Kitchenaid Range Control Board

The Control Board is an OEM part for Whirlpool microwave and wall oven combinations. It is responsible for managing and coordinating the various functions of the appliance, including temperature regulation, cooking modes, and timing.

Over time, exposure to high heat and regular usage can lead to malfunctions. Physical damage or power surges can also cause the control board to fail.

Symptoms of a bad Control Board include:

• Unresponsive touchpad or display
• Inconsistent temperature control
• Error codes displayed
• The appliance not turning on or off properly

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Spark Module is an OEM replacement part for Whirlpool ranges. It is an electrical component that generates the spark needed to ignite the gas burners. By sparking consistently and reliably, the module allows the cooktop burners to ignite with each use.

Causes of a bad spark module can include normal wear and tear over time, exposure to moisture or residue, or issues with the electronic components that produce the spark.

Symptoms of a bad spark module include:

• Burners that will not ignite or light consistently
• Burners that ignite but then immediately go out
• Only some of the burners lighting while others do not
• A clicking sound coming from the ignitors but no visible spark

Note: For harness from spark module to igniters use part number 9756892.

This OEM Whirlpool replacement spark module is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Inverter is an OEM replacment part for Whirlpool microwaves. It regulates the magnitude and duration of electromagnetic waves generated during cooking functions.

Causes of a faulty inverter can include general wear from prolonged use or damage from power surges entering the microwave.

Symptoms include:

• Inconsistent or incomplete heating of foods
• Sparking or burning smells emanating from within
• Control panel errors or failure to properly sense wattage settings

This OEM Whirlpool replacement ensures precise electromagnetic wave output. Compatible with KitchenAid, Maytag, Jenn-Air, and select other branded microwaves, the inverter restores consistent cooking performance.

This electronic control module generates and manages ignition spark for DSI-equipped gas ovens/ranges. Replacing a failed unit restores reliable burner lighting and can resolve issues such as no spark, repeated clicking, or the oven/broiler not igniting.

• Generates high-voltage pulses to ignite gas at the DSI electrodes
• Times and controls ignition cycles; energizes the gas valve only during commanded ignition
• Monitors flame presence through the sense circuit and may retry or lock out if ignition fails
• Common symptoms of failure: oven or broiler won't ignite/heat, no clicking/spark, intermittent ignition, or continuous clicking
• Intended for models that use direct-spark (DSI) ignition systems, not glow-bar/hot-surface igniters

• Disconnect power and shut off gas supply before servicing
• Handle the control as an electrostatic-sensitive device; avoid touching terminals
• Transfer wires one at a time and mount the module securely with a proper ground
• After reassembly, restore utilities and verify normal ignition operation

This replacement part is an oven control board and display. It houses the buttons that users push to control oven operation, including bake functions, temperature, and access to the timer and clock. Over time and through exposure to heat and moisture, the control board may corrode and fail. If the control board is damaged, the oven may not operate correctly or at all.To replace the oven control board, first unplug the oven from the wall. Next, remove the rear access panel from the stove. This should reveal the back of the control board. Remove the mounting screws and disconnect the wiring. Remove the old control board. When ready to install the new board, first remove the protective film, then place it on the slot. Install the mounting screws and reconnect the wiring. Replace the oven's rear access panel. Always wear gloves when repairing an oven.This is a genuine OEM replacement part. It's manufactured by Whirlpool and will fit Whirlpool, KitchenAid, and Kenmore ovens.

This oven control board is manufactured by Whirlpool. It is an electronic component and is responsible for monitoring and controlling the oven's functions, such as bake, broil, and warm, as well as maintaining the appropriate temperature set by the user. This control board does not include the physical controls for the oven.High heat and exposure to moisture can degrade the control board. This may result in intermittent problems or outright failure of the oven. In both cases, the control board will need to be replaced. Before working on the oven, make sure to unplug it or shut off the circuit breaker. Wear gloves at all times and exercise care when disconnecting/connecting the writing to the board.A genuine OEM part, this control board is sold individually. It fits Whirlpool and KitchenAid branded ovens.

The Cntrl-Elec is an OEM component specifically designed for Whirlpool brand gas ranges. This control board module regulates electrical functions and sends signals to components of the electric oven and cooktop controls.

Causes of a bad control board can include moisture damage, physical impact over time, or normal component degradation from regular use of the appliance.

Symptoms of a bad control board include:

• Inability to turn on electric oven bake/broil functions
• Unresponsive touch controls or improper display readings
• Odd noises, smells or sparks coming from control area
• Failure to ignite gas burners or regulate flame levels

This Whirlpool replacement part is also compatible with KitchenAid, Jenn-Air and select Kenmore models.

This electronic control board manages core oven functions. It processes keypad inputs and controls heating so the oven starts, regulates temperature, and responds consistently when the original control has failed.

• Regulates oven heating cycles and sends power to bake and broil circuits
• Interprets keypad/touchpad selections to run chosen functions
• Uses oven sensor feedback to help maintain set temperatures
• Can help with symptoms like no heat, bake/broil won't start, unresponsive controls, or control-related error codes

• Disconnect power at the breaker or unplug the appliance before servicing
• Electrostatic-sensitive part—use ESD protection and handle the board by the edges
• Note/photograph wiring and move connectors to matching terminals on the new board
• Restore power, set the clock, and verify all oven functions after installation

The Noise Filter is an OEM part for Whirlpool built-in wall ovens. It is installed inside the oven cavity near components that produce vibrations, such as the convection fan motor.

Causes of a faulty noise filter include the degradation of noise-dampening materials over many heating and cooling cycles. Physical damage from accidental impact during cleaning could also compromise its sound-blocking ability.

Symptoms of a bad noise filter include:

• Excessive buzzing or humming noises emitted from the oven cavity
• Louder than normal fan or component sounds carrying into the kitchen
• Vibrations felt externally on the oven chassis during operation

This OEM replacement fits several Whirlpool, KitchenAid, and Jenn-Air wall oven models.

This transient suppressor protects the appliance's electronic control by absorbing power-line spikes and electrical transients. Replacing a failed suppressor helps restore stable control operation and helps protect sensitive components from surge-related damage.

• Clamps voltage transients on the AC line to shield the control and related electronics
• Helps reduce interference that can cause erratic displays or unexpected resets
• Failure may leave the control dead, cause intermittent operation, or trip the household breaker
• Often shows visible heat damage, cracking, or discoloration when defective

• Disconnect power at the breaker and verify no voltage is present before servicing
• Access the control compartment; the suppressor is typically located near the electronic control or power input
• Photograph wiring and transfer one lead at a time to ensure correct connections and snug terminals
• Inspect and replace any heat-damaged wires or terminals before reassembly and test

The Electronic Control is an OEM replacement part for Whirlpool gas ranges. It controls various functions such as temperature regulation, timer settings, and cooking modes.

A bad oven control board can occur due to electrical malfunctions, power surges, or general wear and tear. If you notice symptoms such as the oven not reaching the desired temperature, erratic temperature fluctuations, or unresponsive controls, it may be time to replace the control board.

Symptoms of a bad oven control board include:

• Oven not reaching desired temperature
• Erratic temperature fluctuations
• Unresponsive controls

Restore the functionality and precision of your Whirlpool gas range by replacing the faulty or worn-out oven control board with this genuine OEM part.

This Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

The Microwave Inverter Board is an OEM part for Whirlpool brand microwaves. This board works with the magnetron to convert voltage and power the cooking elements.

Causes of a bad inverter board can include failure of electronics over time, shorts or current leaks, or improper installation.

Symptoms of a bad inverter board include:

• The microwave will not power on or heat food properly
• Sparking or burning smells are detected inside the microwave cavity
• The display console does not illuminate or function correctly
• Error codes are frequently displayed

This OEM Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore models.
