Whirlpool Washer GHW9250ML2 Noisy

The Washer Drain Pump Assembly is an OEM part for Whirlpool washing machines. This assembly is essential for the washer's ability to drain water out of the drum after the wash and rinse cycles, ensuring clothes are properly spun and not left soaking wet.

Causes of a malfunctioning washer drain pump assembly can include blockages from small items or debris, such as coins, socks, or lint, that accidentally make their way into the pump.

Symptoms of a bad Washer Drain Pump Assembly include:

• Water not draining out of the washer, leaving clothes wet
• Unusual noises coming from the pump area, indicating a blockage or damage
• The washer stopping mid-cycle due to inability to drain
• Error codes displayed on the washer related to draining issues

This OEM Whirlpool part can also be used on Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore/Sears brand appliances.

The Drive Pulley is an OEM replacement part specific to Whirlpool washing machines. It is a toothed wheel component located inside the washer cabinet that functions with the belt to rotate the wash drum. The drive pulley provides the rotational force needed to agitate clothes and turbulent water during cycle operation.

Causes of a faulty drive pulley include normal wear of the plastic material from extended years of operation.

Symptoms include:

• Abnormal noises (squealing or screeching sounds) emanating from within the washer cabinet
• Slow or weak drum motion, even on high agitation settings
• Premature belt wear due to slipping of the drive pulley teeth
• Visible cracks or splitting in the pulley surface

This genuine OEM part is also compatible with select Maytag, KitchenAid, and other washer brands.

The Drive Belt is an OEM part for Whirlpool front load washing machines. It transmits power from the wash motor to rotate the tub assembly, tumbling clothes during cycles. The belt is designed with deep grooves to securely grip the motor and tub pulleys. It measures 48.22” long uninstalled and will stretch to 51.53” when installed.

Causes of a bad Drive Belt can include cracks developing from repeated flexing during operation or stretching over many years. Debris trapped in the belt path can also wear down the belt prematurely.

Symptoms of a bad belt include:

• The washing tub failing to spin or agitate clothes
• Abnormally loud squealing noises from inside the machine
• The belt slipping off pulleys during cycles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, and select Kenmore front load washers.

The Shock Absorber is an OEM part for Whirlpool washing machines. This component is essential for reducing vibrations and stabilizing the washer drum during operation, particularly during the spin cycle. It helps to absorb shocks and minimize excessive movement, ensuring the washing machine runs smoothly and quietly.

Note: The unit requires a quantity of 4. Package includes 1 only; order as needed.

Symptoms of a failing Shock Absorber include:

• Excessive shaking or vibrating of the washing machine, especially during the spin cycle
• Loud banging or thumping noises during operation
• The washing machine moving or "walking" across the floor
• Visible damage or wear to the shock absorber

Causes of a bad shock absorber can include wear and tear from regular use, heavy or unbalanced loads that put extra strain on the absorbers, or physical damage from impacts or mishandling.

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and some Kenmore models.

Note: This part is a kit of 3 baffles. For 1 baffle, order part# WP8182233. For baffle mounting screw, order part# WPY706189.

The Front Load Washer Drum Baffle Kit is an OEM part for Whirlpool washing machines. This kit includes the drum baffles, which are responsible for lifting and moving clothes within the drum during the wash cycle. This ensures that clothes are thoroughly cleaned by enhancing the tumbling action.

Causes of a bad drum baffle can include wear and tear over time, accidental damage from foreign objects left in the wash, or repeated exposure to heavy loads. These factors can lead to the baffles becoming loose or broken, reducing their effectiveness.

Symptoms of a bad drum baffle include:

• Clothes not tumbling properly
• Excessive noise during the wash cycle
• Visible damage or looseness in the baffles

This OEM part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.

Includes 3 baffles. For single baffle only use part number WP8182233. The mounting screw is part number WPY706189.

This part is a replacement outer tub. This part's intended use is to repair a broken or defective outer tub in washing machines.The outer tub fits over the spin basket and is what ensures that the machine doesn't leak during use by sealing in the water. If this part is broken, water may drip or leak, and thus the front tub should be immediately replaced. It's important that the appliance is unplugged before any attempt is made to replace this part. Work gloves are recommended for proper safety and protection.This is a genuine OEM part made by Whirlpool and has been sourced directly from the manufacturer. This is an authentic OEM replacement part made of high-quality materials. This outer tub can be used with different models of washing machines that have been manufactured by Whirlpool, KitchenAid, Kenmore, Scotsman, and some other brands. It is sold individually.
