Parts for Lg WD-3243RHD / AOWEEUS: Section 2 Parts

This is the refrigerator's water inlet valve assembly. It controls and directs household water into the dispenser and ice maker as needed, restoring proper water flow and ice production.

• Opens to supply water to the ice maker and dispenser when energized
• A common fix for no/low water at the dispenser
• Can resolve no ice production due to no water fill
• May address leaks or continuous dripping from the dispenser/ice maker
• Failure can present as buzzing or clicking with little/no water flow

• Disconnect power and shut off the water supply before servicing
• Have a towel or small container ready to catch residual water
• Note hose and wire locations or take photos before removal
• After installation, restore water and power, then check for leaks and run a test fill

The Water Inlet Valve Assembly is an OEM replacement part for LG washing machines, designed to control the flow of water into the laundry tub. This part is responsible for opening and closing to allow water into the wash drum at the appropriate times during the wash cycle, providing the correct water level and temperature.

Causes of a bad Water Inlet Valve Assembly can include mineral deposits blocking the valve, electrical failure preventing the valve from opening or closing properly, or physical damage to the valve mechanism itself.

Symptoms of a bad Water Inlet Valve Assembly include:

• Inadequate filling of the washer drum
• Water entering the drum when the washer is off
• Unusual noises during the fill cycle
• Water that is too hot or too cold, indicating a failure in valve operation that controls temperature

This OEM LG part can also be used on Kenmore/Sears appliances.

The Drain Hose Assembly is an OEM part for LG washing machines. It is a component designed to transport used water from the washer to the drain. This flexible hose assembly ensures that water flows smoothly out of your washing machine after each cycle, preventing leaks and maintaining the efficiency of your appliance.

Causes for replacement can include wear and tear over time, clogs from lint or small items, kinks that restrict water flow, or damage from moving or improper installation.

Symptoms of a bad Drain Hose Assembly include:

• Water leaking from the back or bottom of the washing machine
• Difficulty draining water out of the washer
• Puddles of water forming around the appliance during or after operation

This OEM LG part is also compatible with some Kenmore models.

This pivot hanger assembly supports and stabilizes the appliance component it mounts to, restoring smooth movement and alignment. Replace a worn or damaged pivot to reduce noise and prevent misalignment that can affect operation. What it does:

• Acts as the pivot point for the hanger to support the drum/door assembly and maintain correct alignment
• Helps eliminate squeaks, scraping, or jerky motion caused by a worn pivot
• Prevents sagging or uneven movement that can lead to rubbing or binding
• Restores proper mechanical support so the appliance operates quietly and reliably

• Unplug the appliance or disconnect power before beginning any repair
• Basic hand tools may be required; follow the appliance service manual for disassembly steps
• Inspect surrounding components (mounts, bearings, fasteners) and replace if worn

This spring-style hose clamp secures a washer's rubber hose to its fitting to maintain a tight, leak-resistant seal. Replacing a weakened clamp helps stop drips and keeps the hose firmly in place during operation.

• Provides constant spring tension to hold a rubber hose on its port
• Helps prevent leaks at the connection point
• Resists vibration so the hose doesn't back off the fitting
• Common signs include water at a hose joint, a loose/detached hose, or a rusted/broken clamp

• Disconnect power and turn off water supply before servicing
• Place a towel or pan to catch residual water from hoses
• Use pliers to compress the ears, slide off the old clamp, position the new clamp behind the hose bead, and release evenly
• After reassembly, run a quick test cycle and check for leaks

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.

A replacement hose clamp that secures a flexible hose to its fitting to help prevent leaks and disconnections. Restores a tight, reliable seal so hoses stay seated during normal use. What it does:

• Holds a rubber or plastic hose firmly to a pump, valve or connection to prevent leaks.
• Helps stop hose pull-off that can cause water leaks or appliance interruptions.
• Commonly replaced when clamps are corroded, bent, cracked or missing.
• Works as a low-cost repair to restore a secure hose connection without replacing the hose assembly.

• Disconnect power to the appliance and shut off the water supply before servicing.
• Use the correct tool (slip-joint pliers for spring-style clamps or a screwdriver for screw-type clamps) and avoid pinching the hose.
• Inspect the hose and fitting for damage; replace the hose if it's cracked or excessively worn.
• After installing, restore power/water and run a short test cycle or check for leaks.
