Parts for Ge JVM3160DF2WW: Interior Part Parts

A replacement oven lamp cover that protects and diffuses the interior light so you can see food clearly while preventing direct contact with the bulb. Fits behind the oven lamp housing to restore safe, even illumination. What it does:

• Protects the oven light bulb from food splatter, heat, and accidental contact
• Diffuses and softens the lamp output for clearer, less-glare interior visibility
• Replaces cracked, cloudy, or missing lens that can reduce oven illumination
• Helps maintain proper lamp alignment and housing coverage during use

• One lamp cover

• Disconnect power to the appliance before servicing to avoid electrical shock
• Allow the oven and bulb to cool completely before removing the old cover
• Access may require removing oven racks and/or a few screws or clips from the lamp housing
• Handle the cover carefully—glass/plastic lenses can chip or crack; tighten fasteners snugly but do not overtighten

The Grease Filter is an OEM part for GE range hoods and microwaves. It captures grease and other airborne particles generated during cooking, preventing them from accumulating in the appliance and ductwork. This filter helps maintain the efficiency of the exhaust system and reduces the risk of grease fires.

Over time, the filter can become saturated with grease and other residues, reducing its effectiveness and potentially causing odors or airflow issues.

Symptoms of a bad grease filter include:

• Reduced airflow or ventilation performance
• Persistent cooking odors
• Visible grease buildup on the filter
• The filter appearing damaged or worn

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Light Socket is an OEM part for GE microwaves. This part holds the light bulb securely in place within the microwave, providing illumination inside the appliance.

Causes of a bad light socket can include wear and tear from frequent use, exposure to high heat, or electrical issues that cause the socket to malfunction.

Symptoms of a bad Light Socket include:

• The light bulb not illuminating when the microwave is in use
• Flickering or intermittent light
• Visible damage or discoloration of the socket
• The bulb not fitting securely or falling out

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Microwave Light Bulb is an OEM replacement part for GE built-in microwaves. As the interior light source, it illuminates the cavity space to view food while cooking or when accessing the microwave.

Symptoms of a bad light bulb include:

• Dim or unilluminated microwave interior
• Burned-out bulb that will not light at all
• Premature bulb failure indicated by flickering or intermittent output

Causes involve standard filament failure over the operational lifespan of the bulb. Improper wattage replacements or defective bulbs can also lead to early burnout.

This GE OEM replacement light bulb is compatible also with some Hotpoint, Corningware, and KitchenAid models.

The Microwave Thermostat is an OEM part for GE Countertop Microwaves. It is a critical component that monitors the microwave's internal temperature to ensure safe operation.

Causes of a bad thermostat can include failure of internal components due to prolonged heat exposure during cooking cycles over many years of use. Steam and splatters introduced into the microwave from heated foods can also damage sensors.

Symptoms of a bad thermostat include:

• Inability to heat or reheat foods adequately
• Short cycling of the microwave interior lights
• Erratic power levels during cook functions
• Overheating errors or shutoffs for safety

This replacement thermostat is also compatible with RCA and some Kenmore countertop microwave models.

This temperature-sensitive thermostat helps protect the microwave and nearby components by switching the circuit based on heat. It typically engages the cooling/vent fan or opens the circuit if excessive heat is detected, preventing overheating damage.

• Monitors temperature and changes state around the 70°C/40°C range
• Helps prevent overheating of internal components during heavy cooking
• Can trigger or regulate the vent/cooling fan on over-the-range units
• Common failure signs: vent fan not auto-cycling with cooktop heat, microwave shutting off from heat, or no continuity when tested at room temp and when heated

• Disconnect power to the appliance before servicing
• Note wire positions; transfer leads one at a time to the new thermostat
• Mount firmly to its bracket or surface for correct heat sensing
• After installation, verify fan operation and monitor for proper cycling

The Capacitor is an OEM part for GE microwaves. It is an electronic component within the microwave's high voltage circuitry. The capacitor works to store and deliver high-voltage electrical energy from the main control board to the magnetron tube in short, powerful bursts required for microwave cooking.

Causes of failure can be due to natural breakdown of the capacitive material over time and use. Capacitors have a limited lifespan that is greatly reduced if subjected to heat, moisture or electrical surges.

Symptoms of a bad capacitor include:

• Inconsistent or incomplete cooking even at high power levels
• Slow or inefficient heating during use
• Sparking or burning smells emanating from inside the microwave

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The High Voltage Diode is an OEM replacement part for GE microwaves. It converts the high voltage of the microwave's power supply into a lower voltage suitable for the magnetron. It acts as a one-way valve for electrical current, allowing it to flow in one direction while preventing it from flowing back in the opposite direction.

Symptoms of a faulty high voltage diode include:

• No power or complete loss of power to the microwave
• Inconsistent or inadequate heating performance
• Unusual electrical smells during operation

A bad high voltage diode can occur due to electrical malfunctions, power surges, or excessive heat exposure. If you notice issues such as no power, uneven heating, or unusual electrical smells coming from the microwave, it may be time to replace the old or damaged high voltage diode with this genuine OEM part.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.


This nut assembly is a small mounting fastener that secures appliance components to studs or brackets, helping keep panels and internal parts stable for safe, quiet operation. What it does

• Secures components to threaded studs or bolts to prevent movement and vibration
• Restores proper fit of panels, trim, or internal assemblies when a worn or missing nut causes looseness
• Prevents electrical or mechanical contact caused by shifting parts
• Simple, durable replacement for a single mounting point

• Disconnect power to the appliance before servicing to avoid shock or injury
• Use the correct size wrench or socket to avoid rounding the nut; snug, not overly tight
• Verify the mating stud/bolt and threads are clean and undamaged before installation
• If other mounting hardware is corroded or damaged, replace all affected fasteners for a secure fit

This nut assembly is a small mounting fastener that secures appliance components to studs or brackets, helping keep panels and internal parts stable for safe, quiet operation. What it does

• Secures components to threaded studs or bolts to prevent movement and vibration
• Restores proper fit of panels, trim, or internal assemblies when a worn or missing nut causes looseness
• Prevents electrical or mechanical contact caused by shifting parts
• Simple, durable replacement for a single mounting point

• Disconnect power to the appliance before servicing to avoid shock or injury
• Use the correct size wrench or socket to avoid rounding the nut; snug, not overly tight
• Verify the mating stud/bolt and threads are clean and undamaged before installation
• If other mounting hardware is corroded or damaged, replace all affected fasteners for a secure fit

This damper bracket secures the air damper assembly to the appliance, keeping the damper aligned for proper venting and reducing vibration. Replacing a damaged bracket helps restore stable damper movement and correct airflow. What it does:

• Secures and supports the air/vent damper so it can open and close correctly
• Prevents rattling or vibration caused by a loose or broken bracket
• Helps resolve improper venting or inconsistent temperature control linked to a misaligned damper
• Works as the mounting point for the damper assembly to the cabinet/chassis

• One damper bracket

• Always disconnect power (and water, if applicable) before servicing the appliance
• Access typically requires removing panels—watch for sharp edges and keep fasteners organized
• Bracket installs with mounting screws; verify damper alignment and smooth movement before reassembly

This damper is the oven vent assembly that controls airflow and venting during cooking, helping the oven purge steam and maintain consistent temperatures. Replacing a faulty damper restores proper vent operation and helps improve cooking performance. What it does:

• Opens and closes the oven vent to regulate airflow and release steam during bake/broil cycles
• Helps maintain proper cooking temperatures by directing exhaust flow
• A failed damper can cause poor temperature recovery, uneven baking or unexpected venting behavior
• Works as the airflow control component in the oven vent system

• Disconnect power to the appliance before starting any repair
• Installation typically requires basic hand tools (screwdriver, nut driver); follow the service manual for disassembly steps
• Handle sheet metal and vents carefully — wear gloves to avoid cuts

This replacement mounting plate secures internal assemblies to the appliance chassis, restoring stable support and alignment. It helps reduce movement and prevents loose or misaligned components for safer, quieter operation. What it does:

• Anchors and supports internal assemblies or housings to the appliance frame.
• Keeps parts aligned to maintain proper fit and operation.
• Helps reduce vibration, rattling, and shifting of mounted components.
• Use when the original plate is bent, cracked, or missing and causes loose mounting or misalignment.

• Disconnect power and water before starting any repair.
• Wear gloves and eye protection; the plate and surrounding areas can have sharp edges.
• Retain or reuse original mounting hardware unless replacements are specified elsewhere.
• Follow the appliance's service manual for removal, orientation, and torque specifications.

The Microwave Power Cord Assembly is an OEM part for GE ranges featuring built-in microwave units.

Causes of failure can be splitting insulation from flexing at plug points, bent pins compromising contacts, or degradation over extended use.

Symptoms of a faulty power cord include:

• Intermittent or failing microwave operation
• Loose connection points presenting shock hazards
• Exposed internal wiring posing fire risks

This OEM part is also compatible with Hotpoint and RCA built-in microwave range models.

This control mounting panel secures the appliance control/console assembly, providing a stable mounting surface that helps keep buttons, switches, and electronics aligned for reliable operation and easier repairs. What it does:

• Provides a rigid mounting surface for the control/console assembly
• Keeps control board and user interface components properly aligned
• Helps prevent movement or vibration-related contact issues
• Common replacement for cracked, bent, or damaged control panels that misalign controls

• Disconnect power to the appliance before starting any repair
• Typically accessed by removing the console or outer panel; keep fasteners organized
• Handle the control board and connectors carefully to avoid damage
