Parts for Thermador PSC486GDZS: 10 - 48`` Cooktop Rough-In Box Parts

This replacement case is the outer housing that secures and protects internal components, restoring proper fit and reducing movement. It helps keep parts aligned for reliable operation and prevents rattling from a damaged enclosure. What it does:

• Holds and supports internal assemblies so controls and mechanisms stay properly positioned
• Protects internal parts from incidental contact and debris
• Reduces vibration and rattling caused by a cracked or broken housing
• A damaged or missing case can allow components to shift or make noise and lead to intermittent operation

• Disconnect power before beginning any repair to avoid electrical shock
• Basic hand tools are typically required; follow for disassembly/reassembly steps
• Handle edges carefully; plastic edges or attached hardware may be sharp
• If clips or mounting hardware are damaged, replace them to ensure a secure fit

This is a quality spark re-igniter module for stoves, ranges, and ovens. This part is located between the cooktop on the stove. This part creates a spark to ignite a low-pressure gas flow that goes to the flame pilot light. It will stay lit until the thermostatic control on the oven is turned to the off position.Sometimes, the spark re-igniter will become damaged or stop working, which can cause problems using the range. If there is a weak or nonexistent spark between the igniter pin and the edge of the gas burner, this is a sign the spark re-igniter needs to be replaced. The first thing to do is unplug the stove from the wall. Access the back of the stove and remove the large panel. Remove the original component and install the new one in its place.This is an authentic OEM replacement part that has been obtained directly from the manufacturer. The spark re-igniter module is sold as a single part. It is made to be compatible with Bosch and Thermador stoves and ranges.

The Simmer Control is an OEM component specifically designed for Bosch ranges. It regulates gas flow to provide the lowest possible flame setting needed for delicate cooking tasks. Precise control allows for uniform, attentive simmering.

Symptoms of a bad simmer control include inconsistent or unadjustable flame heights on low settings. Cracks, damage, or wear of internal mechanisms over time can also cause unstable flame control.

Causes of bad simmer control can be normal wear and tear issues like dirt buildup impeding mechanisms. Accidental impact or overheating leading to cracks are other causes for replacement.

Symptoms of a bad simmer control include:

• Flames that surge or fluctuate below the lowest settings
• Inability to adjust the flame down sufficiently low
• Burners that shut off or cause overflow flooding on low-heat

This OEM Bosch part is also compatible with Thermador and some Kenmore ranges. Replace for dependable, Fine-tuned low-heat performance.


This Tinnerman C nut is a spring-steel speed clip that secures sheet-metal panels and components using a mating screw. It provides a captive thread where a tapped hole or weld nut isn't practical, helping restore proper fit and stop rattles. What it does:

• Provides a captive, reusable threaded anchor for self-tapping or machine screws
• Secures trim, access panels and internal brackets to sheet-metal edges or panels
• Stops panel movement and vibration-related noise when the original clip is damaged or missing
• Works where a conventional nut or stud cannot be used due to limited access

• Disconnect power and unplug the appliance before accessing panels or fasteners
• Position the clip over the panel edge or hole, then press or slide until it snaps into place
• Align the mating screw and thread carefully to avoid cross-threading the clip
• Use hand tools or pliers for placement; do not over-torque the screw once installed

Side trim gasket seals cooktop door edge to reduce rattling and air leakage. Replace when seal is worn, cracked, or no longer fits snugly. Confirm fit with your model number.

Wire grommet that protects electrical wiring where it passes through metal panels. Replace if cracked, torn, or missing to prevent wire damage.

Igniter wire, 29 inches orange in color.

Range not heating or powering on? A damaged wire harness disrupts electrical connections. Direct fit replacement for Bosch ranges. Easy install in 30 minutes.

Internal electrical wire for ranges. Connects electrical components within the appliance. Replace if wire is damaged, frayed, or connection is loose.

Regulates incoming gas pressure to your range. Replace if cracked, leaking from the vent, or damaged. Installs on the gas supply line inlet.

Gas burners won't light or keep clicking? This spark module generates consistent sparks to reliably ignite cooktop burners for safe operation.
