Parts for Ge JGB250DET3BB: 01 - Gas & Burner Parts

Color: White

Replacement control knob for gas range valve stem. Installs on burner or oven controls. Needed when original knob is broken, cracked, or missing.

Replacement fastener nut for gas ranges and cooktops. Secures panels and internal components. Needed when original nut is missing, stripped, or worn.

This manifold panel is the front trim piece that covers and supports the cooktop manifold and controls, restoring the appliance's finished appearance and helping protect internal components from spills and debris. What it does:

• Replaces a cracked, bent, or visibly damaged front manifold trim
• Restores proper alignment and fit of the cooktop front and control area
• Helps protect valves, orifices and internal components from grease and spills
• Improves appearance when the original panel is scratched, dented, or corroded

• Designed for drop-in replacement; follow your model's service manual for disassembly order
• Disconnect power and gas supply before starting work
• Handle edges carefully and support the panel during removal to avoid scratching surrounding surfaces

Size: 8 - 32 inch.

Burner box for gas ranges. Installs beneath the cooktop to house burner components. Replace if cracked, warped, rusted, or damaged from heat exposure.

This small cooktop bracket secures designated components beneath the cooktop surface, keeping them properly positioned and stable. Replace a damaged or missing bracket to restore alignment and reduce movement or rattling during use.

• Provides mounting support for specific under-top components, per model design
• Helps maintain proper alignment and stability of cooktop parts
• Replace when visibly bent, cracked, or corroded

• Disconnect power; for gas models, also shut off gas and allow the unit to cool
• Remove surface components as required (grates/caps/heads for gas; elements/panels for electric) to access under the top
• Lift or remove the cooktop as directed in your model's service information and secure the new bracket with existing hardware
• Reassemble, verify alignment, and for gas units check for leaks if any gas connections were disturbed

This metal bracket mounts beneath a cooktop surface burner and holds the orifice and burner base in position. It ensures proper alignment of the burner assembly for safe and efficient gas flow. Replace this bracket if it is bent, corroded, or broken, which can cause the burner to sit unevenly or not ignite properly.

Secures the cooktop surface to the range chassis for stable alignment. Replace if bracket is bent, broken, or missing to eliminate looseness and gaps.

Manifold pipe for gas ranges. Distributes gas from the valve to the burners. Replace if cracked, damaged, or leaking. Direct fit component.

Protective cover that slips over the gas valve shaft to shield valve components from spills, food debris, and moisture. Replace if cracked or missing.

Orifice holder that mounts under the cooktop to route gas to the rear burner. Replace if cracked, damaged, or when converting between natural gas and LP.

Sits under the cooktop and channels gas from the valve to the front burner head. Replace if cracked, kinked, bent, or broken from lifting the cooktop.

Holds the gas orifice in place at the front burner on gas ranges. Replace if cracked, broken, or kinked from repeated lifting of the cooktop.

Delivers gas from the main supply line to the left rear burner on your gas range or cooktop. Located beneath the cooktop surface, connecting the gas valve to the burner assembly. Replace when the burner won't light, has uneven flames, or you smell gas near that burner.

Fix an oven that won't heat, takes too long to preheat, or makes a whoosh sound when lighting. This bake burner assembly includes the igniter. DIY repair.

Delivers gas from the manifold to your range's surface burner. Replace this tube if it's cracked, leaking, corroded, or damaged to restore safe gas flow.

Secures the igniter to the burner assembly in gas ranges and ovens. Replace if stripped, missing, or damaged during igniter replacement or repair.

Protective shield that covers the oven igniter. Replace if cracked, broken, or missing to shield the igniter from spills, drips, and falling debris.

LP gas burner orifice spud for gas ranges and cooktops. Needed when converting fuel type or replacing a cracked, missing, or incorrect size orifice spud.

Burner orifice spud for gas ranges. Controls gas flow to each burner. Replace if cracked, clogged, or when converting between LP and natural gas.

Burner orifice spud regulates gas flow to the burner on your range or cooktop. Replace if missing, damaged, or when converting between LP and natural gas.

This 270° burner valve controls gas flow to a single cooktop or range burner, restoring predictable flame adjustment and reliable ignition so you can cook safely and accurately. What it does:

• Regulates gas flow to the burner so flame height responds to the control knob
• Enables proper ignition and consistent flame during use
• Common symptoms indicating a faulty valve: burner won't light, flame stays too low or high, or burner only lights intermittently
• Stops gas flow when set to off to help prevent unintended flow

• One 270° burner valve

• Turn off gas supply and power to the appliance before replacing the valve
• Use appropriate wrenching tools and avoid torqueing valve fittings; follow OEM torque guidance if available
• After installation, check all connections for leaks (soap-and-water test) and verify correct burner operation

Fix a burner that won't turn off, has weak flame, or a stiff control knob. This gas valve controls flow to one cooktop burner. Moderate DIY repair.

Burner won't ignite, flame won't adjust, or gas leaks? This top burner valve controls gas flow to your range's surface burners. Moderate DIY repair.

Panel mounting screw secures trim, bezels, and internal components on ranges and cooktops. Replace when stripped, corroded, or missing to restore fit.

Replaces a cracked or faulty gas valve control assembly on your range. Installs on the manifold to regulate gas flow to burners and oven. Direct fit.

The Oven Igniter is an OEM replacement part for GE ovens, designed to ignite the bake igniter to start the heating process. This part is responsible for creating the spark that ignites the gas, providing the heat needed to cook and bake food. Over time, the oven igniter can wear out or become damaged, which can prevent the oven from heating.

Symptoms of a bad Oven Igniter include:

• The oven not heating up at all.
• The oven taking longer than normal to heat.
• Gas smell in the oven due to gas being released without ignition.
• A clicking sound without the oven igniting.

Causes of a bad igniter can include normal wear and tear over time, exposure to excessive heat or moisture, or physical damage from impact or mishandling.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

IMPORTANT: The connector plug may need to be cut off and igniter wires connected to range wires using porcelain wire connectors.

The Oven Igniter is an OEM replacement part for GE ovens, designed to ignite the bake igniter to start the heating process. This part is responsible for creating the spark that ignites the gas, providing the heat needed to cook and bake food. Over time, the oven igniter can wear out or become damaged, which can prevent the oven from heating.

Symptoms of a bad Oven Igniter include:

• The oven not heating up at all.
• The oven taking longer than normal to heat.
• Gas smell in the oven due to gas being released without ignition.
• A clicking sound without the oven igniting.

Causes of a bad igniter can include normal wear and tear over time, exposure to excessive heat or moisture, or physical damage from impact or mishandling.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

IMPORTANT: The connector plug may need to be cut off and igniter wires connected to range wires using porcelain wire connectors.

Manifold supply tube for gas ranges. Delivers gas from the main supply line to the burner manifold. Replace if cracked, damaged, or leaking.

Burner deflector guard for gas ranges. Installs around burner assembly to direct heat and protect components. Replace if cracked, warped, or missing.

This broil shield is a replacement oven part that protects the oven interior from direct broiler heat and splatter, helping prevent damage to the oven cavity and nearby components. It's a direct-fit shield used behind the broil element. What it does:

• Deflects direct broiler heat away from the oven back panel and insulation
• Protects the oven cavity from grease and food splatter during broiling
• Helps prevent warping or damage to interior panels caused by concentrated heat
• Replace when the shield is warped, dented, corroded, or missing to restore proper protection

• One broil shield (one piece as shown)

• Ensure the oven is completely cool and power (and gas, if applicable) is disconnected before starting
• Handle carefully — edges may be sharp; use gloves to protect hands
• Verify correct orientation and secure mounting hardware during installation

This terminal cover protects the oven/range power connection by covering the appliance's rear terminal block, helping prevent accidental contact and keeping wiring secure. It's a direct-replacement exterior cover for the unit's power terminals. What it does:

• Covers the appliance's electrical terminal block to help protect wiring and connectors from damage
• Reduces risk of accidental contact with live terminals when the access panel is opened
• Keeps the terminal area tidier and helps prevent debris buildup around connections
• Commonly replaced when the original cover is cracked, broken, or missing

• One terminal cover

• High-level replacement: remove rear access panel to access the terminal block, then replace the cover and secure with existing screws
• Always disconnect power (unplug or switch off the breaker) before servicing electrical components
• No special tools required beyond a screwdriver; follow OEM instructions if available

Secures and routes wiring in your range. Replace if loose, broken, or wiring is exposed. Verify fit with your model number before ordering.

Secures the thermostat assembly to your gas range or oven frame. Replace this mounting screw if it's stripped, missing, or damaged during repairs.

Gas range burner won't ignite or flame is uneven? This round valve controls gas flow to your burners. A common fix for temperature control issues.
