Parts for Gaggenau EB663-620: 02 - Cavity, Door & Fascia Panel, Upper Parts

Replace a burned-out oven light with this 120V, 15W bulb. It restores interior illumination so you can clearly monitor cooking progress through the window, helping maintain temperature and consistent results.

• Illuminates the oven cavity during preheat, baking, and broiling
• Direct replacement for a failed or dim bulb
• Helps you check food without opening the door
• Common signs of failure: light won't turn on, flickers, or filament appears broken

• Disconnect power to the appliance and allow the oven to cool completely before servicing.
• Remove the glass lens/cover to access the bulb; handle glass carefully.
• Install using a dry cloth or gloves; do not overtighten.
• Match the bulb's voltage and wattage to the original; never exceed the rated wattage.

A supporting sheet that provides a stable mounting surface and protects nearby components from contact and wear. This thin support plate helps keep assemblies aligned for reliable operation and quieter performance. What it does

• Provides structural support and a flat mounting surface for panels or components
• Protects wiring and parts from rubbing, chafing, or direct contact with metal edges
• Helps reduce vibration-related noise by stabilizing components
• Can prevent misalignment symptoms such as sagging panels or rattles

• One supporting sheet

• Disconnect power before servicing to avoid shock or injury
• Handle edges carefully; the sheet may have sharp metal edges
• Follow the appliance service manual for correct placement and fastening

This bottom hinge mounting bracket secures the door hinge to the cabinet, providing stable support and proper door alignment. Replacing a worn bracket helps restore smooth, even door movement and reliable closing.

• Supports and anchors the bottom door hinge to the appliance frame
• Helps correct door sagging, misalignment, or poor sealing
• Can reduce rubbing, squeaking, or uneven door movement
• Maintains proper door geometry for consistent operation

• Disconnect power and allow the unit to cool if working near a heated cavity
• Support the door before loosening hinge hardware to prevent strain or injury
• Transfer any screws or hardware from the original bracket if they are reusable
• Check door alignment and tighten all fasteners securely after installation

This bulb socket is the replacement lamp holder for oven and range interior lights, restoring a secure electrical connection so the light bulb powers reliably for oven lighting and visibility while cooking. What it does:

• Holds and connects the oven light bulb to the appliance wiring for a stable electrical connection
• Re-establishes interior lighting when a damaged or worn socket causes the light to flicker or not illuminate
• Provides a properly seated contact to prevent intermittent contact and arcing symptoms
• Works with the oven's existing bulb and mounting location to restore normal lighting function

• One bulb socket (lamp holder) as described

• Disconnect power to the appliance (unplug or switch off circuit breaker) before servicing
• Access the socket through the oven light cover or interior panel per your model's disassembly steps
• Remove the old socket and transfer wiring or terminals exactly as removed; replace with this socket and reinstall cover

This is a replacement door hinge designed for the top oven door, restoring smooth opening and proper door alignment for safe, even cooking. Fits the specified top oven hinge location and replaces worn or bent hinges. What it does:

• Secures the top oven door to the oven frame and guides door motion during opening and closing
• Restores proper door alignment to help maintain consistent oven temperature and seal
• Reduces sagging, sticking, or uneven door movement caused by a worn hinge
• Compatible only with the specified top oven hinge location

• One (1) door hinge for the top oven

• Turn off power to the appliance before servicing and follow manufacturer's safety recommendations
• Use appropriate tools and support the oven door while removing/installing the hinge to avoid injury or damage
• Reuse original screws or order the correct fasteners separately

This door latch bolt secures a front-load washer door during operation to help the machine start and run safely. It restores the door's ability to lock and stay closed for normal wash cycles. What it does:

• Engages with the door strike to hold the door closed while the washer is running.
• Allows the machine to detect a secure door and begin the selected cycle.
• Helps prevent leaks and interrupts caused by an unlatched door.
• Commonly replaces worn, broken, or bent latch bolts that prevent proper door closure.

• Disconnect power and water before beginning any repair.
• Access typically requires opening the washer door trim or front panel; follow OEM disassembly instructions.
• Inspect surrounding strike and latch housing for damage; replace if necessary.

This door latch bolt secures the oven door during use so it closes and locks reliably, helping the oven maintain temperature and operate safely. Fits the oven's upper or lower door latch assembly. What it does:

• Engages with the door catch to keep the door closed during cooking and self-clean cycles
• Helps prevent heat loss from the oven cavity when the door is properly latched
• Commonly replaced for symptoms like a door that won't stay fully closed, or a latch that feels loose or broken
• Works as the mechanical bolt component inside the latch mechanism

• High-level replacement only; remove power to the appliance before starting work
• Access typically requires removing the oven door or inner door panel—handle glass and trim carefully
• Use appropriate tools and follow OEM instructions or a service manual for reassembly

This oven door latch assembly is the locking mechanism that secures the door and reports lock status to the control. Replacing a worn latch restores reliable door locking and helps self-clean cycles operate correctly.

• Locks the oven door during Self Clean for safety and temperature containment
• Built-in switches signal locked/unlocked status to the control
• Direct replacement for a latch that is stuck, noisy, or fails to lock/unlock
• Can help with issues such as self-clean not starting/finishing, "door/lock" messages, or a door that won't stay locked

• Disconnect power at the breaker before servicing; allow the oven to cool completely
• Access location varies by model; removal of trim/control panel or pulling the oven may be required
• Move wiring one connector at a time to the new assembly; reuse existing hardware as needed
• After installation, verify smooth lock/unlock operation and check door alignment
