Parts for Whirlpool WFW8400TE01: 04 - Dispenser Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

The Water Inlet Valve is an OEM part for Whirlpool washing machines. It controls the flow of water into the washer during the fill cycles, ensuring that the correct amount of water enters the tub for washing and rinsing. This valve is crucial for the proper functioning of the washing machine, as it regulates the water temperature and flow.

Causes of a bad water inlet valve can include mineral deposits from hard water, wear and tear over time, or electrical malfunctions. These issues can cause the valve to either not open or close properly, leading to water flow problems.

Symptoms of a bad Water Inlet Valve include:

• The washer not filling with water
• Slow fill cycles
• Water leaking from the valve
• Incorrect water temperature during cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This drain hose carries used water from the appliance to the household drain. A secure, leak-free drain path helps prevent water from backing up or leaking during and after a cycle.

• Routes wastewater from the unit to the standpipe or sink drain
• Helps resolve issues like slow or incomplete draining
• Can address leaks found around the rear or drain area
• Restores proper water exit flow after hose damage or kinks

• Unplug power and shut off water before servicing
• Have a towel or shallow pan ready to catch residual water
• Note hose routing and connections before removal; transfer any clamps if reused
• Ensure tight, watertight connections and proper routing without kinks

The Hose Clamp is an OEM part for Whirlpool appliances. It secures hoses in place, ensuring a tight connection and preventing leaks in various systems such as washing machines, dishwashers, and refrigerators. This clamp is crucial for maintaining the integrity of the water or air lines it secures.

Causes of a bad hose clamp include wear and tear over time, exposure to water and detergents, or mechanical stress from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Leaks at the hose connection points
• Hoses slipping off the connections
• Visible rust or damage on the clamp
• Reduced appliance efficiency due to leaks

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This replacement screw secures appliance components and panels so they stay aligned and rattle-free during operation. Replace stripped, missing, or corroded hardware to restore a tight fit and dependable performance. What it does

• Fastens brackets, panels, and internal sub-assemblies in the appliance
• Helps maintain alignment to reduce vibration and rattling
• Replaces missing, rusted, or stripped screws that no longer hold
• Useful when a part won't mount securely or a screw backs out during use

• One screw

• Disconnect power; for gas appliances, also shut off the gas supply
• Compare to the original for length and thread style for the location
• Start threads by hand to avoid cross-threading; use the correct driver bit
• Do not overtighten; if the mounting hole or clip is worn, replace it

This nozzle directs and focuses water flow inside the dishwasher so dishes get a thorough rinse. Replaces a worn, cracked, or clogged nozzle to restore spray coverage and help prevent poor cleaning performance. What it does

• Channels water from the spray arm or manifold to create a targeted spray pattern
• Helps maintain even water distribution across racks for better cleaning
• Clogs, cracks, or damage can cause weak spray or spotty wash results
• Compatible with systems that use a snap- or press-fit nozzle on the spray assembly

• Disconnect power and water supply before starting any repair
• Remove the spray arm or access panel as needed to reach the nozzle
• Inspect mating surfaces for debris; press or snap the new nozzle into place until seated

The dispenser actuator cam links the actuator to the dispenser mechanism, converting movement into a precise release. Replacing a worn or broken cam restores smooth, reliable dispensing and helps prevent incomplete or erratic operation. What it does:

• Transfers actuator motion to engage or release the dispenser mechanism
• Maintains correct alignment and travel for consistent operation
• A worn or broken cam can cause the dispenser not to open/close, feel loose or sticky, or make unusual clicking noises
• Common corrective part when the actuator moves but the dispenser doesn't function properly

• 1 dispenser actuator cam

• Disconnect power; turn off water supply if applicable before servicing
• Access the dispenser assembly per your model; note linkage/spring orientation (take photos) before removal
• Align the new cam carefully—do not force; verify smooth actuator travel by hand
• Reassemble and test operation before finalizing

Water distribution lever

The Dispenser Motor and Switch Assembly is an OEM component for Whirlpool washing machines. It operates the detergent and softener dispensers during the wash cycle. The dispenser motor and switch assembly work together to open and close the dispenser drawers at precise times, ensuring detergent and softener are released in the drum at the appropriate phases for optimal cleaning performance.

Causes of a bad dispenser motor and switch assembly can include electrical failures, wear and tear from regular use, or damage from water exposure. These factors can cause the motor to burn out or the switch to malfunction, disrupting the dispensing process.

Symptoms of a bad Dispenser Motor and Switch Assembly include:

• Detergent or fabric softener not dispensing
• Unusual noises from the dispenser area
• Washer displaying error codes related to the dispenser
• Inconsistent or incomplete wash cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This drawer hook is the retainer that keeps an appliance drawer securely seated while still allowing easy release for cleaning or service. Replacing a worn or broken hook restores smooth, reliable drawer operation.

• Secures the drawer in its housing so it stays closed during use
• Acts as the catch/release point for removing the drawer when needed
• Helps maintain proper alignment for smooth opening and closing
• Common symptoms: drawer won't stay closed, pops open or falls out, won't latch, or the hook is visibly cracked/missing

• Disconnect power before servicing
• Fully open and remove the drawer to access the hook area
• Align the new hook with the slots/tabs and snap or seat it into place
• Avoid forcing components; refer to the service manual for model-specific steps

This clamp secures flexible hoses and small-diameter tubing to fittings, helping prevent leaks and maintain proper fluid flow in appliance systems. It's a simple replacement that restores a tight, reliable connection. What it does

• Holds a hose or tube firmly on a barb or nipple to stop leaks and loss of pressure
• Keeps water, drain, or vent hoses seated during normal appliance operation
• Replaces worn, corroded, or loose clamps that cause dripping or poor connections
• Works where a small, durable clamp is required for routing or securing tubing

• One hose clamp

• Inspect hose and fitting for damage; replace hose if cracked or hardened before installing the clamp
• Tighten clamp until snug—do not overtighten; ensure even compression around the hose
• Disconnect power and water as appropriate and take safety precautions before working on the appliance

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

Connector lever

This distribution nozzle directs water flow inside the dishwasher to help ensure proper spray coverage and detergent/rinse aid distribution. Replacing a damaged nozzle restores targeted water delivery for better cleaning and drying performance. What it does:

• Directs and shapes spray from the wash assembly for targeted cleaning
• Helps distribute rinse aid/detergent where designed for optimal results
• Prevents leaks or misdirected spray caused by cracks or clogs
• Faulty nozzles can cause poor cleaning, spotting, or uneven wash performance

• Disconnect power and water supply before beginning any repair.
• Inspect surrounding spray arm/assembly for damage or debris before installation.
• Most installs are a snap-fit or secured with simple fasteners; avoid over-tightening.

The Dispenser Hose is an OEM replacement part for Whirlpool washing machines. This hose is integral in the detergent dispensing system, channeling liquid detergent and other washing agents from the dispenser to the wash drum. It ensures that cleaning agents are efficiently delivered to the laundry load at the appropriate time during the wash cycle.

Symptoms of a bad Dispenser Hose include:

• Leakage of detergent or water from the dispenser
• Detergent not being dispensed into the wash drum
• Residual detergent left in the dispenser after the wash cycle
• Unusual sounds, like gurgling or splashing, during detergent dispensing

Causes for a malfunctioning Dispenser Hose can include blockages from accumulated detergent residue, cracks or holes in the hose, or issues with the connectors that attach it to the dispenser and drum.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Detergent Drawer is an OEM part for Whirlpool washing machines. This drawer holds and dispenses detergent, fabric softener, and bleach into the washer at the appropriate times during the wash cycle.

Causes of a bad detergent drawer can include buildup of detergent residue, damage from overloading, or general wear and tear.

Symptoms of a bad detergent drawer include:

• Detergent not dispensing properly
• Drawer difficult to open or close
• Leaks from the detergent drawer area
• Visible cracks or damage

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Restore the clean look and proper function of your washer's detergent compartment with this detergent dispenser drawer cover. It replaces a cracked or missing cover so the drawer closes correctly and helps reduce splashing at the dispenser. What it does:

• Covers and protects the front of the detergent dispenser drawer
• Helps the drawer align and close properly for consistent dispensing
• Replaces broken or missing cover tabs that prevent the drawer from staying in place
• Common symptoms: cracked/missing cover, broken tabs, drawer won't close or feels loose, splashing/leaks at the dispenser area

• 1 detergent dispenser drawer cover

• Unplug the appliance and shut off water supply before servicing
• Pull the dispenser drawer out and depress the release tab to remove it
• Release the locking tabs to remove the old cover; snap the new cover fully into place
• Reinstall the drawer and run a quick test to check operation

This siphon routes liquid bleach and fabric softener from the dispenser into the washer tub so additives are delivered at the correct time in the cycle. Replacing a faulty siphon restores proper dispensing and helps prevent leaks or staining. What it does:

• Directs bleach and fabric softener from the dispenser to the wash drum during the appropriate cycle.
• Ensures additives are introduced at the correct time for consistent wash results.
• A cracked, clogged, or broken siphon can cause poor dispensing, leaks, or product staining.
• Designed to fit into the dispenser assembly and work with the washer's existing dispenser plumbing.

• Disconnect power (and water if recommended) before servicing the appliance.
• Basic hand tools may be required; refer to the washer's service manual for disassembly steps.
• Handle plastic components gently to avoid cracking or misalignment of sealing surfaces.
