Whirlpool W10563363 Wire Assembly (Freezer 9-Pin Connector) OEM Part

Product Details

Genuine Whirlpool part. Whirlpool brands include Whirlpool, Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, Kenmore, and others.
Whirlpool also makes various appliance models for Sears / Kenmore.

Cross Reference Information

Part Number W10563363 replaces AP5801850.

Description

This wire assembly connects freezer control components using a 9-pin connector to restore electrical continuity and reliable signal routing. It's a factory-style harness designed to replace a damaged or corroded freezer wiring harness. What it does:

• Provides the wiring path between freezer controls/components using a 9-pin plug for secure connections
• Replaces frayed, cut, burned, or corroded wires that cause intermittent operation or loss of function
• Helps stop shorts and open circuits that can prevent compressor, defrost or control circuits from working
• Matches OEM connector configuration to ensure proper fit and electrical contact

What's included: One wire assembly with 9-pin connector as shown. Install notes:

• Disconnect power to the appliance before attempting any repairs to avoid shock or injury
• Verify connector orientation and pin alignment before seating the plug to prevent bent pins
• Route and secure the harness away from heat sources, moving parts, and sharp edges
• If soldering or splicing is required, use proper wire connectors and insulation rated for appliance use
