Parts for Bosch WFR2460 UC/01 (FD 8201-): 03 - Drum Assembly Parts

This rear tub section replaces the back portion of the dishwasher tub to restore proper water containment and support internal components. It helps stop leaks and restore the washer's ability to circulate and drain normally. What it does:

• Replaces the rear section of the dishwasher tub that houses and supports internal components
• Restores a sealed tub to prevent water leaks from the rear area
• Helps resolve symptoms such as water pooling, leaks at the back, or unusual noises from the tub area
• Works with existing mounting points and seals to maintain correct alignment of pumps and spray assemblies

• One tub at rear section

• Use correct tools and follow the manufacturer's service manual; remove power and water supply before servicing
• Inspect and replace any worn gaskets or fasteners when installing to ensure a watertight fit
• Tighten fasteners to manufacturer guidelines and verify alignment of pumps/spray arms before testing
• If you notice corrosion or damage to adjacent components, replace those parts as needed to prevent future leaks

This drum bearing set replaces the rear bearing that supports the dryer drum, restoring smooth rotation and reducing noise. It fits into the drum support housing to help keep the drum aligned during operation. What it does

• Supports the dryer drum so it turns smoothly and stays centered
• Reduces bearing noise such as squealing, grinding, or rumbling
• Helps prevent excessive drum wobble and metal-on-metal contact
• Restores proper drum rotation when worn or seized bearings cause resistance

• Disconnect power before beginning; follow all safety precautions
• Replacement requires opening the cabinet and accessing the rear drum support
• Inspect adjacent parts (rollers, glides, seals) for wear during replacement

The Door Seal, Light Gray is an OEM part for Bosch washing machines. This part ensures a water-tight seal between the door and the machine's body. This part prevents water leaks during the washing cycle, thereby protecting your floors from damage and ensuring that the washing process is both efficient and safe.

Causes for issues with the door seal often involve regular wear and tear from use, exposure to harsh cleaning chemicals that can degrade the rubber, or physical damage from loading and unloading clothes.

Symptoms of a malfunctioning Door Seal include:

• Visible wear, tears, or cracks in the seal
• Water leaking from the front of the washing machine during operation
• A buildup of mold or mildew on the seal, contributing to bad odors

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This door seal holding spring is the wire clamp that secures the washer's door boot to the front opening, keeping the seal seated to help prevent leaks and maintain a proper fit.

• Holds the door seal/boot firmly around the front panel opening
• Helps maintain a watertight seal during wash and spin cycles
• Replaces a stretched, broken, or missing clamp/spring
• Common symptoms: boot won't stay seated, water leaking at the door opening, visible broken/missing spring

• Disconnect power and turn off the water supply before servicing
• Open the door and carefully remove the existing clamp from the gasket groove; avoid puncturing the boot
• Reseat the boot evenly, then stretch and position the new spring/clamp around the groove (spring typically at the bottom)
• Test for leaks after reassembly

The Drive Belt is an OEM part for Bosch washing machines. This belt connects the motor to the drum, enabling the drum to spin during the wash and spin cycles. This belt measures  49.4 inches and replaces a broken or damaged original belt. With 5 ribs and 4 grooves, the high-quality belt transfers drive power to rotate the drum.

Causes of a bad drive belt include normal wear and tear over time, overloading the washer, or a misalignment of the belt and pulleys. These issues can reduce the efficiency of the washing machine and cause it to malfunction.

Symptoms of a bad drive belt include:

• The drum not spinning or agitating
• Unusual noises during operation
• Burning smell from the washer
• Washer stopping mid-cycle

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This front drum motor mounting bushing supports the dryer drum shaft and helps the drum spin smoothly for quiet, even drying. It replaces a worn bearing surface to reduce noise and prevent drum misalignment. What it does:

• Provides a low-friction bearing surface for the drum shaft at the front motor mount
• Helps keep the drum properly aligned during rotation
• Reduces squealing, grinding, or rubbing noises caused by a worn front bushing
• Prevents excess wear on the drum shaft and adjacent components when functioning correctly

• One front drum motor mounting bushing

• Disconnect power before beginning any repair and follow all safety precautions
• Inspect the drum shaft, drum seal, and rear bushing for wear and replace as needed
• Use appropriate tools to remove the old bushing and press or seat the new bushing evenly
• Re-check installation and related components if alignment or noise persists after replacement

The Drum Drive Motor is an OEM part for Bosch washing machines. This motor powers the drive system that rotates the wash drum and tumbles clothes during cycles.

Causes can be normal wear and tear over time spent rotating heavy loads daily. Failure of motor windings from years of continuous use is also common.

Symptoms of a bad drum drive motor include:

• The wash drum failing to turn or tumble clothes
• Abnormally long cycle times
• Strange noises coming from the motor area
• The machine not advancing through cycles

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

The Carbon brush, drum motor is an OEM part for Bosch washing machines. These carbon brushes are responsible for transferring electrical current from the commutator on the motor to power the rotary movement inside the washing machine drum.  Two come per package.

Symptoms of a bad carbon brush, or drum motor can include:

• noisy or squealing sounds coming from the motor during the operation
• the drum fails to spin or spin inconsistently
• the washer is unable to enter spin cycles
• slow or reduced agitation

Causes of a bad part include normal wear and tear over extended use. As the brushes continuously contact the commutator, friction can cause them to wear down over time.

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.

This rear drum motor mounting bushing supports the motor shaft at the back of the tub, keeping the drum aligned and reducing wear. It restores smooth drum rotation and helps reduce noise and vibration when functioning properly. What it does:

• Centers and supports the motor shaft to maintain proper drum alignment.
• Cushions rotating components to reduce squealing, grinding, or scraping noises.
• Helps prevent excess drum wobble and uneven wear on the tub and bearings.
• Can stop intermittent rubbing or burning smells caused by a worn mounting surface.

• Disconnect power before starting and follow all safety precautions; service panels may have sharp edges.
• Access typically requires removing the dryer/heater assembly and drum.
• Inspect mating surfaces and surrounding components (shaft, bearing, seal). Replace any excessively worn parts to prevent repeat failures.
• Use only OEM-recommended parts and fasteners; do not force or press the part in without proper alignment.

This washing machine shock absorber stabilizes the outer tub during wash and spin. Replacing a weakened damper helps control vibration and noise so the washer runs smoother and is less likely to shake, bang, or walk.

• Mounts between the tub assembly and cabinet/base to cushion movement
• Helps prevent excessive vibration, shaking, and thumping noises
• Can reduce "walking" or out-of-balance interruptions when a damper is worn
• Supports smoother, quieter spin performance

• Disconnect power and turn off water supply before servicing
• Remove the appropriate access panel(s) to reach the dampers
• Support the tub when removing mounting pins/bolts; match the original orientation
• Inspect all dampers; replace any that show wear for balanced performance

This spring-tank is the replacement spring assembly used to restore proper door balance and movement. It helps the appliance door open and close smoothly and prevents sudden drops or heavy lifting. What it does

• Provides counterbalance tension for the appliance door to control opening and closing motion
• Reduces sagging or slamming of the door caused by worn or broken springs
• Restores smooth, even movement when the door feels heavy or uneven
• Works as a direct-fit replacement when the original spring assembly fails

• One spring-tank

• Disconnect power and water to the appliance before starting any repair
• Handle spring components carefully; springs are under tension and can cause injury if released unexpectedly
• Use proper tools and follow manufacturer instructions or a service manual for safe removal and installation
