Product Details
Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
See all items in Dryer Fuse Or Sensor.
Whirlpool also makes various appliance models for Sears / Kenmore.
Cross Reference Information
Part Number WPW10194158 replaces AP6016712, 4442057, PS11750005, W10194158.
Description
This cycling thermostat (140°F) regulates dryer temperature by opening and closing to control heat cycles, helping maintain consistent drying and prevent overheating. Designed as a direct replacement for the original temperature control component. What it does:
- Opens at the specified temperature to interrupt the heating circuit and cycles the heater on/off
- Helps maintain consistent drum temperature for reliable drying performance
- Can prevent continuous heating that can cause overheating
- Common symptom: dryer heats erratically, runs but doesn't reach proper temperature, or overheats
What's included: One cycling thermostat (140°F) Install notes:
- Disconnect power to the dryer before inspecting or replacing the thermostat
- Locate the thermostat on the heater assembly/blower housing per your model's service guide
- Replace with the same temperature-rating thermostat and secure all wiring connections
- Test the thermostat for continuity with a multimeter
