Maytag Washer Parts

This is the siphon insert for the washer dispenser's bleach and softener compartments. It restores proper siphoning so additives empty at the right time and helps reduce standing water or residue in the drawer.

• Creates the siphon action that draws bleach and fabric softener from their cups during the rinse cycle
• Promotes complete dispensing and consistent rinse performance
• Helps minimize leftover liquid and residue buildup in the dispenser
• Typical symptoms include bleach or softener remaining after the cycle, standing water in the cups, or weak/irregular dispensing

• Disconnect power and turn off water before servicing
• Remove the dispenser drawer; lift out the old siphon from the bleach/softener cup
• Clean any debris in the cup; firmly seat the new siphon, aligned per the cup markings
• Reinstall the drawer and run a rinse cycle to verify proper draw and no leaks

This replacement control knob restores smooth, reliable turning on your appliance's control panel so you can select settings accurately again. It's designed to slide onto the control shaft and provide a secure, easy-grip interface. What it does

• Attaches to the control shaft to let you select settings
• Replaces cracked, stripped, or missing knobs
• Helps ensure the switch or valve engages properly when turned
• Improves grip and appearance on the front panel

• 1 control knob

• Disconnect power; if servicing a gas appliance, also shut off the gas supply
• Pull the old knob straight off the shaft—do not pry against the panel
• Align the new knob with the shaft flats/splines and press straight on without forcing
• Test operation to ensure the knob fully engages the control

This control panel is designed for use with washing machines. It's on the top back area of the appliance and houses a display and several buttons to control various components in the appliance. It's responsible for starting and stopping components, such as the drain pump and drive motor. If the display isn't working or the washer doesn't spin, fill, or drain, the control panel may be causing the issue.If this part is faulty, it should be replaced. Use work gloves for hand protection and pull the washing machine away from the wall to unplug it. Pull the control knob off the front of the console panel and move to the back of the appliance. Take out the screws on the top of the back panel. Push the control panel back while using a putty knife under the right corner to release the mounting clip. Do the same thing on the other side. Document where the wires are connected to the control panel before removing it. Install the new part and reconnect all the wires.This control panel is made for use with Maytag washing machines. It's an authentic OEM replacement part sourced directly from the manufacturer. The part is sold as an individual item.

This replacement hose routes liquid or air between internal components, maintaining a secure, leak-resistant path. Replace a brittle, cracked, or clogged hose to prevent leaks and restore proper flow and sensing performance.

• Provides a sealed pathway between components such as the pump, tub, valve, drain path, or pressure system
• Helps maintain correct water flow or pressure/level sensing
• Common symptoms: leaks, kinks/cracks, standing water, slow/failed drain or fill, related error codes
• Restores reliable connections when used with properly seated clamps

• Disconnect power and shut off water supply before servicing; allow hot parts to cool
• Place towels or a shallow pan to catch residual water
• Note routing and clamp locations; transfer or replace clamps as needed and seat the hose fully on fittings
• Test for leaks with a short cycle and re-check all connections

The Washing Machine Water Inlet Valve is an OEM part for Whirlpool brand washing machines. It regulates water flow into the washer tub during fill cycles and shuts off the supply automatically when the proper water level is reached.

Causes of a bad inlet valve include mineral buildup inside the valve filter restricting flow over time, or mechanical failures of internal plastic parts like diaphragms and seals due to usage stress.

Symptoms of a bad water inlet valve include:

• Slow or inconsistent filling during wash cycles
• Water failing to shut off fully after the designated fill level
• An inability to properly meter incoming water supply amounts
• Water leaks noticed beneath or around the valve area

This OEM replacement valve ensures precise water flow regulation. Compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and select Kenmore models.

Size: 90 inches long. To order hose extension use 12001585. To order siphon break use 76660.

This dishwasher cam assembly is a precision-molded drive component that converts rotation into the timed movement the mechanism needs. Replacing a worn cam helps restore smooth, reliable actuation during the cycle and reduces sticking or misalignment.

• Converts rotational input into precise motion for the linked latch/actuator mechanism
• Maintains proper timing and engagement so the mechanism operates when commanded
• Wear or cracking can lead to slipping, binding, or incomplete travel
• Typical symptoms: associated action fails to engage/release at the right time, intermittent operation, or clicking/grinding noises from the mechanism

• Disconnect power at the breaker and shut off water before servicing
• Access the mechanism; note cam orientation and linkage positions
• Transfer any reusable pins/springs; install the new cam in the same orientation
• Run a test cycle to ensure proper operation and check for leaks or abnormal noises

Bottle with brush. Color: Black. Size: 0.6 fl.oz.

Located at the bottom of the basket, this impeller-style washplate rotates to move laundry and water for effective cleaning. Replace a cracked or stripped washplate to restore proper wash action and reduce noise and tangling.

• Creates water currents and friction to move clothes during the wash
• Transfers drive motion through the hub; worn splines can slip
• Helps circulate water and detergent through fabrics
• Common symptoms: weak or no agitation, grinding/clicking, wobbling/loose plate, visible cracks or broken fins

• Disconnect power and shut off water before service
• Remove the center cap and bolt; lift the old washplate straight up (work evenly if stuck)
• Inspect and clean mating splines; press the new washplate fully onto the shaft
• Reinstall and tighten the center bolt, replace the cap, and run a test cycle

This upper agitator—also called the clothes mover—is the top section of the agitator in select top-load washers. It works with the agitator cam and dogs to roll laundry over during wash strokes. Replace if cracked, stripped, or no longer engaging. What it does:

• Provides the upper vanes that lift and roll clothes for proper turnover during agitation
• Transfers one-way motion from the cam/dogs to the top section of the agitator
• Helps address symptoms like the top section free-spinning, poor turnover/cleaning, rattling/loose feel, or visible cracks/broken fins

• 1 upper agitator (clothes mover)

• Unplug the washer and turn off water before servicing
• Remove the dispenser and cap to access the center fastener; lift out the agitator assembly
• Separate the old upper section from the cam, seat the new clothes mover fully on the splines, and reassemble
• Hand-check for one-way engagement of the top section before running a test cycle

This door lever actuates the latch/switch when the door closes. If it's worn or broken, the appliance may not sense a closed door and won't start. Replacing it restores proper door engagement and safe, reliable operation. What it does:

• Engages the door latch/switch mechanism so the control knows the door is closed
• Helps ensure the unit only runs with the door fully shut
• Replaces cracked, bent, or missing levers that prevent proper door sensing
• Common symptoms: won't start, must hold/push door to run, "door open" indicator stays on

• 1 door lever

• Disconnect power before servicing
• Access the latch/switch area; note the original lever's orientation and any spring
• Transfer and reuse existing hardware if needed; install the new lever in the same position
• Close the door and test for proper start/stop operation

Restore accurate cycle control with this washer timer. It sequences power to the drive motor, pump, and water inlet valves so the machine fills, washes, drains, and spins at the proper times.

• Advances the cycle through fill, wash, rinse, drain, and spin stages
• Sends power to the motor, pump, and inlet valves in the correct order and duration
• Safe symptoms: washer won't start, won't advance, stops mid-cycle, runs indefinitely, or skips rinse/spin
• Helps when cycles stall or the dial turns without moving the cycle forward

• Unplug the washer before servicing
• Open the control console to access the timer; note or photograph wiring
• Transfer wires one at a time to matching terminals on the new timer
• Reuse your existing knob/dial and mounting hardware; align the timer shaft before tightening

This washer shock absorber helps control tub movement during spin and agitation. Replacing a worn damper restores stability, reduces vibration, and helps prevent excessive noise and shaking during cycles.

• Controls suspension movement to keep the tub steady
• Helps reduce banging, walking, and excessive vibration
• Can alleviate loud thumping or rattling during spin
• Supports smoother, quieter operation when shocks wear out

• Unplug washer and turn off water supply before servicing
• Access from front or rear panel varies by model; support the tub to relieve tension
• Replace in matched positions; some washers use multiple shocks
• Each end is fully seated and locked before reassembly

This drain pump assembly moves water out of the appliance during the drain portion of the cycle. Replacing a weak or failed pump restores proper draining and helps prevent standing water, odors, or repeated drain attempts.

• Actively pumps wastewater through the drain hose to household plumbing
• Engages during the drain step to clear the tub/sump between and after cycles
• Typical failure symptoms: won't drain or drains slowly; water left in the bottom; loud humming/grinding during drain; leaks around the pump area
• May fail due to worn motor, damaged impeller, or debris lodged inside the pump

• Disconnect power and turn off water supply; bail or wet-vac any standing water before starting
• Keep towels or a shallow pan ready; clamp or plug hoses to control residual water
• Transfer hose connections and any mounting hardware from the original pump; ensure seals and clamps are seated firmly
• After installation, run a short cycle to check for leaks

Includes 2 adhesive pads, 2 brackets, 4 screws, and installation instructions.

This dryer temperature selector switch lets you choose between four heat settings for proper fabric care. Replacing a worn switch restores accurate temperature selection so loads dry evenly without overdrying delicate items.

• Controls the dryer's heat level across four selectable settings
• Faulty switch can cause incorrect temperatures or only one setting to work
• May lead to poor drying performance or fabric damage if not functioning
• Restores reliable temperature selection and consistent drying results

• Unplug dryer before servicing; shut off gas if applicable
• Pull control knob straight off to access the switch
• Transfer wires one at a time to the new switch to maintain correct positions
• Ensure switch shaft and flat align with the knob during reassembly
