Parts for Maytag MGR6775BDW: 05 - Gas Controls Parts

5K. Mueller

9K. Mueller.

A set of four valve mounting screws used to secure the water/ice valve or valve bracket in place. These OEM-style screws restore proper valve alignment and fasten valve assemblies for reliable operation. What it does:

• Secures the valve or valve bracket to the appliance chassis to prevent movement during operation
• Helps maintain a tight seal at valve mounting points to reduce risk of leaks
• Replaces missing, stripped, or corroded valve mounting fasteners
• Restores stable valve positioning that can prevent rattling or vibration

• Disconnect power and shut off the water supply before beginning any work
• Use the correct screwdriver or bit to avoid stripping the screw heads
• Thread screws in by hand first, then tighten snugly—do not overtighten to avoid damaging the valve or mounting threads
• If existing threads are damaged, inspect the mounting boss and replace as needed

Burner head sits on the base and distributes gas through precision ports for even flame. Replace if cracked, clogged, or corroded for proper ignition.

Auxiliary burner head for gas ranges and cooktops. Mounts over the orifice to distribute gas through precision ports. Replace if clogged or damaged.

Burner head for gas ranges and cooktops. Distributes gas evenly to create a proper flame. Replace if cracked, damaged, or clogged with buildup.

This burner head mounts on the cooktop and distributes gas evenly to produce a steady flame. Replacing a worn or damaged head restores proper flame pattern and helps your burner light quickly and cook consistently.

• Directs gas through precisely sized ports to create an even flame
• Can resolve issues like uneven flames, yellow/orange flames, or delayed ignition
• Helps when the burner won't light or only lights partially
• Replaces a corroded, clogged, or warped burner head

• Disconnect power and shut off gas supply before servicing
• Allow the cooktop to cool completely
• Lift off the grate and cap; remove the old head and align the new head on the burner base
• Ensure ports are clean and seated correctly; test for proper ignition and flame

Large gray burner cap covers the burner head on your cooktop. Replace if cracked, chipped, or discolored to restore appearance and proper flame shape.

Uneven flames or discolored burner? This medium gray burner cap restores proper flame shape and protects the burner head from spills and debris.

Medium gray burner cap for gas cooktops and ranges. Replaces cracked, chipped, or missing caps that sit atop the burner base during cooking.

Fix a burner that won't light, won't adjust heat properly, or stays on constantly with this range top burner valve. Moderate DIY repair in 30-45 minutes.

Gas burner won't ignite or spark? This surface burner spark electrode generates the spark to light your cooktop burner. Moderate DIY repair.

Secures the center burner orifice on gas ranges for proper alignment and consistent flame. Replace if worn or damaged to restore burner performance.

The Orifice Holder is an OEM part for Whirlpool gas ranges. It includes the spark electrode and the 9.2k orifice, which are essential components for proper ignition and gas flow in the burner assembly.

Causes of a faulty orifice holder can include wear and tear over time, damage from corrosion or debris, or improper adjustment.

Symptoms of a bad orifice holder may include:

• Weak or no ignition spark
• An uneven or weak flame
• Difficulty in adjusting the burner flame
• Gas odor or leakage

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

Fixes weak flame or ignition failure on 12K burners. This orifice holder restores proper gas flow when clogged or damaged. Moderate DIY repair.

Burner won't ignite or flame is weak? This orifice holder aligns the burner orifice and electrode for reliable ignition. Moderate DIY, 30-60 minutes.

This is a small seal that fits around the surface burner control switch on a range, preventing moisture and debris from entering the switch housing. It helps protect the electrical switch components behind the control panel. Replace this seal if it is cracked, deteriorated, or missing, which can allow spills or cleaning liquids to reach the switch and cause erratic burner operation or short circuits.

Burner won't spark or click when turned to Lite? This igniter switch mounts on the gas valve to signal the spark module. DIY fix in under 30 minutes.

Burner won't spark or ignite? This surface burner ignition switch triggers the spark module when you turn the knob. 45-minute DIY repair for ranges.

Gas supply tube that connects the main gas line to the top burners on your range. Replace if cracked, damaged, or leaking to restore safe gas flow.

Burner won't ignite or has weak flame? This right-side top burner tubing restores proper gas flow to your range burner. Simple repair, 2-pack included.

Fix continuous clicking or no-ignite issues on gas range burners. This spark module controls ignition timing and generates sparks to light surface burners.

Broiler won't light or takes too long to ignite? This range broil burner igniter provides the spark to light your oven's broil flame. DIY install.

Fastening screw for securing components inside appliances. Replaces lost, stripped, or damaged screws during repairs or part installations.

The Oven Igniter is an OEM part for Whirlpool ovens. It is responsible for igniting the gas to start the oven heating process. This igniter is crucial for ensuring that the oven reaches and maintains the desired temperature for baking and cooking.

Over time, the igniter can suffer from wear and tear, leading to inefficient ignition or complete failure. Causes of a bad igniter can include repeated heating cycles, electrical issues, or physical damage to the igniter element.

Symptoms of a bad igniter include:

• The oven not heating up or taking too long to preheat
• A noticeable gas smell due to incomplete ignition
•  The igniter glowing without igniting the gas

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Secures the gas orifice to the burner valve assembly on gas ranges. Replace if worn, stripped, or damaged to restore proper orifice positioning.

Secures the gas orifice to the burner valve assembly on gas ranges. Replace if worn, stripped, or damaged to restore proper orifice positioning.

Fix uneven baking or no heat in your range oven with this bake burner tube and orifice assembly. Common repair for gas ranges with heating issues.

Metal grounding screw for electric ranges and ovens. Secures electrical grounding connections. Replace if stripped, corroded, or missing.

Hand-tighten wing nut secures panels, brackets, and components in ranges and ovens for tool-free adjustment. Replace when lost, stripped, or broken.

Hand-tighten wing nut secures panels, brackets, and components in ranges and ovens for tool-free adjustment. Replace when lost, stripped, or broken.

Wire harness for range triple valve assembly. Connects power to gas valves. Replace if wires are frayed, connectors damaged, or harness is missing.

If your oven igniter glows but the oven won't heat, the bake and broil valve likely isn't opening to allow gas flow. Moderate DIY repair in 30-45 minutes.

Replacement mounting screw for securing handles, panels, and internal components. Needed when original screws are stripped, lost, or broken during repairs.
