Parts for Thermador HCSW48TS: 13 - Motor Parts

This fuse cover is a small protective cap that snaps over an appliance fuse to protect it from moisture, debris, and accidental contact. It helps keep the fuse secure and reduces the chance of short circuits or corrosion. What it does:

• Shields the fuse element from dust, moisture, and food particles
• Helps maintain proper electrical contact by keeping the fuse seated
• Reduces risk of accidental touching or shorting of the fuse
• Common symptom: cracked, missing, or damaged cover that leaves the fuse exposed

• Disconnect power to the appliance before accessing the fuse or electrical components
• Handle the fuse and cover carefully; replace any blown fuses per OEM guidance
• Typically snaps into place—no special tools required.

This fan drum is the rotating blower wheel that moves air through the appliance for proper ventilation and drying performance. It replaces a worn or damaged wheel to restore airflow and reduce noise from imbalanced rotation. What it does:

• Spins to circulate air through the appliance's air path and heat exchanger.
• Helps maintain consistent drying or cooling by directing airflow where needed.
• A worn, cracked, or broken drum can cause unusual vibration, rattling, or reduced airflow.
• Replacing a damaged drum often resolves airflow restrictions and excessive blower noise.

• One fan drum

• Disconnect power before accessing internal panels; follow OEM disassembly instructions.
• Inspect surrounding seals, bearings, and mounting hardware; replace any damaged components for best results.
• Handle edges carefully to avoid bending blades; ensure proper seating on the motor shaft during reassembly.

A 3.15 amp glass cartridge fuse that protects appliance circuitry by interrupting power when a fault or overload occurs. Keeps control boards and components from damage by stopping dangerous current flow. What it does:

• Protects electrical circuits by blowing when current exceeds 3.15 amps
• Prevents further damage from short circuits or component failures
• Commonly used in control panels, electronic modules, and power boards
• Symptom: appliance won't power on or certain functions are unresponsive when the fuse is blown

• Disconnect the appliance from power before inspecting or replacing the fuse
• Replace only with a fuse of the same type, size (5 x 20 mm) and rating (3.15 A)
• Handle the glass tube carefully to avoid breaking; ensure proper seating in the fuse holder
• If a new fuse blows immediately, stop and diagnose the underlying electrical fault.
