Parts for Thermador HDW36TS: 06 - Motor Parts

This fuse cover is a small protective cap that snaps over an appliance fuse to protect it from moisture, debris, and accidental contact. It helps keep the fuse secure and reduces the chance of short circuits or corrosion. What it does:

• Shields the fuse element from dust, moisture, and food particles
• Helps maintain proper electrical contact by keeping the fuse seated
• Reduces risk of accidental touching or shorting of the fuse
• Common symptom: cracked, missing, or damaged cover that leaves the fuse exposed

• Disconnect power to the appliance before accessing the fuse or electrical components
• Handle the fuse and cover carefully; replace any blown fuses per OEM guidance
• Typically snaps into place—no special tools required.

This part has been discontinued by the manufacturer and is no longer available.

This fan drum is the rotating blower wheel that moves air through the appliance for proper ventilation and drying performance. It replaces a worn or damaged wheel to restore airflow and reduce noise from imbalanced rotation. What it does:

• Spins to circulate air through the appliance's air path and heat exchanger.
• Helps maintain consistent drying or cooling by directing airflow where needed.
• A worn, cracked, or broken drum can cause unusual vibration, rattling, or reduced airflow.
• Replacing a damaged drum often resolves airflow restrictions and excessive blower noise.

• One fan drum

• Disconnect power before accessing internal panels; follow OEM disassembly instructions.
• Inspect surrounding seals, bearings, and mounting hardware; replace any damaged components for best results.
• Handle edges carefully to avoid bending blades; ensure proper seating on the motor shaft during reassembly.

A 3.15 amp glass cartridge fuse that protects appliance circuitry by interrupting power when a fault or overload occurs. Keeps control boards and components from damage by stopping dangerous current flow. What it does:

• Protects electrical circuits by blowing when current exceeds 3.15 amps
• Prevents further damage from short circuits or component failures
• Commonly used in control panels, electronic modules, and power boards
• Symptom: appliance won't power on or certain functions are unresponsive when the fuse is blown

• Disconnect the appliance from power before inspecting or replacing the fuse
• Replace only with a fuse of the same type, size (5 x 20 mm) and rating (3.15 A)
• Handle the glass tube carefully to avoid breaking; ensure proper seating in the fuse holder
• If a new fuse blows immediately, stop and diagnose the underlying electrical fault.

Keep your appliance's controls working reliably with this switch cover. It mounts over a switch to hold it in place and shield it from damage, helping ensure consistent actuation and long service life.

• Retains and protects a control/interlock switch within its housing
• Helps keep the switch aligned for reliable on/off detection
• Shields the switch from dust and incidental contact
• Cracked, loose, or missing cover can cause intermittent operation or no response when the control is pressed

• Disconnect power to the appliance before servicing
• Remove the necessary panel to access the switch; note wire positions/orientation
• Transfer any clips/screws from the old cover and seat the switch fully
• Secure wiring away from pinch points before reassembly

This control panel is the exterior fascia at the top of the dishwasher door. It provides the labeled surface for the user controls and restores proper button access and appearance when the original is cracked, broken, or worn.

• Serves as the door-mounted fascia for the dishwasher's user controls
• Provides the labeled button layout and covers/protects the control area
• Replaces cracked, loose, or broken panels that can make buttons difficult to press
• Refreshes worn graphics and scuffed or faded appearance

• Disconnect power at the circuit breaker before servicing
• Open the door and remove the screws securing the console/inner door to release the panel
• Support the panel; transfer any handle/trim and the existing switch/control components as required
• Reinstall, align, and secure screws; restore power and verify button operation

The Control Label Overlay is an OEM part for Bosch range hoods. It is the interface label for the range hood's control panel, featuring clear markings for each function, from fan speed adjustments to light settings.

Causes of a bad Control Label Overlay can include exposure to heat and moisture, which can lead to the overlay peeling or the labels fading.

Symptoms of a bad Control Label Overlay include:

• Difficulty in identifying control functions due to faded or worn labels
• Peeling or damaged overlay that compromises usability and appearance
• The need to guess or remember control locations due to obscured labels

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.
