Frigidaire 3203009 Main Wiring Harness (Primary Control Harness) OEM Part

Product Details

Genuine Frigidaire part. Frigidaire brands include Electrolux, Frigidaire, Gibson, Kelvinator, Westinghouse, Kenmore, and others.
Electrolux also makes various appliance models for Sears / Kenmore

Cross Reference Information

Part Number 3203009 replaces AP2130816.

Description

This main wiring harness routes power and signals between the appliance control board and major components, restoring reliable electrical connections for proper operation. Use it when damaged wires or connector issues interrupt function. What it does

• Carries power and control signals from the main control to motors, valves, lights, and sensors
• Replaces frayed, cut, or burnt wiring that can cause intermittent or complete failure of component operation
• Helps resolve symptoms like no power to components, lights or displays not responding, or intermittent operation
• Provides factory-style connector plugs and pre-terminated leads for direct replacement

What's included

• One main wiring harness (one assembly)

Install notes

• Disconnect power before servicing to avoid shock or damage
• Take photos or label connectors before removal to ensure correct reassembly
• Route harness along original wire paths and secure with clips or ties; avoid contact with hot surfaces
• If you find additional damage (melted insulation, damaged connectors), replace affected parts and retest
