Parts for Ge JGP970BEK5BB: Control Panel & Cooktop Parts

A profile black gas valve control knob that restores tactile, reliable burner control. Replaces a cracked, stripped, loose or missing knob so you can adjust the gas valve smoothly while cooking. What it does:

• Fits onto the burner gas valve stem to provide a user-friendly control surface
• Replaces damaged or worn knobs that don't fully engage the valve splines
• Helps when a knob is loose, cracked, stripped, missing, or difficult to turn
• Restores consistent tactile feedback for accurate burner adjustment

• Always turn off the appliance and gas supply before servicing
• Pull the old knob straight off the valve stem; align the new knob's splines and push on until fully seated
• Use only the exact knob design intended for your valve to ensure proper fit and safe operation

Color: glossy black. Measures about 1 inch in diameter, and 1 inch deep.

The Grate Foot is an OEM part for GE cooking ranges and stovetops. This small but essential component provides stability to the burner grates, preventing them from sliding or wobbling during use. Includes 1 rubber foot that goes on the bottom of stove top grates to protect the stovetop if feet become damaged or lost. Sold individually. Order as needed. If you also need an adhesive, order W10841140.

Symptoms of a bad grate foot include:

• Grates that move or wobble when touched
• Scratches or damage to the stovetop surface beneath the grates
• Unstable cookware positioning, potentially leading to spills or uneven cooking

Causes of damage to the grate foot often include regular wear and tear, heat degradation, or impact from heavy pots and pans being dropped or dragged across the grate.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This cooktop grate assembly replaces a damaged or missing grate to restore a stable cooking surface and properly position cookware over the burner. Designed for use on compatible GE gas ranges, it helps ensure even support and safe stovetop use. What it does:

• Provides a stable platform for pots and pans so cookware sits level over the burner
• Keeps cookware centered for consistent heat distribution and safer cooking
• Replaces cracked, warped, or missing grates that can cause wobbling or instability
• Helps protect the cooktop surface and burner components from direct contact with heavy cookware

• Allow the cooktop to cool completely before handling or replacing the grate
• Remove any loose debris and seat the grate fully on the cooktop supports to ensure stability
• No special tools are typically required; handle carefully to avoid chipping or scratching the finish

This grate assembly replaces a damaged or worn cooktop grate to restore a stable, level surface for pots and pans and help ensure even heating. Built to match OEM fit and finish for compatible GE ranges. What it does:

• Supports cookware over the burner, maintaining proper clearance for flames or elements
• Keeps pots and pans steady to reduce tipping and uneven cooking
• Replaces cracked, warped, or chipped grates that interfere with safe use
• Helps maintain proper airflow around the burner for consistent heat

• Turn off and cool the cooktop completely before handling or replacing the grate
• No tools typically required; lift out the old grate and set the new grate into position
• Check that the grate sits level and does not rock before using the burner
• If the grate has porcelain coating, avoid striking or dropping to prevent chipping

This machine screw is an authentic OEM replacement part sourced directly from the manufacturer. It is used in securing the burner head to the gas range top so that it can be used for cooking. If the burner head becomes loose or the screw is missing, it should be replaced. For safety reasons, the burner should not be used until this screw is replaced; the burner head could shift during cooking and lead to a fire. To start, disconnect the gas and power from the stove to prevent accidental ignition of the burner. Make sure the burners are not hot. Remove the burner grate and burner cap from the burner that is missing a screw. Install the new screw in the hole and tighten it with a screwdriver. Put the burner cap and burner grate back on the stove and reconnect the gas and power. Periodic inspection of the burner heads and all associated screws and parts on the stovetop will prevent accidents and keep the stove working correctly. This screw is a silver, metal part that is sold individually. It is designed for use in gas rangetops manufactured by General Electric and Hotpoint.

D burner

H Burner

B Burner

C burner

The Top Burner Igniter is an OEM part for GE gas ranges. It is responsible for igniting the gas to create a flame for cooking on the stovetop burners.

Over time, igniters can degrade due to repeated use, exposure to high temperatures, or buildup of food particles and grease. A malfunctioning igniter can prevent the burner from lighting properly, affecting the cooking performance of the range.

Symptoms of a bad Top Burner Igniter include:

• Burner not lighting
• Delayed ignition or clicking sounds without ignition
• Weak or inconsistent flame
• Smell of gas without ignition

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Approx 4 inches in diameter

Approx 1-1/2 inches in diameter

Approx 2-1/2 inches in diameter

Approx 3 inches in diameter

This is a replacement top burner spring that secures the burner head and helps maintain stable alignment for reliable ignition and even flame. Restores proper seating for many gas cooktop burner assemblies. What it does

• Holds the burner head/assembly in place so the cap and burner stay aligned
• Helps ensure consistent spark/ignition by keeping electrode and burner properly positioned
• Prevents burner wobble or uneven seating that can cause poor heating or flame irregularities
• Small metal coil designed for use with compatible gas cooktop top burner assemblies

• One top burner spring

• Disconnect power and shut off the gas supply before attempting any service; allow the appliance to cool completely.
• Remove burner grates and caps, then replace spring in the burner base per your model's service instructions.
• Use basic hand tools; keep parts organized and avoid damaging electrodes or gas fittings.

The Foam Tape is an OEM part for GE gas ranges. It serves as a sealant, ensuring a proper fit and preventing the escape of heat and gases from the range. This tape helps maintain the efficiency of the range by providing an airtight seal around various components.

Causes of a bad Foam Tape can include wear and tear over time, exposure to high temperatures, or physical damage during cleaning or maintenance. When the foam tape degrades, it can compromise the range's performance and safety.

Symptoms of a bad Foam Tape include:

• Heat escaping from the range
• Gas odors near the appliance
• Visible wear or gaps in the seal
• Decreased cooking efficiency

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Black. D Burner

Black. H Burner

Black. B Burner

Black. C Burner

Note: The part is approximately 4" in diameter.

Small

Note: The part is approximately 2-3/8" in diameter.

Note: The part is approximately 3" in diameter.

Black
