Whirlpool Dryer LER3624BN2 Too hot

This dryer thermal cut-off kit is an authentic OEM replacement part for Whirlpool and Kenmore dryers. It is designed to prevent the dryer from overheating.

This Kit Includes:

• High Limit Thermostat (250°F Limit)
• A Cut Off Fuse (309°F Limit)
• Female Spade Terminals
• Jumper Wires

Over time, these components can fail due to electrical issues, lint buildup blocking the exhaust vent, or normal wear and tear. A malfunctioning thermal cut-off kit can result in overheating, which can pose a safety hazard and affect the dryer’s performance.

Symptoms of a bad Thermal Cut-Off Kit include:

• Dryer not heating
• Dryer overheating
• Dryer shutting off mid-cycle
• No response when attempting to start the dryer

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Restore full heat and end long dry cycles - install the Whirlpool OEM Dryer Heating Element.

Why this heating element?

• Factory-spec 5400 W / 240 V heating element with nickel-chromium coil - built by Whirlpool to Whirlpool OEM standards.
• Broad compatibility: fits Whirlpool, Kenmore 110-series, Roper, Estate, Amana, Maytag & more 27-inch dryers.
• Built to last: high-temp terminals & mica insulation resist fatigue and hotspots.

Fixes these common dryer problems

DIY install — about 20 minutes

1. Unplug dryer and remove back panel to access heater housing.
2. Disconnect wires; remove housing screws and slide assembly out.
3. Swap old element for new, re-use hi-limit thermostat if still good.
4. Re-assemble, run test cycle - enjoy fast, even drying.

The Cycling Thermostat is an OEM part for Whirlpool dryers. It regulates and monitors the temperature inside the dryer during the drying cycle. It ensures that the dryer doesn't overheat and prevents potential damage to clothes or the dryer itself.

Causes of a faulty cycling thermostat can include wear and tear over time, electrical issues, or sensor malfunction.

Symptoms of a bad cycling thermostat may include:

• Clothes taking longer than usual to dry
• Inconsistent drying results
• Overheating or burning smell
• The dryer not heating at all

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Hi-Limit Thermostat is an OEM part for Whirlpool dryers. It plays a crucial role in ensuring the dryer operates at safe temperatures by cutting off power to the heating element if the dryer overheats. This safety mechanism helps prevent potential fires and damage to the appliance.

Common causes of a bad thermostat include normal wear and tear, exposure to excessive heat, or electrical malfunctions.

Symptoms of a bad hi-limit thermostat include:

• The dryer not heating
• The dryer overheating
• The dryer shutting off unexpectedly during a cycle
• Longer drying times

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Get your dryer spinning smoothly again - install the Whirlpool 341241 OEM Drum Belt in minutes.

Why this belt?

• Exact factory spec: 92 ¼-inch length × ¼-inch width, 4 ribs / 3 grooves - built to Whirlpool standards, not a generic copy.
• Broad compatibility: Fits most Whirlpool-made dryers - Kenmore 110-series, Roper, Estate, Maytag, KitchenAid, Admiral, Crosley, Amana & more.
• Quiet, durable rubber: Reinforced EPDM resists cracking and stretch for years of reliable tumbling.

Fixes these common dryer problems

DIY install — about 15 minutes

1. Unplug dryer; remove lint screen housing & front panel.
2. Release belt tension at idler pulley; lift drum slightly to slide old belt off.
3. Loop new belt around drum, idler pulley and motor pulley (ribbed side down).
4. Re-assemble, run test cycle - enjoy quiet, consistent tumbling.
