Parts for Alliance CTSA7AWN: Control Cabinet / Controls Parts

This replacement porcelain touch-up paint restores small chips, scratches and worn spots on enamel-coated appliance surfaces to help improve appearance and slow surface corrosion. Easy to apply for spot repairs. What it does:

• Covers small chips, scratches and scuffs on porcelain/enamel surfaces
• Helps protect exposed metal from moisture that can lead to surface rust
• Matches factory finish color on compatible porcelain-coated panels (spot repairs only)
• Useful for finishing edges around dings and improving visual appearance

• One bottle of porcelain touch-up paint

• Clean and dry the repair area thoroughly; remove loose paint and rust before applying
• Test paint in an inconspicuous spot to confirm color match and adhesion
• Apply sparingly with a fine brush or applicator; allow recommended drying time between coats
• Keep away from open flame; store and dispose of per local regulations; keep out of reach of children

This genuine OEM replacement part is a washer control board for commercial Speed Queen Washers. The control board is the main computer of a washer and controls the washing machine's essential functions. If the washer is no longer turning on, spinning, rinsing, or draining properly, it could mean that it needs to be replaced. Luckily replacing a control board is generally an easy repair.Start by unplugging the washer and pulling it out from the wall. Remove the upper back panel to gain access to the control board. Release the locking tabs that hold the control board in place and remove the wire harness along with any individual wires attached to the old board. Make sure to take note of the orientation of the wires by taking a picture with a phone camera. Reconnect the wire harness and individual wires into their correct terminals on the new board and snap it back in place. reinstall the upper back panel and put the washer back in place.This replacement part is sold individually and is compatible with Speed Queen Commercial washing machines.

This 3-position fabric selector switch is the control behind the knob that lets you choose the fabric setting on your unit. Replacing a worn switch restores positive detents and ensures your selection is recognized instead of ignored or stuck.

• Provides three selectable fabric settings to tailor operation
• Routes the chosen setting to the timer/control
• Typical symptoms: no response when changing settings, intermittent selection, or being stuck on one mode
• Physical clues of failure: loose/no detent feel, broken shaft, or heat-discolored terminals

• Disconnect power before servicing
• Access the control console; remove the knob and retaining hardware to free the old switch
• Photograph/label wire positions and transfer each lead to the same terminals on the new switch
• Reassemble and test all three positions for proper engagement

This timer knob assembly is the replacement control knob that lets you set and adjust cycle time on the dryer/washing machine control. It restores a secure grip and clear cycle selection so you can operate the machine easily. What it does:

• Provides a firm, easy-to-turn control for selecting timer settings and cycles
• Replaces cracked, stripped, or missing knobs that are hard to turn or won't stay set
• Helps ensure the timer/control shaft is engaged for accurate cycle selection
• Matches OEM fit and function for a direct replacement when the knob is worn or damaged

• Disconnect power to the appliance before attempting replacement
• Knob typically pulls straight off the control shaft; align splines and press on until seated
• If a retaining clip or screw is present, remove and reinstall as needed—retain hardware
• Do not force the knob; confirm proper alignment to avoid damaging the control shaft

This timer knob assembly replaces a worn or broken control knob so you can confidently select and adjust cycles. A fresh knob restores a positive grip on the timer shaft and smooth, accurate operation.

• Mounts on the timer shaft to turn and set cycle selection and time
• Restores secure engagement when the original knob is cracked, stripped, loose, or missing
• Helps ensure the timer turns when you rotate the knob
• Common symptoms: knob spins without engaging, difficult to set cycles, visible damage

• Disconnect power to the appliance before servicing
• Pull the old knob straight off the timer shaft; avoid prying that could damage the control
• Align the new knob with the shaft (flat/D-shape) and press until fully seated
• If the original used a small insert or spring clip, transfer it to the new knob if needed

This is a control knob for washing machines. This control knob is used to adjust the water temperature and level settings on the unit. It is manufactured out of a white plastic. The replacement is very easy and takes less than 15 minutes to complete. All that this process involves is pulling the old knob off and sliding the new knob on.A new control knob will be needed if the original is cracked, broken, or damaged in any way. Over time, the white plastic may begin to yellow, and the user may wish to replace the control knob for cosmetic purposes. If the knob is not actuating the desired cycle, it will need to be replaced.This control knob is a genuine SpeedQueen part and is an OEM part sourced directly from the manufacturer. It is sold individually. This specific control knob is compatible with washing machines that are manufactured by the SpeedQueen brand.

This momentary push-to-start switch sends the start command to the washer's control when pressed, restoring reliable Start-button response. It's the common replacement for a worn or unresponsive start control in affected machines. What it does:

• Provides a momentary contact to signal the control board to begin a cycle.
• Replaces a faulty start button that's unresponsive, requires multiple presses, or fails intermittently.
• Installs in the machine console and connects to the existing switch connector.
• Works with factory control circuits to deliver a simple, tactile Start command.

• Disconnect power to the appliance before beginning any repair.
• Access the switch through the console or control panel.
• Handle wiring connectors gently and ensure secure, correct connections before restoring power.
• After installation, run a test cycle to ensure proper Start-button operation.
