Parts for Jenn-Air JGCP648HM00: Burner Box And Grill Parts

This manifold routes dishwasher water from the inlet to the spray arms and valve assembly for consistent cleaning performance. It's a direct-replacement service part that restores proper water flow through the spray system. What it does:

• Channels incoming water from the inlet valve to the upper and lower spray arms and related water passages.
• Helps maintain correct spray-arm delivery so dishes receive full spray coverage.
• Can resolve symptoms like weak spray, uneven cleaning, or visible leaks near the base of the tub when the manifold is damaged or cracked.
• Works with the dishwasher's inlet valve and spray-arm assemblies as part of the water delivery system.

• One replacement manifold

• Recommended for technicians or experienced DIYers; disconnect power and water before beginning.
• Inspect adjoining hoses, clamps, and seals during replacement and replace if worn.
• Tighten fittings to manufacturer torque recommendations; avoid overtightening plastic fittings.
• Run a test cycle and check carefully for leaks after installation.

This speaker module provides audible tones and chimes used by the appliance to signal cycle progress and user alerts. It restores clear sound feedback so you can hear cycle completion, alerts, and error tones. What it does:

• Produces the appliance's audible chimes, beeps, and alert tones
• Signals cycle completion and user prompts with clear sound
• Helps indicate error codes and status changes through audible alerts
• Interfaces with the main control to provide user feedback

• Disconnect power to the appliance before servicing to avoid electrical shock
• Handle the module and wiring harness carefully; avoid static discharge and bent pins
• Reconnect the wiring harness fully and secure the module in its mounting location
• Test the appliance after installation to ensure audible tones function correctly

This gas tubing provides the rigid connection between the appliance's gas valve and burner assembly, restoring a secure fuel path for safe ignition and operation. Designed to match OEM fit and routing. What it does:

• Replaces damaged or corroded gas tubing to stop leaks and restore proper gas flow
• Ensures a sealed connection between the gas valve and burner manifold
• Helps resolve symptoms like gas odor, failure to ignite, or intermittent burner operation
• Maintains correct routing to prevent kinks or contact with hot components

• Always shut off the gas supply and unplug the appliance before starting work
• Use proper fittings and torque to manufacturer spec; inspect all connections for leaks with a soap solution or approved leak detector
• Do not modify the tubing; replace with OEM-specified part for safe operation

This heater deflector directs heated air inside the dryer and protects nearby components from excessive heat, helping maintain proper airflow and reduce wear on internal parts. What it does:

• Shields the dryer cabinet and nearby components from direct heater/element heat
• Helps channel heated air for more even drying performance
• Can prevent heat-related damage that leads to component failure
• Common symptoms: burning or metallic smell, uneven drying, or visible heat damage near the heater area

• Disconnect power (and gas, if applicable) before beginning any repair
• Accessing this part usually requires removing the dryer cabinet or rear panel; follow your model's service instructions
• Handle carefully to avoid bending the deflector; install with original fasteners and correct orientation
• If you see damaged insulation or other heat-damaged parts, inspect and replace those items as needed

The Regulator is an OEM replacement part for Whirlpool gas ranges. It regulates the flow of gas from the supply line to the burners, ensuring safe and efficient operation of your range. It maintains a consistent gas pressure, allowing for accurate and controlled heat distribution during cooking.

A bad pressure regulator can occur due to wear and tear, clogging, or damage to the internal components. If you notice symptoms such as uneven flame, difficulty in igniting the burners, or gas leaks, it may be time to replace the pressure regulator.

Symptoms of a bad gas pressure regulator include:

• Uneven flame
• Difficulty in igniting burners
• Gas leaks

This Whirlpool replacement part is also compatible with Maytag, KitchenAid, Jenn-Air, Amana, Magic Chef, Admiral, Norge, Roper, and Kenmore models.
