Parts for Kenmore 796.81782810 (79681782810, 796 81782810): Control Panel Parts

The Tub Assembly is an OEM component for LG clothes dryers. As the central component housing both the inner and outer drums, the tub assembly is essential for safely drying wet laundry loads. It rotates the drums to circulate air and remove moisture from clothes during cycles.

Causes of a bad tub assembly dryer can include cracks, leaks, or damage to the drum structure from excessive use or unbalanced loads over time. Wear and tear on rotating or suspension components that impair rotation.

Symptoms of an issue with the tub assembly dryer are:

• Inefficient or slow drying times
• Abnormal noises or vibrations during cycles
• Restricted or lack of drum rotation
• Cracks, leaks, or physical damage visible on drums

This OEM LG part is also compatible with Sears/Kenmore.

Fix a dryer that won't heat or leaves clothes damp with this heating element assembly. Generates heat to dry clothes effectively. DIY repair.

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

The Belt is an OEM replacement part for LG dryers that is responsible for connecting the motor to the drum to allow it to tumble. Over time, dryer belts can stretch, wear out, or even break, leading to a drum that won't turn and clothes that don't dry properly.

Symptoms of a bad Dryer Belt include:

• The dryer motor running but the drum not turning.
• A squealing or thumping noise coming from the dryer.
• The dryer not starting at all.

Causes of failure can include regular wear and tear from the dryer's operation, overloading the dryer beyond its capacity, which puts extra strain on the belt, or a misalignment that causes uneven wear. A damaged belt can prevent your dryer from functioning correctly, leading to inefficiency in drying clothes and potential motor damage due to unnecessary strain.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Hi Limit Thermal Fuse is an OEM part for LG dryers. This fuse is a safety device that protects the dryer from overheating by cutting off power to the heating element if the dryer’s temperature exceeds a safe limit. It ensures that the dryer operates within safe temperature ranges, preventing potential fire hazards.

Replace the hi limit thermal fuse if it becomes faulty due to wear and tear, a buildup of lint, or exposure to high temperatures over time. A malfunctioning fuse can compromise the dryer’s ability to regulate heat properly.

Symptoms of a bad hi limit thermal fuse include:

• The dryer not heating
• The dryer shutting off unexpectedly during a cycle
• No response from the dryer when attempting to start a cycle
• Extended drying times due to lack of heat

This OEM LG part is also compatible with Sears/Kenmore models.

Replace your dryer drum seal when clothes take longer to dry or you notice lint buildup. Maintains heat efficiency and prevents air leaks. Confirm fit with your model number.

The Hi Limit Thermostat Assembly is an OEM part for LG dryers. This thermostat monitors and regulates the temperature within the dryer to prevent overheating, ensuring safe and efficient operation. It acts as a safety device that shuts off the heating element if the dryer exceeds a certain temperature, protecting the appliance and your home from potential fire hazards.

Over time, the hi limit thermostat can fail due to wear and tear, electrical issues, or repeated exposure to high temperatures. If the thermostat becomes faulty, it can lead to improper temperature regulation within the dryer.

Symptoms of a bad hi limit thermostat include:

• The dryer overheating
• The dryer not heating at all
• The dryer shutting off mid-cycle
• Extended drying times due to inconsistent heating

This OEM LG part is also compatible with Sears/Kenmore models.

Thread-forming fastener that secures panels, brackets, and internal components. Replace this screw if it's missing, stripped, or damaged during repairs.

This kit includes the high limit thermostat and thermal cut-off fuse that protect the dryer from overheating. The thermostat monitors the exhaust temperature and shuts off the heating element if it gets too hot, while the thermal fuse acts as a one-time safety device that permanently breaks the circuit during a dangerous overheat condition. Replace these components if the dryer won't heat, shuts off prematurely, or won't start at all - a blown thermal fuse is a common cause of a completely non-functional dryer.

This is the top plate assembly that forms the upper exterior surface of the dryer. It provides structural support and a finished appearance to the top of the unit. Replace this panel if it is dented, scratched, rusted, or warped, or if the mounting tabs are broken and the panel no longer sits securely.

Dryer won't tumble or makes loud noise? This complete drum assembly restores proper rotation and quiet operation. Major repair, 2-3 hours for experienced DIYers.

This balance weight is the washer counterweight that helps stabilize the tub during spin cycles to reduce vibration and noise. Replaces a worn or damaged weight to restore smoother, quieter operation. What it does:

• Counterbalances the washer drum to minimize shaking and excessive movement during spin cycles
• Helps prevent banging or knocking noises caused by an unbalanced tub
• Supports even load distribution to reduce stress on suspension components
• Used when a cracked, loose, or missing weight is causing vibration issues

• One balance weight (counterweight)

• Disconnect power and water supply before starting any repair
• Support the tub or cabinet when removing/installing the weight to avoid sudden movement
• Tighten mounting hardware to OEM torque if specified; use the factory fasteners when available

LED light illuminates your dryer drum for easy viewing during operation. Replace when light dims, flickers, or burns out. Verify fit with your model.

Fix improper airflow or loose connections in your dryer with this connector nozzle. Restores correct routing and reduces leaks. Direct-fit replacement.

This duct assembly channels exhaust from the appliance to the home vent, restoring proper airflow and helping reduce lint and moisture buildup. It's a direct-fit replacement for the original ducting on compatible LG units. What it does:

• Directs heated air and moisture from the appliance to the exterior vent
• Replaces damaged, crushed or disconnected ductwork that can restrict airflow
• Helps reduce lint accumulation in the cabinet/vent path when installed and maintained
• Restores a sealed connection between the appliance outlet and household venting

• Disconnect power and unplug the appliance before beginning any repair
• Follow for disassembly and routing; use proper clamps or screws to secure connections
• Inspect connected gaskets, clamps and the external vent path; replace or clean as needed
• Do not operate the appliance with obstructed or damaged venting; clean lint regularly to reduce fire risk

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

This is an authentic OEM drum support roller sourced directly from the manufacturer for use in clothes dryers. During the drying cycle, the drum turns and tosses the clothes around to distribute heat. This drum support roller holds the drum in place as it rotates. Over time, the heat from the dryer can lead to the roller becoming worn. If the dryer is making squealing sounds or thumping when operating, the support roller is worn out and should be replaced. Before replacing the drum support roller, make sure the power is disconnected from the dryer. Remove the top and front panel of the dryer to reach the drum. The idler pulley and dryer belt are underneath the drum; remove these and then take the drum out of the unit and set it aside. Remove the mounting bracket holding the worn drum support roller. Remove and replace the worn roller. While the dryer is apart, inspect the remaining support rollers. Reverse the steps used and put the dryer back together. Power the dryer and make sure the drum turns.This is a black and white, rubber and metal part that is individually sold. It does not come with assembly hardware. This drum support roller is designed for dryers manufactured by LG, Kenmore, and General Electric.

Taptite screw secures dryer panels, brackets, and covers to sheet metal or plastic. Replace if missing, stripped, or damaged during repairs.

Captures lint and debris from laundry to prevent vent clogs. Replace if torn, cracked, or clothes snag on it. Confirm fit with your model number.

Note: Due to manufacturer changes, if you are replacing the lint screen housing [MCK49049101] you must order lint screen filter part number [ADQ56656403].

Dryer stops mid-cycle or won't start? This door latch assembly secures the door to keep your dryer running. Simple 2-minute DIY fix for most models.

Houses the lint filter to capture debris during drying. Replace if cracked, causing clothes to snag or tear. Confirm fit with your model number.

Note: Due to manufacturer changes to this part, you will also need to order lint filter part number ADQ56656403. To purchase the guide and filter in a kit, order part number 383EEL3002Q.

Replace missing or stripped taptite screws that secure panels and internal components. This thread-forming screw creates a tight hold to eliminate rattles.

This is a safety switch assembly that detects whether the dryer door is open or closed. It signals the control board to stop the drum and heating element when the door is opened during a cycle. Replace this switch if the dryer will not start, stops mid-cycle unexpectedly, or continues running with the door open.

Secures the lint filter in proper position to prevent clothes snagging. Replace if cracked, warped, or filter sits unevenly. Confirm fit with your model.

Cover that fits over the dryer's lint filter duct area. Replace if cracked, broken, or missing to keep items from falling into the duct when filter is removed.

Distortion spring that applies tension within the dryer mechanism. Replace if fatigued, broken, or missing to restore proper tension and assembly function.

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

Snap-in hole cap covers unused openings on your dryer cabinet or control panel. Replace cracked, broken, or missing caps to restore a finished look.

Dryer won't auto dry or cycles run too long? This moisture sensor wire harness connects sensor bars to control. Restores accurate dry cycles. DIY-friendly.

This is a mounting bracket that holds the moisture sensor in place inside the dryer drum area. The moisture sensor detects how wet the clothes are and signals the dryer to stop when they are dry. Replace this holder if it is cracked, broken, or missing, which can cause the moisture sensor to shift out of position and lead to clothes being over-dried or under-dried.

This is the rear tub drum for the washer's drum assembly; it supports the inner drum and helps keep loads balanced so the washer can tumble and spin properly. Use this part to restore stable drum rotation and reduce rubbing or banging noises. What it does:

• Supports the inner wash basket and maintains proper alignment during spin cycles
• Keeps the drum centered to prevent rubbing against the cabinet or seal
• Helps reduce loud banging, wobbling or excessive vibration during operation
• Works with the tub seals, bearings and suspension to maintain smooth rotation

• One rear tub drum

• Disconnect power and water before beginning any repair
• This is a major drum component; expect to remove the outer cabinet and other assemblies to access it
• Support the inner drum while separating components; bearings, seal and hardware may need inspection or transfer

Decorative guard panel for dryers. Covers and protects internal components while providing a finished appearance. Replace if cracked, broken, or missing.

The Door Strike is an OEM part for LG dryers. This part engages with the door catch to keep the dryer door securely closed during operation. The door strike is essential for ensuring the door remains tightly shut, allowing the dryer to function efficiently and safely.

Causes of a bad door strike can include wear and tear from regular use, damage from slamming the door, or misalignment issues that prevent it from engaging properly with the door catch.

Symptoms of a bad door strike include:

• The dryer door not staying closed
• The dryer not starting due to the door not being securely latched
• Difficulty in latching the door
• Visible damage or wear on the strike

This OEM LG part is also compatible with Sears/Kenmore.

Precision mounting screw for dryers and laundry centers. Replaces missing, stripped, or damaged screws that secure panels, brackets, and assemblies. Restores stability.

This outer door frame replaces the cosmetic trim that surrounds the microwave door, restoring appearance and helping the door seal and latch properly. It's a direct-fit exterior component for a clean, finished look. What it does:

• Replaces damaged, dented or cracked outer door trim that affects the door's appearance
• Restores proper alignment and support for the door's outer assembly
• Helps maintain a consistent exterior finish and protects internal door components
• Commonly used when the door shows visible wear, cracks, or cosmetic damage

• Designed for direct replacement; follow the microwave's service manual for disassembly and reassembly steps
• Disconnect power to the appliance before beginning work to avoid electrical hazards
• Handle the door and frame carefully to avoid scratching the finish; use soft protection and non-marring tools

Seals your dryer door to prevent heat loss and improve drying efficiency. Replace if torn, cracked, or causing air leaks. Confirm fit with your model number.

This small damper mounts near the dryer door hinge and cushions the door's movement to prevent it from slamming or bouncing when opened or closed. It absorbs impact and reduces stress on the hinge mechanism. Replace this part if the dryer door slams shut forcefully, swings freely without resistance, or if the existing damper is cracked or missing.

The Generator Assembly is an OEM part for LG electric dryers. This crucial assembly houses the heating element that supplies warmth to dry clothes.

Symptoms of a bad generator assembly include:

• Inability to achieve proper drying temperatures
• Drying cycle taking excessively long times
• Insufficient or incomplete drying of clothes loads
• Odor or smoke emanating from dryer interior

Causes of failure can be cracks in insulating materials allowing electricity leaks, broken or corroded terminal connections, or general carbon buildup over years of use.

Replace yours today with this genuine OEM LG assembly to restore fast and efficient drying performance. New heating elements help eliminate safety concerns. This replacement part is compatible with some Samsung, GE, and Kenmore dryer models.

This inlet hose carries water from your home's supply line into the appliance. Replacing a cracked, kinked, or leaking hose restores proper water flow and helps prevent leaks and fill-related errors.

• Connects the household water supply to the unit's fill circuit
• Provides a sealed path for incoming water
• Damage can cause leaks, restricted flow, or fill errors
• Common signs: slow/no fill, visible leaks, kinks, bulges, or brittle tubing

• Unplug the appliance and turn off the water supply before service.
• Place a towel or pan to catch residual water; relieve line pressure before disconnecting.
• Route the new hose without sharp bends; hand-start threads, then snug—do not overtighten.
• Restore water and power; check all connections for leaks.

Fix a dryer that won't start, stops mid-cycle, or has intermittent power issues with this wire harness. Connects electrical components. Moderate DIY repair.

Secures and supports dryer panels and structural components to restore proper alignment. Replace if cracked, broken, or worn to stop panel rattling.

Fix loud banging, grinding noise, or poor drying performance with a new dryer blower wheel. Restores proper airflow through drum and exhaust vent.

This is a fastener and retainer assembly that secures the blower wheel to the motor shaft inside a dryer. It keeps the blower wheel firmly in place so it can properly circulate hot air through the drum and out the exhaust vent. Replace this assembly if the blower wheel wobbles, makes rattling or squealing noises, or if the retainer nut is stripped or broken, causing poor airflow and longer drying times.

Blower housing assembly for dryer that channels heated air from the drum to the exhaust. Replaces a cracked or damaged housing to restore proper airflow and help the dryer dry more efficiently and quietly. What it does:

• Channels heated air from the drum to the exhaust and supports the blower wheel.
• Restores airflow when a damaged or cracked housing is restricting ventilation.
• Commonly used to address reduced drying performance and longer dry times.
• Can also resolve unusual rattling or grinding noises coming from the lower front of the dryer.

• Disconnect power (and gas, if applicable) before beginning work; wear eye protection and gloves.
• Remove access panels and disconnect vent/ducting per your model's service instructions to reach the blower housing.
• Inspect the blower wheel and surrounding seals/gaskets while the housing is out; replace damaged components as needed.
• Reassemble all panels and venting securely and test the dryer for proper airflow and operation after installation.

Base bracket for dryer installation and structural support. Replace if your original bracket is cracked, broken, bent, or missing to restore proper stability.

Duct assembly channels air from dryer drum to blower and exhaust. Replace if cracked, warped, or missing to restore proper airflow and prevent lint bypass.

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

This adjustable leveling leg screws into the dryer base to support and stabilize the cabinet. Replacing a worn or missing foot helps level the appliance, reduce vibration and noise, and keep it steady on uneven floors.

• Provides threaded height adjustment to properly level the dryer
• Stabilizes the cabinet to minimize rocking, vibration, and walking
• Replaces a broken, worn, or missing foot
• Common symptoms: dryer wobbles, is hard to level, or makes rattling/vibration noise

• Disconnect power; shut off gas supply for gas models
• With a helper, carefully tilt or raise the dryer for access
• Unscrew the old leg; thread the new leg into the base by hand, then adjust with a wrench until the dryer sits level and stable
• Ensure all legs contact the floor and the dryer does not rock

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

Protective cover shields internal wiring and electrical terminals in your dryer. Replace if cracked, broken, or missing to prevent accidental contact.

Safety cover cap for dryers and laundry centers. Protects internal components and covers exposed areas. Replace if cracked, broken, or missing.

Metal mounting bracket that secures internal dryer components to the frame. Replace if cracked, bent, or broken to restore proper alignment and stability.

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

Maintains tension on your dryer's drum belt for smooth rotation. Replace if pulley wheel is cracked, shaft worn, or assembly moves excessively during operation.

Idler pulley maintains tension on the dryer belt. Replace if worn, cracked, or causing belt slippage. Installs between motor and drum support system.

This replacement screw secures appliance components in their proper position. Use it to restore a tight, rattle-free fit when the original fastener is missing, stripped, or corroded. What it does:

• Fastens brackets, panels, or trim to keep assemblies aligned and secure
• Helps prevent vibration, rattling, and gaps from loose hardware
• Restores proper attachment when a screw is lost, worn, or damaged
• Common symptoms: loose panel/handle, misalignment, rattling, or a missing screw

• Disconnect power; shut off water or gas before service
• Match location to the original; start threads by hand to avoid cross-threading
• Use the correct driver bit; do not overtighten (especially into plastic)
• If the original hole is stripped, repair threads before installing the new screw

Self-tapping screw secures panels, brackets, and components inside your appliance. Replace stripped, corroded, or missing screws to restore secure fit.

Stationary rack that installs inside your dryer drum to hold shoes, sweaters, and delicates that shouldn't tumble. Replace if cracked, broken, or missing.

This connector nozzle attaches to the appliance's nozzle assembly to route fluid through the system and help maintain a sealed connection. It replaces a worn or cracked nozzle connector to restore proper flow and reduce leaks. What it does:

• Provides a secure connection point for the nozzle assembly, directing fluid through the correct pathway
• Restores a sealed joint to prevent drips or steady leaks at the nozzle area
• Helps eliminate flow interruptions caused by a cracked, split, or damaged connector
• Works as a direct-fit replacement when the original connector is broken or degraded

• One connector nozzle

• Turn off power and shut off the water supply before starting any repair
• Remove only the components necessary to access the nozzle area; use basic hand tools
• Check seals and adjoining hoses for wear and replace if needed to ensure a leak-free connection

Dryer not steaming or refreshing clothes? This water inlet valve controls the steam cycle. Fixes mineral buildup and flow issues. Moderate DIY repair.

Accessory assembly for dryers. Installs on the exterior or interior to provide additional functionality. Replace if cracked, broken, or missing.

Fix leaks or poor water flow with a new washer inlet hose. This part channels household water supply into your machine for proper filling and operation.

This pipe connector joins appliance water tubing to the inlet assembly, restoring a secure, leak-resistant connection so the dispenser or ice-making system can get a steady water supply. Ideal when fittings are cracked or worn. What it does:

• Creates a watertight connection between supply tubing and the appliance inlet/valve
• Stops leaks caused by cracked, split, or loose fittings at the tubing junction
• Restores proper water flow to dispensers and ice makers when a bad connector is the cause
• Helps prevent water pooling and potential damage from slow leaks

• Turn off water supply and disconnect power before replacing the connector
• Inspect tubing ends for damage and trim squarely if needed before installing
• Use correct tools and tighten fittings per manufacturer guidance; do not overtighten
• After installation, restore water and power and check carefully for leaks

If your washer won't fill with water or leaks during fill cycles, a damaged inlet hose is often the cause. This hose restores proper water flow.

This side venting kit allows you to redirect your dryer's exhaust air out through a side wall instead of the back of the unit. It includes the necessary ductwork and connections to safely route hot, moist air outside your home. Use this kit when your dryer installation requires side venting due to space constraints or structural limitations.
