Parts for Thermador PRSE486GDS: 44 - Fasteners Parts

Secures the glass cooktop to the range frame. Replace if clip is cracked, broken, or missing to properly hold the cooktop surface in place during use.

This part has been discontinued by the manufacturer and is no longer available.

M5-0.8 x 25mm hex head bolt for cooktop assembly. Replace missing, stripped, or damaged mounting bolts to secure components during installation or repair.

This is a 1/4-20 hex keps nut — a hex nut with an attached captive washer that helps secure panels, brackets, and fasteners. It provides a simple, vibration-resistant fastening solution for appliance assemblies. What it does

• Fastens components to machine frames, panels, and brackets using a 1/4-20 bolt or stud.
• Captive washer helps resist loosening from vibration and movement.
• Commonly used where a compact, pre-assembled nut-and-washer is needed for reliable retention.
• Replace when threads are stripped, washer is damaged, or parts wobble or rattle.

• One hex keps nut (1/4-20).

• Disconnect power and follow appliance safety procedures before working on hardware.
• Use the correct 1/4" socket or wrench to install; hold the mating bolt head as needed to tighten.
• Tighten securely but avoid over-tightening to prevent thread damage or distortion.
• Replace with the same nut type and size to maintain fit and vibration resistance.

This is a #10 x 1/2 inch pan-head Phillips sheet-metal screw used to fasten appliance panels and internal components. It replaces missing or worn screws to restore proper fit and reduce rattles or loose parts. What it does:

• Secures trim, access panels, brackets and other sheet-metal parts
• Keeps components aligned and prevents vibration-related noise
• Restores proper fastening when original screws are stripped, lost or corroded
• Works where a #10 x 1/2" pan-head Phillips sheet-metal screw is specified

• One #10 x 1/2" pan-head Phillips sheet-metal screw

• Disconnect power and water before servicing the appliance
• Use the correctly sized Phillips screwdriver to avoid stripping the head
• Start threads straight and tighten until snug—do not overtighten to avoid stripping or deforming sheet metal
• Keep small parts away from children and pets

This Tinnerman C nut is a spring-steel speed clip that secures sheet-metal panels and components using a mating screw. It provides a captive thread where a tapped hole or weld nut isn't practical, helping restore proper fit and stop rattles. What it does:

• Provides a captive, reusable threaded anchor for self-tapping or machine screws
• Secures trim, access panels and internal brackets to sheet-metal edges or panels
• Stops panel movement and vibration-related noise when the original clip is damaged or missing
• Works where a conventional nut or stud cannot be used due to limited access

• Disconnect power and unplug the appliance before accessing panels or fasteners
• Position the clip over the panel edge or hole, then press or slide until it snaps into place
• Align the mating screw and thread carefully to avoid cross-threading the clip
• Use hand tools or pliers for placement; do not over-torque the screw once installed

Foam adhesive tape seals gaps between range panels to reduce vibration and eliminate rattling. Replace when worn or loose. Verify fit with your model number.

Mounting screw secures cooktop components and brackets. Replace if screw is stripped, missing, or won't hold tight during installation or repair.

90-degree elbow orifice holder for gas ranges and cooktops. Replace this gas line connector if cracked, broken, or causing improper gas flow alignment.

Package of 60 pyramid shaped briquettes

Mounting screw for securing range components and panels. Replace worn, stripped, or missing screws during repairs or maintenance to ensure proper assembly.

Replacement mounting screw for electric and gas ranges. Secures internal components and panels. Order this #10 x 1-1/2 inch screw if original is missing.
