Parts for Lg DLG7188RM / ACREEUS: Section 3 Parts

This washer tub assembly is the stationary outer tub that surrounds the spin basket and contains the wash water. Replacing a cracked or damaged tub helps stop leaks and restores proper clearance for smooth, quiet washing and spinning.

• Creates a watertight chamber around the basket to hold wash and rinse water
• Maintains proper basket clearance; damage can cause rubbing or scraping sounds
• Provides connection points for hoses and water-level components
• Common signs it may be needed: leaks from the tub area, visible cracks or warping, persistent out-of-balance/spin errors, or internal scraping/grinding noises

• Disconnect power and water; shut off supplies and safely drain remaining water
• This is a major repair—allow time and consider a second person to help lift/support the tub
• Transfer model-specific parts from the original tub to the new tub as needed; reinstall all clamps, bolts, and sensors securely
• After reassembly, level the washer, and run a test cycle to check for leaks

The Gas Burner Valve Assembly is an OEM replacement part for LG gas dryers. It is a component located beneath the gas burner that controls the flow of fuel to ignite and maintain the flame. The valve assembly receives ignition and temperature signals from the dryer's control system to precisely regulate gas levels throughout drying cycles. This gas dryer burner valve includes two solenoid coils.

Causes of a faulty gas valve may involve wear over extended operation, mineral buildup on valve seats, or mechanical issues restricting gas flow at desired levels.

Symptoms of a bad gas burner valve assembly consist of:

• Erratic or inconsistent burner ignition between cycles
• Inability to achieve high heat settings when needed
• Burners not maintaining steady flame patterns
• Potential gas leaks detected around valves or tubing

This OEM LG part is also compatible with some Sears/Kenmore dryers.

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

This is a four ribbed poly V belt.

The Drum Seal is an OEM part for LG dryers. This part ensures a tight seal between the dryer drum and the dryer body, preventing hot air from escaping and maintaining the efficiency of the drying process. A well-functioning drum seal is important for the best dryer performance, contributing to energy efficiency and the prevention of unnecessary wear on clothing during the drying cycle.

Causes of a bad drum seal can range from natural wear and tear over time to overloading the dryer, which can strain and stretch the seal, leading to a poor fit.

Symptoms of a bad Drum Seal include:

• Clothes taking longer to dry
• Increased energy usage due to loss of heat
• Excessive lint and debris outside of the lint filter area
• A noticeable gap between the dryer drum and the dryer body

This OEM LG part is also compatible with some Kenmore models.

This Pipe Assembly routes water into the appliance so the dispenser and ice maker can receive a steady supply. Replacing a damaged tube restores proper water flow and helps stop leaks or pooling inside or beneath the unit. What it does:

• Carries incoming water from the household supply to the appliance's internal water system
• Restores water delivery to the dispenser and ice maker when the original tube is cracked or blocked
• Prevents leaks and water damage caused by split, corroded, or pinched tubing
• Helps eliminate intermittent flow or weak dispenser output caused by a damaged water line

• One complete pipe assembly as shown

• Shut off the refrigerator's water supply and unplug the appliance before beginning
• Handle tubing fittings carefully; use proper tools to avoid damage or overtightening
• Inspect connection points and replace seals or clips if worn; test for leaks after reinstalling

The Dryer Ignitor is an OEM part for LG dryers. It is crucial for the ignition process in gas dryers, responsible for lighting the gas burner that provides heat for drying clothes. This ignitor must heat up to a high temperature to ignite the gas, and its proper function is essential for the dryer to operate safely and efficiently.

Symptoms of a bad Dryer Ignitor include:

• The dryer not heating up, even though all other functions are working correctly.
• The gas valve opening but no flame being produced, indicating the ignitor isn't reaching the necessary temperature.
• Intermittent heating, where the dryer sometimes produces heat and other times does not.

Causes of a bad dryer ignitor can include thermal fuse issues, a broken or malfunctioning ignitor due to wear and tear, or electrical problems affecting power delivery to the ignitor.

This OEM LG part is also compatible with Kenmore models.

For propane order 383EEL3002A.

The Liquid Propane Gas Orifice is an OEM replacement part for LG dryers. This orifice is specifically designed for models that run on liquid propane gas. It regulates the flow of gas into the burner, allowing the dryer to heat up and dry your clothes.

Causes of a faulty orifice can include corrosion from repeated heating cycles breaking down internal components. Orifices degrade naturally over extended use.

Symptoms of a failed orifice include:

• The dryer failing to properly heat or dry clothes
• Yellow flames or plumes of unburnt gas exiting the dryer vent
• Error codes related to gas or heating issues displayed

This OEM LG part is also compatible with some Kenmore models.

For natural gas order 4948EL4001B.

Replacement door gasket that seals the refrigerator/freezer door to help keep cold air in, reduce energy loss, and maintain consistent temperatures for stored food. What it does

• Forms an airtight seal around the door to prevent warm air from entering the compartment.
• Helps maintain even cooling and prevents frost or ice buildup caused by air leaks.
• Can reduce running time and energy use when the original gasket is torn, warped, or no longer seals.
• Common symptoms of a failing gasket: visible gaps, condensation or frost at the door, uneven temperatures, or increased energy use.

• Disconnect power to the appliance and remove food from affected areas before beginning work.
• Inspect the door frame for dirt or debris and clean mating surfaces before installing the new gasket.
• Align the gasket to the door and seat it fully—follow OEM alignment steps for your model; if the gasket is stiff, warm it slightly per OEM guidance to help fit.

This duct assembly channels airflow inside the appliance to guide exhaust and internal air between components. Replacing a damaged or obstructed duct helps restore proper airflow and can reduce poor performance or long cycles. What it does:

• Directs exhaust and circulation air between internal components to maintain airflow
• Prevents leaks that can reduce efficiency or cause longer cycle times
• Helps avoid overheating or moisture build-up from restricted airflow
• Reduces rattling or vibration caused by a cracked or loose duct

• Disconnect power (and turn off gas supply for gas appliances) before beginning work.
• Handle edges carefully — sheet metal can be sharp; wear cut-resistant gloves.
• Ensure duct is seated and fastened to create a tight seal where it connects to other components.
• After reassembly, run a test cycle to confirm airflow and proper operation.

This tub assembly is the main inner drum that holds clothes and spins during the wash and spin cycles, restoring a smooth, balanced wash performance when the original drum is damaged. Designed to replace a worn, cracked, or dented drum to help reduce noise and prevent fabric damage. What it does:

• Holds laundry during wash and spin cycles and provides the rotating surface for tumbling
• Replaces cracked, dented, or bent drums that cause scraping, rubbing, or visible damage to clothes
• Helps stop unusual noises or vibrations caused by a warped or damaged drum
• Restores proper drum alignment so the washer can drain and spin efficiently

• Disconnect power and water supply before beginning service
• Drain remaining water and remove front or top panel before accessing the drum
• Drum replacement typically requires removal of the wash plate, pulley, and possibly the tub seal—have basic hand tools and a service manual or diagram on hand

The High Limit Thermostat is an OEM part for LG dryers, designed to act as a critical safety feature within the appliance. This thermostat monitors the dryer's internal temperature, shutting off the heat source if it detects temperatures that are dangerously high. By doing so, it prevents overheating, which can lead to appliance damage or, in worst-case scenarios, fires. The high limit thermostat is a crucial component for the safe operation of your dryer, ensuring it operates within the specified temperature range.

Causes of a faulty High Limit Thermostat can include a malfunction within the thermostat itself, such as a failure to accurately detect temperature changes, or issues with the dryer that cause it to run hotter than designed, such as restricted airflow or a malfunctioning heating element.

Symptoms of a malfunctioning High Limit Thermostat include:

• The dryer not heating properly or at all
• The dryer repeatedly shutting off during cycles
• Excessive heat emanating from the dryer, indicating it is not regulating temperature correctly

This OEM LG part is also compatible with some Kenmore models.

The Incandescent Lamp is an OEM part for LG dryers. It serves as the interior light source for LG clothes dryers.

Causes of lamp failure relate to typical lifespan expirations, being accidently left on which shortens rated hours, or faulty sockets allowing moisture or other contamination to enter the connection points.

Symptoms of a burned out lamp include:

• Dark or completely unlit drum chamber interior
• Inability to fully inspect clothes during operation
• Difficulty monitoring dryer progress without supplemental lighting

This LG part is also compatible with some Kenmore models.

The Cover, Lamp is an OEM part for LG dryers. This component covers and protects the interior lamp inside the dryer, ensuring it stays secure and free from damage while providing illumination inside the drum.

Over time, the lamp cover can become cracked or damaged due to the high temperatures and vibrations within the dryer. It is essential to replace a faulty lamp cover to maintain the proper lighting and protection for the lamp.

Symptoms of a bad lamp cover include:

• The interior lamp not staying in place
• Visible cracks or damage on the cover
• Reduced or blocked light inside the dryer drum
• The cover falling off or becoming loose

This OEM LG part is also compatible with Sears/Kenmore models.

The High Limit Thermostat is an OEM part for LG dryers, designed to act as a critical safety feature within the appliance. This thermostat monitors the dryer's internal temperature, shutting off the heat source if it detects temperatures that are dangerously high. By doing so, it prevents overheating, which can lead to appliance damage or, in worst-case scenarios, fires. The high limit thermostat is a crucial component for the safe operation of your dryer, ensuring it operates within the specified temperature range.

Causes of a faulty High Limit Thermostat can include a malfunction within the thermostat itself, such as a failure to accurately detect temperature changes, or issues with the dryer that cause it to run hotter than designed, such as restricted airflow or a malfunctioning heating element.

Symptoms of a malfunctioning High Limit Thermostat include:

• The dryer not heating properly or at all
• The dryer repeatedly shutting off during cycles
• Excessive heat emanating from the dryer, indicating it is not regulating temperature correctly

This OEM LG part is also compatible with some Kenmore models.

The Igniter Sensor is an OEM part for LG dryers. This sensor plays a critical role in the ignition process, ensuring that the gas ignites properly to produce the heat necessary for drying clothes efficiently. It helps monitor and regulate the ignition temperature.

Over time, the igniter sensor can become faulty due to regular use, exposure to high temperatures, or electrical issues. These factors can lead to a malfunction, resulting in the dryer not heating properly or failing to start.

Symptoms of a bad igniter sensor include:

• Dryer not heating up
• Long drying times
• Dryer not starting
• Unusual smells or noises during operation

This OEM LG part is also compatible with Sears/Kenmore.

A small mounting bracket that secures and supports internal appliance components to keep shelves, drawers or assemblies aligned and stable. Replaces a cracked, broken or missing supporter to restore proper fit and reduce movement. What it does

• Secures an internal component or assembly in place to prevent sagging or misalignment
• Stops rattling, wobble or looseness caused by a damaged or missing bracket
• Restores correct clearance and support for the associated shelf/drawer/assembly
• Helps maintain normal operation and prevents further wear on adjacent parts

• One supporter holder bracket

• Disconnect power before starting repairs; unplug or flip the appliance breaker
• Remove nearby shelves, drawers or panels to access the damaged bracket
• Inspect mating parts for damage and replace any worn fasteners as needed
• Use basic hand tools;

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

The Dryer Lint Filter is an OEM part for LG dryers. It is designed to capture lint and debris from clothes during the drying cycle, helping to prevent these particles from clogging the dryer vent. This filter is crucial for maintaining the efficiency and safety of your dryer, as a clean lint filter reduces the risk of fires and ensures that the appliance operates at optimal performance levels.

Symptoms of a bad Dryer Lint Filter include:

• Excessive lint accumulation outside the filter area, indicating a tear or hole in the filter.
• Reduced drying efficiency, with clothes taking longer to dry or feeling damp after a complete cycle.
• Noticeable wear or damage to the filter, such as fraying or holes.

Causes of a bad dryer lint filter can include regular wear and tear from usage, accumulation of fabric softener which can clog the mesh, or physical damage from removing or cleaning the filter improperly.

This OEM LG part is also compatible with Sears/Kenmore, ensuring it fits a wide range of dryer models within these brands.

The Lint Filter Guide Cover is an OEM part for LG dryers. It is designed to hold and support the lint filter, ensuring that it remains in place and effectively traps lint and debris during the drying cycle. This guide cover plays a crucial role in maintaining airflow and preventing lint buildup, which can improve dryer efficiency and safety.

Over time, the lint filter guide cover can become damaged or worn out. Causes of a bad guide cover can include regular wear and tear from frequent use, physical damage from removing or inserting the lint filter, or exposure to high heat. A damaged guide cover can result in improper fit or function of the lint filter, leading to lint bypassing the filter and accumulating in the dryer.

Symptoms of a bad lint filter guide cover include:

• The lint filter not fitting securely in place
• Lint escaping and accumulating around the dryer
• Difficulty in inserting or removing the lint filter
• Visible cracks or damage on the guide cover

This OEM LG part is also compatible with Sears/Kenmore.

The Lint Filter Guide is an OEM part for LG dryers. It holds the removable lint filter screen securely in place. Proper alignment and secure mounting of the lint filter is important for effective filtration.

Causes of a faulty lint filter guide can include wear and tear from years of inserting and removing lint screens. Damage such as cracks or breaks could compromise secure mounting.

Symptoms of a problematic filter guide include:

• The lint screen not sitting correctly or falling out of alignment
• Inability to fully insert or remove the lint screen
• Lint scattering inside washer rather than collecting in screen

This OEM LG part is also compatible with some Kenmore models.

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

This moisture sensor connector assembly links the dryer's sensor bars to the control to monitor fabric dryness and adjust cycle time. Replacing a damaged or loose harness restores consistent Auto Dry operation.

• Connects the moisture sensor bars to the main control for Auto Dry feedback
• Transmits the low-voltage signal used to determine when clothes are dry
• Failure may cause Auto Dry to end too soon, run too long, or deliver inconsistent results
• Typical issues include broken wires, loose/corroded terminals, or a heat-damaged plug

• Disconnect power; if gas, shut off gas supply before service
• Access the moisture sensor area at the front/lint housing
• Match routing and clips, seat terminals fully on the sensor tabs, and secure the connector
• Keep wiring clear of sharp edges and moving parts; reassemble and test a Sensor Dry cycle

The Moisture Sensor Holder is an OEM replacement part for  LG dryers. It secures the crucial moisture sensor in place inside the drum. This sensor detects how damp the laundry is to determine when the cycle has finished drying clothes.

Symptoms of a bad moisture sensor holder include:

• The sensor coming loose or not making proper contact
• Inaccurate drying times as the sensor may read inconsistently
• Premature ending of cycles before clothes are completely dry
• Repeated drying error codes displayed

Causes can be cracked or broken clips after years of drum rotation. Vibrations may also loosen mounting screws over time.

Replacing with this genuine LG part ensures the sensor stays positioned correctly. Compatible models include some Kenmore and Sears dryers.

The Blower Wheel is an OEM part for LG dryers. This part circulates air through the dryer drum and out the exhaust vent, ensuring proper airflow for efficient drying of clothes.

Causes of a bad blower wheel can include accumulation of lint and debris, wear and tear over time, or physical damage due to foreign objects entering the blower housing.

Symptoms of a bad blower wheel include:

• Reduced or no airflow from the exhaust vent
• Unusual noises such as rattling or squealing during the drying cycle
• Clothes taking longer to dry or remaining damp
• Overheating or frequent shutdowns of the dryer

This OEM LG part is also compatible with some Kenmore models.

Adapt your gas dryer for propane with this LP conversion kit. It provides the correct orifice and regulator adjustments needed so the burner fires properly on LP fuel, helping ensure safe operation and consistent drying performance after a fuel change.

• Converts a compatible gas dryer from natural gas to liquid propane (LP)
• Helps ensure proper burner flame characteristics on LP
• Appropriate when moving to a home with propane or changing utilities
• Symptoms can include weak heat, improper flame, or sooting

• Disconnect power and shut off gas before servicing
• Installation and regulator/orifice adjustments must be performed per the service manual
• After installation, leak-check all connections and verify proper burner operation
• Do not attempt conversion without the correct kit for your specific model

This dryer duct assembly channels air from the drum to the blower and exhaust. Replacing a cracked or warped housing restores proper airflow, helps prevent lint bypass, and supports consistent drying performance.

• Directs and seals airflow between the drum and blower housing
• Helps maintain drying efficiency by minimizing leaks and lint bypass
• Damage or warping can lead to long dry times and reduced airflow
• Signs of failure include visible cracks, melted spots, or air/lint leakage around the duct area

• Disconnect power; for gas models, turn off the gas supply
• Access from the front by removing the top and front panel
• Note fastener locations and any attached brackets/harnesses, then transfer them to the new assembly
• Vacuum lint from internal ducting and verify seals before test run

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

This metal mounting bracket secures internal components to the appliance frame, restoring proper alignment and reducing movement. Replace a worn or damaged bracket to stop rattling and maintain stable operation. What it does:

• Provides structural support to hold panels, controls, or assemblies in place
• Prevents excess vibration and noise caused by loose parts
• Keeps components aligned for reliable mechanical operation
• Helps maintain safe clearances between moving parts

• Turn off power and unplug the appliance before beginning work
• Use appropriate hand tools; retain any original fasteners unless replacements are specified
• Inspect adjacent parts and mounting points for damage; replace if worn

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

The Idler Pulley Assembly is an OEM part for LG dryers. It plays a critical role in the dryer's drum belt tension system, helping to maintain proper tension on the belt so the drum can rotate smoothly during the drying cycle.

Causes of a bad idler pulley assembly can include wear and tear over time, buildup of lint or debris, or damage from an overloaded dryer. A malfunctioning idler pulley can lead to inefficient drying and potential damage to other dryer components.

Symptoms of a bad idler pulley assembly include:

• Squeaking or squealing noises during operation
• The drum not rotating properly or at all
• The dryer stopping mid-cycle
• The belt slipping or breaking

This OEM LG part is also compatible with Sears/Kenmore.

The Dryer Idler Pulley is an OEM replacement part for LG dryers. It is a critical component that helps guide and maintain proper tension on the dryer belt, ensuring efficient transfer of rotational force from the motor to the dryer drum.

Symptoms of a faulty dryer idler pulley include:

• Squeaking or grinding noises coming from the pulley area
• Visible wear, cracks, or damage to the pulley surface
• Slipping or irregular rotation of the dryer drum

Causes of a bad idler pulley can include normal wear and tear over time, exposure to high temperatures or lint buildup, misalignment or improper tracking, or physical damage from impact or foreign objects.

This OEM LG part is also compatible with Sears/Kenmore dryer models.
