Parts for Kenmore 796.91562910 (79691562910, 796 91562910): Control Panel Parts

The Tub Assembly is an OEM component for LG clothes dryers. As the central component housing both the inner and outer drums, the tub assembly is essential for safely drying wet laundry loads. It rotates the drums to circulate air and remove moisture from clothes during cycles.

Causes of a bad tub assembly dryer can include cracks, leaks, or damage to the drum structure from excessive use or unbalanced loads over time. Wear and tear on rotating or suspension components that impair rotation.

Symptoms of an issue with the tub assembly dryer are:

• Inefficient or slow drying times
• Abnormal noises or vibrations during cycles
• Restricted or lack of drum rotation
• Cracks, leaks, or physical damage visible on drums

This OEM LG part is also compatible with Sears/Kenmore.

The Gas Burner Valve Assembly is an OEM replacement part for LG gas dryers. It is a component located beneath the gas burner that controls the flow of fuel to ignite and maintain the flame. The valve assembly receives ignition and temperature signals from the dryer's control system to precisely regulate gas levels throughout drying cycles. This gas dryer burner valve includes two solenoid coils.

Causes of a faulty gas valve may involve wear over extended operation, mineral buildup on valve seats, or mechanical issues restricting gas flow at desired levels.

Symptoms of a bad gas burner valve assembly consist of:

• Erratic or inconsistent burner ignition between cycles
• Inability to achieve high heat settings when needed
• Burners not maintaining steady flame patterns
• Potential gas leaks detected around valves or tubing

This OEM LG part is also compatible with some Sears/Kenmore dryers.

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

This is a four ribbed poly V belt.

The Belt is an OEM replacement part for LG dryers that is responsible for connecting the motor to the drum to allow it to tumble. Over time, dryer belts can stretch, wear out, or even break, leading to a drum that won't turn and clothes that don't dry properly.

Symptoms of a bad Dryer Belt include:

• The dryer motor running but the drum not turning.
• A squealing or thumping noise coming from the dryer.
• The dryer not starting at all.

Causes of failure can include regular wear and tear from the dryer's operation, overloading the dryer beyond its capacity, which puts extra strain on the belt, or a misalignment that causes uneven wear. A damaged belt can prevent your dryer from functioning correctly, leading to inefficiency in drying clothes and potential motor damage due to unnecessary strain.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Drum Seal is an OEM part for LG dryers. This part ensures a tight seal between the dryer drum and the dryer body, preventing hot air from escaping and maintaining the efficiency of the drying process. A well-functioning drum seal is important for the best dryer performance, contributing to energy efficiency and the prevention of unnecessary wear on clothing during the drying cycle.

Causes of a bad drum seal can range from natural wear and tear over time to overloading the dryer, which can strain and stretch the seal, leading to a poor fit.

Symptoms of a bad Drum Seal include:

• Clothes taking longer to dry
• Increased energy usage due to loss of heat
• Excessive lint and debris outside of the lint filter area
• A noticeable gap between the dryer drum and the dryer body

This OEM LG part is also compatible with some Kenmore models.

This Taptite screw is a factory thread-forming fastener used to secure panels, brackets, and internal components where specified by the manufacturer. It forms threads as it drives for a secure, long-lasting hold when replacing a missing or damaged screw.

• Fastens covers, brackets, and internal parts at the designated mounting points
• Thread-forming "Taptite" design creates mating threads in the receiving hole for a snug fit
• Helps restore alignment and reduce vibration or rattling from loose hardware
• Typical symptoms: loose or misaligned panel/handle, rattles during operation, missing or stripped screw

• Disconnect power (and shut off water/gas if applicable) before servicing
• Replace only in the exact location specified for this part; match head style and length to the original
• Start by hand to avoid cross-threading; if resistance is high, back out and re-start
• Tighten until snug; do not overtighten to prevent stripping or cracking

This Pipe Assembly routes water into the appliance so the dispenser and ice maker can receive a steady supply. Replacing a damaged tube restores proper water flow and helps stop leaks or pooling inside or beneath the unit. What it does:

• Carries incoming water from the household supply to the appliance's internal water system
• Restores water delivery to the dispenser and ice maker when the original tube is cracked or blocked
• Prevents leaks and water damage caused by split, corroded, or pinched tubing
• Helps eliminate intermittent flow or weak dispenser output caused by a damaged water line

• One complete pipe assembly as shown

• Shut off the refrigerator's water supply and unplug the appliance before beginning
• Handle tubing fittings carefully; use proper tools to avoid damage or overtightening
• Inspect connection points and replace seals or clips if worn; test for leaks after reinstalling

The Dryer Ignitor is an OEM part for LG dryers. It is crucial for the ignition process in gas dryers, responsible for lighting the gas burner that provides heat for drying clothes. This ignitor must heat up to a high temperature to ignite the gas, and its proper function is essential for the dryer to operate safely and efficiently.

Symptoms of a bad Dryer Ignitor include:

• The dryer not heating up, even though all other functions are working correctly.
• The gas valve opening but no flame being produced, indicating the ignitor isn't reaching the necessary temperature.
• Intermittent heating, where the dryer sometimes produces heat and other times does not.

Causes of a bad dryer ignitor can include thermal fuse issues, a broken or malfunctioning ignitor due to wear and tear, or electrical problems affecting power delivery to the ignitor.

This OEM LG part is also compatible with Kenmore models.

For propane order 383EEL3002A.

The LP Conversion Kit is an OEM part for LG dryers. This kit is designed to convert a natural gas dryer to use liquid propane (LP) gas. It includes all necessary components to make the conversion safely and effectively, ensuring the dryer operates efficiently with LP gas.

Causes of needing an LP Conversion Kit can include relocating the dryer to an area where only LP gas is available or switching from natural gas to LP gas to meet specific household energy requirements. Proper installation of the conversion kit is crucial for safe and efficient dryer operation.

Symptoms indicating the need for an LP Conversion Kit include:

• Relocating to a home with LP gas service
• Switching energy sources due to availability or preference
• A new dryer installation where only LP gas is supplied

This OEM LG part is also compatible with Sears/Kenmore.

Replacement door gasket that seals the refrigerator/freezer door to help keep cold air in, reduce energy loss, and maintain consistent temperatures for stored food. What it does

• Forms an airtight seal around the door to prevent warm air from entering the compartment.
• Helps maintain even cooling and prevents frost or ice buildup caused by air leaks.
• Can reduce running time and energy use when the original gasket is torn, warped, or no longer seals.
• Common symptoms of a failing gasket: visible gaps, condensation or frost at the door, uneven temperatures, or increased energy use.

• Disconnect power to the appliance and remove food from affected areas before beginning work.
• Inspect the door frame for dirt or debris and clean mating surfaces before installing the new gasket.
• Align the gasket to the door and seat it fully—follow OEM alignment steps for your model; if the gasket is stiff, warm it slightly per OEM guidance to help fit.

This duct assembly channels airflow inside the appliance to guide exhaust and internal air between components. Replacing a damaged or obstructed duct helps restore proper airflow and can reduce poor performance or long cycles. What it does:

• Directs exhaust and circulation air between internal components to maintain airflow
• Prevents leaks that can reduce efficiency or cause longer cycle times
• Helps avoid overheating or moisture build-up from restricted airflow
• Reduces rattling or vibration caused by a cracked or loose duct

• Disconnect power (and turn off gas supply for gas appliances) before beginning work.
• Handle edges carefully — sheet metal can be sharp; wear cut-resistant gloves.
• Ensure duct is seated and fastened to create a tight seal where it connects to other components.
• After reassembly, run a test cycle to confirm airflow and proper operation.

This tub assembly is the washer's inner drum that holds and rotates laundry during wash and spin cycles, restoring proper agitation and spin performance for units with a damaged or worn drum. What it does

• Houses and tumbles clothes so water and detergent move through fabric during wash cycles
• Enables balanced spinning and high-speed rotation during the spin cycle
• A damaged or warped drum can cause loud banging, scraping noises, or clothes abrasion
• Cracks or severe damage may allow water to contact bearings or seals, causing further wear

• Disconnect power and water supply before beginning service
• Replacing the drum requires partial disassembly of the washer cabinet and suspension components; keep fasteners organized
• Inspect and replace related wear items (seal, bearings, spider/bolts) if they show damage

The High Limit Thermostat is an OEM part for LG dryers, designed to act as a critical safety feature within the appliance. This thermostat monitors the dryer's internal temperature, shutting off the heat source if it detects temperatures that are dangerously high. By doing so, it prevents overheating, which can lead to appliance damage or, in worst-case scenarios, fires. The high limit thermostat is a crucial component for the safe operation of your dryer, ensuring it operates within the specified temperature range.

Causes of a faulty High Limit Thermostat can include a malfunction within the thermostat itself, such as a failure to accurately detect temperature changes, or issues with the dryer that cause it to run hotter than designed, such as restricted airflow or a malfunctioning heating element.

Symptoms of a malfunctioning High Limit Thermostat include:

• The dryer not heating properly or at all
• The dryer repeatedly shutting off during cycles
• Excessive heat emanating from the dryer, indicating it is not regulating temperature correctly

This OEM LG part is also compatible with some Kenmore models.

The LAMP, LED is an OEM component specifically designed for LG dryers. It provides illumination inside the dryer drum, a crucial safety feature for easily viewing clothes during operation. Proper lighting allows users to monitor drying progress without hindering efficiency.

Causes of a bad LED lamp can include regular wear and tear over extended use, as well as potential electrical issues disrupting current flow to the lighting source.

Symptoms of a bad LED lamp include:

• Dim or completely absent lighting inside the dryer drum
• Inability to visually inspect clothes without opening the dryer door
• Premature ending of cycles due to detection of insufficient light

The high-efficiency LED technology in this OEM part helps maximize useful life. Replace yours today to restore optimal usability. This LG replacement part is also compatible with Sears/Kenmore models.

This connector nozzle is the small channeling fitting that routes fluid or air where needed in the appliance, restoring correct flow and reducing leaks or poor dispensing when the original is damaged. It's a direct-fit service part designed for straightforward replacement. What it does

• Directs fluid/air through the appliance plumbing or dispenser pathway to ensure proper flow.
• Replaces cracked, broken, or worn nozzle connectors that can cause leaks or reduced dispensing performance.
• Helps restore normal operation when the nozzle is visibly damaged, loose, or obstructed.
• Works as the mating piece between tubing and the appliance's internal assembly to maintain a sealed connection.

• One connector nozzle

• Disconnect power and shut off water supply before servicing.
• Inspect adjoining seals, gaskets, and tubing; replace any damaged components.
• Seat the nozzle fully and secure per OEM torque/fastening guidance to avoid leaks; do not overtighten.

The High Limit Thermostat is an OEM part for LG dryers, designed to act as a critical safety feature within the appliance. This thermostat monitors the dryer's internal temperature, shutting off the heat source if it detects temperatures that are dangerously high. By doing so, it prevents overheating, which can lead to appliance damage or, in worst-case scenarios, fires. The high limit thermostat is a crucial component for the safe operation of your dryer, ensuring it operates within the specified temperature range.

Causes of a faulty High Limit Thermostat can include a malfunction within the thermostat itself, such as a failure to accurately detect temperature changes, or issues with the dryer that cause it to run hotter than designed, such as restricted airflow or a malfunctioning heating element.

Symptoms of a malfunctioning High Limit Thermostat include:

• The dryer not heating properly or at all
• The dryer repeatedly shutting off during cycles
• Excessive heat emanating from the dryer, indicating it is not regulating temperature correctly

This OEM LG part is also compatible with some Kenmore models.

This duct assembly channels exhaust from the appliance to the home vent, restoring proper airflow and helping reduce lint and moisture buildup. It's a direct-fit replacement for the original ducting on compatible LG units. What it does:

• Directs heated air and moisture from the appliance to the exterior vent
• Replaces damaged, crushed or disconnected ductwork that can restrict airflow
• Helps reduce lint accumulation in the cabinet/vent path when installed and maintained
• Restores a sealed connection between the appliance outlet and household venting

• Disconnect power and unplug the appliance before beginning any repair
• Follow for disassembly and routing; use proper clamps or screws to secure connections
• Inspect connected gaskets, clamps and the external vent path; replace or clean as needed
• Do not operate the appliance with obstructed or damaged venting; clean lint regularly to reduce fire risk

The Igniter Sensor is an OEM part for LG dryers. This sensor plays a critical role in the ignition process, ensuring that the gas ignites properly to produce the heat necessary for drying clothes efficiently. It helps monitor and regulate the ignition temperature.

Over time, the igniter sensor can become faulty due to regular use, exposure to high temperatures, or electrical issues. These factors can lead to a malfunction, resulting in the dryer not heating properly or failing to start.

Symptoms of a bad igniter sensor include:

• Dryer not heating up
• Long drying times
• Dryer not starting
• Unusual smells or noises during operation

This OEM LG part is also compatible with Sears/Kenmore.

A small mounting bracket that secures and supports internal appliance components to keep shelves, drawers or assemblies aligned and stable. Replaces a cracked, broken or missing supporter to restore proper fit and reduce movement. What it does

• Secures an internal component or assembly in place to prevent sagging or misalignment
• Stops rattling, wobble or looseness caused by a damaged or missing bracket
• Restores correct clearance and support for the associated shelf/drawer/assembly
• Helps maintain normal operation and prevents further wear on adjacent parts

• One supporter holder bracket

• Disconnect power before starting repairs; unplug or flip the appliance breaker
• Remove nearby shelves, drawers or panels to access the damaged bracket
• Inspect mating parts for damage and replace any worn fasteners as needed
• Use basic hand tools;

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

This is an authentic OEM drum support roller sourced directly from the manufacturer for use in clothes dryers. During the drying cycle, the drum turns and tosses the clothes around to distribute heat. This drum support roller holds the drum in place as it rotates. Over time, the heat from the dryer can lead to the roller becoming worn. If the dryer is making squealing sounds or thumping when operating, the support roller is worn out and should be replaced. Before replacing the drum support roller, make sure the power is disconnected from the dryer. Remove the top and front panel of the dryer to reach the drum. The idler pulley and dryer belt are underneath the drum; remove these and then take the drum out of the unit and set it aside. Remove the mounting bracket holding the worn drum support roller. Remove and replace the worn roller. While the dryer is apart, inspect the remaining support rollers. Reverse the steps used and put the dryer back together. Power the dryer and make sure the drum turns.This is a black and white, rubber and metal part that is individually sold. It does not come with assembly hardware. This drum support roller is designed for dryers manufactured by LG, Kenmore, and General Electric.

A manufacturer-configured replacement component designed to restore the appliance's original factory settings and functions. Use this part when a model-specific, pre-configured module is required to return correct operation. What it does:

• Provides the factory-specific configuration and setup programmed by the manufacturer
• Restores functions controlled by the module when configuration or programming is corrupted
• Resolves symptoms such as appliance not starting, control panel unresponsive, or intermittent/erratic operation linked to configuration errors
• Ensures compatibility with model-specific features when the appliance requires a pre-configured assembly

• Disconnect power to the appliance before starting any work
• Handle electronics carefully; observe electrostatic discharge (ESD) precautions for circuit boards or modules
• Match connectors and mounting locations to the original part; do not force connectors

The High Limit Thermostat Kit is an OEM part for LG dryers. It acts as a safety device that prevents the dryer from overheating by cutting off power to the heating element if the dryer exceeds a certain temperature.

Common causes of a faulty thermostat include regular wear and tear, electrical issues, or a malfunction in the heating system that causes the thermostat to overwork.

Symptoms of a bad High Limit Thermostat include:

• Dryer not heating at all
• Dryer overheating or shutting off unexpectedly
• Clothes taking longer to dry
• The dryer being unusually hot to the touch

This OEM LG part is also compatible with Sears/Kenmore models.

Includes High limit and safety thermostats.

This hinge bracket secures the refrigerator door hinge assembly so the door opens and closes smoothly and stays aligned. Replaces a worn or damaged bracket to restore proper door fit and reduce binding or sagging. What it does:

• Provides a stable mounting point for the door hinge shaft to keep the door aligned
• Restores correct door swing and sealing when original bracket is cracked or bent
• Helps stop door sag, rubbing, or uneven gaps that can cause cooling issues
• Durable molded metal/plastic construction resists wear from normal use

• One hinge bracket

• Recommended for technicians or experienced DIYers; disconnect power and empty door before starting
• Use correct screws and torque; reuse existing fasteners only if undamaged
• Inspect adjacent hinge parts and seals; replace any damaged components to ensure proper alignment
• Handle carefully to avoid damaging door finish and to maintain proper hinge geometry

This is a taptite screw used to fasten components to sheet metal or plastic in your appliance. It forms its own threads as it's driven, helping secure panels, brackets, or covers that have lost or stripped fasteners.

• Provides secure fastening in pre-formed or unthreaded holes
• Helps fix loose, rattling, or misaligned panels and covers
• Commonly used for mounting small brackets and internal trim
• Useful when an original screw is missing or stripped

• Unplug the appliance or shut off power and any water supply before service
• Keep track of screw length and location; replace like-for-like
• Start by hand to avoid cross-threading; do not overtighten
• If the original hole is damaged, assess for safe re-use or repair

The Lint Filter is an OEM part for LG dryers. It is responsible for capturing lint and debris from the laundry, preventing it from clogging the dryer vent and providing easy cleaning. A bad lint filter can be caused by regular use and the accumulation of lint and debris over time. It may also become damaged if not cleaned regularly or if items such as coins or small objects accidentally get caught in the filter. Measures: about 12 in wide by 11 in high

Causes of a lint filter can include normal wear and tear over time, excessive lint buildup or clogging, or physical damage due to improper cleaning or handling.

Symptoms of a bad lint filter include:

• Clothes taking longer than usual to dry.
• Reduced airflow or poor drying efficiency.
• Lint accumulating on the dryer drum or around the door.

This OEM LG part can also be used on Kenmore/Sears appliances.

Note: If your filter won't seat all the way down in the housing, order filter ADQ56656403. Due to manufacturer changes, in some cases, the filter guide MEA49050001 and filter cover MCK66787901 may also need to be replaced.

The Door Latch Assembly is an OEM replacement part for LG dryers. It secures the dryer door safely closed during operation.

Symptoms of a failing latch include:

• The door popping or swinging open during cycles
• Difficulty fully closing and locking the door
• Reduced efficiency as warm air leaks from gaps
• Clothing partially falling out during uncontrolled openings

Causes can be worn gears that no longer hold tight closure after extended use. Over-tightening of the door seal may also put excess strain on the assembly.

This LG OEM replacement part is also compatible with some Kenmore versions.

The Lint Screen Housing is an OEM replacement part for LG dryers. It serves as the enclosure that holds the lint screen or filter, which plays a crucial role in capturing lint and preventing it from accumulating inside the dryer. This housing  measures approximately 17 in x 12 in,

Symptoms of needing to replace the lint screen housing include:

• Difficulty in removing or inserting the lint screen
• Visible cracks, warping, or damage to the existing housing
•  Lint buildup or leakage around the housing area
• The housing becoming loose or not securely holding the lint screen in place

Causes of a faulty lint screen housing can include normal wear and tear over time, exposure to excessive heat or lint buildup, or physical damage due to impact or mishandling.

This OEM LG part is also compatible with Sears/Kenmore dryer models, ensuring a perfect fit and reliable lint filtration for your specific appliance. NOTE: Due to a manufacturing change, this filter housing may be different from your original. If you have any issues installing your filter, you may need to order new filter part# ADQ56656403 and new guide part# MEA49050001 for a proper fit. When ordering [AP5071745} you will need to order filter ADQ56656403.

This taptite screw fastens panels and internal components in your appliance. It forms its own threads as it's driven to create a secure hold, restoring proper fit and reducing rattles caused by loose or missing fasteners.

• Forms threads in the mating material for a tight, secure fit
• Secures covers, brackets, and assemblies during repair or reassembly
• Replace when the original screw is missing, rusted, stripped, or won't tighten
• Helps address loose or rattling panels and misaligned parts

• Disconnect power before servicing
• Start the screw by hand to avoid cross-threading; use the correct driver
• Do not overtighten; if the receiving hole is damaged, repair or replace the mating component
• Reuse any original washers/spacers in the same order if present

The Door Switch Assembly is an OEM part for LG dryers. It ensures the dryer operates only when the door is securely closed, acting as a safety feature to prevent the dryer from running while the door is open.

Causes of a bad door switch assembly can include regular wear and tear from frequent use, electrical issues such as shorts or faulty connections, or physical damage from forceful door closures or impacts.

Symptoms of a bad door switch assembly include:

• The dryer not starting
• The dryer stopping mid-cycle
• The drum light not turning on or off correctly
• The dryer continuing to run with the door open

This OEM LG part is also compatible with Sears/Kenmore models.

The Lint Filter Guide is an OEM part for LG dryers. This part guides and secures the lint filter in place within the dryer. By ensuring the lint filter is correctly positioned, it effectively helps in capturing lint, debris, and other particles from clothes during the drying cycle, contributing to optimal dryer performance and preventing potential airflow blockages that could lead to overheating.

Over time, the Lint Filter Guide can experience wear or damage from frequent use or during the cleaning and maintenance process. Damage to this part can lead to improper placement of the lint filter, which might compromise the dryer's efficiency, increase energy consumption, or pose a fire risk due to accumulated lint.

Symptoms of a bad Lint Filter Guide include:

• Difficulty in inserting or removing the lint filter
• The lint filter not fitting properly or securely
• Increased lint accumulation outside the filter area
• Unusual noises or reduced efficiency during dryer operation

This OEM LG part can also be used on Kenmore/Sears appliances.

The Lint Filter Duct Cover is an OEM part for LG dryers. It is designed to fit over the lint filter and duct area, ensuring that lint is properly trapped and does not escape into the dryer’s internal components. This cover helps maintain efficient airflow and prevents potential lint buildup, which can be a fire hazard. This part measures approximately 11-1/2 inches by 1-1/4 inches.

You should replace the lint filter duct cover if it becomes damaged or cracked, or if it fails to stay securely in place. Common causes of a bad lint filter duct cover include regular wear and tear, accidental damage during cleaning or maintenance, or exposure to high heat that can warp the plastic.

Symptoms of a bad lint filter duct cover include:

• Lint escaping into the dryer drum
• The cover not fitting securely over the lint filter
• Increased drying times due to reduced airflow
• Visible cracks or damage to the cover

This OEM LG part is also compatible with Sears/Kenmore models.

This distortion spring applies the correct tension within the dryer mechanism so parts return to position and operate smoothly. Replacing a fatigued or broken spring helps prevent loose movement, rattling, and inconsistent operation of the related assembly. What it does

• Provides the designed return/tension force for the associated dryer mechanism
• Helps maintain alignment and smooth movement of moving parts
• Can reduce rattling or squeaking caused by weak or missing spring tension
• Symptoms include components not returning to position or intermittent operation

• One distortion spring

• Disconnect power; for gas dryers, also shut off the gas supply
• Allow internal components to cool before service
• Control the spring during removal/installation—springs are under tension and can snap back
• Note the original spring orientation and attachment points to ensure proper reassembly

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

This moisture sensor connector assembly links the dryer's sensor bars to the control to monitor fabric dryness and adjust cycle time. Replacing a damaged or loose harness restores consistent Auto Dry operation.

• Connects the moisture sensor bars to the main control for Auto Dry feedback
• Transmits the low-voltage signal used to determine when clothes are dry
• Failure may cause Auto Dry to end too soon, run too long, or deliver inconsistent results
• Typical issues include broken wires, loose/corroded terminals, or a heat-damaged plug

• Disconnect power; if gas, shut off gas supply before service
• Access the moisture sensor area at the front/lint housing
• Match routing and clips, seat terminals fully on the sensor tabs, and secure the connector
• Keep wiring clear of sharp edges and moving parts; reassemble and test a Sensor Dry cycle

The Moisture Sensor Holder is an OEM replacement part for  LG dryers. It secures the crucial moisture sensor in place inside the drum. This sensor detects how damp the laundry is to determine when the cycle has finished drying clothes.

Symptoms of a bad moisture sensor holder include:

• The sensor coming loose or not making proper contact
• Inaccurate drying times as the sensor may read inconsistently
• Premature ending of cycles before clothes are completely dry
• Repeated drying error codes displayed

Causes can be cracked or broken clips after years of drum rotation. Vibrations may also loosen mounting screws over time.

Replacing with this genuine LG part ensures the sensor stays positioned correctly. Compatible models include some Kenmore and Sears dryers.

This is the rear tub drum for the washer's drum assembly; it supports the inner drum and helps keep loads balanced so the washer can tumble and spin properly. Use this part to restore stable drum rotation and reduce rubbing or banging noises. What it does:

• Supports the inner wash basket and maintains proper alignment during spin cycles
• Keeps the drum centered to prevent rubbing against the cabinet or seal
• Helps reduce loud banging, wobbling or excessive vibration during operation
• Works with the tub seals, bearings and suspension to maintain smooth rotation

• One rear tub drum

• Disconnect power and water before beginning any repair
• This is a major drum component; expect to remove the outer cabinet and other assemblies to access it
• Support the inner drum while separating components; bearings, seal and hardware may need inspection or transfer

The Door Strike is an OEM part for LG dryers. This part engages with the door catch to keep the dryer door securely closed during operation. The door strike is essential for ensuring the door remains tightly shut, allowing the dryer to function efficiently and safely.

Causes of a bad door strike can include wear and tear from regular use, damage from slamming the door, or misalignment issues that prevent it from engaging properly with the door catch.

Symptoms of a bad door strike include:

• The dryer door not staying closed
• The dryer not starting due to the door not being securely latched
• Difficulty in latching the door
• Visible damage or wear on the strike

This OEM LG part is also compatible with Sears/Kenmore.

This precision fastener is designed for specific locations on the appliance. Replacing a missing or damaged screw restores secure mounting and reduces vibration or rattling, helping panels and components stay properly aligned.

• Secures brackets, panels, and internal assemblies where this screw is specified
• Replaces stripped, rusted, or lost hardware
• Helps eliminate looseness, vibration, and noise
• Maintains proper fit and alignment of parts

• Disconnect power and shut off water/gas before servicing
• Use the correct driver; keep removed hardware organized for reassembly
• Do not overtighten; install into clean, undamaged threads
• Confirm location and quantity using your model's parts diagram

The Door Hinge is an OEM part for LG dryers. This hinge supports the dryer door, allowing it to open and close smoothly and securely. It ensures that the door stays aligned and functions properly, providing reliable access to the dryer drum for loading and unloading clothes.

Causes of a bad door hinge can include frequent use leading to wear and tear, physical damage from forceful opening or closing, and rust or corrosion due to exposure to moisture.

Symptoms of a bad door hinge include:

• Difficulty in opening or closing the dryer door
• The door not staying aligned or becoming loose
• Squeaking or grinding noises when moving the door
• Visible damage, bending, or rust on the hinge

This OEM LG part is also compatible with some Kenmore models.

This inner door frame replaces a damaged or cracked refrigerator door interior to restore structural support and help maintain proper door closure. It provides a finished interior surface and supports attached door components. What it does

• Replaces a broken or cracked inner door frame that can cause loose fittings or rough edges
• Restores the interior door structure that supports shelves, trims, and other door-mounted parts
• Helps maintain proper alignment for the door closure to reduce air leaks and temperature issues
• Improves appearance by replacing warped or deformed interior door trim

• Disconnect power to the appliance before beginning any door work to avoid injury
• Remove all door contents and support the door while removing fasteners to prevent damage
• Handle the replacement carefully to avoid scratching painted or plated surfaces
• Tighten fasteners securely and verify door alignment and seal before returning the appliance to service

The Door Seal is an OEM part for LG dryers. It forms a tight seal around the dryer door, preventing heat and moisture from escaping during the drying cycle, which ensures efficient drying and energy use.

Causes of a bad door seal can include wear and tear from regular use, damage from repeated opening and closing of the dryer door, or degradation from exposure to heat and moisture over time. A compromised door seal can lead to longer drying times and increased energy consumption.

Symptoms of a bad door seal include:

• Heat and moisture escaping from the dryer door
• Longer drying times
• Clothes not drying completely
• Visible cracks, tears, or wear on the seal

This OEM LG part is also compatible with Sears/Kenmore.

The Damper is an OEM part for LG dryers. This component helps reduce noise and vibrations by damping the movement of the dryer door. It plays an important role in ensuring smooth and controlled opening and closing of the dryer door.

Causes of a bad damper can include wear over time, damage from repeated usage or unbalanced loads, or accidental impact.

Symptoms of a bad damper include:

• Excessive noise or loud banging when opening or closing the dryer door
• The door not opening or closing smoothly
• Increased vibration levels during operation
• Reduced lifespan of other door components like hinges or latches

This OEM LG part is also compatible with some Kenmore models.

The Generator Assembly is an OEM part for LG electric dryers. This crucial assembly houses the heating element that supplies warmth to dry clothes.

Symptoms of a bad generator assembly include:

• Inability to achieve proper drying temperatures
• Drying cycle taking excessively long times
• Insufficient or incomplete drying of clothes loads
• Odor or smoke emanating from dryer interior

Causes of failure can be cracks in insulating materials allowing electricity leaks, broken or corroded terminal connections, or general carbon buildup over years of use.

Replace yours today with this genuine OEM LG assembly to restore fast and efficient drying performance. New heating elements help eliminate safety concerns. This replacement part is compatible with some Samsung, GE, and Kenmore dryer models.

This frame bracket secures and supports appliance panels and structural components to restore proper alignment and reduce movement. It's a direct-fit replacement that helps stop panel rattling and keeps connected parts stable during operation. What it does:

• Secures the appliance frame or panel to the cabinet to maintain proper alignment.
• Provides structural support to prevent flexing or sagging of connected components.
• Reduces rattling, vibration, and noise caused by a loose or broken bracket.
• Common symptom: visible looseness, misaligned panel or persistent vibration during use.

• Disconnect power (and water if applicable) before beginning any repair.
• Use the OEM service manual or exploded parts diagram for correct placement and fastener locations.
• Typical installation requires basic hand tools; inspect surrounding mounting points and hardware and replace if worn.
• If the bracket is plastic, avoid overtightening screws to prevent cracking.

The Blower Wheel is an OEM part for LG dryers. This part circulates air through the dryer drum and out the exhaust vent, ensuring proper airflow for efficient drying of clothes.

Causes of a bad blower wheel can include accumulation of lint and debris, wear and tear over time, or physical damage due to foreign objects entering the blower housing.

Symptoms of a bad blower wheel include:

• Reduced or no airflow from the exhaust vent
• Unusual noises such as rattling or squealing during the drying cycle
• Clothes taking longer to dry or remaining damp
• Overheating or frequent shutdowns of the dryer

This OEM LG part is also compatible with some Kenmore models.

Adapt your gas dryer for propane with this LP conversion kit. It provides the correct orifice and regulator adjustments needed so the burner fires properly on LP fuel, helping ensure safe operation and consistent drying performance after a fuel change.

• Converts a compatible gas dryer from natural gas to liquid propane (LP)
• Helps ensure proper burner flame characteristics on LP
• Appropriate when moving to a home with propane or changing utilities
• Symptoms can include weak heat, improper flame, or sooting

• Disconnect power and shut off gas before servicing
• Installation and regulator/orifice adjustments must be performed per the service manual
• After installation, leak-check all connections and verify proper burner operation
• Do not attempt conversion without the correct kit for your specific model

This dryer duct assembly channels air from the drum to the blower and exhaust. Replacing a cracked or warped housing restores proper airflow, helps prevent lint bypass, and supports consistent drying performance.

• Directs and seals airflow between the drum and blower housing
• Helps maintain drying efficiency by minimizing leaks and lint bypass
• Damage or warping can lead to long dry times and reduced airflow
• Signs of failure include visible cracks, melted spots, or air/lint leakage around the duct area

• Disconnect power; for gas models, turn off the gas supply
• Access from the front by removing the top and front panel
• Note fastener locations and any attached brackets/harnesses, then transfer them to the new assembly
• Vacuum lint from internal ducting and verify seals before test run

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

This adjustable leveling leg screws into the dryer base to support and stabilize the cabinet. Replacing a worn or missing foot helps level the appliance, reduce vibration and noise, and keep it steady on uneven floors.

• Provides threaded height adjustment to properly level the dryer
• Stabilizes the cabinet to minimize rocking, vibration, and walking
• Replaces a broken, worn, or missing foot
• Common symptoms: dryer wobbles, is hard to level, or makes rattling/vibration noise

• Disconnect power; shut off gas supply for gas models
• With a helper, carefully tilt or raise the dryer for access
• Unscrew the old leg; thread the new leg into the base by hand, then adjust with a wrench until the dryer sits level and stable
• Ensure all legs contact the floor and the dryer does not rock

This power cord assembly supplies AC power to the appliance and restores safe operation after a damaged or faulty cord. It replaces the worn or frayed factory cord so the appliance can power on reliably. What it does

• Provides the main AC connection between the appliance and household power
• Replaces cords with visible damage, exposed wiring, burnt connectors, or intermittent power
• Helps stop arcing, sparking, or overheating caused by a failing cord
• Fits into the appliance's cord terminal block for a direct, plug-in power connection

• One power cord assembly

• Disconnect power at the breaker or unplug the appliance before starting any work
• Tighten all terminal screws securely and route the cord away from sharp edges and moving parts

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

The Motor Bracket is an OEM part for LG dryers. This bracket securely holds the dryer motor in place. It maintains proper alignment and spacing of the motor to allow for smooth operation of the tumble cycle.

Causes of a bad motor bracket can include cracks or breaks developed over time from repeated use and vibration, or damage due to impact or improper installation.

Symptoms of a bad motor bracket include:

• Excessive noise or grinding sounds emanating from the motor area
• The dryer not rotating or tumbling clothes properly
• Increased movement or shaking of the motor
• Poor airflow and inefficient drying performance

This OEM LG part is also compatible with some Kenmore models.

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

This micro switch is a compact, snap-action electrical switch that sends an on/off signal when a lever, latch, or paddle is moved. Replacing a worn switch restores reliable detection and control response for the affected function.

• Converts mechanical movement into an electrical open/close signal to the control
• Commonly used for lever/paddle actuators, latches, or interlock detection within the appliance
• Safe symptom clues: no response when actuated, intermittent operation, or a function stuck on/off
• Physical clues: weak or absent "click" when pressed, heat discoloration or damage at terminals

• Disconnect power before servicing; if the product is connected to a water line, close the supply valve
• Note wire positions and terminal labels (COM/NO/NC); transfer wires one at a time to matching terminals
• Match the actuator orientation and mounting position to the original for proper operation
• After installation, verify continuity with a multimeter and test function before reassembly

The Idler Pulley Assembly is an OEM part for LG dryers. It plays a critical role in the dryer's drum belt tension system, helping to maintain proper tension on the belt so the drum can rotate smoothly during the drying cycle.

Causes of a bad idler pulley assembly can include wear and tear over time, buildup of lint or debris, or damage from an overloaded dryer. A malfunctioning idler pulley can lead to inefficient drying and potential damage to other dryer components.

Symptoms of a bad idler pulley assembly include:

• Squeaking or squealing noises during operation
• The drum not rotating properly or at all
• The dryer stopping mid-cycle
• The belt slipping or breaking

This OEM LG part is also compatible with Sears/Kenmore.

The Dryer Idler Pulley is an OEM replacement part for LG dryers. It is a critical component that helps guide and maintain proper tension on the dryer belt, ensuring efficient transfer of rotational force from the motor to the dryer drum.

Symptoms of a faulty dryer idler pulley include:

• Squeaking or grinding noises coming from the pulley area
• Visible wear, cracks, or damage to the pulley surface
• Slipping or irregular rotation of the dryer drum

Causes of a bad idler pulley can include normal wear and tear over time, exposure to high temperatures or lint buildup, misalignment or improper tracking, or physical damage from impact or foreign objects.

This OEM LG part is also compatible with Sears/Kenmore dryer models.

This replacement screw secures appliance components in their proper position. Use it to restore a tight, rattle-free fit when the original fastener is missing, stripped, or corroded. What it does:

• Fastens brackets, panels, or trim to keep assemblies aligned and secure
• Helps prevent vibration, rattling, and gaps from loose hardware
• Restores proper attachment when a screw is lost, worn, or damaged
• Common symptoms: loose panel/handle, misalignment, rattling, or a missing screw

• Disconnect power; shut off water or gas before service
• Match location to the original; start threads by hand to avoid cross-threading
• Use the correct driver bit; do not overtighten (especially into plastic)
• If the original hole is stripped, repair threads before installing the new screw

This self-tapping screw fastens panels, brackets, and internal components in compatible appliances. Replace a stripped, corroded, or missing screw to restore a secure fit and help prevent vibration, rattling, and misalignment.

• Forms/engages its own threads in sheet metal or plastic for a secure hold
• Secures covers, brackets, and assemblies to maintain alignment
• Helps reduce vibration and noise from loose components
• Replace if the head is stripped/broken, threads are worn, or the screw is missing

• Disconnect power and shut off water or gas, as applicable, before servicing
• Match to the original location and hardware; use identical length and thread where specified
• Start by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving hole is damaged, repair it before installing the new screw

This drying rack sits inside the dryer drum to hold items that shouldn't tumble. It keeps shoes, sweaters, and other delicates stationary so they dry gently using the dryer's airflow and heat.

• Provides a stationary platform in the drum for rack-dry items
• Helps dry shoes, hats, sweaters, and stuffed toys without tumbling
• Replace if the rack is cracked, warped, missing, or won't stay seated
• Enables use of the rack-dry feature on compatible models

• Disconnect power and let the dryer cool before installation
• Open the door and slide the rack into the designated guides until fully seated and level
• Place items flat on the rack; avoid overloading or letting items hang over the edges
• Remove the rack before running regular tumble cycles

This connector nozzle attaches to the appliance's nozzle assembly to route fluid through the system and help maintain a sealed connection. It replaces a worn or cracked nozzle connector to restore proper flow and reduce leaks. What it does:

• Provides a secure connection point for the nozzle assembly, directing fluid through the correct pathway
• Restores a sealed joint to prevent drips or steady leaks at the nozzle area
• Helps eliminate flow interruptions caused by a cracked, split, or damaged connector
• Works as a direct-fit replacement when the original connector is broken or degraded

• One connector nozzle

• Turn off power and shut off the water supply before starting any repair
• Remove only the components necessary to access the nozzle area; use basic hand tools
• Check seals and adjoining hoses for wear and replace if needed to ensure a leak-free connection

The Water Valve is an OEM part for LG dryers. This valve controls the water supply to the dryer's steam setting which helps reduce wrinkles and refresh clothing.

Causes of failure can be mineral buildup overtime restricting flow, damage from freezing during winter months, or worn internal seals and mechanisms.

Symptoms of a bad water valve include:

• Inability to select or utilize the steam cycle
• Drips or leaks at the water inlet port
• Erratic water pressure during steam cycles
• Steam levels that fluctuate or cut off unexpectedly

This OEM LG part is also compatible with some Kenmore models.

This pipe connector joins appliance water tubing to the inlet assembly, restoring a secure, leak-resistant connection so the dispenser or ice-making system can get a steady water supply. Ideal when fittings are cracked or worn. What it does:

• Creates a watertight connection between supply tubing and the appliance inlet/valve
• Stops leaks caused by cracked, split, or loose fittings at the tubing junction
• Restores proper water flow to dispensers and ice makers when a bad connector is the cause
• Helps prevent water pooling and potential damage from slow leaks

• Turn off water supply and disconnect power before replacing the connector
• Inspect tubing ends for damage and trim squarely if needed before installing
• Use correct tools and tighten fittings per manufacturer guidance; do not overtighten
• After installation, restore water and power and check carefully for leaks

This inlet hose delivers water from the household supply to the appliance for normal fill cycles. It restores proper water flow when the original inlet hose is damaged, cracked, or leaking. What it does:

• Channels incoming water from the household supply to the appliance's fill valve
• Replaces a worn, cracked, or leaking inlet hose to stop external leaks
• Helps restore normal fill and wash cycles affected by restricted or damaged hoses
• Fits as a direct replacement for the corresponding OEM inlet connection

• One inlet hose

• Disconnect power and shut off the water supply before starting any work
• Inspect fittings and replace any damaged clamps or seals to ensure a watertight connection
• Hand-tighten connections, then snug with a wrench—avoid over-tightening which can damage fittings
• Test for leaks by running a short fill cycle and checking all connections

The Venting Kit is an OEM part for LG dryers. This part offers flexibility and efficiency in dryer installation and setup, this kit enables side or bottom venting of the appliance, facilitating optimal use of space in your laundry area. It's ideal for situations where the traditional rear venting is not feasible or preferred.

Causes of venting system issues can include blockages, incorrect installation, or the use of incompatible parts, leading to reduced efficiency and potential safety hazards, such as overheating or fire risks.

Symptoms of a bad or improperly installed venting system include:

• Extended drying times
• Excessive humidity or heat in the laundry area
• Unusual noises during operation
• Accumulation of lint in and around the dryer

This OEM LG part is also compatible with some Kenmore models.
