Parts for Lg WD-3274RHD / AOWEEUS: Section 2 Parts

This is the refrigerator's water inlet valve assembly. It controls and directs household water into the dispenser and ice maker as needed, restoring proper water flow and ice production.

• Opens to supply water to the ice maker and dispenser when energized
• A common fix for no/low water at the dispenser
• Can resolve no ice production due to no water fill
• May address leaks or continuous dripping from the dispenser/ice maker
• Failure can present as buzzing or clicking with little/no water flow

• Disconnect power and shut off the water supply before servicing
• Have a towel or small container ready to catch residual water
• Note hose and wire locations or take photos before removal
• After installation, restore water and power, then check for leaks and run a test fill

The Water Inlet Valve Assembly is an OEM replacement part for LG washing machines, designed to control the flow of water into the laundry tub. This part is responsible for opening and closing to allow water into the wash drum at the appropriate times during the wash cycle, providing the correct water level and temperature.

Causes of a bad Water Inlet Valve Assembly can include mineral deposits blocking the valve, electrical failure preventing the valve from opening or closing properly, or physical damage to the valve mechanism itself.

Symptoms of a bad Water Inlet Valve Assembly include:

• Inadequate filling of the washer drum
• Water entering the drum when the washer is off
• Unusual noises during the fill cycle
• Water that is too hot or too cold, indicating a failure in valve operation that controls temperature

This OEM LG part can also be used on Kenmore/Sears appliances.

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.
