Parts for Ge ZISP480DXBSS: 01 - Freezer Door Parts

The water filter is an OEM part for GE refrigerators. This filter removes or reduces various contaminants.

Features and Benefits:

• Easy DIY replacement, typically mounted inside the refrigerator at the back of the compartment.
• Removes or reduces various contaminants in your water and ice, including lead, cysts, asbestos, atrazine, , taste and odor, chlorine, sediment, turbidity, and more
• NSF/ANSI 42 and 53 standards
• 6 Month lifespan filter
• Carbon Block media
• Micron rating: 0.5-1 micron (Class I)

When to replace your filter:

• Bad taste or odor in water and ice
• Cloudy or discolored ice
• Reduced water flow or pressure
• Refrigerator replace filter indicator light is on

Note: If replacing the Culligan metal canister design filter for the first time, a special adapter, part number AP2615702 is needed, which is not included with this part. The compatible bypass cap is part number AP6891551.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This hardware pack provides the assorted fasteners needed to secure trim, panels, and small appliance components, helping replace missing or damaged screws and clips for a clean, stable fit. What it does

• Replaces lost or damaged screws, clips and small fasteners used on appliance trim and panels
• Helps stop rattling or loose panels by restoring proper fastening
• Secures small components during reassembly after maintenance or part replacement
• Useful when original mounting hardware is missing or corroded

• Disconnect power to the appliance before servicing to reduce shock risk
• Use the correct screwdriver or driver bit to avoid stripping fasteners
• Keep small parts away from children and pets; work on a covered surface to catch dropped pieces

The recess door retainer secures the dispenser's ice chute flapper in the refrigerator door. Replacing a cracked or missing retainer restores proper flapper pivot and sealing to help reduce frost buildup and air leaks around the dispenser.

• Holds the recess/ice door on its pivot within the dispenser assembly
• Helps the flapper close fully to seal the ice chute
• Restores smooth open/close action of the dispenser door
• Common symptoms: loose or fallen flapper, poor chute seal, frost or condensation in the dispenser area, and ice clumping near the chute

• Unplug the refrigerator before servicing the dispenser
• Carefully remove the dispenser bezel/control panel to access the ice chute door assembly
• Note spring orientation and retainer position; transfer components to the new retainer
• Verify flapper movement and seal before reassembly and restoring power

The Door Recess Spring is an OEM replacement part for GE side-by-side refrigerators. It sits within the icemaker door frame to control movement and allow smooth closing/opening of the access point.

Causes of a bad icemaker door recess spring include wear and tear of thin metal coils repeatedly compressing over many years of filling cycles. Exposure to humidity intrusions from melting ice accumulates oxidation shortening spring elasticity.

Symptoms of a bad icemaker door recess spring include:

• Difficulty opening and shutting the icemaker access door securely
• Excessive slamming noise caused by abrupt closing
• Sagging or improper alignment of the door against the frame
• Struggles retaining positioning of the transparent plastic doorway

This genuine GE replacement spring is compatible with Hotpoint, RCA and Kenmore models.

The Collar Kit is an OEM component for GE side-by-side refrigerators with an external ice dispenser. It surrounds the door dispensing area and creates a seamless aesthetic transition point. Effective dispensing relies on this collar kit.

Causes of failure can involve cracked or weakened mounting clips that no longer hold the collar securely, dried-out sealing materials failing to block air/temperature loss, or broken plastic pieces altering proper alignment.

Symptoms of a bad collar kit include:

- Dispensed ice having melted or softened exterior surfaces
- Excessive warm air leakage noticeable near the dispensing area doorway
- Potential for liquid spills due to improper sealing

Note: Color Black

Replacing with this genuine GE collar kit ensures optimized sealing around the ice dispensing portal for dependable storage. Compatible replacements include Hotpoint, RCA, and Kenmore branded dispenser fridge models seeking to restore integrity and functionality.


This replacement freezer bottom hinge bushing helps the freezer door pivot smoothly and maintain proper alignment, reducing rubbing and uneven wear for more reliable closing. What it does:

• Provides a smooth pivot surface for the freezer bottom hinge
• Restores proper door alignment to help ensure a tight seal
• Reduces hinge noise, sticking, and rubbing during door movement
• Helps prevent premature wear of the hinge and door components

• One freezer bottom hinge bushing

• Disconnect power to the appliance and empty or support the door before starting
• Support the door while removing hinge fasteners to prevent falling or injury
• Inspect the hinge and shaft for wear; replace the hinge assembly if damaged
• Do not overtighten fasteners; test door operation after installation

This gasket and label assembly is used on side-by-side refrigerators to restore a proper seal at the specified location and provide the matching identification decal. A tight seal helps keep cold air in, moisture out, and performance consistent.

• Creates an air-tight seal between mating refrigerator parts or panels
• Helps maintain stable temperatures and reduce frost/condensation
• Replace if the gasket is torn, deformed, brittle, or missing
• Helps address sweating around edges, warm spots, or longer run times

• Disconnect power before servicing; turn off water supply if working near water components
• Remove the old gasket/label and clean/dry the surfaces thoroughly
• Seat the gasket evenly without twists; ensure full contact all around
• Apply the label in the specified location per your model's documentation

This bin door assembly is the flip-up cover for a small door bin compartment on your refrigerator. Replacing a cracked or missing cover keeps items contained and restores convenient access and a clean, finished look. What it does:

• Covers the door bin compartment and flips up for easy access
• Helps keep items from falling out when the door opens and closes
• Restores proper function when the original cover is cracked, warped, or missing
• Typical symptoms include broken hinge tabs, a cover that won't stay closed, or a loose/misaligned lid

• Includes 1 bin door assembly

• Remove items from the affected bin
• Release the old cover from the hinge tabs or pins and lift it off
• Align the new cover's tabs with the bin hinges and press/snap into place
• Do not force parts; verify smooth open/close after installation

The Dispenser Housing Shield is an OEM part for GE refrigerators. This component plays a crucial role in protecting the internal mechanisms of the water and ice dispenser from damage and contamination. It ensures that the dispenser operates efficiently and maintains hygiene standards by shielding the delicate internal parts from debris and moisture.

Causes of a bad dispenser housing shield can include wear and tear over time, physical damage from excessive force or mishandling, or exposure to moisture that leads to material degradation. Regular inspection and maintenance can help in identifying issues before they affect the dispenser's functionality.

Symptoms of a bad dispenser housing shield include:

• Water or ice leakage from the dispenser area
• Visible cracks or damage to the shield
• Poor water or ice flow
• Contamination of dispensed water or ice

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Dispenser Lever is an OEM part for GE refrigerators. It is located on the front panel of the refrigerator and is responsible for activating the dispenser mechanism. When pressed, it engages the internal mechanisms to dispense ice or water into a glass or container.

Causes of a faulty dispenser lever can include regular wear and tear, physical damage, or misalignment. These factors can result in issues such as the lever not engaging or sticking, difficulty in dispensing ice or water, or improper alignment with the dispenser mechanisms.

Symptoms of a bad dispenser lever may include:

• Inability to dispense ice or water when the lever is pressed
• Sticking or jamming of the lever
• Misalignment with the dispenser mechanisms

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Dispenser Switch is an OEM replacement part for GE refrigerators. This switch is crucial for the functionality of the water and ice dispenser, as it activates the dispensing mechanism when the user presses the lever or button. The switch ensures that the refrigerator dispenses water or ice on demand, providing convenience and ease of use.

Over time, the dispenser switch can wear out or become damaged due to frequent use, exposure to moisture, or electrical issues. This can result in the switch failing to activate the dispenser properly, impacting the performance of the refrigerator's dispensing system.

Symptoms of a bad dispenser switch include:

• The water or ice dispenser not responding when the lever or button is pressed
• Intermittent or inconsistent dispensing of water or ice
• The dispenser working only occasionally or requiring excessive pressure to activate
• No audible click or feedback when pressing the dispenser lever or button

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Torsion Spring is an OEM part for GE refrigerators. It is essential for maintaining the proper tension and operation of the refrigerator door. This spring ensures the door closes smoothly and stays securely shut, preventing cold air from escaping and maintaining the appliance’s efficiency.

Causes of a bad torsion spring can include metal fatigue from regular use, corrosion from exposure to moisture, or damage due to excessive force or mishandling. Over time, these factors can weaken the spring, affecting the door’s performance.

Symptoms of a bad Torsion Spring include:

• Door not staying closed
• Difficulty in opening or closing the door
• Door feels loose or unbalanced
• Unusual noises when operating the door

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This light reflector directs and protects the appliance lamp, improving illumination and preventing direct bulb contact. It restores proper light focus so interior areas are evenly lit and bulbs remain securely positioned. What it does:

• Reflects and directs light from the lamp for better interior visibility
• Shields the bulb from contact with food or components
• Helps maintain consistent light output and coverage
• Commonly replaced when light appears dim, uneven, or the reflector is cracked or missing

• Disconnect power to the appliance before servicing to avoid electric shock
• Remove the bulb before installing the reflector; handle bulbs and reflector with care to avoid damage
• Use only compatible replacement parts and follow the appliance manufacturer's instructions

This refrigerator lamp socket holds an E12-base appliance bulb and provides the electrical connection for the light fixture. Replace it when the light won't turn on or flickers despite a known-good bulb and functioning door switch.

• Secures an E12 (candelabra) bulb and supplies power to it
• Works with the door/light switch to illuminate the compartment or dispenser area
• Typical failures include heat damage, cracking, or internal contact wear
• Symptoms: no light, intermittent flicker, or a bulb that won't seat firmly

• Disconnect power to the refrigerator before servicing
• Remove any lens/cover, note wire placement, and install the new socket in the original orientation
• Use an E12-base appliance bulb with the wattage specified on your model's rating label
• Restore power and verify operation with the door switch

The Dispenser Light is an OEM part for GE refrigerators. It illuminates the water and ice dispenser area, providing visibility when accessing these features in low-light conditions. This light enhances user convenience and helps to ensure accurate and spill-free operation.

Causes of a bad dispenser light can include burnout from regular use, electrical issues, or damage from moisture or impacts. A faulty light can compromise visibility and the overall functionality of the dispenser area.

Symptoms of a bad dispenser light include:

• The light not turning on when using the dispenser
• Flickering or dim illumination
• Complete failure of the light to activate
• Inconsistent or intermittent lighting

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Dispenser Door Recess Crank is an OEM part for GE refrigerators. This crank is a crucial component of the refrigerator's ice and water dispenser system, helping to operate the dispenser door by opening and closing it when activated. It ensures that ice or water is dispensed efficiently and prevents unwanted air from entering the freezer compartment.

You should replace the dispenser door recess crank if it becomes faulty or damaged. Causes of a bad crank can include wear and tear from frequent use, accidental damage, or mechanical failure. A malfunctioning crank can lead to issues with the dispenser door's operation.

Symptoms of a bad dispenser door recess crank include:

• The dispenser door not opening or closing properly
• Ice or water not dispensing correctly
• Unusual noises during the dispensing process
• The dispenser door staying open or not sealing properly

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Ice Dispenser Solenoid is an OEM replacement part for GE refrigerators. It is a crucial component that controls the flow of ice from the ice maker to the dispenser chute.

Symptoms of a bad ice dispenser solenoid include:

• Failure to dispense ice from the dispenser
• Ice getting stuck or jammed in the dispenser chute
• Continuous flow of ice even when the dispenser is not activated

Causes of a bad solenoid can include electrical malfunctions, physical obstructions preventing proper operation, or simply wear and tear over time.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Dispenser Drip Tray is an OEM part for GE refrigerators. It serves as a catchment area for any drips or spills that may occur during the dispensing process. It helps prevent water or ice from dripping onto the floor or making a mess on the front of the refrigerator. For white order WR17X11654.

Causes of a faulty or damaged dispenser drip tray can include regular use, accumulation of debris, or cracks. These factors can result in issues such as water or ice leaking onto the floor, an unsightly appearance, or difficulties in cleaning and maintenance.

Symptoms of a bad dispenser drip tray may include:

• Water or ice leaking from the dispenser area
• Cracks or damage to the drip tray
• Difficulty in removing and cleaning the drip tray

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

6 - 10 pl flp 1/2 s

This thumb screw secures removable panels and small appliance components, letting you hand-tighten connections without tools for quick access and maintenance. It's a simple replacement that restores proper fit and prevents rattles or loose parts. What it does:

• Replaces a worn or missing thumb screw used to fasten access panels or small assemblies
• Allows tool-free tightening and removal for maintenance or service
• Helps stop panel vibration, rattling, or intermittent contact caused by loose fasteners
• Fits standard 6-32 threaded holes and provides a short, secure grip

• One thumb screw (6-32 x 1/2 in)

• Unplug the appliance or turn off power at the breaker before working on it
• Thread by hand; do not force or cross-thread the screw
• Tighten until snug by hand—do not overtighten with tools to avoid damaging threads or components
• If the original screw used a captive or specialized washer, retain or replace that washer if present
