Parts for Thermador RDFS30 S/N 9708 & UP: 05 - Burner Box Assembly Parts

This right-side control panel endcap replaces a cracked, faded or loose trim piece to restore the dishwasher's appearance and help keep the control area protected from moisture and debris. It matches the OEM shape and finish for a clean fit. What it does:

• Replaces a damaged or missing right control-panel endcap to restore cosmetic appearance
• Helps keep moisture and food debris away from edges of the control panel
• Secures the control panel trim so buttons and switches align correctly
• Prevents further chipping or cracking around the control-panel edge

• Disconnect power to the appliance before servicing to reduce shock risk
• Typically installed by removing the outer door panel or release clips—do not force the part into place
• Keep OEM screws and retainers; replace any damaged fasteners for a secure fit

White grommet for range installations. Provides cushioning and sealing where wires or components pass through panels. Replace if cracked or missing.

Replacement glass panel for the range control area. Restores finished appearance over the touch/display surface. Needed when original is cracked or scratched.

This small mounting bracket secures the vacuum (vac) switch in place, keeping the switch stable and properly positioned for reliable pressure sensing. Replacing a worn or broken bracket restores correct switch alignment and function. What it does:

• Holds the vacuum/pressure switch securely to the appliance chassis
• Keeps vacuum tubing and switch terminals aligned to prevent kinks or strain
• Helps maintain consistent pressure sensing for proper system operation
• Commonly needed when the original bracket is cracked, broken, or missing

• Designed for direct replacement; match the bracket to the switch mounting points before installing
• Power off and disconnect the appliance before accessing internal components
• Handle vacuum tubing and switch gently—avoid kinking or stretching lines

Fix range temperature control issues with this vacuum thermostat switch. Restores proper oven cycling when the original switch fails or malfunctions.

Range not heating properly or overheating? This thermostat regulates oven temperature. Common fix for inaccurate temps. Moderate DIY repair.

This part has been discontinued by the manufacturer and is no longer available.

This is a module cover that protects the appliance's control module and electronics from moisture, food soil, and accidental contact. It keeps the control area sealed and helps maintain reliable operation. What it does:

• Shields the control board and wiring from water, debris, and physical contact
• Helps prevent shorting, corrosion, and intermittent control faults due to contamination
• Reduces risk of visible damage to the module from bumps or cleaning
• Commonly replaced when cracked, warped, or missing after service

• One module cover

• Disconnect power to the appliance before starting service
• Remove outer panels or console as needed to access the control module; retain fasteners
• Handle the cover and underlying electronics carefully to avoid damage or ESD
• Secure all screws so the cover seals the module area

Fixes burners that won't ignite or spark continuously. This spark module generates the high-voltage needed for gas ignition. DIY repair, 1-2 hours.
