Parts for Ge JTP27WV1WW: 02 - Upper Body Parts

This lower oven body panel forms the bottom interior of the oven cavity, restoring structural support and protecting internal components from heat and debris. Replace a damaged or warped lower body to maintain safe operation and interior fit. What it does

• Supports the oven floor and provides a secure mounting surface for the lower heating element and related hardware
• Shields wiring and components beneath the cavity from heat, spills and debris
• Helps maintain correct internal airflow and heat containment for consistent cooking
• Addresses visible damage, warping, holes or loose bottom panels that can cause rattling or allow debris into lower areas

• One lower oven body panel

• Disconnect electrical power to the appliance before beginning any repair
• Remove oven racks and heating element access panels as needed; keep or reuse original fasteners unless replacement hardware is specified
• Handle edges carefully — sheet metal can be sharp

Replace your oven's fan housing screen filter to maintain proper ventilation and airflow. Install when screen shows damage or blockage. Verify fit with model.

Insulation panel that installs on the back and bottom of your oven cavity. Replace if damaged, torn, compressed, or missing to maintain heat efficiency.

Insulation panel that installs on top of the oven cavity. Replace if damaged, torn, compressed, missing, or contaminated by pests or moisture.

Insulation panel that installs on the back and bottom of your oven cavity. Replace if damaged, torn, compressed, or missing to maintain heat efficiency.

Replacement oven rack for electric and gas ranges. Installs inside oven cavity. Needed when original rack is missing, damaged, or warped from use.

Slotted grid that rests over the broiler pan to support food during broiling. Replace if cracked, warped, worn, or missing to restore proper function.

Oven not heating or baking unevenly? A faulty bake element is often the cause. This bottom heating element is a straightforward DIY fix in 5-10 minutes.

Broiler won't heat up? This upper heating element restores high-heat broiling and surface browning. Takes about 15 minutes to replace with basic tools.

If your oven won't preheat or shows an F3 error code, this temperature sensor monitors oven heat and safety features. Direct plug replacement, 15-minute fix.

NOTICE: Part has been redesigned. Wire terminals are no longer straight off the the back they are from the side. Depending on your model you may have to make changes to make it fit.

This high-amp SPDT switch routes power between circuits in cooking appliances to control items such as locks, element relays, or fans. Replacing a worn switch restores dependable operation and helps eliminate intermittent on/off issues. What it does:

• Single-pole, double-throw action directs power between NO/NC circuits based on actuator position
• Used to signal or control a component per the model's design (e.g., latch/lock, relay, fan)
• Failure symptoms can include no activation, stuck-on/off behavior, intermittent operation, or heat-damaged terminals
• Electrical tests may show incorrect continuity between COM–NO/NC when pressed or released

• Includes: 1 SPDT high-amp switch

• Disconnect power at the breaker or unplug the appliance before servicing
• Label or photograph wiring; move leads to matching COM/NO/NC terminals on the new switch
• Mount with the correct actuator orientation and secure any bracket or screws
• Inspect connectors for heat damage; ensure tight spade fits, restore power, and test operation

Base rail that guides and supports oven racks for smooth sliding. Replace this structural component if cracked, bent, or worn to restore proper rack movement.

Left side hinge assembly for oven doors. Replaces broken, cracked, or worn hinges that prevent proper door opening and closing. Direct fit component.

This panel conceals and protects internal freezer components while providing a finished interior appearance. Located inside the freezer compartment, replace it when cracked, warped, or allowing moisture and cold air to reach sensitive mechanical parts.

This metal bracket provides structural support for range components like burner assemblies or control panels. It securely holds parts in their proper position during normal cooking operations. Replace when range components become loose, sag, or don't align properly.

Replacement mounting screw for securing panels, trim, and internal brackets. Needed when original fasteners are missing, stripped, or damaged.

Replacement mounting screw for securing panels, brackets, and trim on electric ranges and wall ovens. Needed when original fastener is stripped or missing.

Replacement screw for securing panels, brackets, and internal components in ranges, ovens, and cooktops. Replace missing, stripped, or damaged screws.

Replacement screw for securing panels, brackets, and internal components. Needed when original hardware is stripped, missing, or damaged during repairs.

Black. 8-18 AB HXW 3/8

Replace your missing, worn, or damaged range washer. This small metal component secures parts and assemblies throughout your oven, ensuring proper fit.
