inability to mix thoroughly on higher speeds
• Premature failure of the motor

This OEM replacement is also compatible with Maytag, Whirlpool, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Planetary Assembly is an OEM part for Whirlpool stand mixers. This component is responsible for holding the mixer attachments and rotating them around the bowl, ensuring thorough and even mixing of ingredients.

Over time, the planetary assembly can become worn out or damaged due to frequent use, heavy mixing loads, or lack of proper maintenance. If the planetary assembly is not functioning correctly, it can result in poor mixing performance and uneven results.

Symptoms of a bad planetary assembly include:

• Unusual noises during operation
• Attachments not rotating properly or wobbling
• Inconsistent mixing or ingredients not being fully incorporated
• The mixer head not locking into place

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This door trim restores the appliance's exterior appearance by replacing a damaged or missing Caviar-finish trim piece. It returns a clean, finished look and helps cover fasteners and edges for a seamless door surface. What it does

• Replaces worn, scratched, or gouged trim to improve cosmetic appearance
• Covers mounting holes and seams for a finished look
• Helps maintain proper door alignment where trim interfaces with adjacent parts
• Common symptom: visible chips, scratches, or missing trim exposing fasteners

• One door trim piece in Caviar finish

• Disconnect power to the appliance before beginning service
• Use basic hand tools; remove surrounding trim or fasteners as required for access
• Handle carefully to avoid scratching the new finish during installation
• Follow model-specific instructions for correct alignment and fastening

This Empire red touch-up paint restores the original appliance finish to cover chips, scratches, and small blemishes for a clean, uniform look. Ideal for maintaining the appliance's appearance between larger repairs or panel replacements. What it does:

• Matches the Empire Red appliance color to conceal chips and surface scratches
• Prevents small bare spots from showing and improves overall cosmetic appearance
• Helps maintain consistent color on exterior panels and trim
• Useful for spot repairs after minor impacts or wear

• Clean and dry the surface thoroughly; remove grease and loose paint before applying
• Apply in thin coats, allowing recommended dry time between coats for best results
• Test on an inconspicuous area first to confirm color match
• Follow all product label warnings; use in a well-ventilated area and keep away from heat and open flame

A white replacement bowl support that centers and stabilizes the appliance bowl or glass tray to reduce wobble and noise, helping restore smooth rotation and reliable operation. What it does:

• Centers and supports the bowl or glass tray to prevent off-center rotation and rubbing.
• Keeps the tray steady to reduce vibration and noisy operation.
• Helps the tray rotate smoothly for even heating or proper function.
• Common symptoms it can address: wobbling or off-center bowl/tray, noisy rotation, scraping or unstable tray movement.

• Disconnect power to the appliance before starting any work.
• Remove the bowl or glass tray and lift out the old support; inspect the drive hub or shaft for damage.
• Align the support over the hub/shaft and press into place until fully seated; do not force broken or warped plastic.

This gearcase transfers motor power to the wash tub and agitator, restoring normal agitation and spin cycles for top-load washing machines. Replaces a worn or failed transmission assembly to recover wash performance. What it does:

• Converts motor rotation into the low-speed/high-torque motion needed for agitation and the higher-speed motion for spin
• Restores normal agitation and spinning when a washer fails to move or completes cycles poorly
• Reduces grinding, clunking, or slipping noises caused by worn internal gears
• Helps stop leaks of internal gear lubricant when the seal or housing is compromised

• One gearcase assembly

• Disconnect power and shut off water before starting; follow the washer service manual for safe disassembly
• Gearcase replacement may require removal of the inner tub, drive coupler, and mounting hardware—have basic hand tools ready
• Inspect surrounding seals, gaskets, and mounting bolts; replace any damaged components to prevent leaks

This gearcase is the washer transmission that transfers motor torque to the agitator and basket so the washer can agitate and spin properly. Replaces a worn or damaged gearbox to restore normal wash movement. What it does:

• Transfers drive from the motor to the agitator and outer basket for agitation and spinning
• Replaces stripped or noisy gears that cause grinding, clunking or loss of agitation
• Stops slipping or intermittent agitation caused by internal gear failure
• Helps eliminate unusual vibration or rough operation linked to a failing gearbox

• Disconnect power and turn off water supply before beginning service
• Requires partial disassembly of the washer cabinet and transmission area; follow OEM instructions
• May contain lubricant—inspect seals and surrounding components for leaks while installed

This lower gearcase transfers motor power to the washer's transmission, driving the agitator and drum movement. Replacing a worn gearcase restores proper agitation and reduces grinding or slipping during cycles. What it does:

• Drives the agitator/drum by housing gears that transfer motor torque to the transmission
• Fixes symptoms like no agitation, weak agitation, loud grinding or gear-noise during spin/agitate
• Helps restore consistent wash action and proper load handling when gears are damaged or worn
• Works as the lower gearbox assembly in compatible top-load washers

• One lower gearcase assembly (Imperial Black)

• Disconnect power and water supply before starting; drain washer tub to avoid spills
• Follow the washer's service manual for disassembly steps; removing the agitator and transmission access may be required
• Inspect surrounding seals, bearings and fasteners during replacement and replace if damaged
• Use proper tools and torque specifications

This lower gearcase is the replacement gearbox that transfers motor power to the appliance's drum/rotating assembly, restoring reliable drive movement and reducing grinding or slipping during operation. What it does:

• Transfers motor rotation to the appliance's drum or rotating assembly for normal operation
• Restores proper drive engagement to stop slipping or intermittent rotation
• Eliminates grinding, scraping, or unusual drive noises when worn
• Helps prevent further wear to belts and related drive components

• One lower gearcase (onyx black) as pictured

• Disconnect power before starting and follow for disassembly/reassembly
• Installation typically requires panel removal and basic hand tools; support the drum/assembly while replacing the gearcase
• Inspect and replace worn belts, idlers, or fasteners as needed to ensure long-term operation

This gearcase is the main transmission assembly that transfers motor torque to the washer's tub and agitator, restoring normal agitation and spin performance when the original gearcase fails. What it does

• Converts motor rotation into the gear reductions needed for agitation and spin cycles.
• Commonly replaced for symptoms like no agitation, slow or failed spin, grinding or clunking noises during cycles.
• Contains internal gears and bearings that can wear or break, causing irregular movement or loss of drive.
• Works with the washer's motor coupling and drive components to re-establish reliable drum motion.

• One gearcase (transmission) assembly.

• Disconnect power and water supply before beginning any repair.
• Support the washer cabinet and tub when removing the old gearcase to avoid damage or injury.
• Gearcase assemblies are heavy and contain grease—expect some lubricant exposure; clean hands and work surfaces after installation.
• Use model-specific service manual or exploded parts diagram for proper alignment and reassembly; replacement may require transfer of seals or mounting hardware.

This lower gearcase housing encloses and supports the planetary and lower gear train in a stand mixer. Replacing a damaged housing restores alignment and helps contain lubrication for quieter, consistent mixing performance.

• Houses the lower gear train and planetary shaft to maintain alignment
• Provides a sealed cavity to help retain grease around gears
• Replaces cracked, stripped, or warped housings that cause wobble or noise
• Helpful when you see grease seepage or cosmetic damage to the lower case

• Unplug the mixer and remove bowl and attachments before service
• Open the motor head and remove the planetary/gear stack as required
• Transfer components to the new housing; renew food-grade mixer grease if servicing gears
• Reassemble and verify beater-to-bowl clearance and smooth operation

This bowl and foot assembly replaces a cracked or worn support bowl used to stabilize and support the appliance's internal component, restoring proper alignment and quiet operation. Durable molded construction suits direct-replacement needs. What it does:

• Supports and centers internal components to maintain smooth rotation and balance
• Replaces damaged, cracked, or warped bowl/foot that can cause rattling or uneven operation
• Restores correct spacing to prevent contact between moving parts and the cabinet
• Matches factory fit and finish for a secure, stable installation

• Disconnect power before beginning any repair to avoid electrical hazard
• Handle with care to avoid cracking the plastic; use gentle force when seating into place
• Basic hand tools may be needed to access the mounting area; model-specific diagram for access
