Parts for Lg LMX25981ST / AST2GSC: Section 4 Parts

The Water Filter is an OEM part for LG refrigerators. It is a component that ensures the purity and quality of your drinking water and ice.

The water filter is designed to effectively reduce contaminants, impurities, and odors from your water supply, providing you with clean and refreshing drinking water. It employs advanced filtration technology to remove substances such as chlorine, sediment, and other potentially harmful particles.

Causes of a faulty water filter can include regular usage over time, expiration of its filtering capacity, or clogging due to sediment buildup. These factors can result in compromised water quality, decreased flow rate, or unpleasant taste and odor.

Symptoms of a bad water filter may include:

• Decreased water flow from the dispenser
• Water with an unusual taste or odor
• Visible discoloration or particles in the water

This OEM LG part can also be used on Kenmore/Sears appliances.

This door gasket assembly forms the airtight seal between the door and cabinet. Replacing a worn gasket restores a proper seal to keep cold air in, moisture out, and temperatures stable to help reduce frost and condensation.

• Creates a tight seal around the door perimeter when closed
• Helps maintain interior temperature and reduce cold-air loss
• Helps minimize condensation and frost near the door opening
• Common symptoms of failure: tears/cracks, hardened or warped gasket, visible gaps, door not sealing or popping open

• Disconnect power before servicing and clear items from the door
• Soften the new gasket in warm water or with low heat to relax folds; do not overheat
• Remove the old gasket from the retainer/channel; press the new gasket fully into the channel, starting at the corners
• Close the door and perform a paper-strip test around the perimeter; reseat or adjust hinges as needed for a uniform seal

This door gasket is the flexible magnetic seal that runs around the edge of the refrigerator door to keep cold air in and warm air out, helping maintain proper temperature and energy efficiency.

• Creates an airtight seal between the refrigerator door and cabinet
• Helps prevent temperature swings, frost buildup, and excess run time
• Common failure signs: torn, warped, or hardened seal; doors not sealing; condensation around the door
• Magnetic strip embedded to pull the door closed against the frame

• Unplug the appliance before starting any repair
• Soften the old or new gasket with warm air (hair dryer on low) to ease removal/fit
• Transfer or seat the gasket fully in the door channel; work evenly around corners
• Check door alignment and perform a dollar-bill test to confirm an even seal

This name plate is the exterior emblem that mounts to the appliance's front panel. It replaces a missing, cracked, or faded badge to restore a clean, factory look and cover the designated trim area.

• Attaches to the outer panel to display brand/series identification
• Restores a finished appearance where the original emblem sits
• Direct replacement for a lost, damaged, or worn badge
• Typical symptoms: missing emblem, loose or broken tabs, peeling, or discoloration

• Disconnect power before servicing the appliance
• Carefully remove the old emblem; release any tabs from behind or peel away remaining adhesive
• Clean and dry the mounting surface; remove all residue for best fit
• Align with the recess/holes and press evenly until fully seated

The Freezer Door Handle is an OEM part for LG refrigerators. It provides a convenient grip for opening and closing the freezer door, ensuring easy and efficient access to the freezer compartment.

Over time, freezer door handles can become loose, damaged, or break due to frequent use, accidental impacts, or general wear and tear. These issues can make it difficult to open or close the freezer door properly.

Symptoms of a bad freezer door handle include:

• Loose or wobbly handle
• Visible cracks or breaks in the handle
• Difficulty in opening or closing the freezer door
• Handle detaching from the door

This OEM LG part is also compatible with Sears/Kenmore models.

This is refrigerators door gasket assembly that is used on the right-side door of a french style refrigerator. The gasket assembly is what seals the door to the appliance so that air does not leak into the unit or out of the unit, which helps the appliance maintain a specific temperature.A new refrigerator door gasket assembly will be needed if the gasket is cracked, broken, or damaged in any way. Some refrigerators may begin the beeping alarm that alerts the user that the door is not closed, when in fact, it's just the gasket that has gone bad. The refrigerator door gasket assembly may need to be replaced after normal use over time.This is a genuine LG part and is an OEM part sourced directly from the manufacturer. It is sold individually. This particular refrigerator door gasket assembly is compatible with refrigerators that are manufactured by LG.

A replacement cover frame that restores the finished look and protection around the appliance control area. Replaces a cracked, warped, or scratched trim to keep controls secure and maintain appearance. What it does:

• Covers and protects the control panel edges from bumps, spills, and wear
• Keeps switches and buttons aligned and held in place
• Restores the appliance's finished appearance when the original frame is damaged
• Helps prevent debris from entering the control cavity

• Disconnect power to the appliance before beginning any work
• Remove any outer trim or control panel fasteners to access the existing frame
• Handle the part carefully to avoid scratching the finish during install

Replacement cover frame that restores the appearance around the appliance control area while protecting internal components. Use it to replace cracked, warped, or missing trim and keep the control panel edges aligned and secure. What it does:

• Replaces damaged or cracked trim around the control panel for a finished, uniform look
• Protects underlying switches and electronics from dust and light debris
• Helps keep control-panel edges aligned and prevents loose or flopping trim
• Improves overall appliance appearance after impact or wear

• Disconnect power to the appliance before starting any repairs
• Removal of the control panel or console is typically required; keep all fasteners for reassembly
• Handle edges carefully to avoid scratches or cuts and to prevent damage to the new frame

The Door Latch Cam is an OEM part for LG refrigerators. This component is integral to the proper functioning of the refrigerator door latch system, ensuring the door stays securely closed.

Over time, the door latch cam can become worn out or damaged due to frequent use, exposure to moisture, or accidental impact. When the cam is compromised, it can affect the door's ability to seal properly, which can lead to energy inefficiency and potential spoilage of food.

Symptoms of a bad door latch cam include:

• Difficulty in closing or opening the refrigerator door
• The door not sealing tightly, leading to temperature fluctuations
• Increased energy consumption
• Unusual noises when operating the door latch

This OEM LG part is also compatible with Sears/Kenmore.

The Camshaft is an OEM part for LG refrigerators. It plays a crucial role in the proper operation of the refrigerator's door hinge, ensuring smooth and secure opening and closing. The camshaft helps align the door and maintains the seal, preventing warm air from entering the refrigerator.

You should replace the camshaft if it becomes worn out or damaged. Causes of a bad camshaft can include wear and tear from frequent use, physical damage from impact or mishandling, and misalignment issues that stress the camshaft over time.

Symptoms of a bad camshaft include:

• Difficulty in opening or closing the refrigerator door
• The door not staying closed
• Unusual noises when opening or closing the door
• Misalignment of the refrigerator door

This OEM LG part is also compatible with Sears/Kenmore models.

This refrigerator door basket mounts on the inner door and holds bottles, jars, and condiments. Replace a cracked or missing upper bin to restore secure, organized storage and keep frequently used items within easy reach.

• Attaches to the door liner to support and organize condiments and beverages
• Restores lost storage when a bin is cracked, warped, or missing
• Common symptoms: broken tabs, sagging bin, won't stay seated, or items tipping
• Helps keep frequently used items accessible without opening main shelves

What's included: 1 door basket Install notes:

• Remove contents, then lift the old bin straight up to release
• Align the new basket's hooks/tabs with the door slots and lower or snap into place
• Confirm it's fully engaged before loading items
• Handle carefully; avoid flexing or overloading the bin

This refrigerator door basket mounts on the inner door and holds bottles, jars, and condiments. Replace a cracked or missing upper bin to restore secure, organized storage and keep frequently used items within easy reach.

• Attaches to the door liner to support and organize condiments and beverages
• Restores lost storage when a bin is cracked, warped, or missing
• Common symptoms: broken tabs, sagging bin, won't stay seated, or items tipping
• Helps keep frequently used items accessible without opening main shelves

What's included: 1 door basket Install notes:

• Remove contents, then lift the old bin straight up to release
• Align the new basket's hooks/tabs with the door slots and lower or snap into place
• Confirm it's fully engaged before loading items
• Handle carefully; avoid flexing or overloading the bin

The Tilting Door Basket is an OEM part for LG refrigerators. This basket provides convenient storage in the refrigerator door, designed to tilt outward for easier access to items like beverages, condiments, and snacks. Its design helps maximize space and improve organization within the refrigerator. This basket measures approximately 14 inches wide, 5 inches high, and 4 inches deep.

Causes of a bad door basket can include wear and tear from frequent use, accidental impacts, or damage to the mounting points or tilt mechanism.

Symptoms of a bad tilting door basket include:

• Cracks or visible damage to the basket
• The basket not tilting or staying in place properly
• Difficulty in securing the basket to the door
• Items falling out of the basket

This OEM LG part is also compatible with Sears/Kenmore models.

The Tilting Door Basket is an OEM part for LG refrigerators. This basket provides convenient storage in the refrigerator door, designed to tilt outward for easier access to items like beverages, condiments, and snacks. Its design helps maximize space and improve organization within the refrigerator. This basket measures approximately 14 inches wide, 5 inches high, and 4 inches deep.

Causes of a bad door basket can include wear and tear from frequent use, accidental impacts, or damage to the mounting points or tilt mechanism.

Symptoms of a bad tilting door basket include:

• Cracks or visible damage to the basket
• The basket not tilting or staying in place properly
• Difficulty in securing the basket to the door
• Items falling out of the basket

This OEM LG part is also compatible with Sears/Kenmore models.

The Refrigerator Door Shelf is an OEM part for LG refrigerators. This component is designed to fit snugly into the door of the refrigerator, providing convenient storage space for frequently accessed items such as drinks, condiments, and snacks. The shelf measures about 15 inches wide, 3 inches high, and 8 inches deep, providing plenty of storage space.

Symptoms of a failing Refrigerator Door Shelf include:

• The shelf becoming loose or failing to hold items securely
• Cracks or breaks in the shelf, which compromise its load-bearing capacity
• Sagging or bending of the shelf, particularly when loaded with heavier items
• Difficulty in fitting the shelf into its designated slots on the refrigerator door

Causes of a bad door shelf can include overloading beyond its weight capacity, frequent adjustment or removal of the shelf, or material fatigue from regular use and exposure to temperature variations within the refrigerator.

This OEM LG part is also compatible with Sears/Kenmore models.

This ice gear transfers motor rotation to the refrigerator's ice mechanism so cubes can be dispensed or ejected. Replacing a worn or stripped gear restores smooth, reliable ice operation and helps eliminate grinding or clicking noises.

• Transfers drive from the motor to the ice mechanism (auger/ejector, depending on model)
• Helps move ice through the system for dispensing or harvest
• Common symptoms: no or slow ice dispensing, auger not turning, loud clicking/grinding from the ice bin
• Cracked or stripped teeth indicate the gear should be replaced

• Disconnect power to the refrigerator before servicing
• Remove the ice bin and access the ice assembly per your model; note gear orientation for reassembly
• Align teeth carefully; do not force the gear onto the shaft
• Inspect related parts (drive coupler, auger, motor shaft) and replace any worn components to prevent repeat failure

This small retaining clip secures its mating component within the refrigerator assembly, keeping parts properly seated and reducing vibration. Replacing a damaged or missing clip helps restore a snug fit and reliable operation of the attached piece.

• Holds the designated part firmly in place within the assembly
• Maintains proper alignment to prevent movement or rattling
• Helps ensure panels, ducts, or lines stay secured during use
• Symptoms can include loose or sagging parts, vibration noises, or components that won't stay attached

• Disconnect power; if working near the water system, also shut off the water supply
• Note the original orientation and placement before removal
• Fully seat the mating component, then press the new clip into place without forcing
• Check operation before reassembly

The Water Line Connector is an OEM replacement part for LG refrigerators. It is responsible for connecting the water supply line from the home plumbing to the refrigerator's internal water distribution system, allowing for ice and water dispenser functionality.

Causes of a bad water line connector can include cracking, leaks, or deterioration of the connector material over time due to regular water pressure and temperature fluctuations. Connectors may also become damaged if exposed to impact.

Symptoms of a bad water line connector include:

• Leaks at the connection point between the line and refrigerator
• Loose, slipping, or disconnected water line fitting
• Reduced water pressure or no water flow to the dispenser
• Error codes related to water flow from the refrigerator diagnostics

 This OEM LG part is also compatible with Sears/Kenmore refrigerators.

The Clip is an OEM part for LG refrigerators. This clip secures the water tube in place, preventing it from moving or becoming disconnected. It plays a crucial role in maintaining the proper flow of water to the ice maker and water dispenser.

Causes of a bad water tube clip can include physical damage, wear and tear from regular use, or brittleness due to temperature fluctuations. If the clip fails, it can result in leaks or disconnections, disrupting the water supply.

Symptoms of a bad water tube clip include:

• Water leaks inside or outside the refrigerator
• The water tube becoming loose or disconnected
• Reduced or no water flow to the ice maker or water dispenser

This OEM LG part is also compatible with Sears/Kenmore refrigerators.

Note: 90 degree elbow coupler (Fits 1/4" diameter tubing on each end) For 5/16" elbow connector, order part# 4932JA3009B.

The Water Line Union is an OEM part for LG refrigerators. This component connects sections of the water line, ensuring a secure and leak-free passage of water to the refrigerator's icemaker and water dispenser. It is an elbow tube union connector, which connects two tubes at a 90-degree angle.

Causes of a bad water line union can include wear and tear from frequent use, damage from high water pressure, or deterioration due to mineral buildup and age. A compromised union can lead to water leaks and disruption in the water supply.

Symptoms of a bad Water Line Union include:

• Water leaks around the connection points
• Reduced water flow to the icemaker or water dispenser
• Puddles or moisture near the refrigerator
• Unusual noises from the water line

This OEM LG part is also compatible with Sears/Kenmore.

Located in the left refrigerator door on french door models.
