Parts for Ge JVM1490BD003: 01 - Control Panel, Door, Grille & Case Parts

This 10-watt halogen lamp restores clear lighting in select microwave models. Replace a burned-out bulb so you can see the cavity or the cooktop below more easily during use and keep visibility as intended. What it does:

• Provides illumination inside the microwave cavity or for the cooktop surface, depending on model
• Restores normal brightness after the original bulb has failed
• Common symptoms include no light, dim or flickering light, or intermittent operation
• Use only the specified wattage and lamp type for your model to ensure proper operation

• 1 halogen lamp

• Disconnect power by unplugging the unit or switching off the circuit breaker before servicing
• Allow the area and old bulb to cool completely before handling
• Handle the glass capsule with a clean cloth or gloves; oils from skin can shorten bulb life
• Reinstall any lens or cover securely before restoring power

The Mounting Plate Assembly is an OEM part for GE microwaves. This component is designed to mount and stabilize the microwave over the range, ensuring it is safely anchored in its designated space. The mounting plate serves as an interface between the microwave and the wall or cabinet, distributing the weight evenly and providing a firm foundation for the appliance.

Causes of a bad Mounting Plate Assembly can stem from improper installation, which may lead to undue stress and eventual warping or weakening of the material.

Symptoms of a bad Mounting Plate include:

• Loose or wobbly microwave unit, indicating the plate may be unable to properly support the microwave's weight.

• Difficulty in aligning or fitting the microwave onto the mounting plate, which could be due to warping or damage.

• Visible signs of wear, rust, or damage on the plate itself, which can compromise the stability and safety of the mounted microwave.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This mount vent motor cover secures and protects the dryer vent motor assembly so the motor stays aligned and free from debris. It helps reduce abnormal noise and vibration while maintaining safe airflow through the vent housing. What it does:

• Secures the vent motor to the housing to keep the motor stable during operation
• Protects the motor from lint, dust, and foreign objects that can cause damage
• Helps reduce rattling, vibration, and noise caused by a loose motor mount
• Maintains proper airflow routing around the vent motor for efficient operation

• Disconnect power to the appliance before starting any repair
• Use basic hand tools; retain or replace any mounting screws as needed
• Watch for sharp sheet-metal edges and wear gloves to protect your hands
• Verify motor alignment and secure fasteners snugly but avoid over-tightening

Color: Black

The Switch Monitor Interlock is an OEM replacement part for GE microwaves. This safety component ensures that the microwave operates only when the door is securely closed. It prevents the microwave from running if the door is open, providing a critical safety feature to protect users from exposure to microwave radiation.

Causes of a bad switch monitor interlock can include wear and tear over time, mechanical damage from frequent door opening and closing, or electrical malfunctions that impact its performance.

Symptoms of a bad Switch Monitor Interlock include:

• The microwave not starting or operating intermittently
• The microwave running with the door open
• Error messages or safety warnings displayed on the control panel
• Unusual clicking or buzzing noises when the microwave door is opened or closed

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Door Interlock Switch is an OEM part for GE microwaves. It ensures the safety of the microwave by preventing the appliance from operating while the door is open. This switch is part of a microwave's safety mechanism, which includes multiple interlock systems designed to stop the generation of microwaves immediately once the door is opened, thereby protecting users from exposure to microwave radiation.

Signs that it's time to replace your door interlock switch include the microwave not starting or stopping unexpectedly, the microwave continuing to operate with the door open, or a failure to heat food even though the appliance seems to be running.

Symptoms of a bad Door Interlock Switch include:

• Microwave does not start
• Microwave stops unexpectedly
• The microwave operates with the door open
• Microwave turns on but does not heat food

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

Black

Color: Black. For white order WB15X10070. For bisque order WB15X10071. For the screws order WB02X32722.

The Door Latch Assembly is an OEM part for GE microwaves. This component ensures that the microwave door securely closes and locks, which is essential for the microwave to operate safely and efficiently.

Causes of a bad microwave door latch assembly can include regular wear and tear, physical damage from slamming the door, or misalignment over time. If the latch assembly is compromised, the microwave may not start or operate correctly, posing potential safety risks.

Symptoms of a bad microwave door latch assembly include:

• The microwave door not closing or locking properly
• The microwave not starting or running intermittently
• Error messages or warnings on the control panel
• Difficulty in opening or closing the door

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This nut assembly secures an appliance component to its mounting point, restoring a solid connection and preventing unwanted movement. Replace a damaged or missing nut to stop rattling and keep parts aligned for reliable operation. What it does:

• Fastens a panel, bracket or component to its mounting stud or bolt to maintain proper alignment.
• Restores a secure connection when the original nut is stripped, corroded or missing.
• Helps stop rattling, looseness or parts that won't stay in place.
• Works as a direct replacement to restore proper fit and function.

• Disconnect power (and water if applicable) before beginning any repair.
• Use the correct-size socket or wrench; avoid cross-threading when installing.
• Tighten snugly but do not overtighten — replace mating hardware if threads are damaged.
