Parts for Kitchenaid KRFC704FSS02: Refrigerator Door Parts

This front inner door panel restores the dishwasher's sealed front assembly and provides a finished interior surface. It helps protect internal components and gives a clean, repair-grade replacement for damaged or dented doors. What it does:

• Replaces a damaged, bent, or corroded front inner door panel
• Protects internal components from moisture and debris
• Restores proper door fit and helps prevent leaks when combined with intact gaskets
• Improves appearance of the dishwasher interior and front assembly

• One front inner door panel

• Basic disassembly of the door is required; follow your model's service manual for panel removal/replacement
• Keep power disconnected and water supply off before starting any repair
• Handle edges carefully to avoid cuts and protect painted surfaces from scratches

This factory screw fastens appliance components securely. Replacing a missing, stripped, or rusty screw helps stop rattles, keep panels and brackets aligned, and restore a solid, as-designed fit.

• Secures panels, brackets, and trim to the appliance cabinet or frame
• Helps maintain alignment and reduce vibration or rattling noises
• Replaces damaged, corroded, or missing hardware
• Can resolve loose or shifting components

• Disconnect power and shut off gas/water to the appliance before service.
• Use the correct driver; start threads by hand to avoid cross-threading and do not overtighten.
• Install in the original location and match the OEM fastener type specified in your model's parts diagram.

This stop door is a replacement door stop that helps the appliance door close securely and stay in position. Restores proper door movement and reduces rubbing or misalignment that can cause noise or poor sealing. What it does:

• Replaces a worn or broken door stop to restore normal door closing and positioning
• Helps prevent the door from bouncing, rubbing, or hanging open
• Can reduce door-related noise and improper sealing during use
• Supports reliable door alignment for safer operation

• Disconnect power to the appliance before starting any repair
• Remove the door or access panel as needed to reach the mounting area
• Typical installation uses basic hand tools (screwdriver, nut driver); retain existing fasteners unless replacement hardware is provided
• Inspect surrounding hinges and catches and replace if damaged

This rail-mulln (mullion rail) replaces the vertical trim piece that runs between appliance door sections to restore proper fit and appearance. It helps keep the door edges aligned and maintains a finished look. What it does:

• Provides the vertical trim between door panels or appliance sections for a finished appearance
• Helps maintain door alignment and consistent spacing between panels
• Covers and protects the seam where two door sections meet
• Reduces light and air leakage at the door seam

• Disconnect power to the appliance before starting any repair
• Remove adjacent trim or door panels to access the mullion rail
• Handle trim pieces carefully to avoid scratching or bending; use proper fasteners

This door bumper cushions and stabilizes the appliance door to reduce noise and wear from slamming. It helps the door close smoothly and maintain proper alignment for reliable operation. What it does:

• Absorbs impact to prevent metal-on-metal contact and reduce slamming noise
• Helps the door sit evenly to improve latch engagement and sealing
• Reduces vibration and rattling during operation
• Simple replacement that restores proper door feel and alignment

• Disconnect power to the appliance before starting any repair
• Access the bumper by opening the door; some models may require removing the door or inner panel
• Press or snap the bumper into the locating hole or slot until secure; replace any retaining clips if present

The Nameplate is an OEM part for Whirlpool appliances. It serves as an identification label, typically displaying the brand name and model number, providing a clean and professional appearance for the appliance.

You should replace this nameplate if it becomes damaged or worn out. Common causes of a bad nameplate include wear and tear from regular cleaning, exposure to moisture or heat that can cause peeling or fading, and accidental impact that can lead to cracks or detachment.

Symptoms of a bad nameplate include:

• Fading or illegible text
• Peeling or detaching from the appliance surface
• Visible cracks or damage
• The nameplatae being completely missing

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This replacement screw fastens appliance panels and components securely. Replace a missing, stripped, or corroded original to restore a tight fit and help prevent rattling, vibration, and gradual loosening of assemblies.

• Secures panels, brackets, and internal assemblies to the frame
• Replaces damaged or missing hardware to maintain proper fit
• Helps reduce vibration, noise, and movement caused by loose parts
• Supports correct alignment at the original mounting points

• Disconnect power and shut off water or gas before service.
• Match the original screw's location and length; replace one at a time if needed.
• Use the correct driver/bit and avoid overtightening to prevent stripping plastic or metal.
• Reuse any washers or clips only if in good condition.

The Refrigerator Door Shelf Bin is an OEM part for Whirlpool refrigerators. It provides storage for eggs, condiments, and other small items directly in the refrigerator door.

Causes of a bad shelf bin can include cracked or broken plastic.

Symptoms of a bad shelf bin include:

• Items falling out of alignment or between cracks
• Difficulty deploying or stowing the shelf tray
• Leaks or odors from cracked surfaces

This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This is the cantilever-style door shelf bin that locks into the refrigerator door rails to hold bottles, jars, and condiments. Replacing a cracked or missing bin restores secure storage and full door capacity. What it does:

• Provides adjustable storage on the inner door using cantilever slots
• Helps keep items stable when opening and closing the door
• Common replacement signs: cracks, broken locking tabs, won't stay seated, falls off the rail
• Restores usable space and keeps contents organized

• 1 door shelf bin

• Remove the old bin by lifting up to release it from the cantilever slots, then pull out
• Align the new bin's hooks with the desired slots and press down until it clicks securely
• Verify the door closes freely and avoid overloading the bin
• Wear gloves to protect hands from sharp edges on broken plastic

This gasket seals the refrigerator's ice compartment. Replacing a worn or damaged seal restores a tight barrier that keeps cold air in and moisture out, helping reduce frost, condensation, and ice clumping around the ice bin and chute.

• Creates an airtight seal around the ice compartment door/housing to limit warm air infiltration
• Helps maintain proper temperature and airflow in the ice area for consistent ice quality
• Reduces frost and condensation at the ice chute and inside the bin
• Common signs of failure: tears, warping, or compression; persistent frost/moisture; ice clumping or melting in the bin

• Disconnect power to the refrigerator before servicing
• Remove the ice bin and any covers to access the gasket channel
• Pull out the old gasket; clean mating surfaces; press the new gasket in evenly without stretching
• Verify full, even contact around the perimeter before restoring power

The Door Closer is an OEM part for Whirlpool refrigerators. It is a hydraulic piston positioned behind the refrigerator's gasket seal that controls door closing pressure.

Symptoms of a bad door closer include:

• Door not latching or staying firmly closed
• Excessive force needed to open/close the door
• Leaks occurring around door joints
• Improper cooling due to loose door seal

Causes of a bad door closer typically include dried-out fluid after years of usage stresses. Impact damage to mounting points may cause improper alignment as well.

The door closer plays a crucial role in maintaining a tight fit between refrigerator components every time the door shuts. It prevents warm air and moisture exchange for efficient energy usage.

This OEM Whirlpool replacement part is compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

The Closing Cam is an OEM component used in Whirlpool side-by-side refrigerators. It is the mechanism located on the inner refrigerator door that utilizes a rotating cam configuration to gently pull the door closed.

Causes of a damaged closing cam can include stresses from opening and closing the door many times over the years. The constant motion wears down parts through normal use.

Symptoms of a faulty cam include:

• Door not latching securely in the closed position
• Loud slamming sound instead of a soft pull to close
• Cracks, fractures or a wobbly cam shaft

This Whirlpool OEM part is also compatible for use in some KitchenAid, Jenn-Air and select Kenmore refrigerator models.

This door gasket seals the refrigerator/freezer door to keep cold air in and humidity out, helping the appliance run efficiently and protecting stored food. It replaces a torn, warped, or leaking seal. What it does:

• Forms an airtight seal around the door to reduce frost buildup and prevent warm air leaks
• Helps maintain consistent internal temperatures for food safety
• Can reduce excessive run time and cycling caused by a failing seal
• Stops drafts, moisture, and odors from entering the compartment

• One door gasket

• Remove old gasket and clean mating surfaces before installing the new gasket
• Align gasket into the door channel and press firmly; some models require softening with warm air for a snug fit
• Check seal by closing the door and inspecting for gaps; adjust as needed

This cantilever door bin mounts on the inner door to provide secure, convenient storage. Replacing a cracked or missing bin restores organized space for bottles and condiments and helps prevent items from tipping or falling when the door opens.

• Mounts to the door liner rails as a cantilever shelf to hold containers
• Keeps frequently used items organized and within easy reach
• Replace if the bin is cracked, broken, or warped
• Replace if tabs are worn, the bin falls off, won't stay seated, or is missing

• Disconnect power to the refrigerator before servicing
• Remove contents; lift the old bin up and out of the door ladder/slots
• Align the new bin with the slots and press down until fully seated and secure
• Verify the door closes freely and avoid overloading the bin

This water tube routes potable water between the water valve and the refrigerator's dispenser or ice maker. Replace a damaged or kinked tube to restore proper water delivery and prevent leaks at the junction points. What it does

• Carries water from the inlet valve to the ice maker or dispenser assemblies
• Prevents kinks and directs flow along the refrigerator cabinet path
• Stops leaks and drips when the original tube is cracked, split, or pinched
• Helps restore normal water dispense and ice production when the tube is the source of the fault

• Disconnect power and shut off the water supply before starting work.
• Inspect and reuse or replace any clamps, ferrules, or fittings only if they show wear.
• Route the tube following the original path to avoid pinches and contact with sharp edges or moving parts.
• After installation, turn on water and power, then check all connections carefully for leaks.

The Door Gasket is an OEM replacement part for Whirlpool refrigerators. It is designed to create a tight seal between the fresh food door and the refrigerator cabinet, preventing cold air from escaping and maintaining a reliable barrier against cold air leaks.

A bad fresh food door gasket can occur due to wear and tear, cracks, or damage to its structure. If you notice symptoms such as condensation or frost buildup inside the refrigerator, difficulty in maintaining temperature, or the door not closing properly, it may be time to replace the door gasket.

Symptoms of a bad fresh food door gasket include:

• Condensation or frost buildup inside the refrigerator
• Difficulty in maintaining temperature
• Door not closing properly

Restore your refrigerator by replacing the faulty or damaged fresh food door gasket with this genuine OEM part.

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.


The door gasket is an OEM part for Whirlpool refrigerators. It forms a seal between the refrigerator door and body, working to ensure peak cooling and energy efficiency. This rubber gasket acts as insulation, preventing warm air from entering the refrigerator compartment each time the door is opened.

Causes of a bad door gasket can include cracks, tears, or compression from repeatedly opening and closing the refrigerator door over an extended period of time.

Symptoms of a bad door gasket include:

• Inefficient cooling and higher energy costs
• Warm air leaking into the refrigerator
• Moisture buildup or frost inside the body
• Difficulty properly sealing the door shut

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This cover is an access panel that protects internal components and keeps the appliance enclosure finished and secure. It restores a clean exterior and helps prevent dirt, lint, and accidental contact with parts behind the panel. What it does:

• Shields internal wiring and components from debris and accidental contact
• Maintains the appliance's finished appearance by replacing a damaged or missing panel
• Helps reduce airflow of lint and dust into service areas
• Useful when troubleshooting or servicing — provides a removable access point

• Disconnect power (and gas/water if applicable) before starting any service
• Basic hand tools (screwdriver, nut driver) are typically required for removal/installation
• Handle part carefully to avoid scratching the finished surface

The Fill Tube Assembly is an OEM part for Whirlpool refrigerators. It is responsible for transporting water from the water supply to the ice maker. The fill tube allows the ice maker to receive a constant supply of water needed to produce fresh ice.

Causes of a bad fill tube assembly can include cracks, holes or kinks developing over time, which impair proper water flow to the ice maker. Mineral buildup or sediment clogs can also restrict water flow through the tube.

Symptoms of a bad fill tube assembly include:

• Ice maker not producing ice or producing less ice than normal
• Ice cubes appearing partially formed or mushy
• Water leaks from the ice maker area
• Ice maker is making unusual noises during operation

This genuine OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
