Parts for Kenmore 796.81722000 (79681722000, 796 81722000): Control Panel Parts

This water tank assembly collects condensation produced during the drying cycle in a ventless or condenser dryer. It is a removable reservoir that must be emptied periodically to allow the dryer to continue operating. Replace this tank if it is cracked, leaking, or if the dryer displays a full tank error even after emptying.

This washer tub assembly is the stationary outer tub that surrounds the spin basket and contains the wash water. Replacing a cracked or damaged tub helps stop leaks and restores proper clearance for smooth, quiet washing and spinning.

• Creates a watertight chamber around the basket to hold wash and rinse water
• Maintains proper basket clearance; damage can cause rubbing or scraping sounds
• Provides connection points for hoses and water-level components
• Common signs it may be needed: leaks from the tub area, visible cracks or warping, persistent out-of-balance/spin errors, or internal scraping/grinding noises

• Disconnect power and water; shut off supplies and safely drain remaining water
• This is a major repair—allow time and consider a second person to help lift/support the tub
• Transfer model-specific parts from the original tub to the new tub as needed; reinstall all clamps, bolts, and sensors securely
• After reassembly, level the washer, and run a test cycle to check for leaks

The Heater Assembly is an OEM replacement part for LG dryers. It is a critical component responsible for generating the heat necessary for drying clothes efficiently and effectively.

Symptoms of a bad heater assembly:

• Dryer not producing enough heat or failing to dry clothes completely
• Excessive drying times or inconsistent drying performance
• Visible damage or breaks in the heating element coil
• Burning odors or smoke emanating from the dryer during operation

Causes of a bad dryer heater assembly can include mechanical failure, electrical malfunctions, or simply reaching the end of its lifespan due to repeated heating and cooling cycles.

This OEM LG part is also compatible with Sears/Kenmore dryer models.

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

The Belt is an OEM replacement part for LG dryers that is responsible for connecting the motor to the drum to allow it to tumble. Over time, dryer belts can stretch, wear out, or even break, leading to a drum that won't turn and clothes that don't dry properly.

Symptoms of a bad Dryer Belt include:

• The dryer motor running but the drum not turning.
• A squealing or thumping noise coming from the dryer.
• The dryer not starting at all.

Causes of failure can include regular wear and tear from the dryer's operation, overloading the dryer beyond its capacity, which puts extra strain on the belt, or a misalignment that causes uneven wear. A damaged belt can prevent your dryer from functioning correctly, leading to inefficiency in drying clothes and potential motor damage due to unnecessary strain.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Hi Limit Thermal Fuse is an OEM part for LG dryers. This fuse is a safety device that protects the dryer from overheating by cutting off power to the heating element if the dryer’s temperature exceeds a safe limit. It ensures that the dryer operates within safe temperature ranges, preventing potential fire hazards.

Replace the hi limit thermal fuse if it becomes faulty due to wear and tear, a buildup of lint, or exposure to high temperatures over time. A malfunctioning fuse can compromise the dryer’s ability to regulate heat properly.

Symptoms of a bad hi limit thermal fuse include:

• The dryer not heating
• The dryer shutting off unexpectedly during a cycle
• No response from the dryer when attempting to start a cycle
• Extended drying times due to lack of heat

This OEM LG part is also compatible with Sears/Kenmore models.

Replace your dryer drum seal when clothes take longer to dry or you notice lint buildup. Maintains heat efficiency and prevents air leaks. Confirm fit with your model number.

The Hi Limit Thermostat Assembly is an OEM part for LG dryers. This thermostat monitors and regulates the temperature within the dryer to prevent overheating, ensuring safe and efficient operation. It acts as a safety device that shuts off the heating element if the dryer exceeds a certain temperature, protecting the appliance and your home from potential fire hazards.

Over time, the hi limit thermostat can fail due to wear and tear, electrical issues, or repeated exposure to high temperatures. If the thermostat becomes faulty, it can lead to improper temperature regulation within the dryer.

Symptoms of a bad hi limit thermostat include:

• The dryer overheating
• The dryer not heating at all
• The dryer shutting off mid-cycle
• Extended drying times due to inconsistent heating

This OEM LG part is also compatible with Sears/Kenmore models.

Dryer lint guide assembly directs airflow and lint to the trap. Replace if cracked, broken, or missing to restore proper lint collection.

This dryer guide cover cap installs on the drum or guide assembly. Replace if your original cover is cracked, broken, missing, or worn from regular use.

Dryer won't tumble or makes loud noise? This complete Drum Tub Assembly restores proper rotation and quiet operation. Major repair, 2-3 hours for experienced DIYers.

This balance weight is the washer counterweight that helps stabilize the tub during spin cycles to reduce vibration and noise. Replaces a worn or damaged weight to restore smoother, quieter operation. What it does:

• Counterbalances the washer drum to minimize shaking and excessive movement during spin cycles
• Helps prevent banging or knocking noises caused by an unbalanced tub
• Supports even load distribution to reduce stress on suspension components
• Used when a cracked, loose, or missing weight is causing vibration issues

• One balance weight (counterweight)

• Disconnect power and water supply before starting any repair
• Support the tub or cabinet when removing/installing the weight to avoid sudden movement
• Tighten mounting hardware to OEM torque if specified; use the factory fasteners when available

The Incandescent Lamp is an OEM part for LG dryers. It serves as the interior light source for LG clothes dryers.

Causes of lamp failure relate to typical lifespan expirations, being accidently left on which shortens rated hours, or faulty sockets allowing moisture or other contamination to enter the connection points.

Symptoms of a burned out lamp include:

• Dark or completely unlit drum chamber interior
• Inability to fully inspect clothes during operation
• Difficulty monitoring dryer progress without supplemental lighting

This LG part is also compatible with some Kenmore models.

This is a translucent plastic lens that covers the drum light inside the dryer. It protects the light bulb from heat, lint, and tumbling clothes while allowing light to illuminate the drum interior. Replace this cover if it is cracked, yellowed, melted, or missing, which can leave the bulb exposed to damage.

This duct assembly channels exhaust from the appliance to the home vent, restoring proper airflow and helping reduce lint and moisture buildup. It's a direct-fit replacement for the original ducting on compatible LG units. What it does:

• Directs heated air and moisture from the appliance to the exterior vent
• Replaces damaged, crushed or disconnected ductwork that can restrict airflow
• Helps reduce lint accumulation in the cabinet/vent path when installed and maintained
• Restores a sealed connection between the appliance outlet and household venting

• Disconnect power and unplug the appliance before beginning any repair
• Follow for disassembly and routing; use proper clamps or screws to secure connections
• Inspect connected gaskets, clamps and the external vent path; replace or clean as needed
• Do not operate the appliance with obstructed or damaged venting; clean lint regularly to reduce fire risk

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

Taptite screw secures dryer panels, brackets, and covers to sheet metal or plastic. Replace if missing, stripped, or damaged during repairs.

Captures lint and debris from laundry to prevent vent clogs. Replace if torn, cracked, or clothes snag on it. Confirm fit with your model number.

Note: Due to manufacturer changes, if you are replacing the lint screen housing [MCK49049101] you must order lint screen filter part number [ADQ56656403].

Dryer stops mid-cycle or won't start? This door latch assembly secures the door to keep your dryer running. Simple 2-minute DIY fix for most models.

Houses the lint filter to capture debris during drying. Replace if cracked, causing clothes to snag or tear. Confirm fit with your model number.

Note: Due to manufacturer changes to this part, you will also need to order lint filter part number ADQ56656403. To purchase the guide and filter in a kit, order part number 383EEL3002Q.

Replace missing or stripped taptite screws that secure panels and internal components. This thread-forming screw creates a tight hold to eliminate rattles.

This is a safety switch assembly that detects whether the dryer door is open or closed. It signals the control board to stop the drum and heating element when the door is opened during a cycle. Replace this switch if the dryer will not start, stops mid-cycle unexpectedly, or continues running with the door open.

Secures the lint filter in proper position to prevent clothes snagging. Replace if cracked, warped, or filter sits unevenly. Confirm fit with your model.

Cover that fits over the dryer's lint filter duct area. Replace if cracked, broken, or missing to keep items from falling into the duct when filter is removed.

Distortion spring that applies tension within the dryer mechanism. Replace if fatigued, broken, or missing to restore proper tension and assembly function.

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

Snap-in hole cap covers unused openings on your dryer cabinet or control panel. Replace cracked, broken, or missing caps to restore a finished look.

Dryer won't auto dry or cycles run too long? This moisture sensor wire harness connects sensor bars to control. Restores accurate dry cycles. DIY-friendly.

This is a mounting bracket that holds the moisture sensor in place inside the dryer drum area. The moisture sensor detects how wet the clothes are and signals the dryer to stop when they are dry. Replace this holder if it is cracked, broken, or missing, which can cause the moisture sensor to shift out of position and lead to clothes being over-dried or under-dried.

Directs steam spray into the dryer drum during Steam/Refresh cycles. Replace if nozzle is clogged, cracked, or leaking to restore proper mist distribution.

The Door Strike is an OEM part for LG dryers. This part engages with the door catch to keep the dryer door securely closed during operation. The door strike is essential for ensuring the door remains tightly shut, allowing the dryer to function efficiently and safely.

Causes of a bad door strike can include wear and tear from regular use, damage from slamming the door, or misalignment issues that prevent it from engaging properly with the door catch.

Symptoms of a bad door strike include:

• The dryer door not staying closed
• The dryer not starting due to the door not being securely latched
• Difficulty in latching the door
• Visible damage or wear on the strike

This OEM LG part is also compatible with Sears/Kenmore.

This outer door frame replaces the cosmetic trim that surrounds the microwave door, restoring appearance and helping the door seal and latch properly. It's a direct-fit exterior component for a clean, finished look. What it does:

• Replaces damaged, dented or cracked outer door trim that affects the door's appearance
• Restores proper alignment and support for the door's outer assembly
• Helps maintain a consistent exterior finish and protects internal door components
• Commonly used when the door shows visible wear, cracks, or cosmetic damage

• Designed for direct replacement; follow the microwave's service manual for disassembly and reassembly steps
• Disconnect power to the appliance before beginning work to avoid electrical hazards
• Handle the door and frame carefully to avoid scratching the finish; use soft protection and non-marring tools

Sound dampening insulation that reduces dryer noise and vibration. Replace if worn, torn, or missing to restore quiet operation and cushioning.

This generator assembly senses motor rotation and provides the control board with speed/position feedback so the washer can time cycles and spin properly. It replaces a worn or damaged sensor assembly to restore reliable cycle control. What it does:

• Detects motor rotation and sends position/speed signals to the washer control board
• Helps the machine maintain correct spin speeds and cycle timing
• Can address symptoms like no spin, erratic spinning, or motor-related error codes when the generator fails
• Works with the motor/mounting components to ensure accurate feedback for drive operations

• One generator assembly

• Disconnect power before servicing to avoid shock or injury
• Requires basic tools and access to the washer's motor area; handle connectors and sensor surfaces carefully
• Reuse or replace any mounting hardware only if specified by the manufacturer

The DC pump motor assembly powers the pump that moves water through your appliance. Replacing a worn motor helps restore proper water flow so cycles can complete and reduces issues like standing water and excessive noise.

• Drives the pump impeller to move water for draining or circulation, as designed by the appliance
• Supports proper cycle completion by clearing water from the tub or sump
• Common symptoms of a failing motor include standing water, incomplete draining/circulation, loud humming or grinding near the pump, or cycle errors
• May run intermittently, stall, or overheat as internal components wear

• Disconnect power and turn off the water supply before servicing
• Expect residual water; protect the area with towels or a shallow pan
• Note wiring connectors and hose routing; transfer any brackets, grommets, or seals from the original as needed
• Secure hose clamps and test for leaks while running a brief test cycle

This is a flexible hose that connects the condensate drain pump to the water drainage system in a condensing dryer. It carries collected moisture from the pump to the drain outlet or reservoir. Replace this hose if you notice water leaking beneath or behind the dryer, or if the pump is running but water is not being properly drained.

This dryer vent hose connects your dryer to the exhaust vent. Replace if cracked, torn, kinked, or showing wear that restricts airflow and lint removal.

Wire harness for dryers. Connects electrical components inside the cabinet. Replace if wires are frayed, damaged, or connectors are broken or melted.

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.

This side vent hole cover seals unused ventilation openings in your dryer cabinet. It prevents lint buildup and maintains proper airflow through the designated exhaust path. Install this cover if you have an open hole causing lint to escape into areas where it shouldn't or affecting drying efficiency.

Fix loud banging, grinding noise, or poor drying performance with a new dryer blower wheel. Restores proper airflow through drum and exhaust vent.

This is a fastener and retainer assembly that secures the blower wheel to the motor shaft inside a dryer. It keeps the blower wheel firmly in place so it can properly circulate hot air through the drum and out the exhaust vent. Replace this assembly if the blower wheel wobbles, makes rattling or squealing noises, or if the retainer nut is stripped or broken, causing poor airflow and longer drying times.

Base bracket for dryer installation and structural support. Replace if your original bracket is cracked, broken, bent, or missing to restore proper stability.

Duct assembly channels air from dryer drum to blower and exhaust. Replace if cracked, warped, or missing to restore proper airflow and prevent lint bypass.

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

This adjustable leveling leg screws into the dryer base to support and stabilize the cabinet. Replacing a worn or missing foot helps level the appliance, reduce vibration and noise, and keep it steady on uneven floors.

• Provides threaded height adjustment to properly level the dryer
• Stabilizes the cabinet to minimize rocking, vibration, and walking
• Replaces a broken, worn, or missing foot
• Common symptoms: dryer wobbles, is hard to level, or makes rattling/vibration noise

• Disconnect power; shut off gas supply for gas models
• With a helper, carefully tilt or raise the dryer for access
• Unscrew the old leg; thread the new leg into the base by hand, then adjust with a wrench until the dryer sits level and stable
• Ensure all legs contact the floor and the dryer does not rock

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

Protective cover shields internal wiring and electrical terminals in your dryer. Replace if cracked, broken, or missing to prevent accidental contact.

Safety cover cap for dryers and laundry centers. Protects internal components and covers exposed areas. Replace if cracked, broken, or missing.

Multi-connector wire harness routes power and signals between dryer components. Replace if original is damaged, burnt, frayed, or has loose connections.

Metal mounting bracket that secures internal dryer components to the frame. Replace if cracked, bent, or broken to restore proper alignment and stability.

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

This micro switch is a compact, snap-action electrical switch that sends an on/off signal when a lever, latch, or paddle is moved. Replacing a worn switch restores reliable detection and control response for the affected function.

• Converts mechanical movement into an electrical open/close signal to the control
• Commonly used for lever/paddle actuators, latches, or interlock detection within the appliance
• Safe symptom clues: no response when actuated, intermittent operation, or a function stuck on/off
• Physical clues: weak or absent "click" when pressed, heat discoloration or damage at terminals

• Disconnect power before servicing; if the product is connected to a water line, close the supply valve
• Note wire positions and terminal labels (COM/NO/NC); transfer wires one at a time to matching terminals
• Match the actuator orientation and mounting position to the original for proper operation
• After installation, verify continuity with a multimeter and test function before reassembly

Maintains tension on your dryer's drum belt for smooth rotation. Replace if pulley wheel is cracked, shaft worn, or assembly moves excessively during operation.

Idler pulley maintains tension on the dryer belt. Replace if worn, cracked, or causing belt slippage. Installs between motor and drum support system.

This replacement screw secures appliance components in their proper position. Use it to restore a tight, rattle-free fit when the original fastener is missing, stripped, or corroded. What it does:

• Fastens brackets, panels, or trim to keep assemblies aligned and secure
• Helps prevent vibration, rattling, and gaps from loose hardware
• Restores proper attachment when a screw is lost, worn, or damaged
• Common symptoms: loose panel/handle, misalignment, rattling, or a missing screw

• Disconnect power; shut off water or gas before service
• Match location to the original; start threads by hand to avoid cross-threading
• Use the correct driver bit; do not overtighten (especially into plastic)
• If the original hole is stripped, repair threads before installing the new screw

Self-tapping screw secures panels, brackets, and components inside your appliance. Replace stripped, corroded, or missing screws to restore secure fit.

Stationary rack that installs inside your dryer drum to hold shoes, sweaters, and delicates that shouldn't tumble. Replace if cracked, broken, or missing.

This side venting kit allows you to redirect your dryer's exhaust air out through a side wall instead of the back of the unit. It includes the necessary ductwork and connections to safely route hot, moist air outside your home. Use this kit when your dryer installation requires side venting due to space constraints or structural limitations.
