Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number R0131134 replaces AP4246697, 916147, AH2166645, EA2166645, PS2166645.
Description
This wiring harness is a factory-style wire assembly that delivers reliable electrical connections between controls and components to restore proper function and signal flow in your appliance. It replaces damaged or worn wiring for safer operation. What it does:
- Carries power and control signals between the control board and key components
- Re-establishes interrupted circuits that can cause intermittent or complete feature failure
- Helps stop issues caused by frayed, burned, or broken wires
- Can resolve symptoms such as no power to certain functions, components that don't respond, or intermittent operation
What's included: One wiring harness assembly as pictured. Install notes:
- Always disconnect the appliance from power (unplug or shut off breaker) before servicing
- Compare the harness to the original and route wires along the same paths, securing with existing clips or ties
- Make sure connector tabs fully seat and locking tabs engage; avoid forcing misaligned connectors
- If you see melted connectors or corrosion, replace affected mating parts as needed and inspect surrounding insulation
