Maytag Dishwasher Parts

This fill and drain hose assembly connects a portable dishwasher to a sink, delivering fresh water in and routing wastewater out. Replacing a worn hose helps restore proper filling, draining, and leak-free operation.

• Supplies incoming water from the faucet to the appliance during fill
• Returns wastewater to the sink during drain cycles
• Helps prevent leaks at hose connections and along the hose body
• Common symptoms: leaks from the hose or coupler area, won't fill or slow fill, won't drain or backs up, visible kinks/cracks

• Disconnect power and close the water supply before service; expect residual water—use a towel or pan
• Note original routing and retainers; install the new hose without sharp bends or kinks
• Ensure secure connections at both the appliance and sink; use the correct faucet adapter required by your setup
• Run a short test cycle and check all connections for leaks

This dishrack wheel lets the dishwasher rack glide smoothly in and out. Replacing a worn or broken wheel restores easy rack movement and helps keep the rack aligned during loading and unloading.

• Provides rolling support for the dish rack inside the rail/track
• Helps keep the rack level and properly aligned
• Common symptoms include rack hard to slide, wobbling/sagging rack, or a cracked/missing wheel
• Can reduce scraping or clicking noises when moving the rack

• Disconnect power before servicing; remove the rack from the tracks as needed
• Release the old wheel from its axle/retainer; note its orientation
• Snap the new wheel onto the existing axle/retainer and ensure it spins freely
• Reinstall the rack and test for smooth operation

Comes with the metal shields

This base heater assembly restores the oven's lower heating function in select convection microwaves. It delivers bottom radiant heat for baking and crisping so the unit can preheat properly and brown foods evenly.

• Supplies bottom heat during convection, bake, or crisp cycles
• Works with the control and temperature sensor to reach and maintain set temperature
• Common symptoms of a failed heater may include no heat in convection mode, very long preheat, or poor browning/crisping
• Visible damage to the element or tripping a circuit breaker may also indicate a shorted heater

• Disconnect power before servicing. Microwaves contain high-voltage components that can retain a charge even when unplugged
• Allow the unit to cool completely; access typically requires removing the outer cover or lowering an over-the-range unit
• Note wire locations and routing before removal; transfer any brackets, shields, or screws from the original assembly
• Route wires exactly as original and avoid pinching; confirm clearances before reassembly and test a convection preheat

Note: Right Hand side with release lever.

This overfill control float sits in the dishwasher tub and rises with the water level to signal the float switch to stop filling. Replacing a cracked or sticking float helps prevent leaks and recurring fill issues. What it does:

• Rises with the water level to actuate the float switch and stop the inlet valve
• Helps prevent overfilling and water leaking from the door
• A float stuck in the UP position can cause no fill or short fill
• A float stuck DOWN or damaged can allow overfilling

• 1 overfill control float

• Disconnect power and turn off water before servicing
• Remove the lower rack; lift out the old float from its guide and clear any debris in the well
• Insert the new float, ensuring it moves freely and reliably actuates the switch when raised

The Dishrack Roller and Axle Assembly is an OEM part for Whirlpool dishwashers. This part facilitates the smooth movement and operation of the upper dishrack inside the dishwasher tub.

Causes of a bad Dishrack Roller and Axle Assembly may stem from wear and tear over time, damage from misuse or improper loading, or debris accumulation hindering the rollers' movement.

Symptoms of needing to replace the Dishrack Roller and Axle Assembly can include:

• Difficulty in sliding the dishrack in or out of the tub
• Excessive noise or grinding sounds when moving the dishrack
• The dishrack becoming stuck or not rolling properly on the track

This OEM Whirlpool part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and some Kenmore models.

Left hand hinge. For right hinge use WP8066056

This wheel mount assembly fits the dishwasher's upper rack track and provides the roller that lets the rack glide in and out. Replacing a worn or broken mount restores smooth movement and keeps the rack aligned on the rails. What it does:

• Supports and guides the upper rack along the side rails
• Replaces cracked, missing, or seized rollers that make the rack hard to slide
• Helps prevent the rack from popping off the track or sitting unevenly
• Can reduce scraping or squeaking noises when moving the rack

• One upper rack wheel mount assembly

• Disconnect power to the dishwasher before servicing
• Open the door and remove the upper rack by releasing the rail stops
• Depress the locking tab to remove the old wheel mount from the rail; align and snap the new assembly into place
• Reinstall the rack and rail stops; check for smooth rack travel

This lower spray arm assembly circulates wash water from the pump to clean dishes on the lower rack. The integrated shield helps direct water flow and protect the arm from debris, restoring consistent wash coverage.

• Distributes high-pressure water across the lower rack for effective cleaning
• Shield design helps prevent debris intrusion and improves spray pattern
• Common failure signs: poor lower-rack cleaning, noisy or restricted rotation, cracked or warped arm, clogged spray holes
• Also addresses leaking or splashing caused by a damaged or misaligned arm/shield

• Disconnect power and turn off water supply before servicing
• Remove lower rack; lift off old arm assembly per model design
• Clear any debris from pump outlet and sump before installing
• Ensure the new arm spins freely and is fully seated; test for smooth rotation

This wheel mounting strip secures the rack rollers to the dishwasher rack, keeping the rack aligned and rolling smoothly in and out. Replacing a worn or broken strip restores proper rack support and slide action.

• Holds multiple rack wheels in position along the rack edge
• Helps prevent sagging, binding, or uneven rack movement
• Common fix for racks that derail, feel wobbly, or won't roll smoothly
• Durable molded piece designed for the rack's wheel row

• Disconnect power and water before servicing
• Remove the rack, then transfer wheels from the old strip to the new one
• Snap or fasten the strip to the rack as designed; verify wheel rotation
• Check rack travel on both rails before returning to service

Color: Stainless

This water inlet valve regulates the flow of household water into the appliance. When the control energizes the solenoid, it opens to deliver the correct amount of water for filling and operation, restoring proper flow and performance.

• Controls on/off flow from the household water supply
• Opens when signaled to provide the correct amount of water for fill functions
• Helps maintain consistent water flow to the system
• Common failure symptoms: no water flow, slow fill, intermittent filling, or leaking at the valve body

• Disconnect power and turn off the water supply before servicing
• Place a towel to catch residual water and relieve line pressure
• Note tubing and wire locations before removal; transfer any brackets or clips as needed
• After installation, restore water and power, check for leaks, and purge air from the lines

The Fold Away Tine Pivot is an OEM part for Whirlpool dishwashers. This component allows the fold-away tines in the dishwasher rack to pivot, enabling flexible loading configurations to accommodate different types and sizes of dishes.

Causes of a bad fold away tine pivot can include regular wear and tear, repeated adjustments leading to stress fractures, or physical damage from heavy dishes or improper handling.

Symptoms of a bad fold away tine pivot include:

• Tines not staying in place or collapsing unexpectedly
• Difficulty adjusting the tines
• The pivot appearing cracked or broken
• Reduced stability of dishes during the wash cycle

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Supplies water to the spray arm.

Color: Grey. 4oz bottle with brush used for touching up damage to your dishracks. For blue use W10840471. For white use WP676453. For tips use 676458.
