Parts for Thermador CMT-227: 03 - Body Page 2 Parts

This terminal block provides a secure connection point for appliance wiring, restoring safe electrical continuity and helping prevent loose or intermittent power at the connection. Designed to match original OEM fit and function. What it does:

• Secures and organizes incoming and internal wiring at a single connection point
• Provides a stable electrical connection to prevent arcing or intermittent power
• Replaces damaged, cracked, or corroded terminal mounts that cause intermittent operation
• Restores factory routing and strain relief for attached wires

• One terminal block

• Disconnect power before servicing to avoid shock or injury
• Verify wire placement and tightness of screws; replace any frayed or damaged wires
• Inspect surrounding insulation and mounting hardware; reuse original screws if undamaged

This shoulder bolt secures the dishwasher door strap/hinge area to keep the door aligned and operating smoothly. It replaces a worn or stripped fastener to restore proper door fit and reduce rattling or uneven closing. What it does:

• Fastens the door strap/hinge assembly to the door frame for stable operation
• Maintains correct door alignment to prevent sagging or uneven gaps
• Stops symptoms like loose door movement, rattling, or difficulty latching
• Designed to match the OEM shoulder and thread dimensions for proper fit

• Disconnect power to the appliance before beginning any repair
• Use appropriate hand tools; avoid overtightening the bolt to prevent damage
• Inspect mating parts (strap/hinge) for wear; replace if damaged before reinstalling

This cover cap protects and finishes a CMT assembly opening, keeping internal components shielded from dirt, moisture and accidental contact. It restores the original look and helps maintain proper operation. What it does:

• Covers and protects exposed openings on the CMT assembly
• Keeps dust, debris and moisture out of internal components
• Prevents accidental contact with underlying parts or connections
• Restores the appliance's finished appearance after service

• Disconnect power (and water if applicable) before servicing
• Remove surrounding trim or fasteners as needed to access the mounting location
• Handle carefully to avoid cracking plastic; align and press or fasten per OEM locations
• If any clips or screws are damaged, replace them to ensure secure fit

This hinge stop secures and limits door movement for proper alignment and safe operation, helping prevent over-travel and wear on the hinge assembly. It's a direct-fit replacement designed to restore correct door stopping action. What it does

• Acts as the mechanical stop that limits door swing to the intended opening angle.
• Restores proper door alignment when the hinge no longer catches or the door swings too far.
• Helps reduce stress and wear on hinge pins and mounting points.
• Common symptom: door drifts past the closed/stop position or hangs unevenly.

• One hinge stop

• Disconnect power to the appliance before starting work when applicable.
• Access may require removing door trim or covers; keep fasteners organized.
• Use basic hand tools; avoid forcing components to prevent damage.
