Parts for Thermador CGB30RCULP: 04 - Burner & Electrode Spark Parts

This control panel is the user interface assembly for the oven/range, giving you the buttons, touch controls and display area used to set cooking functions and temperatures. Restores normal control response and visible display. What it does:

• Replaces the front console that houses control buttons/touch pads and display elements
• Restores button responsiveness and on-screen status when controls are unresponsive or missing
• Addresses display issues such as blank or unreadable control readouts related to the console
• Works with the range's control electronics to accept user input and show operating information

• Disconnect power at the breaker before starting any repair to avoid shock
• Handle the assembly carefully to avoid damaging the display lens or attached ribbon/harness
• Test operation after reconnecting power before fully reassembling the unit

Color: black. It measures about 5 inches wide by 21 inches deep.

This radiant surface element heats a cooking zone beneath a ceramic-glass cooktop. Replace a failed element to restore consistent, controllable heat when a burner no longer heats correctly.

• Converts electrical energy into radiant heat for its designated burner zone under the glass top
• Works with the control to cycle heat and maintain the selected temperature
• Typical symptoms when failed: burner will not heat, heats unevenly or only partially, or takes much longer to reach temperature
• Visible damage or hot spots beneath the glass can also indicate a failed element

• Disconnect power at the breaker and allow the cooktop to cool completely
• Lift/remove the cooktop glass to access the element; support the glass to avoid stress or cracks
• Transfer wires from the old element to the new one one-by-one; reuse existing brackets/clips if serviceable
• Seat the element flat and centered; avoid touching the coil surface; reassemble and test operation

This center radiant burner is the glass-top heating element that provides even surface heat for the middle cooking zone. Replaces a cracked, non-heating, or intermittently working center radiant on compatible ceramic/glass cooktops. What it does

• Heats the center cooking area for pans placed over the middle zone
• Restores consistent power delivery when the center burner fails to heat
• Replaces visibly cracked, chipped, or burned glass/element assemblies
• Stops flickering or intermittent on/off operation caused by a damaged element

• One radiant middle (center glass burner) element

• Disconnect power at the breaker before attempting any repair
• Handle the glass element carefully; wear gloves and eye protection for safety
• Installation typically requires lifting the cooktop and removing mounting screws.

This is a cooktop burner igniter OEM replacement part for Bosch cooktops and ranges and is sold as an individual part. This part creates a spark that ignites the burner within your cooktop or stovetop and is made of a combination of metal and ceramic.

Causes of a bad ignition plug can include issues with the electronic module, worn electrodes that no longer spark reliably, or damaged wiring.

Symptoms of a bad ignition plug include:

• Gas burners that will not light or remain lit
• Delayed ignition of one or more burners
• Intermittent or no sparking from the ignition plug

This OEM Bosch part is also compatible with Thermador, Gaggenau and some Kenmore models.

The Igniter Mounting Clip is an OEM part for Bosch ranges. It secures the igniter to the range top, ensuring it is properly aligned and stable for optimal ignition performance. The surface igniter is crucial for the ignition of gas burners, facilitating an immediate and safe flame to cook with.

Over time, the Igniter Mounting Clip can succumb to various forms of wear and tear, including corrosion from exposure to moisture, degradation from frequent heating cycles, or physical damage during cleaning or maintenance activities.

Symptoms of a compromised Igniter Mounting Clip include:

• The surface igniter becoming loose or dislodged
• Difficulty in igniting the burner or uneven flames
• Noisy or irregular ignition sounds
• Visible signs of damage or corrosion on the clip

This genuine OEM Bosch part is also compatible with Thermador, Gaggenau and select Kenmore models.

This bracket securely mounts the spark igniter electrode at the burner, keeping the tip in the correct position for a strong ignition arc. A bent or corroded bracket can cause weak spark, misfires, or a burner that won't light.

• Holds the ignition electrode firmly next to the burner port
• Maintains proper gap and alignment for reliable sparking
• Replaces brackets that are bent, broken, or corroded
• Common symptoms: burner won't ignite or lights intermittently, weak/no visible spark, electrode feels loose or out of position

• Disconnect power and shut off gas; allow the appliance to cool
• Remove grates/caps and panels as needed to access the burner area
• Transfer the existing electrode to the new bracket and secure with the original hardware
• Restore gas and power, then test for proper spark and burner ignition

Replacement 1/4-20 x 1/2 stainless steel bolt that secures appliance components and restores proper fit. Use when mounting hardware is missing, corroded, or loose to stop rattling and maintain alignment. What it does:

• Fastens panels, brackets and other appliance components to prevent movement and vibration
• Replaces missing, stripped, or corroded bolts that can cause loose parts or noise
• 1/4-20 thread with 1/2" length for applications requiring that fit (per part listing)
• Stainless steel construction helps resist corrosion in humid or wet areas

• Disconnect power and water (if applicable) and remove outer panels before servicing for safety
• Start threads by hand to avoid cross-threading, then tighten with the proper wrench or socket
• Do not overtighten; snug until secure and follow manufacturer torque specs if available

A hex keps nut (1/4-20) — a hex nut with an integrated locking washer — provides a secure, vibration-resistant fastening for appliance assemblies; stainless steel construction helps resist corrosion in wet or humid areas. What it does:

• Provides a locking nut solution for 1/4-20 bolts and studs; replaces stripped or damaged nuts to restore a secure connection.
• Integrated keps (locking) washer helps prevent loosening from vibration — useful when panels, brackets, or components wobble or rattle.
• Stainless steel material resists rust and corrosion in damp or high-humidity locations.
• Ideal for replacing missing or corroded hardware during repairs or reassembly.

• Use the correct size socket or wrench; tighten to the appliance manufacturer's specified torque where available and avoid overtightening.
• Disconnect power and shut off water supply when working near electrical or plumbing components.
• Inspect mating threads and replace damaged studs or bolts before installing this nut to ensure a proper, long-lasting fit.
