Parts for Whirlpool CAE2745FQ0: 03 - Controls And Water Inlet Parts

This control panel is the console assembly that houses the oven/range user controls and display, restoring responsive button input and clear status feedback for normal operation. It replaces a worn, cracked, or unresponsive console to return reliable control. What it does:

• Provides the front-facing buttons, touch controls and display interface used to select bake, broil, timers and settings
• Routes user commands to the oven control board so cycles and temperature changes start correctly
• Commonly replaces panels that are cracked, faded, or have unresponsive buttons or missing indicators
• Helps resolve intermittent or no-response control inputs when the panel hardware is the failed component

• One control panel (console assembly) as shown

• Disconnect power to the appliance at the breaker before starting; electric shock hazard
• Handle the assembly carefully to avoid damaging the display, ribbon cables, and connectors
• Some models require removing trim, screws, or the oven door for access; keep fasteners organized
• If you see additional electronic damage or error codes after swap, verify the main control board and wiring harness

This genuine replacement part is a control board for washing machines. The control board is the main computer that controls the essential functions of the washer. If the washer is no longer spinning, rinsing, or draining properly, it might be time for a new control board. Luckily, replacing the control board is a simple process.To replace the control board, make sure the washer is unplugged. Pull the washer out to gain access to the upper back panel of the appliance. Remove the upper back panel and locate the old control board. Take note of the orientation of the wires with a phone camera. Remove the wire harness and individual wires. Connect the wires to the new control board in the correct order. Snap the control board back into its original place and reinstall the top panel of the dryer.This OEM replacement control board is compatible with Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Sears/Kenmore brand dryers.

The Screw is an OEM component compatible with Whirlpool washing machines. This screw secures the rear panel onto the cabinet frame, ensuring a sturdy connection between housing components.  Proper installation is critical for the washer's structural integrity.

Causes of a bad screw include corrosion from repeated water exposure or stresses from years of use. Loosening can occur from vibrations weakening the threads over time.

Symptoms of a bad screw include:

• Rear panel detaching from frame opening gaps
• Increased noise and vibrations from a compromised seal
• Stress on other connections from improper mounting points
• Potential leak paths from openings near hoses or tub areas

This OEM Whirlpool replacement screw helps maintain a tight panel closure. It is compatible with additional brands like Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Whirlpool screw is an OEM replacement part responsible for securing various components or parts on different types of Whirlpool appliances. The screw is designed to provide a secure and reliable fastening connection, ensuring that different parts of the appliance stay in place. It is commonly used in different locations within the appliance, such as the cabinet, panels, or other structural elements.

This part fixes the following symptoms:

• Loose or wobbly components within the appliance
• Panels or parts that are not securely attached
• Rattling or unusual noises due to loose parts
• Damaged or missing screw

The Whirlpool screw can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

This replacement power cord restores safe, consistent electrical connection to compatible electric ranges and ovens. Durable construction helps prevent intermittent power and heat-related damage so your appliance can heat and operate reliably. What it does:

• Replaces a damaged, frayed, or burned power cord that causes intermittent power or no power to the appliance
• Provides the main AC connection between the appliance and household electrical supply
• Helps prevent arcing, sparks, and overheating associated with worn or compromised cords
• Suitable when a visible cord fault or connector damage is present

• One power cord

• Disconnect power at the breaker or unplug the appliance before starting any work
• Tighten all terminal connections securely and route the cord away from heat sources and moving parts

The Screw is an OEM component compatible with Whirlpool washing machines. This screw secures the rear bulkhead to the tub, ensuring vibrations are reduced through solid mounting points. Properly installed screws dampen oscillating movement.

Causes of a bad screw include damage from water exposure like corrosion or breakage from stress concentrations if the tub bangs around during imbalanced loads.

Symptoms of a bad screw include:

• Loose or detached rear bulkhead allowing side-to-side play
• Excessive noise and shaking felt through the surrounding walls
• Development of micro-cracks around screw holes over time
• Potential leak paths if holes are no longer sealed

This Whirlpool replacement screw restores a stable suspension system. It is compatible with additional brands like Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This control knob replaces a worn or broken stove/oven front control knob, restoring easy, accurate control of burner and oven settings. It fits on the control shaft to provide a secure, user-friendly grip. What it does:

• Replaces a damaged or missing stove/oven control knob so you can change burner or oven settings
• Provides a positive tactile click and clear pointer for accurate heat selection
• Helps prevent slipping or incomplete engagement that can affect temperature selection
• Matches OEM fit and function for direct, no-modification swap

• One control knob as shown

• Remove power to the appliance before attempting service (unplug or shut off breaker)
• Pull old knob straight off the control shaft; align new knob on splines and push until fully seated
• If the knob feels loose or won't engage, check the control shaft and splines are not damaged

This replacement control knob restores reliable user control for your appliance's front panel. It provides a firm grip for selecting settings so you can operate cycles, temperatures, or functions with confidence. What it does

• Replaces a cracked, stripped, or missing control knob so settings can be selected and held securely.
• Provides tactile feedback and a positive grip for turning and selecting controls.
• Helps eliminate slipping or loose control operation that prevents accurate selection of cycles or temperatures.
• Fits onto the appliance control shaft to restore normal manual control.

• Disconnect power (and gas supply for gas appliances) before servicing.
• Typically a push-on replacement onto the control shaft; align splines and press firmly until seated.
• If knob is tight or stuck, use gentle leverage; avoid excessive force that could damage the control shaft.

The Cycle Switch is an OEM part for Whirlpool washing machines. It is responsible for controlling the various cycles of the washing machine, such as wash, rinse, and spin. This switch ensures that the machine progresses through each cycle correctly, maintaining the proper sequence for effective cleaning.

Causes of a bad cycle switch can include wear and tear from frequent use, electrical malfunctions, or mechanical failure within the switch mechanism.

Symptoms of a bad cycle switch include:

• The washing machine not advancing through cycles
• The machine getting stuck on a particular cycle
• Irregular or inconsistent cycle timings
• The machine not starting or stopping at the correct times

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

This wire harness assembly routes power and signals between appliance components to restore reliable electrical connections. It replaces a damaged or worn multi-conductor harness to help eliminate intermittent operation and restore proper control functions. What it does:

• Carries power and control signals between modules, switches, and motors
• Replaces frayed, burned, or disconnected wiring that can cause intermittent or no operation
• Helps stop electrical arcing, shorts, and loose-connection symptoms that trigger errors or shutdowns
• Restores reliable connections for proper appliance control and performance

• One complete wire harness assembly as shown

• Disconnect power (unplug or shut off breaker) before starting any work
• Take reference photos of the original harness routing and connector positions to ensure correct reassembly
• Match connectors and routing exactly; avoid stretching or pinching wires when reinstalling
• If you see burned terminals, damaged connectors, or other component damage, inspect related parts and replace as needed

The Valve is an OEM replacement part for Whirlpool washing machines. It is a component that regulates the water coming into the tub.

Causes of failure generally include wear and tear over time, mineral buildup affecting valve operation, or damage from freezing.

Symptoms of a bad valve can include:

• Failure to fill or drain the tub properly
• Abnormal water levels during functions
• Inability to switch between temperature settings
• Water leaks from the valve area

This is a genuine Whirlpool OEM replacement this part is also compatible with Maytag, Jenn-Air and some Kenmore models.

This wire harness routes power and signals between the appliance control and internal components to restore reliable electrical connections. It replaces a damaged or frayed harness to help eliminate intermittent operation and component power loss. What it does:

• Provides the factory wiring connections between the control, motors, switches, and sensors
• Replaces broken, burnt, or corroded wiring that can cause components to stop working
• Helps address symptoms such as intermittent operation, no power to a component, or electrical arcing
• Maintains proper connector fit and wire routing to prevent shorts and rubbing

• Disconnect power (unplug or switch off breaker) before starting any repair
• Handle connectors by the housings, not the wires; secure harness with existing clips or ties
• Test appliance operation after installation; revert power off before making adjustments

This pushbutton installs in the control console and actuates the underlying switch, restoring positive, reliable selection of a cycle or feature and a clean, finished appearance when the original button is worn, sticky, or broken. What it does

• Provides the user-facing cap that presses the internal control switch
• Restores smooth button travel and positive engagement
• Helps ensure selections register consistently
• Common symptoms: button cap cracked/missing, sticks or won't spring back, selection only registers when pressed hard, loose or wobbly button

• 1 pushbutton

• Disconnect power before servicing to avoid electrical shock
• Access the control/console per your service manual
• Note orientation; release retaining tabs and remove old button
• Seat the new button fully; test travel and function before reassembly

This replacement mounting bracket secures appliance panels and components to restore proper fit and reduce movement. It's a direct-fit bracket used where the original metal support has cracked, bent, or detached. What it does:

• Provides a stable mounting point to keep panels, consoles or assemblies aligned and secure
• Stops rubbing, rattling or vibration caused by a loose or damaged bracket
• Restores correct spacing so doors and panels close and operate smoothly
• Matches OEM fit to maintain factory alignment and assembly integrity

• Disconnect power (and water if applicable) before starting any repair
• Basic hand tools are typically required; remove surrounding trim or panels for access
• Align bracket before tightening fasteners; do not overtighten to avoid stripping threads

10 - 16 x 1/2

Size: 1-1/16 x 5/8 inch. Used for fill hose. For a 4 pack order 285448A

The Coin Slide Interface is an OEM part for Whirlpool commercial washers. It is a component that allows users to insert coins or tokens to activate the machine and initiate the laundry cycle.

Causes of a faulty coin slide interface can include regular wear and tear, damage due to misuse or vandalism, or electrical component failure. These factors can result in issues such as coin rejection, incorrect coin counting, or the inability to start the machine using coins.

Symptoms of a Bad Part:

• Will not start
• Not washing properly
• Timer will not set

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Replacement wire harness that reconnects an appliance's electrical components to restore reliable power and signal paths for controls and motors. Use when worn or damaged wiring causes intermittent operation or control failures. What it does:

• Routes and links power and signal lines between the control board and components.
• Restores reliable connections to eliminate intermittent or lost function.
• Common symptom fixes: appliance won't start, controls or displays unresponsive, specific cycles or features fail.
• Helps address visible wiring damage, burned connectors, or loose plug connections.

• Disconnect power (and water, if applicable) before beginning any work.
• Follow the appliance's service manual or parts diagram to confirm routing and connector orientation.
• Inspect connectors and mating terminals for damage; replace if corroded or burned.
• Do not modify the harness; secure wiring to prevent pinching and avoid contact with high-heat areas.

Number-8, 18-thread screw used to secure panels, brackets and small assemblies in Whirlpool appliances. Replacing a missing or damaged screw restores secure mounting and helps stop rattling or loose parts. What it does:

• Fastens trim, panels, brackets or small appliance components that use a #8-18 threaded fastener
• Restores secure mounting when a screw is lost, stripped or damaged
• Helps eliminate vibration-related noise from loose parts
• Simple replacement part for basic fastening needs

• Disconnect power to the appliance before servicing and work on a cool, stable surface
• Use the correct screwdriver or driver bit to avoid cam-out or stripped heads
• Thread in straight and tighten until snug; do not over-torque to avoid stripping threads or damaging components
• Replace with the identical screw type and size for proper fit and function
