Parts for Kenmore 796.71522210 (79671522210, 796 71522210): Drum And Motor Assembly Parts

This washer tub assembly is the stationary outer tub that surrounds the spin basket and contains the wash water. Replacing a cracked or damaged tub helps stop leaks and restores proper clearance for smooth, quiet washing and spinning.

• Creates a watertight chamber around the basket to hold wash and rinse water
• Maintains proper basket clearance; damage can cause rubbing or scraping sounds
• Provides connection points for hoses and water-level components
• Common signs it may be needed: leaks from the tub area, visible cracks or warping, persistent out-of-balance/spin errors, or internal scraping/grinding noises

• Disconnect power and water; shut off supplies and safely drain remaining water
• This is a major repair—allow time and consider a second person to help lift/support the tub
• Transfer model-specific parts from the original tub to the new tub as needed; reinstall all clamps, bolts, and sensors securely
• After reassembly, level the washer, and run a test cycle to check for leaks

This is the gas valve assembly that controls the flow of gas to the burner in a gas dryer. It includes the solenoid coils and valve body that open and close to regulate gas delivery for heating. Replace this assembly if your gas dryer runs but produces no heat, heats intermittently, or if the gas igniter glows but the gas never ignites.

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

The Belt is an OEM replacement part for LG dryers that is responsible for connecting the motor to the drum to allow it to tumble. Over time, dryer belts can stretch, wear out, or even break, leading to a drum that won't turn and clothes that don't dry properly.

Symptoms of a bad Dryer Belt include:

• The dryer motor running but the drum not turning.
• A squealing or thumping noise coming from the dryer.
• The dryer not starting at all.

Causes of failure can include regular wear and tear from the dryer's operation, overloading the dryer beyond its capacity, which puts extra strain on the belt, or a misalignment that causes uneven wear. A damaged belt can prevent your dryer from functioning correctly, leading to inefficiency in drying clothes and potential motor damage due to unnecessary strain.

This OEM LG part can also be used on Kenmore/Sears appliances.

Replace your dryer drum seal when clothes take longer to dry or you notice lint buildup. Maintains heat efficiency and prevents air leaks. Confirm fit with your model number.

Base bracket for dryers. Mounts to the bottom of the cabinet to secure the base assembly. Replace if bracket is cracked, bent, or missing hardware.

This Pipe Assembly routes water into the appliance so the dispenser and ice maker can receive a steady supply. Replacing a damaged tube restores proper water flow and helps stop leaks or pooling inside or beneath the unit. What it does:

• Carries incoming water from the household supply to the appliance's internal water system
• Restores water delivery to the dispenser and ice maker when the original tube is cracked or blocked
• Prevents leaks and water damage caused by split, corroded, or pinched tubing
• Helps eliminate intermittent flow or weak dispenser output caused by a damaged water line

• One complete pipe assembly as shown

• Shut off the refrigerator's water supply and unplug the appliance before beginning
• Handle tubing fittings carefully; use proper tools to avoid damage or overtightening
• Inspect connection points and replace seals or clips if worn; test for leaks after reinstalling

Dryer won't heat or takes too long to dry? A faulty igniter often causes no heat in gas dryers. Moderate DIY repair with front panel removal required.

For propane order 383EEL3002A.

Converting your dryer from natural gas to propane? This LP conversion kit includes the orifice and components needed. Moderate difficulty repair.

Pipe connector for dryers and laundry centers. Replaces broken, cracked, or missing mechanical pipe connectors. Essential for secure pipe assembly.

This is a small O-ring gasket that creates an airtight seal at the gas supply pipe connection on a gas dryer. It prevents gas from leaking at the fitting where the supply line connects to the dryer's gas valve. Replace this seal if you detect a gas smell near the connection point or if the fitting fails a leak test.

This is the gas tube assembly that connects the gas valve to the burner assembly inside the dryer. It channels gas from the manifold to the burner where it is ignited to produce heat for drying. Replace this tube if you detect a gas smell near the dryer, notice visible damage or corrosion on the tube, or if the dryer fails to heat properly.

Internal exhaust duct assembly that channels hot air between dryer components. Replace if cracked, rusted, burned, or causing stains on clothing.

This sub tub assembly replaces the inner drum housing that supports the wash basket and channels water during cycles. It restores proper drum support and helps stop rubbing, banging, or abnormal noise during operation. What it does:

• Houses and supports the wash basket so laundry tumbles correctly
• Directs wash and rinse water within the washer cabinet
• Prevents metal-to-metal contact that can cause noise or fabric damage
• Helps maintain proper drum alignment and smooth rotation

• Disconnect power and water supply before starting work
• This is a heavy, bulky component — have a helper or use lifting aids
• Inspect and replace any associated seals, gaskets, or bearings as needed

Dryer not heating or overheating? The high limit thermostat shuts off heat at unsafe temperatures. Moderate difficulty repair requiring partial disassembly.

Dryer drum light not working or bulb melted in socket? This interior light socket assembly restores illumination. Simple push-in installation.

This is a translucent plastic lens that covers the drum light inside the dryer. It protects the light bulb from heat, lint, and tumbling clothes while allowing light to illuminate the drum interior. Replace this cover if it is cracked, yellowed, melted, or missing, which can leave the bulb exposed to damage.

Dryer not heating or overheating? The high limit thermostat shuts off heat at unsafe temperatures. Moderate difficulty repair requiring partial disassembly.

Dryer duct assembly that connects the drum to the blower housing. Replace if cracked, damaged, or has torn foam seals around openings.

The Igniter Sensor is an OEM part for LG dryers. This sensor plays a critical role in the ignition process, ensuring that the gas ignites properly to produce the heat necessary for drying clothes efficiently. It helps monitor and regulate the ignition temperature.

Over time, the igniter sensor can become faulty due to regular use, exposure to high temperatures, or electrical issues. These factors can lead to a malfunction, resulting in the dryer not heating properly or failing to start.

Symptoms of a bad igniter sensor include:

• Dryer not heating up
• Long drying times
• Dryer not starting
• Unusual smells or noises during operation

This OEM LG part is also compatible with Sears/Kenmore.

Mounting bracket that secures internal dryer components. Replace if cracked, broken, or missing to restore proper alignment and stability of assemblies.

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

Dryer lint filter screen traps lint and debris during drying cycles. Replace if cracked, damaged, or lost to maintain airflow and efficiency.

Note: Does not include moisture sensor bars. For the moisture sensor bars, order 2 of part# 6500EL3001A.

The Guide Cover is an OEM part for LG dryers. The part allows dust and debris to exit the dryer drum while preventing small clothing items from slipping through.

Causes of a bad Guide Cover can include accumulation of lint and debris that can restrict airflow, physical damage from handling or excessive use, and general wear that can compromise the fit and effectiveness of the cover.

Symptoms of a bad Guide Cover include:

• Increased drying times due to poor airflow.
• Unusual noises from lint hitting the fan or other components.
• Overheating of the dryer.
• Visible damage or misalignment of the cover that affects performance.

This OEM LG part is also compatible with Sears/Kenmore.

Guides and secures the lint filter in place within your dryer. Replace if cracked, broken, or missing to properly hold the lint screen assembly.

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

Dryer won't auto dry or cycles run too long? This moisture sensor wire harness connects sensor bars to control. Restores accurate dry cycles. DIY-friendly.

This is a mounting holder or grille that secures the moisture sensor bars inside the dryer drum area. The moisture sensor detects how wet the clothes are and signals the control board to end the cycle when they're dry. Replace this holder if it is cracked, broken, or missing, which can cause the sensor bars to be misaligned and lead to clothes coming out still damp or the dryer running too long.

Directs steam spray into the dryer drum during Steam/Refresh cycles. Replace if nozzle is clogged, cracked, or leaking to restore proper mist distribution.

Fix loud banging, grinding noise, or poor drying performance with a new dryer blower wheel. Restores proper airflow through drum and exhaust vent.

This is a fastener and retainer assembly that secures the blower wheel to the motor shaft inside a dryer. It keeps the blower wheel firmly in place so it can properly circulate hot air through the drum and out the exhaust vent. Replace this assembly if the blower wheel wobbles, makes rattling or squealing noises, or if the retainer nut is stripped or broken, causing poor airflow and longer drying times.

Blower housing assembly for dryer that channels heated air from the drum to the exhaust. Replaces a cracked or damaged housing to restore proper airflow and help the dryer dry more efficiently and quietly. What it does:

• Channels heated air from the drum to the exhaust and supports the blower wheel.
• Restores airflow when a damaged or cracked housing is restricting ventilation.
• Commonly used to address reduced drying performance and longer dry times.
• Can also resolve unusual rattling or grinding noises coming from the lower front of the dryer.

• Disconnect power (and gas, if applicable) before beginning work; wear eye protection and gloves.
• Remove access panels and disconnect vent/ducting per your model's service instructions to reach the blower housing.
• Inspect the blower wheel and surrounding seals/gaskets while the housing is out; replace damaged components as needed.
• Reassemble all panels and venting securely and test the dryer for proper airflow and operation after installation.

Duct assembly channels air from dryer drum to blower and exhaust. Replace if cracked, warped, or missing to restore proper airflow and prevent lint bypass.

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

Metal mounting bracket that secures internal dryer components to the frame. Replace if cracked, bent, or broken to restore proper alignment and stability.

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

This micro switch is a compact, snap-action electrical switch that sends an on/off signal when a lever, latch, or paddle is moved. Replacing a worn switch restores reliable detection and control response for the affected function.

• Converts mechanical movement into an electrical open/close signal to the control
• Commonly used for lever/paddle actuators, latches, or interlock detection within the appliance
• Safe symptom clues: no response when actuated, intermittent operation, or a function stuck on/off
• Physical clues: weak or absent "click" when pressed, heat discoloration or damage at terminals

• Disconnect power before servicing; if the product is connected to a water line, close the supply valve
• Note wire positions and terminal labels (COM/NO/NC); transfer wires one at a time to matching terminals
• Match the actuator orientation and mounting position to the original for proper operation
• After installation, verify continuity with a multimeter and test function before reassembly

Maintains tension on your dryer's drum belt for smooth rotation. Replace if pulley wheel is cracked, shaft worn, or assembly moves excessively during operation.

Idler pulley maintains tension on the dryer belt. Replace if worn, cracked, or causing belt slippage. Installs between motor and drum support system.

This replacement screw secures appliance components in their proper position. Use it to restore a tight, rattle-free fit when the original fastener is missing, stripped, or corroded. What it does:

• Fastens brackets, panels, or trim to keep assemblies aligned and secure
• Helps prevent vibration, rattling, and gaps from loose hardware
• Restores proper attachment when a screw is lost, worn, or damaged
• Common symptoms: loose panel/handle, misalignment, rattling, or a missing screw

• Disconnect power; shut off water or gas before service
• Match location to the original; start threads by hand to avoid cross-threading
• Use the correct driver bit; do not overtighten (especially into plastic)
• If the original hole is stripped, repair threads before installing the new screw

Self-tapping screw secures panels, brackets, and components inside your appliance. Replace stripped, corroded, or missing screws to restore secure fit.
