Parts for Kitchenaid KRSC700HBS01: Air Flow Parts

Instruction sheet included.

This air duct routes heated air from the dryer drum to the exhaust path, restoring proper airflow for efficient drying and venting. Designed to match the OEM shape for a secure fit and reliable operation. What it does:

• Channels heated air from the dryer drum to the vent system for normal drying performance
• Helps maintain proper airflow to prevent extended dry times and overheating
• Replaces cracked, crushed, or blocked ducts that cause reduced airflow or hot spots
• Restores sealed air path to reduce lint buildup in adjacent areas

• Recommended for technicians or experienced DIYers; disconnect power before service
• Inspect adjoining seals and clamps and replace if damaged to ensure an airtight connection
• Handle carefully to avoid bending or creasing the duct; secure per OEM mounting points

Size: 8 x 1/2 ab.

This motor grommet cushions and secures the appliance motor to the cabinet, helping reduce vibration and noise for smoother operation. It's a direct-fit rubber mounting grommet used where the motor meets the frame. What it does:

• Absorbs motor vibration to reduce noise and movement
• Protects the motor mounting studs and surrounding sheet metal from wear
• Helps maintain proper motor alignment for reliable operation
• Commonly replaced when rubber is cracked, torn, or deteriorated

• Disconnect power before beginning any service.
• Access and remove the motor mounting hardware or panel to reach the old grommet.
• Replace with the new grommet, ensuring it is fully seated on the motor stud and in the mounting hole.
• Reinstall hardware, restore panels, and test the appliance for secure, quiet operation.

This 8-18 x 5/8-inch screw secures appliance panels, brackets, and covers. Replacing a missing or stripped fastener restores a tight fit and helps prevent vibration or loosening where this exact size is specified.

• Fastens sheet-metal or plastic components where a #8-18 x 5/8 screw is called for
• Helps maintain alignment and reduce rattling or vibration
• Replaces stripped, corroded, or missing screws of the same size
• Common symptoms: loose panels, gaps/poor fit, rattling noises, or visible missing hardware

• Disconnect power and shut off gas/water (as applicable) before service
• Match thread and length to the original; replace screws one at a time to keep parts aligned
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening
• If the receiving threads are damaged, additional repair (clip, insert, or new nut) may be needed
