Parts for Ge EDW2030F02WW: Dishwasher Parts

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

The Tub Corner Baffle is an OEM part for GE dishwashers. It is strategically placed at the corners of the dishwasher tub to prevent water from leaking out during operation.  For the left side use WD8X228. Color: Black.

Symptoms of a bad Tub Corner Baffle include:

• Water leaking from the corners of the dishwasher door.
• Pools of water forming near the dishwasher after operation.
• Decreased cleaning performance due to water escaping the wash cycle area.

Causes of a bad tub corner baffle can include wear and tear from regular use, improper installation leading to gaps or looseness, and degradation of the material over time due to exposure to detergents and high temperatures.

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Tub Corner Baffle is an OEM part for GE dishwashers. This rubber component is placed in the corners of the dishwasher tub to prevent water from leaking out during the wash cycle. It acts as a barrier, directing water back into the tub and ensuring efficient operation. This is the left side. For the right side, use WD8X227.

Causes of a bad part can include prolonged exposure to detergents and hot water, leading to material breakdown, or physical damage from loading and unloading dishes.

Symptoms of a bad Tub Corner Baffle include:

• Visible signs of wear or damage
• Water leakage from the corners of the dishwasher door
• Unusual noises during operation

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

Color: Purple.

Replacement latch keeper for the dryer door latch assembly that secures the latch and keeps the door closed during operation. Restores reliable door engagement to help the appliance start and complete cycles. What it does:

• Secures the door latch so the dryer door stays closed during operation.
• Aligns with the latch mechanism to maintain proper door engagement.
• Common symptom: dryer door won't latch or feels loose, causing the cycle to not start or stop unexpectedly.
• Replaces worn or broken keeper pieces that allow rattling or misalignment.

• Disconnect power (unplug electric or shut off gas and breaker) before servicing.
• Access with basic hand tools; remove the door or front panel as needed to reach the keeper.
• Install carefully to avoid cracking surrounding plastic; do not force parts into place.
• After installation, verify the door closes securely and the dryer starts through a test cycle.

This leveling screw adjusts your dishwasher's leveling leg so you can set the cabinet height and get the unit perfectly level. Proper leveling helps the door seal correctly, reduces rocking, and cuts excess vibration and noise.

• Threads into the leveling leg to raise or lower the dishwasher for accurate leveling and stability
• Helps prevent rocking or wobbling and supports proper door alignment and sealing
• Can reduce vibration/noise associated with an out-of-level installation
• Replaces a stripped, bent, or missing adjustment screw to restore adjustability

• Disconnect power and turn off the water supply; protect flooring before adjusting or replacing
• Remove the toe-kick/access panel to reach the adjuster; support the dishwasher's weight before turning the screw
• Start threads by hand to avoid cross-threading; do not overtighten
• After adjustment, verify level side-to-side and front-to-back with a level and recheck door operation

The Heating Element Assembly is an OEM part for GE dishwashers. This part heats the air during the drying cycle, ensuring that dishes come out dry and free of water spots.

Causes of a bad heating element can include mineral buildup from hard water, electrical issues such as a short circuit or faulty wiring, or general wear and tear over time that leads to reduced efficiency or failure.

Symptoms of a bad heating element include:

• Dishes remaining wet after the drying cycle
• The dishwasher not heating up during the drying phase
• The drying cycle taking longer than usual or not completing
• Error codes related to drying issues displayed on the control panel

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This support calrod assembly secures and positions the oven/range heating element so it heats evenly and stays stable during operation. Replaces a worn or damaged support to restore proper element alignment and reduce rubbing or sparking. What it does:

• Holds the tubular heating element in the correct orientation inside the oven or range
• Prevents the element from sagging, contacting interior surfaces, or vibrating during use
• Helps maintain consistent heating performance and reduces risk of element wear
• Common symptom: element rubbing, touching oven walls, or uneven heat distribution

• One support calrod assembly

• Disconnect power at the breaker or unplug the appliance before starting any repair
• Handle heating elements and support parts carefully to avoid bending or damaging the element
• Follow OEM service instructions for removal and reassembly; verify correct element alignment before restoring power

This float dome positions and protects the float inside the tub so the appliance can sense water level correctly. Replacing a cracked or missing float dome helps restore reliable fill control and reduces overfill or erratic fill symptoms. What it does

• Houses and guides the float so the fill sensor detects water level accurately.
• Prevents the float from sticking or catching on the tub, which can cause overfilling.
• Helps stop intermittent or continuous fill problems caused by a broken or displaced float.
• Keeps debris away from the float area to reduce false water-level readings.

• Disconnect power and water supply before accessing the tub or removing panels.
• Remove the lower access panel or kickplate to reach the float area; handle plastic parts gently to avoid cracking.
• Inspect surrounding seals and the float itself; replace any damaged components for reliable operation.
• After installation, restore power and run a short fill/drain cycle to verify correct float movement and water-level control.

This dishwasher float rises with the water level to engage the float switch. It regulates filling and helps prevent overflows, protecting your kitchen from leaks and keeping wash cycles running properly. What it does:

• Rises with the tub's water level and actuates the float switch
• Signals the inlet valve to stop water flow at the correct level
• A stuck, worn, or broken float may cause overfilling or no-fill conditions
• Symptoms can include leaking from overfill or no water entering during fill

• 1 float

• Disconnect power and turn off the water supply before servicing
• Open the door; remove the lower rack for access
• Lift off any float cap/retainer, pull the old float straight up, and seat the new float
• Ensure the float moves freely; restore power/water and run a brief fill test

This float stem is part of the dishwasher's water-level/overfill system. It guides the tub float and actuates the float switch so the unit fills correctly and shuts off on time. Replace a worn or broken stem to restore reliable fill protection.

• Connects the float to the switch mechanism beneath the tub
• Provides smooth vertical travel of the float through the opening
• Triggers the float switch to stop filling at the proper level
• Causes symptoms such as no fill, continuous filling/overfilling, a stuck or wobbly float, or intermittent fill issues

• Disconnect power at the breaker and shut off the water supply before servicing
• Remove the lower rack; lift off the float cap from inside the tub
• On some models, release the retainer/clip from beneath the tub; pull out the old stem
• Guide the new stem through the opening and ensure it engages the float switch lever; confirm the float moves freely and actuates the switch before restoring power

The Complete GE Pump and Motor Assembly is an OEM replacement part for GE dishwashers. This assembly is integral to the dishwasher’s functionality, as it combines both the pump and motor components that work together to circulate water during the wash and rinse cycles. The pump forces water through the spray arms, while the motor drives this process, ensuring thorough cleaning of the dishes.

Over time, the pump and motor assembly can wear out due to constant use and exposure to water and detergents. Additionally, debris or hard water buildup can clog the pump, causing strain on the motor and leading to failures. Electrical issues or damage from power surges can also impair the assembly's performance.

Symptoms of a bad pump and motor assembly include:

• The dishwasher not cleaning dishes properly
• Water not circulating or spraying during cycles
• Unusual noises, such as grinding or humming, coming from the dishwasher
• Water not draining properly from the tub
• The dishwasher not starting or completing cycles

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 8-32 x 5/8 inch.

This kit is used to repair a leaking pump on GE made dishwashers. For a complete pump/motor assembly get WD26X10013.

This sump clamp secures the dishwasher sump to the tub assembly, keeping the gasket compressed for a watertight seal. Replacing a weakened or corroded clamp helps stop leaks from the base and restores proper wash system sealing.

• Holds the sump firmly to maintain seal compression
• Helps prevent water leaking from the bottom of the dishwasher during operation
• Replace when the existing clamp is rusted, broken, stripped, or won't tighten

• Disconnect power at the breaker and shut off the water supply
• Remove the toe kick and, if needed, pull the dishwasher forward for access
• Position the clamp over the sump-to-tub joint and tighten evenly; do not overtighten
• Reseat the sump gasket and run a leak test after reassembly

This OEM Replacement Part is a rubber connector with female threads. It is designed to provide a secure connection between the spray arm and the pump in a dishwasher. The connector measures 2-3/4 inches in diameter and 2-1/8 inches in height. This part is crucial to ensuring the proper functioning and efficiency of your dishwasher's spray arm pump.

Over time, the pump connector can wear out or become damaged due to repeated exposure to water, detergent, and high temperatures. This wear and tear can lead to leaks or a decrease in the dishwasher’s performance.

Symptoms of a bad pump connector include:

• Water leaks under or around the dishwasher
• Reduced water pressure during the cleaning cycle
• The dishwasher not draining properly
• Unusual noises during operation

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: This connector has female threads. For male threads use WD18X206.

A replacement clamp that secures hoses or wiring to keep lines routed and stable, helping prevent rubbing, leaks and noise. Restores a reliable hold for tubing and harnesses so the appliance runs quietly and safely. What it does:

• Holds hoses, tubing or wire harnesses in place to reduce movement and chafing.
• Helps prevent leaks and water line abrasion caused by loose fittings.
• Reduces rattling or vibration from unsecured lines or cables.
• Keeps routing organized so adjacent components aren't stressed or worn.

• Disconnect power before servicing the appliance; shut off water supply when working on water or drain lines.
• Remove the old clamp and position the replacement so it fully engages the hose or harness, avoiding twists.
• Use appropriate hand tools (pliers or screwdriver) and secure the clamp evenly; avoid overtightening.
• Inspect surrounding hoses and wiring for damage while installing; replace any components that show wear.

The Drain Hose is an OEM part for GE dishwashers. This part carries the wastewater from the dishwasher to the household plumbing, ensuring efficient and effective drainage after each wash cycle.

Causes of a bad drain hose can include regular wear and tear, kinks or bends that restrict water flow, or damage from improper installation.

Symptoms of a bad drain hose include:

• Water not draining properly from the dishwasher
• Leaks or puddles of water around the dishwasher
• Visible cracks or splits in the hose
• Unpleasant odors due to stagnant water

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This float switch detects rising water in the refrigerator drain pan or lower cabinet area and signals the appliance control to help prevent overflow and water damage. Use it to replace a failed or intermittent water-level sensor. What it does:

• Senses high water level in the drain pan or collection area and closes the circuit to alert the control.
• Helps identify causes of leaks and pooling under or behind the appliance.
• Commonly used when symptoms include water on the floor, drip pan overflow, or water-related error/alert conditions.
• Matches OEM function for refrigeration units that include a float-based water-detection circuit.

• Disconnect power to the appliance before starting any repairs; shut off the water supply if working near water lines.
• Access may require removing lower kick plate or back panel; handle plastic clips and fasteners carefully.
• Disconnect electrical connector gently and note orientation before installing the replacement; secure wiring and verify float moves freely.
• Restore power and run a short test cycle or simulate water level to ensure proper operation.

This replacement part is a lower arm spray, and it is intended for use in different types of appliances. This is a genuine replacement part made by General Electric. The lower arm sprays are an important part of the cleaning process in many dishwashers. This spray arm is situated underneath the top dish rack and projects water downward for more sufficient cleaning.A new lower spray arm might be needed if the user notices the current one is failing to spin or expel water. If dishes are coming out of the dishwasher and are only partially cleaned, then it might be time for a new arm spray. Be sure the water is completely turned off from the appliance before attempting to repair this part. Refer to the user guide for more specific directions on how to replace the lower arm spray. This lower arm spray is sold individually and is sourced directly from the manufacturer. This dispenser is a genuine OEM part.

The Filter & Gasket Assembly is an OEM part for GE dishwashers. This part traps food particles and debris during the wash cycle, preventing them from redepositing on dishes or clogging the drain system.

Causes of a bad Filter & Gasket Assembly can include wear and tear from regular use, accumulation of hard water minerals or detergents affecting the gasket's seal, and damage to the filter mesh that allows larger particles to pass through or clog the assembly.

Symptoms of a bad Filter & Gasket Assembly include:

• Poor cleaning performance, with food particles left on dishes after a cycle
• Water leakage around the dishwasher's base, indicating a compromised gasket
• Unpleasant odors from trapped food particles that are not properly filtered out

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This pushnut fastener is a small push-on retainer used to secure shafts, rods, or trim where a threaded fastener isn't required. It provides a secure hold while allowing quick, tool-free installation for maintenance or repairs. What it does:

• Secures axles, shafts, or trim pieces by gripping the mating shaft with a one-way push-on design
• Keeps panels, knobs, or small components from sliding off during operation
• Helps stop rattles or loose parts caused by worn or missing retainers
• Simple, non-threaded solution where a reusable bolt or clip isn't needed

• One pushnut fastener

• Press onto clean, appropriately sized shaft until fully seated; do not hammer with excessive force
• Wear eye protection when installing small retainers to prevent injury from sudden release
• Replace with identical part number to ensure correct fit and retention
• Use appropriate pry tools or cutters to avoid damaging surrounding parts

The Piston & Nut Assembly is an OEM part for GE dishwashers. It plays a critical role in the dishwasher’s water management system, helping to control water flow and ensuring proper drainage during the wash cycle.

You should replace this piston & nut assembly if it becomes worn out or damaged. Causes of a bad piston & nut assembly can include mineral buildup from hard water, general wear and tear from regular use, or physical damage due to debris or foreign objects in the dishwasher.

Symptoms of a bad piston & nut assembly include:

• Water not draining properly from the dishwasher
• Puddles of water at the bottom of the dishwasher after a cycle
• Unusual noises during the drain cycle
• Incomplete cleaning of dishes due to improper water flow

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

A stainless steel hex-washer-head screw used to secure panels and components on compatible appliances. Corrosion-resistant construction helps maintain a secure fit where short, strong fasteners are required. What it does

• Fastens appliance panels, trim, or brackets where an 8-18 thread and short 3/8" length are specified
• Hex washer head provides a larger bearing surface to reduce pull-through
• Stainless finish resists rust in humid appliance areas
• Common replacement when original mounting screw is stripped, missing, or corroded

• One stainless steel hex-washer-head screw

• Use the correct 8-18 thread fastener and do not force mismatched screws to avoid thread damage
• Tighten securely but avoid overtightening to prevent stripped threads or cracked panels
• Power tools may be used with appropriate bit, but start by hand to ensure proper alignment
• If installing near electrical components, disconnect power before servicing

This 3rd level spray arm assembly restores targeted wash action from the top of the tub, improving coverage to the upper rack. Replace it if jets are clogged, the arm is damaged, or upper-rack cleaning performance has declined.

• Directs wash water from above to reach items on the upper rack and hard-to-hit areas
• Helps ensure even spray coverage when functioning properly
• Common symptoms of failure: upper-rack dishes still dirty, weak spray from the ceiling area, visible cracks or mineral buildup, rattling during cycles
• Restores intended water distribution for consistent cleaning results

• Disconnect power and turn off the water supply before servicing
• Open the door; remove the upper rack if needed for access
• Release the mounting clip/retainer or screw, remove the old assembly, and seat the new one until fully secured
• Ensure proper clearance/orientation; run a short test cycle to confirm spray and operation

Used to supply water to the upper spray washarm.

This replacement part is an upper rack slide, and it is intended for use in different types of appliances. This is a genuine replacement part made by General Electric. This upper rack slide is an important part of many appliances. This particular one is typically found in dishwashers and helps guide the upper rack in and out. This allows the user to have easy access to the rack in order to place and remove dishes before and after the cleaning process. A new upper slide rack might be needed if the current ones are broken or damaged in any way. It is possible that these slides become stripped over many years of use and need to be replaced. If the upper rack is tilted or not sturdy while being slid back inside the main tub, the upper rack slide might be the problem. Be sure the dishwasher is completely empty prior to replacing this part. This is a genuine OEM part and is sourced directly from the manufacturer. This upper arm rack slide is sold individually.

Includes screws.

Left side. Color: white. It measures about 1 inch high by 1-1/2 inches deep.

For the right side. Color: white. It measures about 1 inch high by 1-1/2 inches deep.

The Roller and Stud Assembly - 4 Pack is an OEM part for GE dishwashers. This assembly includes four rollers and studs that are essential for the smooth operation of the dishwasher's lower rack. The rollers ensure that the rack glides in and out effortlessly, providing easy access for loading and unloading dishes.

Causes of a bad roller and stud assembly include regular wear and tear, accumulation of dirt and debris that can hinder movement, and damage from heavy loads or improper loading of dishes.

Symptoms of a bad roller and stud assembly include:

• Difficulty pulling the rack in and out
• Squeaking or grinding noises during rack movement
• The rack getting stuck or detaching from the guide rail

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Lower Dishrack Roller is an OEM part for GE dishwashers. Good rollers allow the dishrack to slide in and out of the dishwasher smoothly. These rollers attach to the dishrack, providing mobility and convenience when loading or unloading dishes. Note: This kit includes one roller and one axle.

Causes of damage to the dishrack rollers often involve overloading the dishrack with heavy dishes, which can put excessive stress on the rollers, or normal wear and tear from repeated use.

Symptoms of a bad Lower Dishrack Roller Kit include:

• The lower dishrack sticking or struggling to slide in and out.
• Visible damage or wear on the rollers, such as cracks or flat spots.
• The dishrack sitting unevenly in the dishwasher, potentially due to missing rollers.
• Noise when moving the dishrack, indicating worn or damaged rollers.

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Lower Dishrack Roller Kit is an OEM part for GE dishwashers. This kit includes 8 wheels and 8 axles. It allows it to glide smoothly in and out of the dishwasher. Proper functioning of these rollers is crucial for the easy loading and unloading of dishes, ensuring that the dishrack moves efficiently along its tracks.

You should replace the lower dishrack roller kit if the rollers become worn out or damaged. Common causes of roller issues include wear and tear from frequent use, accumulation of debris, or breakage due to heavy loads or accidental impact.

Symptoms of a bad lower dishrack roller kit include:

• Difficulty sliding the lower dishrack in and out
• The dishrack derailing or not staying on its tracks
• Unusual noises when moving the dishrack
• Visible damage or wear to the rollers

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Lower Dishrack Roller Kit is an OEM part for GE dishwashers. This kit includes 8 wheels and 8 axles. It allows it to glide smoothly in and out of the dishwasher. Proper functioning of these rollers is crucial for the easy loading and unloading of dishes, ensuring that the dishrack moves efficiently along its tracks.

You should replace the lower dishrack roller kit if the rollers become worn out or damaged. Common causes of roller issues include wear and tear from frequent use, accumulation of debris, or breakage due to heavy loads or accidental impact.

Symptoms of a bad lower dishrack roller kit include:

• Difficulty sliding the lower dishrack in and out
• The dishrack derailing or not staying on its tracks
• Unusual noises when moving the dishrack
• Visible damage or wear to the rollers

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces

Color: White.

White. 8-18 x 5/16 inch.

The Water Inlet Valve is an OEM part for GE dishwashers. It is responsible for opening and closing the water supply to the dishwasher. It regulates the water pressure and ensures the proper amount of water is dispensed for each cycle. This part has a 3/8” inlet and includes the mounting bracket.

Causes of a faulty water inlet valve can include wear and tear over time, sediment or debris buildup, electrical component failure, or damage due to high water pressure. These factors can result in issues such as inadequate water flow, leaks, or the dishwasher not filling or draining properly.

Symptoms of a bad water inlet valve may include:

• Insufficient water supply or low water pressure
• Leaks around the valve area
• Inability to start or complete dishwasher cycles

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

This is a replacement fastener screw used to secure panels and components on compatible appliances, restoring proper fit and reducing movement. It's a simple, direct replacement when an original screw is missing or damaged. What it does:

• Secures access panels, covers, or internal components to prevent rattling and movement
• Helps maintain proper alignment of parts so doors and panels close correctly
• Replaces missing, stripped, or broken screws that can cause loose parts or noise
• Restores the appliance's original fit where a matching OEM fastener is required

• One replacement screw

• Turn off and unplug the appliance before starting any repair
• Use the correct driver and avoid over-tightening to prevent stripping threads
• If the original screw was holding electrical components, ensure power is disconnected and follow OEM safety instructions

Size: 8-32 x 5/16 inch.

This lower front toe kick panel restores a clean, finished look at the base of the dishwasher and helps shield the bottom area from debris and bumps. Replace a cracked, dented, or missing panel to secure the opening.

• Covers and conceals the lower access opening at floor level
• Helps protect base components from accidental contact and household debris
• Restores appearance when the original panel is damaged or missing
• Common symptoms: visible gap at the bottom front, loose or rattling kickplate, bent or broken panel

• Disconnect electrical power before servicing
• Open the door to access and remove the mounting screws holding the old panel
• Position the new panel, align tabs/slots, and reinstall screws—do not overtighten
• The panel clears the floor and does not interfere with door operation

The Silverware Basket Assembly is an OEM part for GE dishwashers. Located in the lower rack, the silverware basket contains and separates utensils during the wash cycle. The basket measures approximately 3 inches wide by 8-1/2 inches high by 20 inches deep.

Causes of basket failure involve typical wear from extended use, exposure to harsh detergents over time, or damage through accidental mishandling.

Symptoms of a bad silverware basket include:

• Cracked or broken basket pieces that separate from the frame
• Difficulty removing or inserting utensils smoothly
• Utensils not getting cleaned due to wear/tears in the basket

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Silverware Basket Assembly is an OEM part for GE dishwashers. Located in the lower rack, the silverware basket contains and separates utensils during the wash cycle. The basket measures approximately 3 inches wide by 8-1/2 inches high by 20 inches deep.

Causes of basket failure involve typical wear from extended use, exposure to harsh detergents over time, or damage through accidental mishandling.

Symptoms of a bad silverware basket include:

• Cracked or broken basket pieces that separate from the frame
• Difficulty removing or inserting utensils smoothly
• Utensils not getting cleaned due to wear/tears in the basket

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 10-16 ab.

This hex-washer-head screw secures panels, brackets, and internal components in your dishwasher. Replacing a stripped, rusty, or missing fastener restores a tight fit, reduces rattling, and helps keep assemblies properly aligned during operation.

• Fastens components to frames, panels, and mounting brackets inside the dishwasher
• Helps maintain alignment and resist loosening from vibration
• Replaces missing, worn, or corroded screws
• Signs of trouble: loose or rattling panels, hardware that won't tighten, or a visible missing screw

• Disconnect power and water supply before servicing
• Note the original screw's location/orientation and install in the same hole
• Start threads by hand to avoid cross-threading; use the correct nut driver or socket
• Tighten snugly without over-torquing to prevent stripping

• Head style: Hex washer-head
• Size: #10-16 thread, 3/8 in length
• Sold individually

This genuine replacement fill hose routes incoming water from the inlet valve to the dishwasher tub, restoring proper water delivery for washing cycles. Replaces worn or cracked hoses to help stop leaks and ensure reliable fill performance. What it does:

• Carries water from the inlet valve to the dishwasher tub during fill cycles
• Restores proper water flow when original hose is leaking, split, or clogged
• Helps prevent water damage caused by deteriorated or cracked hose sections
• Works with the dishwasher's fill and wash functions to maintain normal operation

• Disconnect power and shut off the household water supply before starting
• Inspect clamps, grommets, and fittings and replace if damaged
• Route hose without kinks and secure with proper clamps to avoid leaks

This hose clamp secures a washer or dryer hose connection to help prevent leaks and keep hoses firmly attached during operation. It's a simple replacement for worn or loose hose fasteners. What it does:

• Holds inlet or drain hose to the appliance fitting to reduce slipping and leaks
• Restores a tight seal at hose connection points that may be leaking or wobbling
• Keeps hoses positioned correctly during fill and drain cycles
• Useful when clamp is rusted, stretched, or no longer grips reliably

• One hose clamp

• Disconnect power and turn off the water supply before replacing the clamp
• Slide clamp onto hose, position over the fitting, then compress or tighten per clamp type (use pliers or screwdriver as required)
• Inspect the hose and fitting; replace the hose if cracked or damaged
• Test for leaks after restoring power and water

This hose clamp kit secures the washer's hoses at the pump, tub, or valve connections, helping stop leaks and hose blow-offs. Replace worn or missing clamps to restore a tight, reliable seal during fill, wash, and drain.

• Secures drain, pump, and fill hoses to fittings to maintain a watertight seal
• Helps prevent drips, leaks, and hoses slipping off during vibration
• Replaces clamps that are rusted, stripped, deformed, or missing
• Common symptoms: water leaking at hose joints, loose hose connections, clamp won't tighten
• Useful when installing a new hose, pump, or valve

• Unplug the washer and turn off water supplies; have towels or a pan ready for residual water
• Release and remove old clamps; seat the hose fully over the fitting before installing new clamps
• Tighten evenly and do not overtighten to avoid hose or fitting damage
• Restore power and water, then run a short cycle to check for leaks at each connection

This is the complete right side hinge assembly. For left side use WD14X10007.

The Door Latch Assembly is an OEM part for GE dishwashers. This part ensures the door of your dishwasher shut and locks securely. This part is integral for the safe and efficient operation of your appliance, as it helps to prevent water from leaking during cycles and ensures the dishwasher only runs when the door is properly closed.

Causes for door latch issues typically involve regular wear and tear, accidental damage from forceful use, or degradation of the latch's mechanical or electrical components.

Symptoms of a malfunctioning Door Latch Assembly include:

• Difficulty in closing or locking the dishwasher door
• The dishwasher not starting, indicating the door isn't recognized as securely latched
• Water leakage around the door, suggesting an incomplete seal
• Noticeable damage to the latch itself, impairing its function

This OEM GE part is also compatible with Hotpoint, RCA, and some Kenmore models.

This switch interlock assembly secures the appliance door and completes the electrical circuit so the unit can start and run safely. Replacing a worn interlock restores reliable door sensing and helps ensure normal cycle operation. What it does:

• Detects and holds the door/lid closed so the appliance will start
• Completes the electrical pathway for motor and control circuits
• Prevents operation when the door is open or not fully latched
• Can stop mid-cycle or prevent starting when the interlock fails

• One switch interlock assembly

• Disconnect power (unplug or switch off the breaker) before replacing the part
• Handle mounting screws and wiring harness carefully; match connector orientation when reinstalling
• Verify door alignment and latch function before restoring power

Inner door panel replaces the interior face of the appliance door, restoring a clean surface and proper support for door components so the door can close and seal as intended. Ideal when the door liner is cracked, dented, or visibly worn. What it does:

• Serves as the interior surface of the door and supports the inner glass or window.
• Provides a mounting surface for latches, seals, and related hardware to help maintain a proper door closure.
• Reduces rattling, visible damage, or interior door gaps that can affect operation.
• Protects internal door components from debris and normal wear.

• Disconnect power and unplug the appliance before starting any repair.
• Use basic hand tools to remove door trim or screws; keep all fasteners for reassembly.
• Handle inner glass and sharp edges carefully—wear gloves and eye protection.
• Refer to the appliance's service manual or OEM instructions for model-specific removal and reinstallation steps.

Size: 8-18 x 7/8 inch.

This rinse aid tank is the reservoir inside the dishwasher dispenser that holds liquid rinse agent and releases it during the final rinse. Replacing a damaged tank helps restore proper dispensing, reduce spotting, and prevent leaks at the dispenser.

• Stores rinse aid within the dispenser assembly
• Works with the dispenser to release a measured dose during the rinse cycle
• Failure signs: rinse aid not dispensing, dishes with spots/poor drying, rinse aid level dropping rapidly, or leaks near the dispenser area
• Visible cracks or damage to the reservoir indicate replacement is needed

• Disconnect power at the breaker and shut off water before servicing
• Remove the inner door panel to access the dispenser
• Transfer any reusable seals or clips from the original tank; seat and secure the tank per service instructions
• Reassemble, refill the reservoir with rinse aid, and run a test cycle to check for leaks

This replacement door vent directs humid air out of the dishwasher during the dry cycle. Restoring a damaged or missing vent helps maintain proper airflow and reduce unwanted moisture around the door area. What it does:

• Vents steam from the tub to help manage moisture during drying
• Routes airflow away from the door and control area
• Helps limit condensation and odor buildup inside the door
• Common signs of failure: visible cracks or broken louvers, steam/moisture escaping at the door top, water spots near the vent, or a loose/rattling vent

• 1 door vent

• Disconnect power at the breaker before servicing
• Open the door; remove screws or release tabs to remove the old vent (varies by model)
• Note orientation, seat the new vent fully, and secure without overtightening
• Reassemble and run a short cycle to check for proper sealing and airflow

The Detergent cup cover is an OEM component for GE dishwashers. It serves to protect the detergent cup assembly while allowing for easy access. Made of durable plastic, the cover clicks securely into place during operation to prevent accidental opening.

Causes of a bad detergent cup cover include cracks or breaks from heavy use over time.

Symptoms of a bad detergent cup cover can include:

• Difficulty opening or closing the detergent cup cover properly
• Portions of the cover assembly no longer intact or missing
• Leaks developing around the perimeter of the cover

This genuine GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Size: 10-12 x 1/2 inch.

The Detergent Cup Latch is an OEM part for GE dishwashers, specifically designed for certain models. It is located on the detergent dispenser assembly. When the detergent cup is loaded with detergent, the latch holds it in place and prevents it from accidentally opening or spilling during the wash cycle.

Causes of a faulty or damaged detergent cup latch can include regular wear and tear, misalignment, or breakage. These factors can result in issues such as the detergent cup not staying closed, detergent not being dispensed properly, or leaks from the detergent compartment.

Symptoms of a bad detergent cup latch may include:

• The detergent cup not staying closed during the wash cycle
• Detergent not being released or dispensed into the dishwasher
• Leaks or spills from the detergent cup area

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.

The Fill Cap Assembly is an OEM part for GE dishwashers. This assembly includes the cap that covers the opening where rinse aid or other additives are poured into the dishwasher. It ensures that the additives are securely contained and properly dispensed during the wash cycles, contributing to effective cleaning and drying.

Over time, the fill cap assembly can become damaged due to regular use, exposure to cleaning agents, or accidental mishandling. A compromised fill cap can lead to leaks or improper dispensing of rinse aid, affecting the dishwasher's performance.

Symptoms of a bad fill cap assembly include:

• Rinse aid or additives leaking from the dispenser
• The cap not securing properly or coming off easily
• Improper dispensing of rinse aid
• Visible cracks or damage to the cap

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Damper has adhesive backing.

Size: 8-16 x 2 inch ss.

The Detergent cup spring is an OEM component for GE dishwashers. As part of the detergent cup assembly, this spring ensures the detergent cup door remains securely closed during the wash cycle. It provides just the right amount of pressure to keep dishes clean while preventing leaks or spills.

Causes of a bad detergent cup spring include general wear and tear, repeated use breaking down the coils of the spring, or damage from forceful handling.

Symptoms of a bad detergent cup spring are:

• Detergent residue building up outside the detergent cup area
• Signs of liquid detergent leaks underneath the detergent cup door
• The detergent cup door remains slightly ajar during the cycle

This genuine GE OEM replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

The Dishwasher Door Gasket is an OEM part for GE dishwashers. It forms a seal around the dishwasher door to prevent water from leaking during the wash cycle. The gasket has an approximate length of 89 inches.

Causes of a bad door gasket can include wear and tear over time, improper cleaning or maintenance, or damage from sharp objects or harsh chemicals. These issues can cause the gasket to become brittle, cracked, or misshapen, compromising its sealing capability.

Symptoms of a bad door gasket include:

• Water leaking from the bottom of the dishwasher door
• Visible cracks or tears in the gasket
• The dishwasher door not closing properly
• Excess moisture around the dishwasher area

This GE replacement part is also compatible with Hotpoint, RCA, and some Kenmore models.

Note: For the short 4" piece of gasket in the bottom middle, also order WD08X10015.

The Door Gasket Insert is an OEM part for GE dishwashers, specially designed to create a watertight seal along the dishwasher door's perimeter. This insert is crucial for preventing water from leaking out of the dishwasher during operation. It fits snugly into the door's groove, ensuring that the door closes securely and no water can escape during the washing and rinsing cycles.

Causes for a Door Gasket Insert to fail include regular wear and tear from daily use, exposure to harsh detergents and high temperatures, and physical damage from loading and unloading dishes.

Symptoms of a bad Door Gasket Insert include:

• Water leaking from around the dishwasher door.
• The dishwasher door feels loose or doesn't close as tightly as before.
• Visible signs of wear, such as cracks, brittleness, or deformation in the gasket.

This OEM GE part can also be used on Hotpoint, RCA, and Kenmore/Sears appliances.


This mounting bracket kit secures the appliance cabinet for improved stability and alignment, helping stop movement, vibration, or panel gaps caused by broken or missing brackets. Restores the cabinet mounting to factory-style support. What it does

• Secures the appliance cabinet to the chassis or mounting points to keep panels aligned
• Replaces cracked, bent, or missing brackets that allow the cabinet to shift or vibrate
• Helps reduce rattling, rubbing, or movement during operation
• Provides the mounting points needed for proper panel fit and safe operation

• Disconnect power (and gas, if applicable) before starting any repairs
• Use the appliance service manual or exploded parts list for model-specific steps and correct fasteners
• Wear gloves and eye protection; handle sheet metal carefully to avoid cuts

Color: White.

Color: Black.

Includes 12 screws.

Color: White.

Includes 12 screws.

The Affresh Dishwasher Cleaner is an OEM accessory designed specifically for Whirlpool brand dishwashers. This citrus-scented tablet removes residue, odor-causing soils, and food particles from the dishwasher tub and gasket area during the cleaning cycle. Symptoms of a buildup include unwanted odors emanating from the dishwasher, especially after opening the door. Over time, residue and grime accumulate in hard-to-reach areas and provide an environment for mold and mildew growth.

Regular cleaning helps prevent this by removing leftover soils before they harden or encourage bacterial activity. The Affresh tablet utilizes a unique blend of cleaning ingredients that target soils and biofilms through a combination of powerful scrubbing action and natural cleaning enzymes.

As the #1 recommended dishwasher cleaner brand, Affresh is also compatible for use in Maytag, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper and select Kenmore dishwashers for consistent cleanliness and freshness. The package includes six tablets 4.2 ounces
