Parts for Ge PFE28RSHCSS: Machine Compartment Parts

This SCR (silicon controlled rectifier) controls high-current switching in the appliance's power circuit to enable reliable on/off control of heating or motor circuits. Designed for direct replacement of the original SCR component. What it does:

• Acts as a solid-state switch to control power to heating elements or motors when triggered by the appliance control board.
• Helps regulate current during start-up and run cycles to maintain proper operation of the appliance.
• Failures can cause symptoms such as no heat, intermittent operation, or the appliance not powering its load.
• Matches the OEM mounting and stud terminal configuration for proper electrical connection.

• One SCR component (8-32 stud) as pictured.

• Disconnect power to the appliance before servicing to avoid shock or damage.
• Use proper tools for the 8-32 stud terminals and ensure secure electrical and heatsink connections.
• Inspect mounting surfaces and replace any damaged hardware or thermal pads as needed for safe operation.

This compressor mounting stud secures the compressor to the refrigerator chassis, keeping the unit stable and reducing vibration and noise. It's a durable replacement part for worn, bent, or missing compressor mounting hardware. What it does:

• Provides a secure attachment point between the compressor and cabinet/frame
• Helps reduce compressor vibration and operational noise when correctly installed
• Prevents compressor movement that can stress refrigerant lines or electrical connections
• Commonly replaced when the original stud is corroded, damaged, or missing

• Disconnect power to the appliance before beginning any repair.
• Support the compressor while removing/installing mounting hardware to avoid strain on lines and fittings.
• Replace any associated nuts, washers, or insulators if worn or damaged; use correct hardware orientation.

This is a replacement screw used to secure appliance components and panels so parts stay properly attached for safe operation. It's a direct-fit fastener matching OEM form and function. What it does

• Secures panels, trim, or internal components to prevent rattling or gaps
• Restores factory attachment where a screw is missing or stripped
• Helps maintain proper alignment of housing and service access
• Suitable when repair requires original-fit fasteners

• Disconnect power or unplug the appliance before servicing to avoid shock
• Use the matching screwdriver or bit to avoid stripping the head
• Thread carefully and avoid overtightening to prevent damage to threads or plastic parts
• Keep removed screws organized; replace only the screws that match the original locations

The Main Control Board (Reflashed) is an OEM replacement part for GE refrigerators. This board serves as the central hub for managing key refrigerator functions, including temperature regulation, defrost cycles, and operation of fans and compressors. The "reflashed" designation indicates that the board is pre-programmed with the latest firmware specific to your appliance model, ensuring optimal performance.

Over time, control boards can fail due to power surges, electrical component wear, or environmental factors such as moisture. A faulty board can disrupt the refrigerator’s functionality, leading to inefficient cooling and other operational issues.

Symptoms of a bad main control board include:

• Inconsistent or incorrect temperatures in the refrigerator or freezer
• Unresponsive controls or display malfunctions
• The refrigerator not cooling, or cycling excessively
• Error codes or unusual noises during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This condenser support is the replacement mounting bracket that holds the refrigerator condenser or condenser coil securely in place, helping maintain proper clearance and airflow for reliable cooling performance. What it does:

• Secures the condenser or condenser coil to the cabinet to prevent movement or vibration
• Maintains correct condenser positioning to support consistent airflow and heat dissipation
• Helps reduce rattling or noise caused by a loose condenser assembly
• Supports overall cooling reliability by keeping components aligned

• One condenser support bracket

• Installation requires basic hand tools; disconnect power before beginning any repair
• Handle sharp sheet-metal edges carefully to avoid cuts
• Reinstall any removed panels or fasteners to restore proper airflow paths

The Condenser Fan Motor Assembly is an OEM part for GE refrigerators. This part is responsible for circulating air through the refrigerator condenser coils and over the compressor. It plays a role in dissipating heat away from the refrigerator's cooling system, ensuring that the appliance operates efficiently and maintains the set temperatures to keep your food fresh and safe.

Causes of a bad condenser fan motor can include overheating due to blockages in the fan blades, wear and tear on the motor bearings, or electrical faults that prevent the motor from running.

Symptoms of a bad Condenser Fan Motor Assembly include:

• The refrigerator runs warmer than usual
• Unusual noises coming from the back of the refrigerator
• The fan motor does not run when the compressor is on
• Increased energy bills due to the refrigerator working harder to maintain temperature

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This variable speed compressor kit restores efficient, quieter cooling by replacing a failed variable-speed compressor assembly. Designed for compatible refrigerators, it helps re-establish proper temperature control and energy-efficient operation. What it does:

• Replaces the variable-speed compressor to restore compressor-driven cooling
• Allows the fridge to modulate speed for more consistent temperatures and reduced cycling
• Commonly used when the compressor fails, hums loudly, or the unit no longer cools reliably
• Helps address symptoms such as warm compartments, frequent on/off cycling, or abnormal compressor noise

• Disconnect power before starting any repair to avoid electrical shock
• Seal system components and refrigerant are involved; refrigeration system work should be performed by a licensed HVAC/R technician
• Handle the compressor and mounting hardware carefully to avoid damage to lines or electronic controls
• Verify system charge and leak-free operation after installation

This valve body assembly routes and supports the refrigerator's water flow for the dispenser and ice maker. Replacing a cracked or leaking body restores proper water delivery and helps prevent leaks at the rear of the unit.

• Directs incoming water to the dispenser and/or ice maker
• Maintains sealed connections for water lines and valve components
• Helps resolve leaks around the rear valve area
• Symptoms can include no/slow dispenser flow or an ice maker not filling

• Unplug the refrigerator and shut off the household water supply
• Relieve line pressure; place a towel or container to catch residual water
• Note tubing and wire positions; transfer to the new assembly and ensure every connection is fully seated
• Restore water and power, then check all joints for leaks while dispensing and during an ice maker fill

This valve body assembly routes and supports the refrigerator's water flow for the dispenser and ice maker. Replacing a cracked or leaking body restores proper water delivery and helps prevent leaks at the rear of the unit.

• Directs incoming water to the dispenser and/or ice maker
• Maintains sealed connections for water lines and valve components
• Helps resolve leaks around the rear valve area
• Symptoms can include no/slow dispenser flow or an ice maker not filling

• Unplug the refrigerator and shut off the household water supply
• Relieve line pressure; place a towel or container to catch residual water
• Note tubing and wire positions; transfer to the new assembly and ensure every connection is fully seated
• Restore water and power, then check all joints for leaks while dispensing and during an ice maker fill

This replacement power cord provides the appliance's main AC connection so it can receive power and operate reliably. It restores a safe, factory-style power connection when the original cord is damaged or worn. What it does

• Supplies mains power to the appliance through the cabinet connection
• Replaces frayed, cut, melted, or damaged cords that cause intermittent power or no power
• Helps eliminate burning smells, arcing, or visible insulation damage at the cord
• Matches OEM electrical connection style for proper fit and secure contact

• One power cord assembly

• Disconnect power at the breaker or unplug the appliance before inspecting or replacing the cord
• Verify cord routing and strain relief position to prevent pinch points or abrasion
• Use proper tools and fasteners; tighten connections securely but do not overtighten

This refrigerator drain tube and valve assembly channels defrost water to the drain pan, while the valve helps block warm air from entering the drain. Replace a cracked or clogged assembly to address leaks and recurring ice buildup. What it does:

• Routes defrost water from the evaporator to the drain pan beneath the unit
• Integrated valve helps prevent warm air backflow that can lead to frost and drain clogs
• A damaged or obstructed tube/valve may cause water inside the compartments or on the floor
• Visual cracks, deformation, or blockage indicate the assembly should be replaced

• One drain tube and valve assembly

• Disconnect power and wear cut-resistant gloves before servicing
• Pull the refrigerator forward and remove the rear lower access panel
• Locate the drain outlet above the drain pan; remove the old tube/valve and clear any debris from the drain
• Seat the new assembly fully and ensure proper routing into the drain pan before restoring power

This screw fastens appliance panels, brackets, and trim so parts stay secure and aligned. Replace a missing, stripped, or rusty screw to stop rattles and restore a tight, factory fit.

• Secures covers, brackets, and trim to the appliance cabinet or liner
• Replaces missing, stripped, or corroded hardware
• Helps reduce vibration noise and loose or misaligned parts
• Maintains proper fit of guards, kickplates, or internal panels

• Disconnect power; turn off water supply if working near water lines
• Match to the original fastener to size and thread
• Start threads by hand to avoid cross-threading; tighten snugly, not excessively
• If threading into plastic, avoid overtightening to prevent damage
