Parts for Ge EWA2500A0WW: Washer Parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

White. Left hand side

White. Right had side

This washer water level pressure switch senses tub fill via air pressure and tells the control when to stop filling and advance. Replacing a failed switch restores accurate water levels to prevent overfilling, underfilling, and cycle stalls.

• Monitors air pressure from the tub through a small hose to determine the selected water level
• Signals the timer/control to open/close the inlet valves and move the cycle to agitation/spin
• Symptoms include overfilling or not stopping fill, little or no fill, or cycles that won't advance because "full" isn't detected
• Water level doesn't match the selector setting or changes unpredictably

• Disconnect power and shut off water supply before servicing
• Access the control console; label or photograph wire locations and transfer them to the new switch one at a time
• Move the existing pressure hose to the new switch; ensure the hose is clear, not kinked or cracked, and fully seated
• Reinstall the knob/control panel and test fill at multiple level settings; access and steps may vary by model

Size: 8-18 ab.

The Button is an OEM component for GE top-load washers. Located on the control panel, this button actuates a specific function such as starting or pausing the cycle. Designed for durability, the textured plastic construction withstands millions of presses over decades of use.

Symptoms of a bad button include:

• The button sticking in the depressed position
• Failure to trigger the assigned function when pressed
• Cracks developing in the plastic face over time

Causes may consist of cracked circuitry behind the panel from water intrusion or repeated impact. General wear reducing button sensitivity also occurs.

This GE button restores full operation for select models including those by Hotpoint, RCA, and compatible Kenmore lines.

The Control Knob and Clip is an OEM part for GE washing machines and dryers. It attaches directly to the control shaft and is used to set the machine's cycles and settings. This knob allows for easy adjustment of washing or drying operations, making it a user-friendly interface for managing the appliance's functions.

Symptoms of a bad Control Knob and Clip include:

• The knob failing to engage the control shaft, resulting in no response when turned.
• Cracks or breaks in the knob, making it difficult to grasp or turn.
• The knob slipping or spinning freely without changing settings, indicating that the clip may be worn or broken.

Causes of a bad control knob and clip can include physical damage from excessive force, wear and tear from frequent use, or degradation of the materials due to age or environmental factors.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Knob Clip is an OEM part for GE washing machines and dryers. This small but crucial component is designed to secure the control knob to the appliance's control panel.

Over time, knob clips can wear out or break due to frequent use or accidental damage. When this happens, the control knob may become loose, fall off easily, or fail to engage the control panel properly, making it difficult to set the appliance to the desired cycle or function.

Symptoms of a bad Knob Clip include:

• The control knob is loose or falls off the panel easily.
• Difficulty in adjusting settings due to a loose knob.
• The knob does not stay in place or slips when turned.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 8-18 b.

Size: 8-18 b.

This lid bumper cushions your washer lid where it meets the top panel, softening closure and protecting the finish. Replacing worn or missing bumpers reduces slamming and rattles for a quieter, smoother close.

• Cushions contact between the lid and top panel to reduce slamming noise
• Protects painted/enamel surfaces from chips and scratches at contact points
• Helps the lid sit level and minimizes vibration or rattling
• Replace if the bumper is missing, cracked, flattened, or hardened

• Disconnect power to the washer before servicing.
• Open the lid and locate the bumper(s) at the front corners (on the lid underside or top panel lip).
• Pull the old bumper straight out; clean the mounting hole.
• Press the new bumper firmly into the hole until fully seated and flush; test lid closure.

This small bushing fits the washer's lid hinge to provide a smooth, stable pivot. Replacing a worn hinge bushing restores proper lid alignment and helps reduce squeaks, rubbing, or excessive play when opening and closing the lid. What it does:

• Acts as a low-friction sleeve between the hinge pin and bracket
• Supports smooth lid movement and helps maintain alignment
• Reduces metal-on-metal wear and hinge noise
• Symptoms of wear can include squeaking, binding, scraping, or a loose/wobbly lid

• 1 hinge bushing

• Disconnect power before servicing
• Support the lid to prevent it from dropping when the hinge is loosened
• Remove hinge hardware to access and swap the bushing; reassemble and check lid alignment
• Many models use a bushing on each hinge—inspect both sides and replace as needed

This double-style hinge bushing supports the washer lid hinge pin and provides a smooth bearing surface. Replacing a worn bushing restores quiet, even lid movement and helps keep the lid properly aligned over time.

• Supports and centers the lid at the hinge
• Provides a low-friction bearing surface for the hinge pin/rod
• Helps reduce squeaking, looseness, and metal-on-metal wear
• Can help resolve a wobbly, misaligned, or scraping lid

• Disconnect power before servicing; support the lid to prevent dropping
• Remove the hinge pin/rod or screws as your model requires to access the bushing
• Pry out the worn bushing and press the new bushing fully into the hinge opening
• Reassemble and check lid operation; consider replacing the opposite-side bushing if worn

This short wireform hinge secures and guides a door or panel so it opens and closes smoothly. It restores proper alignment and reduces binding or sag that can prevent a door from seating correctly. What it does:

• Provides pivot support for a door or access panel to maintain correct motion and alignment
• Replaces bent, worn, or broken hinge hardware that causes uneven closing or door sag
• Reduces noise and binding during opening/closing when the original hinge has lost shape
• Works with existing hinge mounts and fasteners when in good condition

• One short wireform hinge

• Designed for straightforward replacement; verify correct hinge orientation before removing the old part
• Use appropriate hand tools and keep fasteners organized for reassembly
• Disconnect power or gas and follow appliance safety instructions when replacing hinges on powered appliances
• Address those issues before installing the new hinge

A single replacement screw used to secure appliance panels, trim, and internal brackets so components stay aligned and reduce rattling. Simple, direct-fit fastener for restoring proper mounting and stable operation. What it does:

• Secures panels, mounting brackets, trim pieces and other appliance components
• Helps stop rattling, vibration, or loose panels caused by missing or stripped fasteners
• Restores proper alignment of doors and access panels when original screw is lost or damaged
• Matches the OEM fastening point for a straightforward hardware replacement

• Disconnect power to the appliance before working on electrical components or access panels
• Use the correct screwdriver to avoid stripping the head; match drive type to the screw
• Tighten firmly but do not overtighten—stop when snug to avoid damaging threads or parts
• Keep removed fasteners organized and compare with the replacement to ensure correct fit

The Fabric Softener Dispenser is an OEM replacement part for GE washers. It is located on the top of the agitator. This dispenser allows for easy addition of fabric softener or other washing aids at the ideal time in the cycle. With a simple twist and pour into the reservoir, it then evenly releases the solution to condition clothes during the final rinse.

Causes of a bad dispenser can include cracks or leaks allowing premature discharge into the wash drum. Mineral buildup may also clog the release nozzles.

Symptoms of a bad dispenser include:

• Fabric softener not fully dispensing or splashing outside the dispenser cup
• Stains or residue transferring onto clothes from residues
• Strong chemical smells if the contents extra release early

This GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Agitator Assembly is an OEM part for GE washing machines. This essential component is responsible for moving clothes during the wash cycle, ensuring thorough cleaning by continually shifting the laundry within the drum. The agitator's design includes fins or vanes that help to circulate water and detergent through the clothes, effectively removing dirt without causing excessive wear to the fabric.

Symptoms of a bad Agitator Assembly include:

• The agitator not moving or only moving weakly during the wash cycle.
• Unusual noises like grinding or thumping indicating mechanical issues.
• Clothes coming out still dirty or less clean than expected, suggesting insufficient agitation.
• The top portion of the agitator moving independently from the base, known as "stripped" agitator dogs.

Causes of a bad agitator can include worn out mechanical parts such as gears or bearings, a damaged drive shaft, or the agitator becoming detached from the transmission due to loosening of the securing bolt.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models,

Pro Tip: When replacing the agitator, also consider replacing the agitator coupling (WH49X10042).

The Washer Agitator Coupler Kit is an OEM part for GE washing machines. This kit includes the coupler component that connects the agitator to the washing machine's transmission. It plays a pivotal role in the washing process by transmitting rotational force from the motor to the agitator, enabling it to move back and forth and effectively clean clothes.

Symptoms of a bad Washer Agitator Coupler include:

• The agitator failing to move or moving weakly during cycles, which can result in poorly washed clothes.
• Unusual noises from the washing machine during operation, indicating a mechanical issue.
• The agitator slipping or feeling loose when manually pushed or pulled.

Causes of a bad agitator coupler can include wear and tear from regular use, excessive load sizes that strain the agitator, or material fatigue that weakens the coupler over time.

This OEM replacement part is essential for restoring proper functionality to your GE washing machine and is also compatible with Hotpoint, RCA, and some Kenmore models.

The Drain Pump Inlet Hose is an OEM part for GE washing machines. This hose plays a crucial role in the laundry process, ensuring that used water is efficiently removed from the washer, which helps in preventing standing water, odors, and potential mold growth inside the appliance.

Causes for issues with the drain pump inlet hose often involve natural wear and tear from constant exposure to water and laundry chemicals, physical damage from overloading or moving the washer, or blockages from lint, small garments, or other debris.

Symptoms of a malfunctioning Drain Pump Inlet Hose include:

• Water leaking from the bottom or back of the washing machine
• Slower than normal drain times, indicating possible clogs
• Visible wear, cracks, or damage to the hose

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Drain Hose is an OEM part for GE washing machines. It is specifically designed to channel used water out of the washer and into the household drainage system.

Causes of a bad drain hose can include physical damage from movement or installation, clogging from lint and debris, or degradation of the hose material over time, leading to leaks and inefficiency.

Symptoms of a bad Drain Hose include:

• Water leaking from the back or underside of the washing machine
• Pools of water around the area where the washing machine is installed
• Signs of wear or damage to the hose, such as cracks, holes, or bulging

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This tub clamp secures the washer tub or associated hoses to keep components aligned and sealed during operation. It replaces a worn or broken clamp to reduce movement and help prevent leaks and noise. What it does:

• Holds the tub/hose connection or tub assembly parts together to maintain a tight fit
• Helps prevent leaks caused by loose or damaged clamps
• Reduces rubbing, vibration, and associated noise from a loose tub assembly
• Restores proper component alignment after clamp failure

• Disconnect power and turn off water supply before starting any repair
• Inspect mating parts (tub, hoses, mounting points) for damage and clean before installing
• Use appropriate clamp pliers or screwdriver as required; ensure clamp is seated and tightened evenly

5/16-18 tpt ihw s n

The Washer Agitator Coupler Kit is an OEM part for GE washing machines. This kit includes the coupler component that connects the agitator to the washing machine's transmission. It plays a pivotal role in the washing process by transmitting rotational force from the motor to the agitator, enabling it to move back and forth and effectively clean clothes.

Symptoms of a bad Washer Agitator Coupler include:

• The agitator failing to move or moving weakly during cycles, which can result in poorly washed clothes.
• Unusual noises from the washing machine during operation, indicating a mechanical issue.
• The agitator slipping or feeling loose when manually pushed or pulled.

Causes of a bad agitator coupler can include wear and tear from regular use, excessive load sizes that strain the agitator, or material fatigue that weakens the coupler over time.

This OEM replacement part is essential for restoring proper functionality to your GE washing machine and is also compatible with Hotpoint, RCA, and some Kenmore models.

This Tub Seal is an OEM replacement part for GE washing machines that is responsible for preventing water from leaking from the tub. This part is located at the base of the washing machine tub and creates a seal between the tub and the transmission to prevent water from leaking out during the wash cycle.

This part fixes the following symptoms-

• Water leaking from the underside of the washing machine.
• A musty or mildew smell coming from the machine.
• Unusual noises during use.

Causes of a bad tub seal can range from normal wear and tear to a misaligned tub or an overloaded washing machine, which puts extra pressure on the seal. Additionally, the buildup of hard water minerals can degrade the seal's material over time.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This tub-bearing split ring is an OEM replacement part designed for GE washing machines. This part measures 2 inches in diameter. It is positioned between the inner and outer tubs to hold the tub bearing inside the outer tub. The Tub Bearing Split Ring not only supports the tub/hub assembly but also ensures smooth operation.

Symptoms of a bad Tub Bearing Split Ring include:

• Excessive vibration or tub imbalance during spins
• Loud clunking, knocking or grinding sounds
• Reduced spin speeds or inability to achieve high RPMs
• Premature tub or bearing wear requiring replacement

Causes can be extended use over time which leads to wear and fatigue of the split ring material. Cracks or breaks can develop, reducing its stability and load-bearing capacity.

This genuine GE replacement part is also compatible with Hotpoint, RCA and some Kenmore front-load models.

NOTE: For the washer outer tub seal order WH02X10383.

This tub-bearing washer is an OEM replacement part for GE washing machines. It is designed to keep your washing machine's inside tub spinning smoothly during cycles. The bearing Measures approximately 1 inch in inner diameter and 2 inches in outer diameter.

Causes of a bad tub-bearing washer can include wear and tear from extended use. Exposure to vibrations during high-speed spins may cause fatigue of the washer material over time as well.

Symptoms of a bad tub bearing washer include:

• Excessive tub vibration or imbalance at high speeds
• Abnormal noises such as grinding or clicking sounds
• Premature failure of the tub bearing itself
• Reduced spin capabilities or inability to hit maximum RPM

This OEM part is also compatible with Hotpoint, RCA and select Kenmore front-load washers.

The Hub Washer is an OEM part for GE washing machines, designed to fit between the transmission and the inner tub. The hub washer acts as both a seal and a buffer, reducing wear on both the transmission and the tub by absorbing some of the operational stresses.

Causes of damage to the hub washer often include normal wear and tear from repeated use, exposure to harsh detergents or water conditions that can degrade the material, or overloading of the washing machine, which puts additional stress on mechanical components.

Symptoms of a bad Hub Washer include:

• Leaks from the bottom of the washing machine
• Unusual noises during the wash or spin cycles, such as grinding or squeaking
• Difficulty in agitating or spinning, which could be caused by excessive friction or misalignment due to a worn or damaged hub washer.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This tub assembly replaces a cracked or leaking wash tub to restore proper water containment and drum support for your washer, helping reduce leaks, rubbing noises, and abnormal vibration during cycles. What it does:

• Provides the sealed reservoir that holds wash water and supports the inner drum during wash and spin cycles
• Helps stop or reduce water leaks caused by cracked or damaged tubs
• Can resolve rubbing, scraping, or thumping noises from a warped or broken tub
• Helps stabilize the drum to reduce vibration and improve spin performance

• Disconnect power and shut off water supply before starting; wear gloves and eye protection
• Tub assemblies are heavy and bulky—use two people or appropriate lifting equipment
• Follow the washer OEM service manual for disassembly, seal transfer/replacement, and torque specifications
• If bearings, seals, or mounting hardware show wear, replace them per OEM guidance for a complete repair

A replacement baffle screw and flat washer used to secure the baffle or trim piece in ovens and ranges. Restores proper attachment to reduce vibration and keep the baffle aligned for normal operation. What it does

• Secures the baffle or trim to the oven/range body and prevents movement or rattling.
• Replaces missing, stripped, or corroded mounting hardware that can cause loose or misaligned baffles.
• Helps maintain a tight fit so trim and baffle sit flush with surrounding panels.
• Small, direct-replacement fastener for original baffle mounting points.

• Disconnect power and allow the appliance to cool before accessing internal panels.
• Use the matching size screwdriver; start threads by hand to avoid cross-threading.
• Tighten until snug — avoid over-tightening, which can strip threads or deform the washer.
• Repair or replace the mounting bracket before installing this hardware.

The Inner Tub Mounting is an OEM part for GE washing machines. It secures the inner tub to the washer's outer tub, providing stability and support during the wash and spin cycles. This mounting component is crucial for the proper alignment and operation of the washer's drum.

Causes of a bad mounting include excessive loads, continuous use over time, or physical damage due to impacts or misalignment. A faulty inner tub mounting can lead to significant operational issues and potential damage to other components.

Symptoms of a bad inner tub mounting include:

• Excessive vibration or shaking during wash or spin cycles
• Unusual noises or banging sounds
• The inner tub appearing misaligned or loose
• Leaks from the washer during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Hub Nut is an OEM part for GE washing machines. This component secures the inner tub to the drive mechanism, ensuring that it remains in place during the agitation and spinning cycles. This lock-down nut is reverse threaded, meaning that it is loosed by rotating it clockwise. For easier removal of the old nut, it is recommended to use the tub nut spanner wrench WX5X1325.

Symptoms of a bad Hub Nut include:

• Unusual noises like banging or grinding during the spin cycle.
• The inner tub moving excessively or becoming loose.
• Leakage around the center of the machine, indicating a seal failure possibly related to a loose hub nut.
• Inefficiency in spinning or agitating clothes properly.

Causes of a bad hub nut can include corrosion due to exposure to water and detergent, improper initial installation, or loosening over time from the vibration and movement of the washing machine.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Hose is not required. Kit includes bleach funnel, clamps, wire tie, and cap.

Outer tub cover kit that replaces a cracked or missing washer tub cover, protecting the inner tub and helping stop rubbing, noise and fabric snags. Restores proper tub clearance for smoother drum movement and quieter operation. What it does:

• Covers the outer wash tub to protect the inner tub and fasteners from contact and wear
• Helps stop rubbing, scraping or thumping sounds caused by tub-to-tub contact
• Reduces the chance of clothes catching between the inner and outer tubs
• Restores correct tub spacing so the drum spins without interference

• Disconnect power and water supply before starting any repair
• Access may require removing the agitator or inner tub and using basic hand tools
• Inspect mounting clips, seals and surrounding components and replace any damaged items
• Test the washer on a short cycle after installation to ensure proper fit and quiet operation

Size: 14-10 a trt 7/8 s.

Size: 8 - 18 ab.

The Tub Dampening Strap Retainer is an OEM part for GE washing machines. This part holds the tub dampening straps in place, which help to stabilize the washing machine tub during operation.

Causes of a bad retainer can include regular wear and tear, physical damage from heavy loads or impacts, and degradation over time.

Symptoms of a bad tub dampening strap retainer include:

• Excessive vibration or shaking during wash cycles
• Increased noise levels during operation
• The washing machine moving or becoming unbalanced during use
• Visible damage or wear on the retainer or straps

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This locking clip secures a mating part—often a control knob—onto its shaft on select laundry appliances. Replacing a worn or missing clip restores a tight fit so controls stay in place and operate as intended during use.

• Locks a knob, lever, or similar component onto its shaft/post to prevent it from slipping off
• Maintains a firm fit to reduce wobble and intermittent control engagement
• Replace if the clip is bent, fatigued, corroded, or missing
• Typical symptoms include a knob that falls off, feels loose, or spins without engaging

• Disconnect power to the appliance; turn off water supply for washers
• Pull the affected component straight off to access the clip
• Use needle-nose pliers to remove/install the clip; avoid deforming it
• Ensure the clip is fully seated; test for a snug fit before reassembly

This front panel assembly replaces a cracked, worn or damaged console face to restore your appliance's appearance and support the control components. It provides the outer housing for buttons, displays and mounting points. What it does

• Covers and protects the control area from spills, dust and impact.
• Provides mounting locations and alignment for buttons, switches and display components.
• Restores a secure, finished surface when the original panel is cracked, warped or missing.
• Resolves cosmetic issues and loose or misaligned controls that affect operation.

• One panel front assembly.

• Disconnect power (unplug or switch off breaker) before starting any repair.
• Remove any trim, bezels or clips carefully to avoid damaging adjacent parts; keep fasteners for reinstallation.
• Handle edges and mounting tabs gently; some panels use plastic clips that can break if forced.
• If the control components or display must be transferred, note connector locations and orientation before disconnecting.

This front panel assembly replaces a cracked, worn or damaged console face to restore your appliance's appearance and support the control components. It provides the outer housing for buttons, displays and mounting points. What it does

• Covers and protects the control area from spills, dust and impact.
• Provides mounting locations and alignment for buttons, switches and display components.
• Restores a secure, finished surface when the original panel is cracked, warped or missing.
• Resolves cosmetic issues and loose or misaligned controls that affect operation.

• One panel front assembly.

• Disconnect power (unplug or switch off breaker) before starting any repair.
• Remove any trim, bezels or clips carefully to avoid damaging adjacent parts; keep fasteners for reinstallation.
• Handle edges and mounting tabs gently; some panels use plastic clips that can break if forced.
• If the control components or display must be transferred, note connector locations and orientation before disconnecting.

This shipping bar assembly secures the oven door and internal components during transport to prevent movement and damage. Replacing a damaged or missing shipping bar helps ensure the range or oven door stays protected while moving the appliance. What it does:

• Holds the oven door and internal parts in place during shipment to reduce jostling and impact
• Prevents door misalignment or damage caused by transit
• Helps avoid rattling or loose parts after relocation
• Used only for transport/protection; remove before regular appliance operation if instructed by manufacturer

• One shipping bar assembly

• Intended for use during shipping/transport — confirm removal instructions in your owner's manual before operating the appliance
• Install or remove with the appliance powered off and according to manufacturer guidance
• Keep small fasteners and clips secure; replace any missing hardware with OEM-specified parts

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.

A small push-in plug button used to fill or cover an access hole or trim opening and restore a finished appearance. Designed to snap into place for a secure fit and to keep dirt and moisture out. What it does:

• Covers unused holes or fastener openings to restore a finished look
• Helps keep dirt, moisture, and debris from entering cavities
• Holds trim or panels flush by filling gaps where a fastener or post is missing
• Commonly replaced when cracked, lost, loose, or causing rattles or gaps

• One plug button

• Disconnect power to the appliance before accessing panels or trim
• Typically snaps into place—press firmly until seated; may require removing trim for access
• Avoid prying with sharp tools that can damage surrounding surfaces
• Replace only with the exact part number to ensure proper fit and finish

Alignment pin keeps the appliance door hinge aligned so the door closes evenly and seals correctly. Replacing a damaged pin restores proper door fit and helps stop sagging, rubbing, or uneven gaps. What it does:

• Positions and secures the door hinge during normal operation
• Restores correct hinge alignment when pins are worn or bent
• Helps eliminate door sag, misalignment, grinding, or difficulty closing
• Works with the hinge assembly to maintain an even seal and proper door movement

• Disconnect power to the appliance before beginning any repair; ensure the appliance is stable and cool.
• Support the door or hinge assembly while removing and installing the pin to avoid dropping or misaligning heavy components.
• Use basic hand tools; ensure pin orientation and full engagement in the hinge before testing.
• Keep small parts and fasteners secure during reassembly and test the door several times to ensure proper operation.

This clip cover is a small snap-in plastic trim piece that protects and secures appliance panels or trim, giving a finished look and hiding fasteners. Replaces broken or missing covers to restore appearance and retention. What it does:

• Snaps into place to conceal screws or clip anchors on trim and panels
• Helps hold lightweight trim pieces securely to the cabinet or frame
• Prevents exposed fasteners and reduces snagging or sharp edges
• Useful when cracked, worn or lost covers cause loose or rattling trim

• One clip cover

• Disconnect power or unplug the appliance before accessing panels or trim
• Push the clip cover onto the mating clip or anchor until it snaps fully into place
• Use a small flat tool only to remove; avoid prying on surrounding trim to prevent damage
• Replace any damaged mounting clips before installing the cover for a secure fit

The Lid Assembly is an OEM part for GE washing machines. This part is the lid of the washer. It is essential for securely covering the washer drum, preventing water from splashing out during the wash cycle, and allowing safe operation by ensuring the washer does not run with the lid open.

Causes of a bad lid assembly can include general wear and tear, physical damage from heavy loads or impacts, or issues with the hinges or latch mechanisms.

Symptoms of a bad lid assembly include:

• Difficulty in opening or closing the lid
• Washer not starting or stopping mid-cycle due to a faulty lid switch
• Visible cracks or damage on the lid
• Water leaking from the top of the washer

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This tub shield protects the washer's inner drum edge from wear and keeps clothing and items from catching on the tub lip. It helps reduce fabric snags and prevents damage to the drum opening during normal use. What it does:

• Covers the exposed edge of the inner tub to prevent garments from catching or tearing
• Protects the tub rim from chips, gouges, and wear that can lead to leaks or rough spots
• Helps keep the drum seal area smooth for consistent door/tub engagement
• Commonly replaced when you see fabric snags, visible tub edge damage, or persistent abrasion marks

• One tub shield

• Disconnect power and water supply before starting any repair
• Typically installs around the inner tub lip; may require drum rotation and simple fasteners or clips
• Inspect the tub rim and door seal while replacing the shield; replace damaged seals as needed

This tub shield protects the washer's inner drum edge from wear and keeps clothing and items from catching on the tub lip. It helps reduce fabric snags and prevents damage to the drum opening during normal use. What it does:

• Covers the exposed edge of the inner tub to prevent garments from catching or tearing
• Protects the tub rim from chips, gouges, and wear that can lead to leaks or rough spots
• Helps keep the drum seal area smooth for consistent door/tub engagement
• Commonly replaced when you see fabric snags, visible tub edge damage, or persistent abrasion marks

• One tub shield

• Disconnect power and water supply before starting any repair
• Typically installs around the inner tub lip; may require drum rotation and simple fasteners or clips
• Inspect the tub rim and door seal while replacing the shield; replace damaged seals as needed

Size: 1/4 - 20 b.

Transmission drive pulley nut.

The Suspension Rod & Spring Assembly is an OEM part for GE washing machines. This assembly includes a rod and spring that supports the washer tub, helping to absorb shocks and reduce vibrations during the wash and spin cycles.

Causes of a bad suspension rod & spring assembly can include wear and tear from regular use, excessive loads that strain the components, or damage from impact or mishandling.

Symptoms of a bad suspension rod & spring assembly include:

• Excessive shaking or vibrating during the wash cycle
• Loud banging or thumping noises
• The washer tub being off-balance or tilted
• The washer moving or "walking"

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Suspension Rod & Spring Assembly is an OEM part for GE washing machines. This assembly helps support the washer tub, reducing vibrations and maintaining balance during the wash and spin cycles. It ensures that the washer operates smoothly and minimizes excessive movement.

Causes of a bad suspension rod & spring assembly can include wear and tear from regular use, damage from heavy or unbalanced loads, or corrosion over time. The springs can lose tension, and the rods can become bent or damaged, affecting the washer's stability.

Symptoms of a bad suspension rod & spring assembly include:

• Excessive shaking or vibrating during the wash or spin cycle
• Loud banging noises during operation
• The washer tub appearing unbalanced or leaning to one side
• Clothes not spinning dry effectively

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 10-12 a. Includes 12 screws.

The Suspension Rod Support is an OEM part for GE washing machines. This part maintains the stability of the washing machine's drum by supporting the suspension rods, which help absorb vibrations and shocks during operation.

Causes of a bad suspension rod support can include wear and tear from regular use, corrosion due to exposure to moisture, or physical damage from overloading the washer.

Symptoms of a bad suspension rod support include:

• Excessive shaking or vibrating during the wash cycle
• Loud banging noises
• The washer moving or "walking" during operation
• The drum being off-balance

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This leveling leg threads into the base of your washer to set height and keep the cabinet stable on uneven floors. Replacing worn or missing legs reduces vibration, walking, and noise for smoother, safer operation.

• Provides an adjustable foot to level and support the washer
• Helps reduce vibration, rocking, and "walking" during spin
• Replaces stripped, cracked, or missing leveling feet
• Helps with excessive shaking, rattling noises, or out-of-balance conditions

• Disconnect power and water; pull the washer forward for access.
• Support the appliance to prevent tipping; unscrew the old leg by hand or with pliers.
• Thread the new leg into the base; adjust all feet until level front-to-back and side-to-side.
• Ensure each foot contacts the floor firmly and the cabinet is stable before use.

Includes 12 screws.

Harness to corset & shifter

The Drive Belt is an OEM part for GE washing machines. It functions as a critical component that connects the motor to the drum, transferring power from the motor, which in turn allows the drum to spin during the wash cycle. Made from rubber reinforced with fibers, this belt is designed to withstand the stress of spinning and agitating motions.

Symptoms of a bad Drive Belt include:

• The washing machine drum not spinning,
• A squealing or screeching sound when the washer is running,
• Visible fraying, glazing, or signs of wear on the belt,
• The belt slipping off the motor or drum pulley.

Causes of drive belt failure typically include regular wear and tear from use, overloading of the washer which puts extra strain on the belt, or exposure to oils and other substances that can degrade the rubber.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

For retaining clip separately use WH1X2733. For washers with removable front panel.

These GE screws are a 12-pack of OEM replacement parts responsible for securing and fastening various components and panels in a GE range or oven. These screws are designed with a hexagonal head, which allows for the use of a compatible wrench or socket for tightening. They are commonly used to attach sheet metal panels, brackets, and other parts within the appliance, ensuring that these components remain securely in place during operation.

This part fixes the following symptoms:

• Loose or wobbly parts or panels within the appliance's interior or exterior
• Panels or components falling out of place, creating gaps or exposing internal parts
• Unusual noises or rattling sounds during the appliance's operation

The GE screws can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This hose clamp kit secures the washer's hoses at the pump, tub, or valve connections, helping stop leaks and hose blow-offs. Replace worn or missing clamps to restore a tight, reliable seal during fill, wash, and drain.

• Secures drain, pump, and fill hoses to fittings to maintain a watertight seal
• Helps prevent drips, leaks, and hoses slipping off during vibration
• Replaces clamps that are rusted, stripped, deformed, or missing
• Common symptoms: water leaking at hose joints, loose hose connections, clamp won't tighten
• Useful when installing a new hose, pump, or valve

• Unplug the washer and turn off water supplies; have towels or a pan ready for residual water
• Release and remove old clamps; seat the hose fully over the fitting before installing new clamps
• Tighten evenly and do not overtighten to avoid hose or fitting damage
• Restore power and water, then run a short cycle to check for leaks at each connection

The Water Inlet Fill Spout is an OEM replacement part for GE washing machines. It guides water from the inlet valve to the wash tub for a controlled flow. The fill spout is designed to reduce splashing and ensure that water is evenly distributed within the washing machine.

A bad Water Inlet Fill Spout can be due to cracks or damage from material wear, blockages caused by debris or mineral buildup, or issues with its connection to the inlet valve.

Symptoms of a malfunctioning Water Inlet Fill Spout include:

• Water splashing or leaking during the fill cycle
• Inefficient filling of the washing machine
• Visible damage or cracks in the spout
• Restricted water flow into the wash tub

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Water Inlet Valve is an OEM part for GE washing machines. This component is crucial for controlling the flow of water into the washer during the wash and rinse cycles. It works by opening and closing the solenoids to allow the appropriate amount of hot or cold water to enter the washing machine, based on the selected settings.

Symptoms of a failing Water Inlet Valve include:

• The washing machine not filling with water or filling very slowly
• The washer filling with water even when it is turned off
• Water leaking from the valve area
• The washing machine displaying error codes related to water supply issues
• Inconsistent water temperatures during cycles

Causes of a bad water inlet valve can include mineral deposits or debris clogging the valve, wear and tear on the solenoid coils, or electrical issues such as faulty wiring or connections.

This OEM GE part is also compatible with some models from Hotpoint, RCA, and Kenmore.

Includes 12 washers.

The Washer Fill Hoses are OEM parts for various washing machines, specifically designed to transport hot and cold water from the home's supply lines to the washer. These hoses are essential for the proper functioning of the washing machine, ensuring a steady and reliable flow of water during the wash and rinse cycles. Coming in packs of 2, each hose measures 5 ft.

Causes of bad washer fill hoses can include wear and tear over time, exposure to high water pressure, or damage from kinks and bends. Additionally, hoses can deteriorate due to exposure to harsh water conditions or chemical buildup.

Symptoms of bad washer fill hoses include:

• Leaks or puddles around the washing machine
• Reduced water flow into the washer
• Visible cracks or bulges in the hoses
• The washer taking longer than usual to fill with water

These washer fill hoses are compatible with a variety of washing machine brands and models, ensuring a secure and efficient water supply.

The anti-siphon clip secures the washer's drain hose to a standpipe or laundry tub, maintaining the proper air gap to prevent siphoning and backflow. It keeps the hose stable so the washer fills and drains as intended.

• Maintains an air break at the drain to help stop unintended siphoning
• Holds the drain hose securely to a standpipe or sink/tub
• Helps prevent "filling and draining at the same time" or low water levels
• Helps keep the hose from vibrating loose or popping out during cycles

• Unplug the appliance and shut off water before starting
• Route the drain hose per the installation manual; avoid kinks or submerging the hose end
• Snap the clip onto the hose and fasten it to the standpipe or tub edge
• Run a quick test to verify no leaks and correct hose position

The Drain Hose Clip is an OEM part for GE washing machines. It secures the drain hose to the back of the washer, preventing it from becoming dislodged during operation. This ensures that water is properly directed out of the washer and into the household drain system, preventing leaks and water damage.

Causes of a bad drain hose clip can include wear and tear from regular use, damage from improper handling during installation or maintenance, or breakage due to repeated stress and movement of the washer.

Symptoms of a bad drain hose clip include:

• Water leaking from the back of the washer
• Drain hose detaching or becoming loose during operation
• Difficulty securing the drain hose in place
• Visible damage or cracking on the clip

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: For the entire drain hose, use part number WH41X10096.

The Screw is an OEM part for GE appliances, commonly used in washing machines, dryers, and other household appliances. This screw is designed to secure various components, ensuring they remain properly aligned and fastened during operation. Its precise design and durable construction are tailored to meet the specific requirements of GE appliances.

Over time, screws can become damaged or lost due to regular use, vibration, or during maintenance and repair activities. A missing or damaged screw can lead to loose parts, affecting the overall functionality and safety of the appliance.

Symptoms of a bad or missing screw include:

• Loose or rattling components
• Misalignment of parts
• Noise during operation
• Parts or panels not staying securely in place

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

This flood hose gasket seals the joint where the washer's flood/overflow hose connects to the outer tub. A fresh seal helps stop seepage from the tub area, preventing drips or moisture around the top or rear of the washer.

• Creates a watertight seal at the flood/overflow hose connection to the outer tub
• Helps prevent leaks during fill, wash, and spin
• Typical failure signs: drips from the top/back of the tub, visible cracks or deformation, or a loose hose connection

• Disconnect power and turn off water supply before servicing
• Access the flood hose connection at the tub; remove the hose and old gasket
• Seat the new gasket fully and reconnect the hose securely
• Run a short cycle to check for leaks

The Affresh Washer Cleaner 3 Pack is an OEM cleaning accessory designed specifically for washing machines. This multipack contains 3 packets of a proven formula that helps eliminate odors from the washer tub, door, gasket, and drain areas. Regular cleaning is important to remove dirt, soap scum, mildew, and other residue that can build up over time and lead to odors. The Affresh tablets contain oxygen-powered enzymes and fresh scent boosters that are released during the cleaning cycle to safely and effectively eliminate musty smells.

This multipack of Green 4.2-ounce tablets ensures you have enough doses for consistent cleaning to keep your washer smelling fresh. As the #1 recommended washer cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore washers.
