Parts for Whirlpool LER3622DZ2: 01 - Section Parts

This air duct assembly directs dryer exhaust airflow to the vent path, restoring proper air movement for efficient drying and safer operation. Replaces a damaged, cracked, or restricted duct to help reduce long dry times and airflow problems. What it does

• Channels heated air from the blower housing toward the exhaust vent.
• Restores proper airflow to reduce extended dry cycles and improve lint evacuation.
• Helps prevent overheating caused by a blocked or broken duct.
• Can reduce abnormal noises from air leaks or rattling duct sections.

• One air duct assembly.

• Disconnect power (and gas supply for gas models) before starting any repairs.
• Inspect adjoining seals and clamps; replace if worn to ensure a secure, leak-free fit.
• Wear gloves to protect hands from sharp edges and lint.

Replace worn, stripped, or missing 8-18 x 3/8 machine screws that secure control panels, trim pieces, and brackets on your appliance. Restores tight fit.

Dryer won't heat? This high limit thermostat cycles the heating element to maintain safe temperatures. A simple 5-10 minute fix with a multimeter test.

Dryer won't heat or start? A blown thermal fuse is often the cause. This safety component is a simple DIY fix taking about 5-10 minutes to replace.

Seals the lint screen housing to prevent air leaks and maintain proper airflow. Replace if damaged, missing, or causing lint buildup. Verify fit.

Dryer not heating or drying properly? A damaged blower wheel restricts airflow, preventing hot air circulation. Attaches to motor shaft with left-hand threads.

Dryer won't signal when cycle ends or buzzer stuck on? This adjustable buzzer kit restores audible alerts for timers and notifications. DIY install.

Fastener secures panels, brackets, and internal assemblies in washers, dryers, and refrigerators. Replace stripped, missing, or worn screws.

Fan scroll housing for dryers. Encloses and directs airflow from the blower fan. Replace if cracked, broken, or damaged to restore proper air circulation.

Front drum bulkhead for your dryer. This structural component supports the drum assembly. Replace if cracked, broken, or worn to restore proper drum support.

Secures components in place to prevent movement and reduce vibration during operation. Replace if damaged or missing to restore proper alignment and performance.

Dryer not heating or damaging clothes with rust marks? This heater housing supports the heating element and channels airflow. Moderate DIY repair.

Replacement screw for washers. Used to secure various components including handles, panels, and internal parts. Order if original is missing or stripped.

Secures the air duct to your dryer's blower housing. Replace if loose, cracked, or missing to prevent air leaks and maintain efficient drying. Verify fit.

Dryer not heating or shuts off after a few minutes? A faulty thermostat often causes temperature regulation failure. Easy DIY fix with a multimeter test.

Flat spacer washer that maintains proper spacing between dryer drum components. Replace when worn to reduce friction and prevent metal grinding noises.

Fix dryer electrical connection issues with this terminal. Used for wiring connections in heating and control circuits. Simple installation in minutes.

Dryer not heating or taking too long to dry? This heating element generates the hot air for drying cycles. DIY-friendly repair, typically 10-15 minutes.

Connects power to your dryer's heating element. Replace this wire if it's frayed, burned, corroded, or broken to restore the electrical connection.

Dryer won't power on or trips breaker? This terminal block plug connects power to your dryer's electrical system. Common fix for power issues.

Stack kit connector for dryers. Secures stacked washer-dryer units together. Replace if broken, cracked, or missing to ensure stable stacking.

Structural gusset bracket that secures the dryer cabinet to the bulkhead. Replace if cracked, bent, or damaged to restore proper cabinet alignment.

Fix washer shaking and excessive vibration during spin cycles. This leveling leg locking nut secures adjustable legs to stabilize your machine.

Front bulkhead for dryer drum assembly. Mounts between the drum and front panel. Replace if cracked, warped, or damaged to restore proper drum support.

Seals the gap between drum and bulkhead to maintain airflow and quiet operation. Replace when worn to eliminate squealing, reduce lint buildup, and prevent fabric snags. Confirm fit by model number.

Dryer drum baffle installs inside the drum to lift and tumble clothes evenly. Replace when cracked, broken, or missing to restore proper drum function.

Supports the front drum edge for smooth, quiet rotation. Replace when worn to stop scraping noises or drum wobble. Confirm fit with your model number.

Dryer won't start or stops mid-cycle with buzzing? A cracked motor connector housing causes intermittent power to the motor. Quick DIY repair fix.

Secures drum support rollers to their shafts in your dryer. Replace if broken, missing, or damaged during roller maintenance to keep drum wheels stable.

Rear drum support roller kit for dryers. Mounts behind the drum to maintain alignment and smooth rotation. Replace when rollers are worn or damaged.

Left-side shaft that supports the drum roller assembly in your dryer. Replace if worn, bent, or damaged to restore proper drum rotation and alignment.

Right-side shaft for dryer drum support roller. Replace if worn, bent, scored, or damaged to restore proper drum rotation. Installs on right side of cabinet.

Replacement mounting screw for securing components and housings in place. Order a new screw if yours is stripped, missing, or damaged during repairs.

Timer won't advance or dryer cycles incorrectly? This resistor regulates voltage to your dryer's timer motor. DIY-friendly repair, typically 15-30 minutes.

Traps lint and debris during drying to prevent vent clogs. Replace when torn, damaged, or no longer catching lint effectively. Verify fit with your model.

Traps lint and debris during drying to prevent vent clogs. Replace when torn, damaged, or no longer catching lint effectively. Verify fit with your model.

Mounts the washer top panel to the cabinet frame. Replace if screw is stripped, rusted, missing, or damaged during cabinet disassembly and repair work.

Distributes load under drum support fasteners to prevent hardware loosening. Replace if worn, cracked, or causing noise. Confirm fit with your model number.

Factory protective shield panel for dryer assembly. Guards internal components and directs heat or airflow. Replace if cracked, broken, or missing.

Touch-up paint. Color: Almond. Size: 1 qt. can. (Uncut)

White acrylic touch-up paint for appliances. Covers scratches, chips, and scuffs on refrigerators, washers, dryers, and ranges. 1-quart can restores finish.

Gray acrylic spray paint for coating worn or chipped dryer drum interiors. Restores the protective finish when the original coating is scratched or flaking.

Touch-up paint for appliances in almond color. Repairs chips, scratches, and worn spots on ovens, refrigerators, microwaves, and dryers.

Almond spray paint for appliance exteriors. Covers scratches, chips, and worn finishes on refrigerators, freezers, and other units. 13 oz can.

White acrylic spray paint for appliance exterior touch-ups. Restores worn, chipped, or scratched surfaces on refrigerators, ranges, and more. 13 oz can.

Touch-up paint for covering scratches, chips, and minor blemishes on appliance exteriors. Restores appearance and protects surfaces when finish is damaged.
