Parts for Maytag LSG9900AAE: 17 - Tub Parts

This water inlet valve controls water flow to the dispenser and ice-making systems, restoring proper fill and dispensing when the valve fails. Replaces a worn or leaking inlet valve to stop interruptions in water delivery. What it does:

• Opens and closes water supply lines when the dispenser or ice maker calls for water
• Commonly used when no water dispenses from the fridge or ice maker won't fill
• Can stop leaks or intermittent flow caused by a faulty valve or solenoid
• Operates as an electrical valve assembly actuated by appliance controls

• Disconnect power and shut off the household water supply before starting
• Drain lines/dispense any remaining water and have a towel handy for drips
• Replacement typically requires basic hand tools and disconnecting/reconnecting water fittings; follow OEM diagram for correct plumbing/electrical connections
• After installation, restore water and power, then check all connections for leaks and proper operation

The Hose Clamp is an OEM part for Whirlpool appliances. It secures hoses in place, ensuring a tight connection and preventing leaks in various systems such as washing machines, dishwashers, and refrigerators. This clamp is crucial for maintaining the integrity of the water or air lines it secures.

Causes of a bad hose clamp include wear and tear over time, exposure to water and detergents, or mechanical stress from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Leaks at the hose connection points
• Hoses slipping off the connections
• Visible rust or damage on the clamp
• Reduced appliance efficiency due to leaks

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Hose Clamp is an OEM part for Whirlpool appliances. It secures hoses in place, ensuring a tight connection and preventing leaks in various systems such as washing machines, dishwashers, and refrigerators. This clamp is crucial for maintaining the integrity of the water or air lines it secures.

Causes of a bad hose clamp include wear and tear over time, exposure to water and detergents, or mechanical stress from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Leaks at the hose connection points
• Hoses slipping off the connections
• Visible rust or damage on the clamp
• Reduced appliance efficiency due to leaks

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

For complete assembly order WP206680.

This injector seal fits the refrigerator's water injector. It restores a tight, watertight/airtight connection where the injector passes through the liner or mates to the fill tube, helping prevent leaks and frost around the opening.

• Seals the injector-to-liner/fill-tube connection to stop water seepage and air leaks
• Helps prevent frost/ice buildup near the injector area and fill tube freeze-ups
• Addresses issues from a cracked, shrunken, or missing seal
• Common symptoms: water drips at the back/freezer wall and frost near the fill opening

• Disconnect power and shut off the water supply before servicing
• Access the injector area (rear of freezer or cabinet, depending on model)
• Remove the old seal; press the new seal fully and evenly into place
• Reassemble, restore water/power, and check for leaks and proper fill

For complete assembly order WP206680.

This injector nozzle channels incoming water from the fill hose into the wash basket. Replacing a cracked or clogged nozzle helps stop leaks and restores a clean, controlled water stream during fill. What it does:

• Directs incoming water into the tub via the injector assembly
• Works with the injector cap to diffuse flow and reduce splashback/siphoning
• Maintains a proper spray pattern during fill
• Common symptoms include water leaking or spraying from the injector area, visible cracks, or mineral buildup restricting flow

• 1 injector nozzle

• Disconnect power and turn off water supply before servicing
• Access the injector assembly by removing the cabinet/top per your model's procedure
• Release the hose clamp, remove the old nozzle, and install the new nozzle oriented toward the tub; reinstall the injector cap if your model uses one, and secure the clamp
• Restore water and power, then run a test fill to check for leaks

The Injector Valve is an OEM replacement part specific to Whirlpool washing machines. It plays an important role in properly dispensing detergent into the wash load. Located inside the detergent dispenser drawer, the injector valve regulates the flow of water at timed intervals to fully dissolve and evenly distribute detergent among clothes. Washer air gap rubber injector. For the injector nozzle order WP213015. For a kit that includes the injector valve, nozzle, and two clamps order 12001677

Causes of a bad injector valve can include clogging from mineral deposits or debris, wear and tear from regular use, or damage from high water pressure. A malfunctioning injector valve can lead to improper water levels and affect the washing machine's performance.

Symptoms of a bad injector valve include:

• Inadequate water filling the washer
• Water leaks around the valve area
• Unusual noises during the water filling cycle
• The washer not advancing through cycles properly
• Visible debris or deposits at the injector valve opening

It is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore washers.

Specs: 10 - 16 x .375

This small sleeve fits into the water/ice injector assembly to help guide and seal the water path. A worn or missing sleeve can lead to leaks, poor ice production, or water dispensing issues at the injector.

• Provides a sealed passage for water at the injector point
• Helps prevent drips and internal leaks near the dispenser/ice maker feed
• Resolves symptoms like leaking at the injector, weak ice fill, or irregular water flow
• Restores proper alignment and flow through the injector assembly

• Disconnect power and shut off the water supply before servicing
• Access the injector area per your model's service or user manual
• Note orientation of the original sleeve; press the new sleeve fully into place
• Check for secure tubing connections and verify no leaks after restoring water and power

Hose washer and plastic insert for inlet hose. To order separately: for washer use WPY013783, for strainer use WP22002960.

Size: 6 foot long. Washers not included. This is one hose, for a set with washers order 285363. For inlet hose screen use 285452A and for inlet hose washers use 285448A

This small retaining clip secures components in place inside the appliance, helping prevent movement, vibration, and premature wear. Replace a bent, fatigued, or missing clip to restore a solid, factory-tight hold.

• Holds panels, brackets, or tubing securely in their mounts
• Helps maintain alignment to reduce rattles, rubbing, or intermittent issues
• Common signs of failure: missing clip, loose fit, buzzing/vibration, parts that won't stay seated
• Restores proper retention after service, transport, or vibration-related fatigue

• Disconnect power and shut off gas/water before servicing
• Note the original clip's orientation; remove with needle-nose pliers
• Seat the new clip fully—do not over-bend; spring tension provides the hold
• Test operation before reassembly

The Tub Bearing Kit is an OEM part for Whirlpool washers. It includes all the necessary components to replace the tub bearing which is responsible for supporting the inner tub and allowing it to spin smoothly during the wash cycle. Over time, the bearing may wear out or become damaged, leading to excessive noise, vibrations, or even leaks from the washer.

Causes of a bad tub bearing can include regular wear and tear, exposure to heavy loads or unbalanced loads that put excessive strain on the bearing, or damage due to water leaks.

Symptoms of a bad tub bearing include:

• Excessive noise or grinding during the wash cycle.
• Vibrations or shaking of the washer.
• Leaks from the washer, around the tub area.
• The inner tub not spinning or becoming stuck.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Note: It is advised to replace the Mounting Stem Repair Kit, part number 6-2040130 at the same time.  To complete the repair, you’ll also need a Spanner Wrench to complete the repair (TB123B).

This Torx-head screw set replaces worn, stripped or missing Torx fasteners used throughout the appliance to keep panels and components securely fastened. Restoring proper fasteners reduces vibration and prevents loose parts. What it does:

• Secures control panels, trim pieces or internal components that use Torx-head screws
• Replaces damaged or corroded Torx screws that can cause rattling or misalignment
• Helps restore proper fit and finish after repairs or disassembly
• Uses a Torx drive for a more secure torque transfer than standard Phillips heads

• Unplug the appliance or disconnect power before starting any repair
• Use the correct-size Torx driver to avoid stripping the screw head
• Tighten screws snugly but avoid over-torquing to prevent thread or part damage
• Keep removed screws organized and compare to the new set before installation

The Mounting Stem Repair Kit is an OEM part for Whirlpool washing machines. It includes all necessary components to repair the mounting stem, which is a critical part of the washer's tub support system. Comes with the hub assembly, seal, and spanner nut. 6-2040130 should also be replaced at the same time. A spanner wrench is required to complete the repair TB123B.

Symptoms of a bad mounting stem include:

• Excessive noise or vibration during the spin cycle.
• The washer tub appearing loose or off-balance.
• Leakage around the central area of the washer, indicating a possible seal failure.

Causes of a bad mounting stem can include wear and tear from normal usage, especially with heavy loads, or corrosion and material fatigue that weaken the stem's integrity.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This small clamping nut secures a mating clamp or bracket so the connected component stays firmly in place. Replacing a worn, stripped, or missing nut restores a solid hold and helps prevent looseness or leaks around the secured area.

• Secures a clamp or bracket to its mounting point
• Restores proper clamping force when the original nut is stripped or missing
• Common signs: loose clamp, rattling/vibration, clamp won't tighten, minor leaks where the clamp is used
• Durable hardware replacement to maintain stable, reliable assemblies

• Disconnect power and shut off water/gas to the appliance before service
• Note clamp/bracket orientation before removal for correct reassembly
• Start threads by hand to prevent cross-threading; then tighten with the appropriate tool
• Do not overtighten—snug just enough to securely clamp the component

This agitator seal assembly sits at the agitator/drive-shaft pass-through to keep wash water inside the tub and away from the drive system. Replacing a worn seal helps stop center-post leaks and protects internal components from moisture.

• Seals the opening where the agitator/drive shaft passes through the tub or centerpost
• Helps prevent water from migrating into the centerpost/gearcase area
• Supports reliable agitation and spin by keeping contaminants out of the drive assembly
• Common symptoms of failure: water leaking from the center of the tub or beneath the washer, or rust/water tracks around the agitator hub

• Disconnect power and shut off water; wear gloves and eye protection
• Remove agitator cap and fastener, then lift the agitator to access the seal (procedure varies by model)
• Note the original seal orientation; clean mating surfaces and install the new seal squarely (lightly lubricate only if specified by the manufacturer)
• Reassemble and run a short fill/agitate test while observing for leaks

The Tub Bearing Kit is an OEM part for Whirlpool washers. It includes all the necessary components to replace the tub bearing which is responsible for supporting the inner tub and allowing it to spin smoothly during the wash cycle. Over time, the bearing may wear out or become damaged, leading to excessive noise, vibrations, or even leaks from the washer.

Causes of a bad tub bearing can include regular wear and tear, exposure to heavy loads or unbalanced loads that put excessive strain on the bearing, or damage due to water leaks.

Symptoms of a bad tub bearing include:

• Excessive noise or grinding during the wash cycle.
• Vibrations or shaking of the washer.
• Leaks from the washer, around the tub area.
• The inner tub not spinning or becoming stuck.

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Note: It is advised to replace the Mounting Stem Repair Kit, part number 6-2040130 at the same time.  To complete the repair, you’ll also need a Spanner Wrench to complete the repair (TB123B).

The Hose Clamp is an OEM part for Whirlpool washing machines. This clamp secures the hose in place, ensuring a tight connection and preventing leaks during operation. It is essential for maintaining the integrity of the washing machine's water system, securing hoses that carry water to and from the washer.

Common causes of a bad hose clamp include rust, physical damage, or loosening from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Water leaks around the hose connection points
• The hose slipping off the fitting
• Visible rust or wear on the clamp
• Difficulty in tightening the clamp to secure the hose

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

The Hose Clamp is an OEM part for Whirlpool appliances. It secures hoses in place, ensuring a tight connection and preventing leaks in various systems such as washing machines, dishwashers, and refrigerators. This clamp is crucial for maintaining the integrity of the water or air lines it secures.

Causes of a bad hose clamp include wear and tear over time, exposure to water and detergents, or mechanical stress from repeated tightening and loosening.

Symptoms of a bad hose clamp include:

• Leaks at the hose connection points
• Hoses slipping off the connections
• Visible rust or damage on the clamp
• Reduced appliance efficiency due to leaks

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This part has been discontinued by the manufacturer and is no longer available.

This digital water level switch senses tub water height and tells the washer control when to stop filling, helping the machine use the correct water amount each cycle. It restores proper fill control and water-level signals to the control board. What it does:

• Detects and reports water level to the washer control so cycles advance correctly
• Stops water fill when the proper level is reached to prevent overfilling
• A failed switch can cause underfilling, overfilling, filling errors, or stalled cycles
• Works with the washer's pressure/air system to translate tub water height into an electrical signal

• One water level switch (digital)

• Always disconnect power to the appliance before starting service
• Access typically requires removing the control console or top panel; keep track of fasteners
• Handle the small pressure/air hose and electrical connector gently to avoid damage
• Verify the part number for routing and connector orientation

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

A replacement nut and bolt fastener used to secure appliance components and restore proper connection. Helps stop rattling and keeps panels, brackets, or assemblies held firmly in place. What it does

• Secures panels, brackets, or small assemblies to prevent movement and vibration.
• Restores a loose or missing fastener that can cause rattling or misalignment.
• Provides a direct-fit replacement when the original nut or bolt is stripped, worn, or lost.

• Turn off power and unplug the appliance before servicing electrical units.
• Use appropriate hand tools and matched-size sockets/wrenches to avoid rounding heads.
• Replace with the correct torque per manufacturer guidance; do not overtighten.
• If other fasteners are corroded or damaged, inspect and replace as needed.

This replacement seal restores a tight, leak-resistant barrier between mating parts inside your appliance. Replacing a hardened or damaged seal helps stop seepage and keeps the system operating as designed. What it does:

• Forms a tight barrier between components to contain fluids and prevent leaks
• Helps maintain proper pressure/flow at the sealed joint
• Reduces risk of moisture damage around the connection point
• Common signs it's worn: drips or puddles, dampness around the joint, musty odors, visible cracking or flattening of the old seal

• 1 seal

• Disconnect power and shut off water or gas supplies before servicing
• Access the sealed joint; remove the old seal and clean mating surfaces thoroughly
• Lightly lubricate with manufacturer-approved lubricant; install without twisting
• Reassemble, restore utilities, and check closely for leaks during initial operation

This drain hose routes wastewater from the appliance to the household drain, helping remove used water after a cycle. It replaces a damaged, kinked or leaking hose to restore proper draining and prevent puddling. What it does:

• Carries discharge water away from the appliance during drain cycles
• Restores proper draining when the original hose is cracked, split or leaking
• Helps prevent backups and standing water inside the appliance
• Works with the appliance's pump and drain system to maintain normal operation

• One replacement drain hose

• Disconnect power and water before starting any work
• Verify hose routing and secure clamps to prevent kinks and leaks
• Inspect and replace any worn clamps or fittings as needed
• After installation, run a short cycle and check for leaks and proper drainage

This retaining washer secures a center-mounted component within the assembly, keeping parts aligned and in place during operation. Replacing a worn or missing washer helps prevent looseness, vibration, and noise for more reliable performance. What it does:

• Holds a component on a center shaft or stud to prevent axial movement
• Maintains proper alignment under rotation and load
• Can reduce wobble, rattling, or scraping noises from a shifting assembly
• In applicable washers, can help restore consistent agitation or spin when parts have been moving out of place

• 1 retaining washer

• Disconnect power and water before servicing; wear cut-resistant gloves
• Note the order and orientation of all spacers, washers, and clips during disassembly
• Clean mating surfaces and ensure the washer is fully seated before reassembly
• Inspect adjacent hardware for wear or damage and replace as needed

This hose clamp secures a rubber or plastic hose to its fitting to maintain a tight, leak-resistant seal. Replace a worn or missing clamp to stop drips and keep appliance water connections secure.

• Fastens a hose to a barb or port to prevent leaks
• Helps keep hoses from slipping off due to vibration or pressure
• Restores proper sealing when a clamp is rusted, bent, or stripped
• Common symptoms: water dripping at a hose joint, loose hose connection, or a clamp that won't tighten

• Disconnect power and shut off the water supply before servicing
• Place a towel to catch residual water when removing hoses
• Position the clamp just behind the hose barb/bead and secure with the appropriate tool
• Restore water and power, then run a quick check for leaks at the connection

This hose clamp secures a hose connection to prevent leaks and keep your appliance running smoothly. It provides a tight, reliable hold on the hose fitting so water or air stays contained during operation.

• Tightens around a hose and fitting to maintain a secure seal
• Helps stop drips, seepage, or loose connections
• Common fix when you see moisture around a hose joint
• Useful if a clamp is rusted, stretched, or no longer holding tension

• Unplug power and shut off water (if applicable) before servicing
• Note clamp position/orientation before removal
• Use appropriate screwdriver or nut driver to tighten evenly
• Do not overtighten—ensure a snug, leak-free seal without damaging the hose

The Tub to Pump Hose is an OEM part for Whirlpool washing machines. This hose connects the tub to the pump, allowing water to drain from the tub during the washing and rinsing cycles. It is designed to handle the water flow and pressure within the washer, ensuring efficient drainage.

Causes of a bad tub to pump hose can include wear and tear over time, exposure to harsh chemicals or debris, or damage due to accidental punctures or kinks. When the hose is compromised, it can lead to drainage issues and potential water leaks.

Symptoms of a bad tub to pump hose include:

• Water not draining from the washer
•  Leaks or puddles underneath the washer
• Visible cracks or wear on the hose
• Error codes related to drainage problems

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
