Parts for Lg WKEX200HBA/00: Dispenser / Control Panel Assy Parts

This washer tub assembly is the stationary outer tub that surrounds the spin basket and contains the wash water. Replacing a cracked or damaged tub helps stop leaks and restores proper clearance for smooth, quiet washing and spinning.

• Creates a watertight chamber around the basket to hold wash and rinse water
• Maintains proper basket clearance; damage can cause rubbing or scraping sounds
• Provides connection points for hoses and water-level components
• Common signs it may be needed: leaks from the tub area, visible cracks or warping, persistent out-of-balance/spin errors, or internal scraping/grinding noises

• Disconnect power and water; shut off supplies and safely drain remaining water
• This is a major repair—allow time and consider a second person to help lift/support the tub
• Transfer model-specific parts from the original tub to the new tub as needed; reinstall all clamps, bolts, and sensors securely
• After reassembly, level the washer, and run a test cycle to check for leaks

This drain pump assembly removes and directs wash water out of the tub so cycles can complete and clothes can drain. Replaces a failed pump to restore normal draining and cycle completion. What it does:

• Pumps water from the washer tub to the drain during drain and spin cycles.
• Commonly replaces pumps that cause standing water or failure to drain.
• Can resolve loud grinding or humming from the pump area and drain-related error codes.
• Compatible when the original pump assembly is corroded, clogged, or electrically failed.

• Disconnect power and turn off water supply before starting any repair.
• Drain remaining water from the washer to avoid spills when accessing the pump.
• Remove the service panel to access and replace the pump; note hose and wiring positions for reassembly.
• Handle the pump and impeller gently; secure all hose clamps and electrical connectors before testing.

This bolt assembly secures the appliance drum or tub to its mounting, restoring proper alignment and helping reduce noise, wobble and vibration caused by a loose or damaged fastener. What it does:

• Fastens the drum/tub to the suspension, shaft or mounting bracket to keep the assembly stable
• Replaces a worn, bent or broken bolt that can allow rubbing, knocking or excessive vibration
• Helps stop intermittent banging or misalignment caused by a loose or missing fastener
• Use only if the part matches your appliance's parts diagram and service manual

• Disconnect power (and water for washers) before beginning any repair
• Access and removal steps vary by model — follow the OEM service manual or exploded parts diagram
• Use correct tools and torque; do not overtighten or modify the bolt
• Inspect nearby mounts, bushings and suspension components for wear while replacing the bolt

Replacement bolt assembly that secures internal appliance components and restores proper alignment. Replacing a worn or damaged bolt helps stop rattling, prevent parts from shifting, and keeps panels and brackets securely fastened. What it does:

• Secures mounting points, brackets or panels to hold parts in place and maintain alignment.
• Prevents movement that can cause rattling, vibration, or misaligned components.
• Replaces missing, stripped, or damaged bolts that allow parts to shift or sag.
• Helps restore stable operation and reduces noise caused by loose hardware.

• Disconnect power (and water, if applicable) before starting any repairs.
• Use the correct hand tools; avoid forcing the bolt and do not overtighten.
• Wear gloves and eye protection; watch for sharp edges on panels and brackets.
• After installation, verify parts are aligned and test the appliance for normal operation.

The Heater Assembly is an OEM replacement part for LG dryers. It is a critical component responsible for generating the heat necessary for drying clothes efficiently and effectively.

Symptoms of a bad heater assembly:

• Dryer not producing enough heat or failing to dry clothes completely
• Excessive drying times or inconsistent drying performance
• Visible damage or breaks in the heating element coil
• Burning odors or smoke emanating from the dryer during operation

Causes of a bad dryer heater assembly can include mechanical failure, electrical malfunctions, or simply reaching the end of its lifespan due to repeated heating and cooling cycles.

This OEM LG part is also compatible with Sears/Kenmore dryer models.

This bracket is a replacement mounting bracket used to secure components inside the appliance, restoring proper alignment and support so parts stay fixed and operate correctly. What it does:

• Provides structural support for internal components to prevent shifting or vibration
• Secures panels or assemblies to maintain correct alignment during operation
• Helps stop rattling or loose parts that can cause noise or wear
• Fits into the original mounting locations to restore factory stability

• One replacement mounting bracket

• Disconnect power and unplug the appliance before beginning any repair
• Retain all original fasteners; use only the specified screws/bolts for secure mounting
• Inspect surrounding components for damage and replace any worn fasteners or clips as needed

The Dryer Drum Baffle is an OEM part for LG dryers. This baffle is attached to the inside of the dryer drum and is designed to help lift and tumble clothes during the drying cycle.

Causes of a bad dryer drum baffle can include wear and tear from regular use, physical damage from heavy or sharp objects, or becoming loose due to vibration over time.

Symptoms of a bad dryer drum baffle include:

• Thumping or banging noises during the drying cycle
• Clothes not tumbling properly, leading to uneven drying
• Loose or rattling baffle inside the drum
• Visible damage or breakage on the baffle

This OEM LG part is also compatible with some Kenmore models.

The Motor Rotor Bolt is an OEM part for LG washing machines. It secures the rotor to the motor shaft, playing a crucial role in the efficient functioning of the motor and ensuring the washer drum spins correctly during wash cycles.

Causes of a bad motor rotor bolt can include wear and tear from prolonged use, corrosion due to exposure to moisture, or damage from over-tightening or accidental impacts. A faulty motor rotor bolt can compromise the stability of the motor, leading to various operational issues.

Symptoms of a bad motor rotor bolt include:

• The washer drum not spinning or spinning irregularly
• Unusual noises during operation, such as banging or clunking
• The washer failing to complete cycles or stopping mid-cycle
• Visible wear or damage to the bolt or surrounding components

This OEM LG part is also compatible with Sears/Kenmore models.

This parts assembly is the factory replacement assembly used to restore proper operation by replacing a damaged or worn assembly. It installs in-line with existing components to recover normal function. What it does:

• Replaces a damaged or failing assembly that can cause intermittent or no operation
• Restores electrical and/or mechanical connections between related components
• Helps eliminate symptoms such as unresponsive controls, loss of function, or erratic operation
• Matches OEM fit and mounting points for a direct replacement

• Requires basic mechanical skills; verify power is disconnected before starting
• Compare the assembly to the original for orientation and connector matches before installation
• Use proper tools and follow manufacturer service instructions
• Handle connectors and wiring carefully to avoid damage

This is a four ribbed poly V belt.

This is the main power control circuit board that manages an appliance's power distribution and electronic control functions, restoring proper control if the original board fails. It replaces the unit's primary control module to help return normal operation. What it does

• Controls power and electronic signals for the appliance's user interface and functional components
• Can stop appliance from powering on or cause a blank/unresponsive display when faulty
• May cause intermittent operation, random resets, or failure to start individual cycles/components
• Supports communication between sensors, switches, and relays to coordinate normal operation

• One main power control PCB assembly

• Disconnect all power before starting; verify mains are off to avoid shock
• Handle the board by edges and avoid touching components; observe electrostatic discharge (ESD) precautions
• Transfer any user connectors or standoffs exactly as removed; ensure all wiring harnesses seat fully

The Hi Limit Thermal Fuse is an OEM part for LG dryers. This fuse is a safety device that protects the dryer from overheating by cutting off power to the heating element if the dryer’s temperature exceeds a safe limit. It ensures that the dryer operates within safe temperature ranges, preventing potential fire hazards.

Replace the hi limit thermal fuse if it becomes faulty due to wear and tear, a buildup of lint, or exposure to high temperatures over time. A malfunctioning fuse can compromise the dryer’s ability to regulate heat properly.

Symptoms of a bad hi limit thermal fuse include:

• The dryer not heating
• The dryer shutting off unexpectedly during a cycle
• No response from the dryer when attempting to start a cycle
• Extended drying times due to lack of heat

This OEM LG part is also compatible with Sears/Kenmore models.

The Outer Door Boot Seal Clamp is an OEM part for LG washing machines. This clamp secures the outer door boot seal, ensuring a tight seal to prevent water leaks during the wash cycle.

You should replace the outer door boot seal clamp if it becomes damaged or loses its tension, which can happen due to regular use, exposure to harsh cleaning agents, or physical wear and tear.

Symptoms of a bad outer door boot seal clamp include:

• Water leaks from the door area during the wash cycle
• Loose or shifting door boot seal
• Difficulty in closing the washing machine door securely

This OEM LG part is also compatible with Sears/Kenmore.

This genuine replacement parts assembly restores the original hardware and connections in compatible LG appliances, helping return worn or damaged assemblies to proper fit and function. Use it to replace broken, loose, or non-functioning component groupings. What it does

• Replaces the original grouped components that secure and connect related parts within the appliance
• Restores proper mechanical fit and electrical connections where an assembly has failed or become loose
• Addresses symptoms such as loose panels, intermittent connections, or components that no longer align or engage
• Helps prevent further wear by restoring correct mounting and support for adjoining parts

• Disconnect power (and water, if applicable) before beginning any repair.
• Handle connectors and fragile components carefully; avoid bending contacts or stressing wiring.
• Match the assembly visually and by part number before installation to ensure compatibility.

The Drum Seal is an OEM part for LG dryers. This part ensures a tight seal between the dryer drum and the dryer body, preventing hot air from escaping and maintaining the efficiency of the drying process. A well-functioning drum seal is important for the best dryer performance, contributing to energy efficiency and the prevention of unnecessary wear on clothing during the drying cycle.

Causes of a bad drum seal can range from natural wear and tear over time to overloading the dryer, which can strain and stretch the seal, leading to a poor fit.

Symptoms of a bad Drum Seal include:

• Clothes taking longer to dry
• Increased energy usage due to loss of heat
• Excessive lint and debris outside of the lint filter area
• A noticeable gap between the dryer drum and the dryer body

This OEM LG part is also compatible with some Kenmore models.

The Hi Limit Thermostat Assembly is an OEM part for LG dryers. This thermostat monitors and regulates the temperature within the dryer to prevent overheating, ensuring safe and efficient operation. It acts as a safety device that shuts off the heating element if the dryer exceeds a certain temperature, protecting the appliance and your home from potential fire hazards.

Over time, the hi limit thermostat can fail due to wear and tear, electrical issues, or repeated exposure to high temperatures. If the thermostat becomes faulty, it can lead to improper temperature regulation within the dryer.

Symptoms of a bad hi limit thermostat include:

• The dryer overheating
• The dryer not heating at all
• The dryer shutting off mid-cycle
• Extended drying times due to inconsistent heating

This OEM LG part is also compatible with Sears/Kenmore models.

This Taptite screw is a factory thread-forming fastener used to secure panels, brackets, and internal components where specified by the manufacturer. It forms threads as it drives for a secure, long-lasting hold when replacing a missing or damaged screw.

• Fastens covers, brackets, and internal parts at the designated mounting points
• Thread-forming "Taptite" design creates mating threads in the receiving hole for a snug fit
• Helps restore alignment and reduce vibration or rattling from loose hardware
• Typical symptoms: loose or misaligned panel/handle, rattles during operation, missing or stripped screw

• Disconnect power (and shut off water/gas if applicable) before servicing
• Replace only in the exact location specified for this part; match head style and length to the original
• Start by hand to avoid cross-threading; if resistance is high, back out and re-start
• Tighten until snug; do not overtighten to prevent stripping or cracking

The Motor Stator Bolt is an OEM part for LG washing machines. This bolt secures the stator to the motor, ensuring the stability and proper functioning of the washing machine's motor assembly.

Causes of a bad motor stator bolt can include wear and tear over time, improper installation, or damage from over-tightening or impact. A compromised bolt can lead to instability in the motor, potentially affecting the washer's performance.

Symptoms of a bad motor stator bolt include:

• Unusual noises during the wash cycle
• Vibrations or shaking of the washer
• The motor not functioning properly or failing to start

This OEM LG part is also compatible with Sears/Kenmore.

This single wire harness connects electrical components to restore power and signal routing for the appliance. It replaces a damaged or worn harness to help re-establish reliable electrical connections. What it does:

• Transfers power and signals between control boards, sensors, and actuators
• Helps resolve intermittent operation, failure to start, or component non-response when caused by wiring faults
• Replaces frayed, burned, or connector-damaged wiring to restore proper circuit continuity
• Matches OEM connector types and routing for a direct-fit replacement

• One single wire harness as shown

• Power off and unplug the appliance before beginning any repair
• Verify the harness routing and connector orientation match the original before securing
• Use appropriate tools and avoid pinching wires; replace any mounting clips that are damaged

This connector nozzle is a small replacement plumbing/airflow fitting that restores a secure, directed connection between hoses or tubing in compatible LG appliances. It helps stop leaks and keeps fluid or airflow routed where it belongs. What it does

• Provides a sealed connection point for a hose or tube to the appliance
• Directs fluid or air flow through the intended channel to prevent leaks or misrouting
• Replaces worn, cracked, or damaged nozzles that cause dripping or reduced performance
• Fits into the appliance's existing plumbing or tubing coupling to restore proper operation

• One connector nozzle

• Turn off power to the appliance before beginning work
• Shut off the water supply and relieve any pressure if the nozzle is part of a water line
• Remove only the damaged nozzle and install the replacement by seating it fully and securing clamps or fittings as originally installed
• If you notice persistent leaks after installation, recheck hose seating and clamps.

This internal inlet hose directs incoming water into the appliance's fill system. Replacing a cracked or leaking hose restores proper water flow during cycles and helps prevent water damage around the unit. What it does:

• Routes water from the supply or inlet valve into the unit during fill
• Maintains a sealed path to help prevent drips and leaks when clamped correctly
• Common failure symptoms: water on the floor, slow or no fill, visible cracks/bulges/kinks, or dripping at hose connections
• Restores consistent water delivery to the dispenser, tub, or reservoir

• 1 inlet hose

• Disconnect power and shut off the water supply before servicing
• Place a towel or pan to catch residual water; relieve line pressure
• Note hose routing and transfer any reusable clamps/fittings from the original
• Secure all connections, restore water/power, and run a test cycle to check for leaks

The Inlet Valve Assembly is an OEM component specifically designed for LG front-load washers. Located near the water supply hose connection, the inlet valve controls the flow of water entering the washer tub.

Symptoms of a bad inlet valve assembly include:

• Slow or incomplete fills during wash cycles
• Water leaks when the washer is off or idle
• Fluctuations in water levels inside the tub
• The valve becomes difficult to turn on or off

Causes of failure can be mineral buildup clogging internal ports, worn seals no longer tightly closing the passageway, or damaged electronics affecting valve operations.

The Inlet Valve Assembly is an OEM part for LG front-loading washing machines. It is a critical component that controls water flow into the washer tub. Comprised of durable solenoid valves and precision sealing elements, the inlet valve assembly works automatically to supply the appropriate amounts of hot and cold water at predetermined stages in each cycle.

Causes of a bad inlet valve can include mineral buildup obstructing valve ports over time, worn valve seals resulting in water leaks, or electrical faults preventing the solenoids from opening and closing reliably.

Symptoms of a bad inlet valve assembly include:

• The washer failing to fill with water
• Uneven or unbalanced water temperature
• Water leaks at the valve connections
• Error codes related to water level or temperature detection

This OEM LG part is also compatible with Sears/Kenmore front-load washers.


The Float Assembly is an OEM part for LG washing machines. This part monitors and controls the water level within the appliance. It's a safety feature that prevents water overflow and potential flooding, contributing to the efficient operation of the washing machine by maintaining the correct water level for each cycle.

Causes of a bad Float Assembly can vary from simple blockages that prevent the float from moving freely to electrical faults within the switch mechanism.

Symptoms of a bad Float Assembly include:

• Water overflowing from the washing machine
• Inadequate water levels that affect the washing cycle's effectiveness
• The washing machine failing to start the fill cycle due to a malfunctioning float switch

This OEM LG part is also compatible with some Kenmore models.

The Stator Assembly is an OEM part for LG washing machines. The stator assembly acts as the stationary component of the motor that drives the wash drum and basket. It converts alternating current into mechanical motion through electromagnetic induction, working together with the rotor to power the motor.

Causes of a bad stator assembly can include defects in the windings, bearing wear, or damage due to excessive heat.

Symptoms of a bad stator assembly include:

• The motor failing to start or run
• Abnormal noises coming from the transmission
• Vibration or shaking issues
• Inability to advance cycles

This OEM LG part is also compatible with some Kenmore models.

This base bracket mounts to the washer's lower frame to hold associated components securely in place. By keeping parts properly anchored, it helps maintain alignment and stability during operation to minimize vibration and noise.

• Attaches to the washer base and provides a mounting point for designated hardware
• Helps keep assemblies from shifting during agitation and spin
• Supports smooth, quieter operation by reducing vibration and rattling
• Common signs of failure include a bent or cracked bracket, loose/misaligned parts, or unusual noises from the base area

• Disconnect power and water supply before servicing; move the appliance for safe access
• Carefully tip or lay the washer back on protective padding; use a helper for stability
• Note the bracket's orientation and reuse existing mounting hardware as applicable
• Tighten fasteners securely and verify nearby parts have proper clearance before test run

This tub assembly is the washer's inner drum that holds and rotates laundry during wash and spin cycles, restoring proper agitation and spin performance for units with a damaged or worn drum. What it does

• Houses and tumbles clothes so water and detergent move through fabric during wash cycles
• Enables balanced spinning and high-speed rotation during the spin cycle
• A damaged or warped drum can cause loud banging, scraping noises, or clothes abrasion
• Cracks or severe damage may allow water to contact bearings or seals, causing further wear

• Disconnect power and water supply before beginning service
• Replacing the drum requires partial disassembly of the washer cabinet and suspension components; keep fasteners organized
• Inspect and replace related wear items (seal, bearings, spider/bolts) if they show damage

This top plate is the outer cooktop panel that covers and protects the range's internal components while providing a finished surface. It restores appearance and helps maintain proper airflow and safety around heating elements. What it does:

• Replaces a cracked, warped, dented, or cosmetically damaged cooktop outer panel
• Shields internal components from spills, debris and direct heat exposure
• Helps maintain the correct clearance and alignment for heating elements and grates
• Restores the range's finished look and supports proper operation of surface components

• One top plate

• Disconnect power to the appliance before beginning any work
• Removal typically requires removing burners/grates and several mounting screws; keep fasteners organized
• Handle the panel carefully to avoid cuts or further damage; two people may be needed for larger panels

This drawer panel assembly restores the finished front of a refrigerator/freezer drawer, returning a clean appearance and proper fit. Designed to replace cracked, dented, or loose drawer fronts for a secure, finished look. What it does:

• Replaces damaged or cracked drawer front surfaces for improved appearance.
• Restores proper alignment and a snug fit to help the drawer close correctly.
• Replaces broken or worn mounting tabs that cause a loose or wobbly panel.
• Helps prevent drafts or gaps caused by a misshapen or damaged front.

• Disconnect power and empty the drawer before starting; follow appliance safety precautions.
• Basic hand tools are typically required; remove trim or screws securing the old panel to install the new one.
• Handle edges and mounting tabs carefully to avoid damage during installation.

The LAMP, LED is an OEM component specifically designed for LG dryers. It provides illumination inside the dryer drum, a crucial safety feature for easily viewing clothes during operation. Proper lighting allows users to monitor drying progress without hindering efficiency.

Causes of a bad LED lamp can include regular wear and tear over extended use, as well as potential electrical issues disrupting current flow to the lighting source.

Symptoms of a bad LED lamp include:

• Dim or completely absent lighting inside the dryer drum
• Inability to visually inspect clothes without opening the dryer door
• Premature ending of cycles due to detection of insufficient light

The high-efficiency LED technology in this OEM part helps maximize useful life. Replace yours today to restore optimal usability. This LG replacement part is also compatible with Sears/Kenmore models.

This softener cap seals and directs fabric softener within the washer dispenser to prevent leaks and ensure proper dispensing. Replacing a damaged cap restores correct softener flow and helps avoid dispenser drips or residue buildup. What it does

• Seals the fabric softener compartment to prevent leaks during fill and agitation
• Directs softener into the wash at the correct cycle, helping prevent early-release or pooling
• Reduces dispenser residue and clogs caused by cracked or warped caps
• Commonly replaced when the cap is cracked, missing, or no longer forms a proper seal

• One softener dispenser cap as shown

• High-level replacement — remove the dispenser assembly cover before swapping the cap
• Power off and disconnect the washer before servicing to avoid electrical or mechanical injury
• Handle small plastic parts carefully to avoid damage; test dispenser operation after reassembly

This replacement siphon cap seals the siphon/drain connection to help prevent leaks and keep the appliance's drainage operating as intended. It restores a watertight seal and helps reduce drips or odors caused by a compromised cap. What it does:

• Seals the siphon/drain connection to prevent water leaks and drips
• Helps maintain proper drainage by preserving the siphon's seal
• Reduces the chance of odors from slow or exposed drains
• Replaces a worn, cracked, or missing siphon cap to restore normal operation

• One siphon sealing cap

• Turn off and unplug the appliance and shut off the water supply before servicing
• Remove the old cap and clean the mating surface before installing the new cap
• Press the cap into place until fully seated; ensure a snug, leak-free fit

The Detergent Dispenser Box is an OEM part for LG washing machines. Housed within the washer door, this compartment delivers precise amounts of detergent at the optimal time.

Symptoms of a bad dispenser box include:

• Cracks or breaks compromising the dispenser structure
• Detergent leaking or residual buildup outside of the box
• Failure to fully dispense detergent during wash cycles

Causes of failure can include plastic fatigue from years of opening/closing the washer door. Repeated impacts may also damage internal mechanisms. This OEM LG part can also be used on Kenmore/Sears appliances.

The Roller Kit is an OEM part for LG dryers. This 4 roller kit includes replacement drum support rollers, which are essential for allowing the dryer drum to rotate smoothly during operation. The rollers are designed to provide stable support for the drum, minimizing noise and ensuring efficient drying performance.

Over time, drum rollers can wear out due to continuous use, exposure to heavy loads, or lack of proper lubrication. When the rollers become damaged or worn, they may develop flat spots, lose their smooth surface, or begin to squeak. These issues can lead to improper drum rotation or increased strain on other dryer components.

Symptoms of a bad Roller Kit include:

• Loud squeaking, rumbling, or thumping noises during operation
• The dryer drum not spinning or rotating unevenly
• Excessive vibrations while the dryer is running

This OEM LG part is also compatible with Sears/Kenmore.

A manufacturer-configured replacement component designed to restore the appliance's original factory settings and functions. Use this part when a model-specific, pre-configured module is required to return correct operation. What it does:

• Provides the factory-specific configuration and setup programmed by the manufacturer
• Restores functions controlled by the module when configuration or programming is corrupted
• Resolves symptoms such as appliance not starting, control panel unresponsive, or intermittent/erratic operation linked to configuration errors
• Ensures compatibility with model-specific features when the appliance requires a pre-configured assembly

• Disconnect power to the appliance before starting any work
• Handle electronics carefully; observe electrostatic discharge (ESD) precautions for circuit boards or modules
• Match connectors and mounting locations to the original part; do not force connectors

This hinge bracket secures a refrigerator door hinge assembly to the cabinet, restoring proper door alignment and smooth opening. Replace a damaged or bent bracket to stop sagging, binding, or uneven door gaps. What it does:

• Supports the door hinge, maintaining correct door alignment and seal
• Prevents door sag that can cause gaps, poor cooling, or uneven wear
• Helps stop binding or noisy door operation caused by a cracked or bent bracket
• Works as the mounting point between the hinge and cabinet/frame

• One hinge bracket

• Disconnect power and empty the door before removing hinge components to avoid injury or damage
• Loosen or remove hinge fasteners, support the door while swapping the bracket, then retighten fasteners to secure alignment
• Check door alignment and gasket seal after installation; adjust hinge position as needed
• Use appropriate tools and follow safety precautions; for complex repairs

This drain hose cap seals and secures the refrigerator defrost drain outlet so meltwater is directed into the drain hose instead of pooling in the cabinet. Replaces a worn or damaged cap to help stop interior leaks and water buildup. What it does:

• Seals the defrost drain outlet to prevent water from spilling into drawers or onto shelves.
• Guides defrost/meltwater into the drain hose and toward the drain pan.
• Helps reduce odors and pests entering through an open drain opening.
• Fits onto the drain outlet to replace cracked, missing, or loose caps.

• Disconnect power before working inside the refrigerator to avoid electrical hazard.
• Remove shelves and drawers as needed to access the drain outlet; clear any visible debris or ice first.
• Press the cap firmly onto the drain outlet/hose until fully seated; avoid excessive force or prying tools.
• After installation, pour a small amount of warm water down the drain to confirm proper flow and seating.

This replacement case is the outer housing that protects and encloses internal components, keeping them secure and helping maintain proper airflow and alignment. It restores the appliance's structural support and appearance. What it does:

• Covers and protects internal parts from dust, debris, and accidental contact
• Helps maintain component alignment and reduces movement or rattling
• Assists in directing airflow or ventilation pathways as designed
• Restores the appliance's outer appearance after damage or wear

• One replacement case

• Disconnect power before starting any repair; follow all safety precautions
• Handle with care to avoid scratching or cracking the replacement case
• Minor disassembly of adjacent panels or brackets may be required for fitment

This cabinet cover assembly is the outer trim piece that protects and finishes the appliance cabinet, keeping internal components and wiring concealed while restoring the appliance's appearance. It provides a secure, finished surface where the cabinet joins other panels. What it does:

• Covers and protects control boxes, wiring and internal components from dust and accidental contact
• Restores the appliance's exterior appearance when the original cover is cracked or missing
• Helps maintain correct panel alignment and reduces light leakage behind control areas
• Damaged or loose covers can cause visible gaps, vibration noise, or expose internal parts

• One cabinet cover assembly

• Always unplug the appliance or switch off power at the breaker before starting work
• Remove adjacent panels or trim as needed to access mounting screws; retain hardware for reassembly
• Handle edges carefully—use gloves to avoid cuts on metal or sharp plastic edges

The Lint Filter is an OEM part for LG dryers. This essential component is designed to trap lint and debris from the drying clothes, preventing it from accumulating in the dryer's exhaust system. By effectively capturing lint, the filter helps maintain efficient airflow, reduces the risk of fires, and ensures that the dryer operates safely and efficiently.

Symptoms of a failing Lint Filter include:

• Lint and debris escaping into the dryer's vent system
• Increased drying times due to restricted airflow
• The dryer overheating, which can be felt on the exterior
• The filter being cracked, warped, or having holes
• Difficulty inserting or removing the filter from its slot

Causes of a bad lint filter can include regular wear and tear, damage from overloading the dryer, or improper cleaning and maintenance that lead to blockages or breakage.

This OEM LG part is also compatible with some Kenmore models.

The Vent Hose is an OEM part for LG washing machines. This hose is essential for ensuring proper ventilation within the washer, allowing air to circulate and preventing the buildup of moisture and mildew. It helps maintain the efficiency of the washing machine by facilitating the expulsion of air and excess water vapor during operation.

Causes of a bad washer vent hose can include wear and tear over time, blockages from lint or debris, or damage due to bending or pinching.

Symptoms of a bad vent hose include:

• Excessive moisture or condensation inside the washer
• Musty odors from the washing machine
• Visible cracks or holes in the hose
• Poor ventilation leading to inefficient washing cycles

This OEM LG part is also compatible with Sears/Kenmore.

The Door Latch Assembly is an OEM replacement part for LG dryers. It secures the dryer door safely closed during operation.

Symptoms of a failing latch include:

• The door popping or swinging open during cycles
• Difficulty fully closing and locking the door
• Reduced efficiency as warm air leaks from gaps
• Clothing partially falling out during uncontrolled openings

Causes can be worn gears that no longer hold tight closure after extended use. Over-tightening of the door seal may also put excess strain on the assembly.

This LG OEM replacement part is also compatible with some Kenmore versions.

The Lint Screen Housing is an OEM replacement part for LG dryers. It serves as the enclosure that holds the lint screen or filter, which plays a crucial role in capturing lint and preventing it from accumulating inside the dryer. This housing  measures approximately 17 in x 12 in,

Symptoms of needing to replace the lint screen housing include:

• Difficulty in removing or inserting the lint screen
• Visible cracks, warping, or damage to the existing housing
•  Lint buildup or leakage around the housing area
• The housing becoming loose or not securely holding the lint screen in place

Causes of a faulty lint screen housing can include normal wear and tear over time, exposure to excessive heat or lint buildup, or physical damage due to impact or mishandling.

This OEM LG part is also compatible with Sears/Kenmore dryer models, ensuring a perfect fit and reliable lint filtration for your specific appliance. NOTE: Due to a manufacturing change, this filter housing may be different from your original. If you have any issues installing your filter, you may need to order new filter part# ADQ56656403 and new guide part# MEA49050001 for a proper fit. When ordering [AP5071745} you will need to order filter ADQ56656403.

The Dispenser Inlet Hose is an OEM part for LG washing machines. This hose directs water from the water inlet valve to the detergent dispenser, ensuring that water mixes with the detergent before entering the drum for efficient washing. The hose is designed to withstand high water pressure and temperature fluctuations.

Over time, the dispenser inlet hose can become clogged, cracked, or worn out due to regular use. Causes of a bad inlet hose include mineral deposits or debris buildup, wear and tear, and exposure to high temperatures or pressure that can cause the hose to degrade.

Symptoms of a bad dispenser inlet hose include:

• Leaking water around the detergent dispenser area
• Reduced water flow into the dispenser
• Visible cracks or wear on the hose
• Incomplete dissolution of detergent during wash cycles

This OEM LG part is also compatible with Sears/Kenmore.

This inlet hose connects the home water supply to the appliance so it can fill properly. It replaces a worn or leaking supply hose to restore safe, reliable water flow for normal cycles. What it does:

• Directs incoming water from the household supply to the appliance inlet valve
• Works with the appliance's inlet valve and fittings to allow proper fill and rinse actions
• Commonly replaces hoses that leak, spray, kink, or block water flow
• Helps stop slow fills or intermittent filling caused by damaged or deteriorated hoses

• One inlet hose

• Turn off water supply and disconnect power before starting work
• Inspect and replace any damaged O-rings or fittings; use approved replacement fittings if needed
• Hand-tighten connections, then snug with a wrench—avoid over-tightening to prevent damage
• After installation, restore water and power, run a short fill cycle, and check all connections for leaks

This safety interlock assembly secures the washer door and signals the control when it's safe to run a cycle. Replacing a faulty unit helps restore proper locking and start functions to prevent interruptions and error codes.

• Locks the washer door and confirms it is closed to allow the cycle to start
• Sends door-closed/locked status to the control throughout the cycle
• Helps prevent the door from opening during spin or when water is present
• Common symptoms: won't start, won't lock/unlock, door error (dE) messages, cycle stops mid-wash

• Disconnect power before servicing; wear cut-resistant gloves
• Access the lock at the door opening; remove the mounting screws and disconnect the harness
• Transfer connectors to the new assembly, align, and secure without overtightening
• Ensure the door strike aligns smoothly with the new lock before testing

The Lint Filter Guide is an OEM part for LG dryers. This part guides and secures the lint filter in place within the dryer. By ensuring the lint filter is correctly positioned, it effectively helps in capturing lint, debris, and other particles from clothes during the drying cycle, contributing to optimal dryer performance and preventing potential airflow blockages that could lead to overheating.

Over time, the Lint Filter Guide can experience wear or damage from frequent use or during the cleaning and maintenance process. Damage to this part can lead to improper placement of the lint filter, which might compromise the dryer's efficiency, increase energy consumption, or pose a fire risk due to accumulated lint.

Symptoms of a bad Lint Filter Guide include:

• Difficulty in inserting or removing the lint filter
• The lint filter not fitting properly or securely
• Increased lint accumulation outside the filter area
• Unusual noises or reduced efficiency during dryer operation

This OEM LG part can also be used on Kenmore/Sears appliances.

The Lint Filter Duct Cover is an OEM part for LG dryers. It is designed to fit over the lint filter and duct area, ensuring that lint is properly trapped and does not escape into the dryer’s internal components. This cover helps maintain efficient airflow and prevents potential lint buildup, which can be a fire hazard. This part measures approximately 11-1/2 inches by 1-1/4 inches.

You should replace the lint filter duct cover if it becomes damaged or cracked, or if it fails to stay securely in place. Common causes of a bad lint filter duct cover include regular wear and tear, accidental damage during cleaning or maintenance, or exposure to high heat that can warp the plastic.

Symptoms of a bad lint filter duct cover include:

• Lint escaping into the dryer drum
• The cover not fitting securely over the lint filter
• Increased drying times due to reduced airflow
• Visible cracks or damage to the cover

This OEM LG part is also compatible with Sears/Kenmore models.

This taptite screw fastens panels and internal components in your appliance. It forms its own threads as it's driven to create a secure hold, restoring proper fit and reducing rattles caused by loose or missing fasteners.

• Forms threads in the mating material for a tight, secure fit
• Secures covers, brackets, and assemblies during repair or reassembly
• Replace when the original screw is missing, rusted, stripped, or won't tighten
• Helps address loose or rattling panels and misaligned parts

• Disconnect power before servicing
• Start the screw by hand to avoid cross-threading; use the correct driver
• Do not overtighten; if the receiving hole is damaged, repair or replace the mating component
• Reuse any original washers/spacers in the same order if present

This distortion spring applies the correct tension within the dryer mechanism so parts return to position and operate smoothly. Replacing a fatigued or broken spring helps prevent loose movement, rattling, and inconsistent operation of the related assembly. What it does

• Provides the designed return/tension force for the associated dryer mechanism
• Helps maintain alignment and smooth movement of moving parts
• Can reduce rattling or squeaking caused by weak or missing spring tension
• Symptoms include components not returning to position or intermittent operation

• One distortion spring

• Disconnect power; for gas dryers, also shut off the gas supply
• Allow internal components to cool before service
• Control the spring during removal/installation—springs are under tension and can snap back
• Note the original spring orientation and attachment points to ensure proper reassembly

The Dryer Moisture Sensor Bar is an OEM part for LG dryers. It plays a critical role in detecting the moisture level of clothes during the drying cycle, enabling the dryer to adjust the drying time automatically. This ensures efficient operation, preventing over-drying, which can damage fabrics and increase energy consumption.

Symptoms of a bad Dryer Moisture Sensor Bar include:

• Clothes remaining damp after a complete drying cycle
• The dryer continually running without stopping
• Inconsistent drying results, with some clothes over-dried and others still wet

Causes of a bad moisture sensor bar can stem from a buildup of lint and fabric softener residue, which insulates the sensor and impairs its ability to accurately detect moisture. Additionally, wear and tear or damage from loading and unloading can affect its functionality.

Regular cleaning and maintenance are recommended to ensure that your LG dryer operates efficiently and preserves the life of your clothes.

This moisture sensor connector assembly links the dryer's sensor bars to the control to monitor fabric dryness and adjust cycle time. Replacing a damaged or loose harness restores consistent Auto Dry operation.

• Connects the moisture sensor bars to the main control for Auto Dry feedback
• Transmits the low-voltage signal used to determine when clothes are dry
• Failure may cause Auto Dry to end too soon, run too long, or deliver inconsistent results
• Typical issues include broken wires, loose/corroded terminals, or a heat-damaged plug

• Disconnect power; if gas, shut off gas supply before service
• Access the moisture sensor area at the front/lint housing
• Match routing and clips, seat terminals fully on the sensor tabs, and secure the connector
• Keep wiring clear of sharp edges and moving parts; reassemble and test a Sensor Dry cycle

This is the direct-drive rotor for the dishwasher wash motor. It pairs with the stator to spin the impeller and circulate wash water through the spray arms, helping restore proper spray pressure and quieter operation when the original rotor is worn.

• Couples with the stator to drive the circulation pump impeller
• Moves wash water through the spray arms for consistent cleaning performance
• Common failure signs: little or no spray, poor cleaning, loud humming or grinding from the pump area, or intermittent wash action
• Physical damage or weakened magnets can prevent proper rotation

• Disconnect power and water supply and pull the unit forward for access
• Remove the toe-kick and drain remaining water at the sump
• Remove the pump cover and center fastener, then pull the old rotor straight off
• Seat the new rotor fully, reassemble, and run a test cycle to check operation and leaks

The Moisture Sensor Holder is an OEM replacement part for  LG dryers. It secures the crucial moisture sensor in place inside the drum. This sensor detects how damp the laundry is to determine when the cycle has finished drying clothes.

Symptoms of a bad moisture sensor holder include:

• The sensor coming loose or not making proper contact
• Inaccurate drying times as the sensor may read inconsistently
• Premature ending of cycles before clothes are completely dry
• Repeated drying error codes displayed

Causes can be cracked or broken clips after years of drum rotation. Vibrations may also loosen mounting screws over time.

Replacing with this genuine LG part ensures the sensor stays positioned correctly. Compatible models include some Kenmore and Sears dryers.

This is the rear tub drum for the washer's drum assembly; it supports the inner drum and helps keep loads balanced so the washer can tumble and spin properly. Use this part to restore stable drum rotation and reduce rubbing or banging noises. What it does:

• Supports the inner wash basket and maintains proper alignment during spin cycles
• Keeps the drum centered to prevent rubbing against the cabinet or seal
• Helps reduce loud banging, wobbling or excessive vibration during operation
• Works with the tub seals, bearings and suspension to maintain smooth rotation

• One rear tub drum

• Disconnect power and water before beginning any repair
• This is a major drum component; expect to remove the outer cabinet and other assemblies to access it
• Support the inner drum while separating components; bearings, seal and hardware may need inspection or transfer

This is an LG washer door assembly. The washer door ensures an air-tight seal between the door and washer so no water leaks out during use. If water is leaking from the washing machine during its cycles, this could be an indicator of a faulty door. The door not shutting properly could also prevent the machine from starting its cycle. This door is for a front-loading washing machine, which contain sensors that can tell when the door is shut. The washing machine will not start without engaging these sensors. Unplug the unit from its power sources before starting installation. This listing includes the hinges. Follow instructions for attaching the hinges to the appliance and the door. There are also plates that need to be installed that fasten the door shut, ensuring a tight lock during use.This door assembly is a genuine OEM replacement product sourced directly from LG. The listing is for an individual door assembly only, and there are no other parts included. This product is compatible with LG appliances.

Locker hook secures the appliance door or access panel so it stays closed during operation. Replacing a worn or broken hook restores reliable latching and prevents the door from popping open or causing noise. What it does:

• Engages with the catch or striker to hold the door/panel closed during cycles.
• Restores proper door latching and alignment for normal operation.
• Common symptoms: door won't stay closed, rattling or intermittent latching, or door popping open.
• Small replacement part used in the latch area of the cabinet or door assembly.

• Always disconnect power (and water if applicable) before servicing the appliance.
• Access the latch area by opening or removing the door/access panel per the service manual.
• Remove and save any fasteners or clips; install the new hook in the same orientation and secure all fasteners.

The Pressure Switch Assembly is an OEM part for LG washers. This pressure switch plays a crucial role in monitoring the pressure levels within the washer tub during various cycles and phases of operation. It is designed to open and close electrical circuits precisely based on pressure readings, signaling the control board to advance the program as needed.

Symptoms of a bad pressure switch include:

• Inability to complete cycles
• Error codes related to pressure
• Repeatedly stopping or not starting cycles
• Strange noises or vibrations

Causes of failure can include cracks, corrosion or wear over prolonged use. Replace yours today with this genuine LG part to restore optimal functioning and performance.

This OEM LG part is also compatible with Sears/Kenmore.

This precision fastener is designed for specific locations on the appliance. Replacing a missing or damaged screw restores secure mounting and reduces vibration or rattling, helping panels and components stay properly aligned.

• Secures brackets, panels, and internal assemblies where this screw is specified
• Replaces stripped, rusted, or lost hardware
• Helps eliminate looseness, vibration, and noise
• Maintains proper fit and alignment of parts

• Disconnect power and shut off water/gas before servicing
• Use the correct driver; keep removed hardware organized for reassembly
• Do not overtighten; install into clean, undamaged threads
• Confirm location and quantity using your model's parts diagram

This power cord assembly restores a secure electrical connection to your appliance so it can safely receive power. It replaces a worn, damaged, or faulty cord to help prevent interruptions and poor contact during normal use. What it does:

• Re-establishes the appliance's main power connection for reliable operation
• Replaces frayed, burnt, or damaged cord insulation and terminals
• Can stop intermittent power loss, sparking, or poor contact at the cord connection
• Provides the correct OEM-fit electrical cord and connector interface

• Always disconnect power at the breaker or unplug the appliance before starting work.
• Tighten terminal screws securely and avoid pinching or kinking the cord.

The Drain Hose Assembly is an OEM replacement part for LG washing machines. It is the hose directly responsible for draining water from the washer tub and out of the home during and after each cycle.

Symptoms of a bad drain hose assembly include:

• Puddling, pooling, or slowly draining water inside the washer tub
• Water not fully draining or machine not fully emptying after cycles
• Leaks or drips from hose connections or along its length
• Deterioration, cracking, or splits in the hose material

Causes can be regular wear and tear over extended use, mineral or sediment buildup, cracking from drying out, or accidental damage.

This OEM LG drain hose assembly is also compatible with some Kenmore washer models.

This is a replacement door hinge that restores proper alignment and secure movement for a fridge or freezer door. It helps the door open and close smoothly and maintain a tight seal to preserve temperature control. What it does:

• Provides a stable pivot point so the door opens and closes correctly
• Restores proper door alignment to prevent rubbing or sagging
• Helps the door seal fully to reduce cooling loss and improve efficiency
• Replaces a worn, bent, or broken hinge that causes noise or uneven movement

• One hinge

• Unplug the appliance or shut off power before starting any repair
• Support the door securely (use a helper or prop) before removing the hinge fasteners
• Use the correct fasteners and torque to avoid stripping threads or misalignment

This pivot hanger assembly supports and stabilizes the appliance component it mounts to, restoring smooth movement and alignment. Replace a worn or damaged pivot to reduce noise and prevent misalignment that can affect operation. What it does:

• Acts as the pivot point for the hanger to support the drum/door assembly and maintain correct alignment
• Helps eliminate squeaks, scraping, or jerky motion caused by a worn pivot
• Prevents sagging or uneven movement that can lead to rubbing or binding
• Restores proper mechanical support so the appliance operates quietly and reliably

• Unplug the appliance or disconnect power before beginning any repair
• Basic hand tools may be required; follow the appliance service manual for disassembly steps
• Inspect surrounding components (mounts, bearings, fasteners) and replace if worn

The Door Seal is an OEM part for LG dryers. It forms a tight seal around the dryer door, preventing heat and moisture from escaping during the drying cycle, which ensures efficient drying and energy use.

Causes of a bad door seal can include wear and tear from regular use, damage from repeated opening and closing of the dryer door, or degradation from exposure to heat and moisture over time. A compromised door seal can lead to longer drying times and increased energy consumption.

Symptoms of a bad door seal include:

• Heat and moisture escaping from the dryer door
• Longer drying times
• Clothes not drying completely
• Visible cracks, tears, or wear on the seal

This OEM LG part is also compatible with Sears/Kenmore.

The Clamp is an OEM part for LG washing machines. It is used to secure the hose connections within the washer, ensuring that water flows correctly without leaks.

Over time, the clamp can become worn or damaged due to repeated exposure to water, vibration, or general wear and tear. If the clamp fails, it can lead to water leaks or hoses becoming detached.

Symptoms of a bad clamp include:

• Water leaking from hose connections
• Hoses coming loose or detaching during operation
• Visible rust or damage on the clamp
• Poor water flow or pressure issues

This OEM LG part is also compatible with Sears/Kenmore models.

This hose clamp secures a rubber hose connection to prevent leaks where the hose meets its fitting. A tight, uniform seal helps maintain proper water flow and keeps the appliance operating reliably.

• Provides a tight, 360-degree seal around the hose barb/fitting
• Helps correct issues like water leaks at the hose connection point
• Maintains correct hose attachment during operation and vibration
• Step-less ear design distributes clamping force evenly

• Unplug power and shut off water supply before servicing
• Note clamp orientation and hose routing before removal
• Use appropriate ear-clamp pincers or pliers to compress the clamp evenly
• Check the hose and fitting for wear; replace if cracked or deformed

This hose clamp secures a washer hose to its fitting to maintain a tight, leak-resistant connection. Replace a weakened or damaged clamp to stop seepage at hose joints and keep the washer operating reliably.

• Holds the hose firmly on pump, tub, or drain fittings to help prevent leaks
• Maintains clamping pressure during operation and vibration
• Replace if rusted, bent, cracked, or no longer holding tension
• Typical symptoms: water dripping at hose connections or a hose that slips off

• Disconnect power and shut off water; drain any remaining water from the unit
• Release and slide back the old clamp, then remove the hose
• Fully seat the hose on the fitting and position the clamp just behind the hose bead/ridge
• Secure the clamp and run a brief test to check for leaks

A replacement hose clamp that secures a flexible hose to its fitting to help prevent leaks and disconnections. Restores a tight, reliable seal so hoses stay seated during normal use. What it does:

• Holds a rubber or plastic hose firmly to a pump, valve or connection to prevent leaks.
• Helps stop hose pull-off that can cause water leaks or appliance interruptions.
• Commonly replaced when clamps are corroded, bent, cracked or missing.
• Works as a low-cost repair to restore a secure hose connection without replacing the hose assembly.

• Disconnect power to the appliance and shut off the water supply before servicing.
• Use the correct tool (slip-joint pliers for spring-style clamps or a screwdriver for screw-type clamps) and avoid pinching the hose.
• Inspect the hose and fitting for damage; replace the hose if it's cracked or excessively worn.
• After installing, restore power/water and run a short test cycle or check for leaks.

The NOISE FILTER ASSEMBLY is an OEM part for LG washing machines. It is a component designed to minimize vibrations and reduce noise emanating from the washer during operation. Proper noise damping is important for smooth functionality without disturbance.

Causes of a bad noise filter assembly can include cracks or tears developing over extended use. Physical damage from impact could also compromise its noise-blocking abilities.

Symptoms of a bad noise filter assembly include:

• Loud banging or clanking noises during wash and spin cycles
• Excessive vibrations felt through the washer cabinetry
• Increased stress on other components from inadequate dampening
• Premature wear of suspension components like legs and runners

Replace yours today with this genuine OEM LG part to restore a quiet wash experience. This replacement assembly ensures optimum vibration control. It is also compatible with Sears/Kenmore models.

The Gasket is an OEM part for LG washers. This part creates a watertight seal between the door and the drum, preventing any leaks. It seals the door, keeping water from escaping during the wash cycle.

A bad door boot gasket can occur due to wear and tear, mold or mildew buildup, or physical damage. If you notice symptoms such as water leaking from the door, visible tears or cracks in the gasket, or a musty odor coming from your washer, it's time to replace the the worn-out or damaged door boot gasket with this genuine OEM part.

Symptoms of a bad door boot gasket include:

• Water leaking from the door
• Visible tears or cracks in the gasket
• Musty odor coming from the washer

This LG replacement part is also compatible with select Kenmore models.


This frame bracket secures and supports appliance panels and structural components to restore proper alignment and reduce movement. It's a direct-fit replacement that helps stop panel rattling and keeps connected parts stable during operation. What it does:

• Secures the appliance frame or panel to the cabinet to maintain proper alignment.
• Provides structural support to prevent flexing or sagging of connected components.
• Reduces rattling, vibration, and noise caused by a loose or broken bracket.
• Common symptom: visible looseness, misaligned panel or persistent vibration during use.

• Disconnect power (and water if applicable) before beginning any repair.
• Use the OEM service manual or exploded parts diagram for correct placement and fastener locations.
• Typical installation requires basic hand tools; inspect surrounding mounting points and hardware and replace if worn.
• If the bracket is plastic, avoid overtightening screws to prevent cracking.

The Blower Wheel is an OEM part for LG dryers. This part circulates air through the dryer drum and out the exhaust vent, ensuring proper airflow for efficient drying of clothes.

Causes of a bad blower wheel can include accumulation of lint and debris, wear and tear over time, or physical damage due to foreign objects entering the blower housing.

Symptoms of a bad blower wheel include:

• Reduced or no airflow from the exhaust vent
• Unusual noises such as rattling or squealing during the drying cycle
• Clothes taking longer to dry or remaining damp
• Overheating or frequent shutdowns of the dryer

This OEM LG part is also compatible with some Kenmore models.

Adapt your gas dryer for propane with this LP conversion kit. It provides the correct orifice and regulator adjustments needed so the burner fires properly on LP fuel, helping ensure safe operation and consistent drying performance after a fuel change.

• Converts a compatible gas dryer from natural gas to liquid propane (LP)
• Helps ensure proper burner flame characteristics on LP
• Appropriate when moving to a home with propane or changing utilities
• Symptoms can include weak heat, improper flame, or sooting

• Disconnect power and shut off gas before servicing
• Installation and regulator/orifice adjustments must be performed per the service manual
• After installation, leak-check all connections and verify proper burner operation
• Do not attempt conversion without the correct kit for your specific model

A molded water guide that routes dispenser water inside the refrigerator to the dispenser/ice area, helping direct flow and reduce splashing. Fits the factory mounting points for a clean, secure path for water. What it does

• Channels water from the inlet tubing toward the dispenser/ice assembly to prevent misdirected flow.
• Helps keep water from pooling or dripping inside the cabinet or on internal components.
• Common replacement when you see water on shelves, puddling near the dispenser, or reduced or misdirected dispenser flow.
• Preserves proper alignment of the dispenser plumbing to prevent kinks or strain on tubing.

• One water guide (single molded channel) as shown.

• Turn off the refrigerator and shut off the water supply before starting; disconnect power for safety.
• Remove interior panels or shelves as needed to access mounting points; keep fasteners for reassembly.
• Inspect adjoining tubing and seals for damage and replace any worn components to ensure a leak-free fit.
• After installation, restore power and water, then check carefully for leaks during an initial test dispense.

Blower housing assembly for dryer that channels heated air from the drum to the exhaust. Replaces a cracked or damaged housing to restore proper airflow and help the dryer dry more efficiently and quietly. What it does:

• Channels heated air from the drum to the exhaust and supports the blower wheel.
• Restores airflow when a damaged or cracked housing is restricting ventilation.
• Commonly used to address reduced drying performance and longer dry times.
• Can also resolve unusual rattling or grinding noises coming from the lower front of the dryer.

• Disconnect power (and gas, if applicable) before beginning work; wear eye protection and gloves.
• Remove access panels and disconnect vent/ducting per your model's service instructions to reach the blower housing.
• Inspect the blower wheel and surrounding seals/gaskets while the housing is out; replace damaged components as needed.
• Reassemble all panels and venting securely and test the dryer for proper airflow and operation after installation.

The Tub to Pump Hose is an OEM replacement part for LG top-load washing machines. This hose safely transports water between the wash tub and drain pump. The hose measures 13 inches in length.

Causes of failure relate to constant flexing under water pressure strains that accumulate over years of usage. Excess minerals in hard water areas promote accelerated breakdown of flexible PVC material.

Symptoms of a cracked or leaking tub to pump hose include:

• Water not draining or taking an abnormally long time
• Water continually accumulating inside the machine cabinet
• Error codes related to drainage issues displayed
• Puddles forming near or under the back of the washer

This genuine LG hose is also compatible with select Sears/Kenmore units as well.

This dryer duct assembly channels air from the drum to the blower and exhaust. Replacing a cracked or warped housing restores proper airflow, helps prevent lint bypass, and supports consistent drying performance.

• Directs and seals airflow between the drum and blower housing
• Helps maintain drying efficiency by minimizing leaks and lint bypass
• Damage or warping can lead to long dry times and reduced airflow
• Signs of failure include visible cracks, melted spots, or air/lint leakage around the duct area

• Disconnect power; for gas models, turn off the gas supply
• Access from the front by removing the top and front panel
• Note fastener locations and any attached brackets/harnesses, then transfer them to the new assembly
• Vacuum lint from internal ducting and verify seals before test run

This guide assembly is a replacement slide guide that helps support and align moving components for smooth operation and reliable engagement. It restores proper tracking and reduces wobble or binding in the mechanism. What it does:

• Provides stable support and alignment for a sliding component to prevent mis-tracking and uneven movement
• Reduces noise, sticking, or binding caused by worn or damaged guides
• Helps maintain proper clearance and engagement of the moving part
• Matches OEM fit and mounting points for direct replacement

• Turn off and unplug the appliance before beginning any repair to avoid electrical shock
• Remove any obstructing panels or components to access the guide
• Inspect mating parts (slides, rails, fasteners) and replace any damaged hardware to ensure correct fit

The Air Chamber is an OEM part for LG washing machines. This part connects to the pressure switch and ensures the washer machine fills with the correct amount of water for the selected cycle.

Causes of a bad  Air Chamber can include clogging due to detergent residue or debris, cracks or perforations that lead to air leaks, and aging of the material, which might compromise its integrity and function.

Symptoms of a faulty Air Chamber include:

• Inaccurate water level readings leading to overfilling or insufficient water during cycles
• Unusual noises during the fill cycle, indicating air escaping
• The washing machine failing to start the wash cycle due to improper water level detection
• Error codes displayed on the machine that relate to water level issues

This OEM LG part is also compatible with some Kenmore models.

The Dryer Thermistor is an OEM part for LG dryers, designed to monitor and help regulate the temperature within the dryer by providing feedback to the control board about the temperature inside the drum. This allows the dryer to adjust its heat settings accordingly, preventing overheating and ensuring clothes are dried evenly and safely.

Symptoms of a bad Dryer Thermistor include:

• Clothes not drying properly or taking longer than usual to dry.
• The dryer repeatedly stopping during a cycle.
• Error messages appearing on the dryer's display panel.
• The dryer getting too hot or not heating enough.

Causes of a bad Dryer Thermistor can include a buildup of lint and debris affecting its ability to accurately sense temperature, wear and tear over time, or electrical issues within the dryer's circuitry.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Dryer Blower Thermostat is an OEM replacement part for LG dryers. It plays a role in regulating the operation of the blower motor, which is responsible for circulating hot air throughout the dryer during the drying cycle.

Causes of a bad dryer blower thermostat can include electrical malfunctions, physical damage, or simply wear and tear over time.

Symptoms of a bad dryer blower thermostat include:

• The dryer not heating up properly or taking longer to dry clothes
• The blower motor failing to turn on or running continuously
• Inconsistent or inadequate airflow during the drying cycle
• Error codes or fault indicators related to the thermostat or blower motor

This OEM LG part is also compatible with Sears/Kenmore models.

This safety cover is an internal protective shield used inside the dryer to guard components and help maintain proper airflow. Replacing a cracked or missing cover helps keep wiring and moving parts enclosed for safer operation. What it does:

• Shields internal wiring and components from accidental contact
• Helps channel air and lint flow as designed
• Replaces a damaged, heat-warped, or missing cover
• Helps resolve rattling/vibration noises and visible gaps where the cover mounts

• Includes 1 safety cover

• Unplug the dryer; for gas models, shut off gas and allow the unit to cool
• Access the cover location per your model's service manual; remove panels as needed
• Position the cover correctly and secure using existing hardware/clips
• Do not operate the dryer with the cover removed or loose

This spring-style hose clamp secures a washer's rubber hose to its fitting to maintain a tight, leak-resistant seal. Replacing a weakened clamp helps stop drips and keeps the hose firmly in place during operation.

• Provides constant spring tension to hold a rubber hose on its port
• Helps prevent leaks at the connection point
• Resists vibration so the hose doesn't back off the fitting
• Common signs include water at a hose joint, a loose/detached hose, or a rusted/broken clamp

• Disconnect power and turn off water supply before servicing
• Place a towel or pan to catch residual water from hoses
• Use pliers to compress the ears, slide off the old clamp, position the new clamp behind the hose bead, and release evenly
• After reassembly, run a quick test cycle and check for leaks

The Motor Bracket is an OEM part for LG dryers. This bracket securely holds the dryer motor in place. It maintains proper alignment and spacing of the motor to allow for smooth operation of the tumble cycle.

Causes of a bad motor bracket can include cracks or breaks developed over time from repeated use and vibration, or damage due to impact or improper installation.

Symptoms of a bad motor bracket include:

• Excessive noise or grinding sounds emanating from the motor area
• The dryer not rotating or tumbling clothes properly
• Increased movement or shaking of the motor
• Poor airflow and inefficient drying performance

This OEM LG part is also compatible with some Kenmore models.

This factory kit reconfigures your dryer's exhaust to exit from the side or bottom instead of the rear. It's ideal for tight installations or when the wall vent location requires an alternate exhaust path. What it does:

• Redirects the exhaust outlet to the left, right, or bottom on compatible models (orientation varies by model)
• Enables installation in closets or shallow spaces where rear venting isn't practical
• Replaces missing or damaged side/bottom vent hardware
• Helps maintain a proper metal exhaust path when relocating the dryer

• One side vent kit

• Disconnect electrical power and shut off gas supply (if applicable) before starting
• Follow the model-specific instructions supplied with the kit or in your dryer's installation manual
• Use rigid or semi-rigid metal ducting only; avoid plastic or vinyl
• After assembly, check for secure connections, no kinks, and unobstructed airflow

The Drum Motor Assembly is an OEM part for LG dryers. It serves as the powerhouse that drives the drum, enabling it to tumble clothes during the drying cycle. This essential component ensures your dryer operates smoothly, providing the necessary torque for consistent and efficient drying performance.

Causes of failure might include wear and tear from prolonged use, overload from trying to dry heavy loads, electrical issues like short circuits, or physical damage to the motor components.

Symptoms of a bad Drum Motor Assembly include:

• The dryer drum fails to turn, even though the dryer powers on.
• Unusual noises, such as humming or buzzing, indicating the motor is struggling.
• The dryer stops unexpectedly during cycles or won't start at all.
• Decreased drying efficiency or clothes taking longer to dry due to inconsistent drum speed.

This OEM LG part is also compatible with Sears/Kenmore.

The Hinge Pin is an OEM part for LG washing machines. It serves as a pivot point for the washer door, allowing it to open and close smoothly. This component is crucial for maintaining the proper alignment and function of the washer door, ensuring a secure and reliable seal during operation.

Common causes of a bad hinge pin include frequent use leading to wear and tear, physical damage from accidental impacts, or rust and corrosion over time. A compromised hinge pin can result in misalignment of the door, affecting the washing machine's ability to close properly and maintain an effective seal.

Symptoms of a bad hinge pin include:

• Difficulty opening or closing the washer door
• Door not staying securely closed during operation
• Squeaking or grinding noises when the door is moved
• Visible wear or damage to the hinge pin

This OEM LG part is also compatible with Sears/Kenmore models.

This clamp secures hoses, tubing or wiring to the appliance frame to help prevent rubbing, vibration and routing issues. It restores a solid attachment point so lines stay in place during normal use. What it does:

• Holds a hose, tubing or wire bundle in place to prevent chafing and abrasion
• Keeps components routed away from moving parts and hot surfaces
• Reduces rattling or vibration caused by loose lines
• Helps maintain safe, reliable connections by preventing strain on fittings

• Disconnect power and shut off water before servicing
• Use basic hand tools; avoid over-tightening which can pinch hoses or wires
• Inspect adjacent hoses/wires for wear and replace if damaged
• Take photos before removal to ensure correct reinstallation

This micro switch is a compact, snap-action electrical switch that sends an on/off signal when a lever, latch, or paddle is moved. Replacing a worn switch restores reliable detection and control response for the affected function.

• Converts mechanical movement into an electrical open/close signal to the control
• Commonly used for lever/paddle actuators, latches, or interlock detection within the appliance
• Safe symptom clues: no response when actuated, intermittent operation, or a function stuck on/off
• Physical clues: weak or absent "click" when pressed, heat discoloration or damage at terminals

• Disconnect power before servicing; if the product is connected to a water line, close the supply valve
• Note wire positions and terminal labels (COM/NO/NC); transfer wires one at a time to matching terminals
• Match the actuator orientation and mounting position to the original for proper operation
• After installation, verify continuity with a multimeter and test function before reassembly

The Idler Pulley Assembly is an OEM part for LG dryers. It plays a critical role in the dryer's drum belt tension system, helping to maintain proper tension on the belt so the drum can rotate smoothly during the drying cycle.

Causes of a bad idler pulley assembly can include wear and tear over time, buildup of lint or debris, or damage from an overloaded dryer. A malfunctioning idler pulley can lead to inefficient drying and potential damage to other dryer components.

Symptoms of a bad idler pulley assembly include:

• Squeaking or squealing noises during operation
• The drum not rotating properly or at all
• The dryer stopping mid-cycle
• The belt slipping or breaking

This OEM LG part is also compatible with Sears/Kenmore.

The Dryer Idler Pulley is an OEM replacement part for LG dryers. It is a critical component that helps guide and maintain proper tension on the dryer belt, ensuring efficient transfer of rotational force from the motor to the dryer drum.

Symptoms of a faulty dryer idler pulley include:

• Squeaking or grinding noises coming from the pulley area
• Visible wear, cracks, or damage to the pulley surface
• Slipping or irregular rotation of the dryer drum

Causes of a bad idler pulley can include normal wear and tear over time, exposure to high temperatures or lint buildup, misalignment or improper tracking, or physical damage from impact or foreign objects.

This OEM LG part is also compatible with Sears/Kenmore dryer models.

This replacement screw secures appliance components in their proper position. Use it to restore a tight, rattle-free fit when the original fastener is missing, stripped, or corroded. What it does:

• Fastens brackets, panels, or trim to keep assemblies aligned and secure
• Helps prevent vibration, rattling, and gaps from loose hardware
• Restores proper attachment when a screw is lost, worn, or damaged
• Common symptoms: loose panel/handle, misalignment, rattling, or a missing screw

• Disconnect power; shut off water or gas before service
• Match location to the original; start threads by hand to avoid cross-threading
• Use the correct driver bit; do not overtighten (especially into plastic)
• If the original hole is stripped, repair threads before installing the new screw

This self-tapping screw fastens panels, brackets, and internal components in compatible appliances. Replace a stripped, corroded, or missing screw to restore a secure fit and help prevent vibration, rattling, and misalignment.

• Forms/engages its own threads in sheet metal or plastic for a secure hold
• Secures covers, brackets, and assemblies to maintain alignment
• Helps reduce vibration and noise from loose components
• Replace if the head is stripped/broken, threads are worn, or the screw is missing

• Disconnect power and shut off water or gas, as applicable, before servicing
• Match to the original location and hardware; use identical length and thread where specified
• Start by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving hole is damaged, repair it before installing the new screw

This drying rack sits inside the dryer drum to hold items that shouldn't tumble. It keeps shoes, sweaters, and other delicates stationary so they dry gently using the dryer's airflow and heat.

• Provides a stationary platform in the drum for rack-dry items
• Helps dry shoes, hats, sweaters, and stuffed toys without tumbling
• Replace if the rack is cracked, warped, missing, or won't stay seated
• Enables use of the rack-dry feature on compatible models

• Disconnect power and let the dryer cool before installation
• Open the door and slide the rack into the designated guides until fully seated and level
• Place items flat on the rack; avoid overloading or letting items hang over the edges
• Remove the rack before running regular tumble cycles

This connector nozzle attaches to the appliance's nozzle assembly to route fluid through the system and help maintain a sealed connection. It replaces a worn or cracked nozzle connector to restore proper flow and reduce leaks. What it does:

• Provides a secure connection point for the nozzle assembly, directing fluid through the correct pathway
• Restores a sealed joint to prevent drips or steady leaks at the nozzle area
• Helps eliminate flow interruptions caused by a cracked, split, or damaged connector
• Works as a direct-fit replacement when the original connector is broken or degraded

• One connector nozzle

• Turn off power and shut off the water supply before starting any repair
• Remove only the components necessary to access the nozzle area; use basic hand tools
• Check seals and adjoining hoses for wear and replace if needed to ensure a leak-free connection

The Water Valve is an OEM part for LG dryers. This valve controls the water supply to the dryer's steam setting which helps reduce wrinkles and refresh clothing.

Causes of failure can be mineral buildup overtime restricting flow, damage from freezing during winter months, or worn internal seals and mechanisms.

Symptoms of a bad water valve include:

• Inability to select or utilize the steam cycle
• Drips or leaks at the water inlet port
• Erratic water pressure during steam cycles
• Steam levels that fluctuate or cut off unexpectedly

This OEM LG part is also compatible with some Kenmore models.

The Venting Kit is an OEM part for LG dryers. This part offers flexibility and efficiency in dryer installation and setup, this kit enables side or bottom venting of the appliance, facilitating optimal use of space in your laundry area. It's ideal for situations where the traditional rear venting is not feasible or preferred.

Causes of venting system issues can include blockages, incorrect installation, or the use of incompatible parts, leading to reduced efficiency and potential safety hazards, such as overheating or fire risks.

Symptoms of a bad or improperly installed venting system include:

• Extended drying times
• Excessive humidity or heat in the laundry area
• Unusual noises during operation
• Accumulation of lint in and around the dryer

This OEM LG part is also compatible with some Kenmore models.

This multi-connector harness is the replacement wire assembly that links the appliance's control board to multiple components so signals and power flow correctly. Installing the correct harness restores reliable electrical connections and control response. What it does:

• Routes power and signal between the control board and connected components using multiple color-coded wires and connectors
• Replaces damaged, burnt, or frayed wiring that can cause intermittent operation or failure to start
• Prevents short circuits and poor connections that produce error codes or erratic performance
• Maintains correct connector pin layout for proper component communication

• One multi-connector harness (single assembly)

• Disconnect power before beginning work to avoid shock or damage
• Verify connector orientation and full seat on both ends; do not force mismatched plugs
• Inspect mating connectors and terminals for damage or corrosion before installation

The Dispenser Hose is an OEM part for LG washing machines. It connects the detergent dispenser to the washer tub, allowing detergent and other cleaning agents to be delivered effectively during the wash cycle.

Causes of a bad dispenser hose can include regular wear and tear, damage from harsh detergents, or physical damage due to kinks, pinches, or impact. Over time, the hose can become brittle, cracked, or clogged, affecting its ability to function properly.

Symptoms of a bad dispenser hose include:

• Leaks or drips from the hose area
• Detergent not dispensing correctly or at all
• Water pooling around the washer
• Visible cracks or splits in the hose

This OEM LG part is also compatible with Sears/Kenmore models.

Includes sensor probe

This DC pump motor assembly drives the appliance pump to move and remove water during drain and circulation cycles. It restores pump operation so the washer/dishwasher can empty properly and avoid standing water. What it does:

• Powers the drain/recirculation pump to move water out of the tub during drain and wash cycles.
• Common repair when the appliance fails to drain, leaves standing water, or shows drain-related errors.
• Helps restore normal water flow for wash, rinse and drain sequences.

• Disconnect power (and water, if applicable) before servicing the appliance.
• Inspect hoses, filters and the pump housing for clogs before replacing the motor.
• Note connector orientation and mounting location; transfer gaskets/seals if the original must be reused.

The Suspension Spring is an OEM part for LG washing machines, specifically designed to support the tub assembly and maintain its stability during the wash and spin cycles. This spring plays a critical role in absorbing vibrations and reducing the amount of movement transferred to the washing machine's frame, ensuring smooth and quiet operation.

Causes for a Suspension Spring to fail include normal wear and tear from repeated use, overloading the washing machine beyond its capacity, which can stretch or stress the springs, and corrosion from exposure to moisture and laundry detergents.

Symptoms of a bad Suspension Spring include:

• Increased vibration and noise during the spin cycle.
• The washing machine "walking" or moving from its original position.
• Uneven drum movement, leading to inconsistent washing and spinning.

This OEM LG part can also be used on Kenmore/Sears appliances.

The Holder is an OEM part for LG front-loading washing machines. It is a plastic mounting bracket or suspension system that attaches to the rear of the washer tub and helps secure internal components like hoses, pulleys, and the rear bearing in place during spin cycles. Subject to force and vibration, the holder must withstand years of washing use.

Symptoms of a bad holder include:

• Loosening or detaching internal parts leading to noise and imbalance
• Cracking or damage of the plastic bracketry
• Bearing or tub damage from improperly secured components

Causes can be fatigue from repeated wash cycles, stress cracks from heavy loads, or material deterioration over time. Replace with this OEM LG holder to maintain drum balance and suspend components securely. It is also compatible with Sears/Kenmore front-load washers.

The Damper Assembly is an OEM replacement part for LG washing machines. It is a critical component that helps regulate the balance and vibration levels during the spin cycle.

Causes of a bad damper assembly in a washing machine can include excessive wear and tear due to repeated high-speed spinning, damage from excessive vibrations or unbalanced loads, or failure of the internal components responsible for dampening and stabilizing the tub motion.

Symptoms of a bad washing machine damper assembly include:

• Excessive shaking or vibrations during the spin cycle
• Loud thumping or banging noises
• The washer visibly moving or walking across the floor
• Potential leaks due to increased stress on the tub and other components

This OEM LG part is also compatible with Sears/Kenmore models.
