Parts for Gaggenau EB388-610: 05 - Fascia Panel Parts

This electronic control module manages a dishwasher's user interface and wash cycle logic so the appliance responds correctly to commands and runs programmed cycles. Replaces a failed control board to restore normal cycle selection and operation. What it does:

• Interprets button/knob inputs and starts the selected wash cycle
• Sends signals to pumps, valves, and heaters to control cycle timing
• Stores and runs cycle logic and diagnostics used by the machine
• Common symptoms: unresponsive or blank display, touchpad/buttons not working, cycles won't start, or dishwasher stops mid-cycle

• Disconnect power to the appliance before attempting any service
• Handle the board by its edges and avoid touching components to prevent ESD damage
• Reconnect all wiring harnesses to their matching connectors; ensure secure seating

This replacement trim strip attaches to the lower-right area of the appliance fascia to restore a finished appearance and help protect the cabinet edge. Designed to match the original fit and finish for a clean front panel. What it does

• Covers and protects the lower-right edge of the fascia from chips, dings, and wear.
• Restores the factory appearance of the appliance front where trim is cracked, broken, or missing.
• Helps maintain a sealed edge to reduce dirt buildup along the cabinet interface.
• Fits the right-side lower section of the fascia for proper alignment and aesthetics.

• One trim strip, fascia (bottom right) as specified.

• Disconnect power and follow the appliance manufacturer's safety instructions before servicing.
• Installation typically requires removing the lower access panel or prying away old trim; use a trim tool to avoid scratching the fascia.
• Inspect mounting clips or fasteners during replacement; replace any damaged clips with OEM parts for correct fit.
• Do not force the trim into place; ensure alignment and engagement of all mounting points.

This electronic control module replaces the appliance's main control board to restore correct cycle control and user-interface functions. Designed to address failures in the control electronics so the appliance can run programmed cycles reliably. What it does:

• Receives inputs from buttons/sensors and directs power to components during cycles
• Controls timing, cycle selection, and start/stop functions
• Can resolve symptoms like unresponsive controls, incorrect cycles, or a blank/erratic display
• Works with the appliance's existing wiring harness and user interface to manage operation

• One control module

• Disconnect power to the appliance before starting any repairs
• Handle the board carefully; avoid static discharge and do not touch soldered components
• Verify connector orientation and secure all wiring; recheck connections before restoring power
• For any calibration or programming steps after installation

This trim strip is a decorative door trim piece that restores the finished appearance of the appliance and covers the cabinet edge for a clean fit. It helps replace worn, damaged, or missing trim for improved aesthetics. What it does:

• Covers and protects the door edge and mounting gap to restore a finished look
• Hides cosmetic damage, dents, or worn paint along the door perimeter
• Helps keep dirt and moisture out of exposed gaps around the door
• Matches OEM shape so the door panel sits flush and looks factory-finished

• Disconnect power to the appliance before starting any repair to avoid injury
• Remove the door panel or access trim fasteners for safe removal/installation
• Handle edges carefully—trim may have sharp metal or plastic edges
• Retain all fasteners; replacement may require reinstalling existing clips or screws
