Parts for Thermador RDSS30RS/01: Burner Box Parts

This small mounting bracket secures the vacuum (vac) switch in place, keeping the switch stable and properly positioned for reliable pressure sensing. Replacing a worn or broken bracket restores correct switch alignment and function. What it does:

• Holds the vacuum/pressure switch securely to the appliance chassis
• Keeps vacuum tubing and switch terminals aligned to prevent kinks or strain
• Helps maintain consistent pressure sensing for proper system operation
• Commonly needed when the original bracket is cracked, broken, or missing

• Designed for direct replacement; match the bracket to the switch mounting points before installing
• Power off and disconnect the appliance before accessing internal components
• Handle vacuum tubing and switch gently—avoid kinking or stretching lines

This vacuum thermostat is a small control switch that helps regulate temperature-related vacuum signals in compatible appliances, restoring proper cycling and control for critical functions. Designed as a direct-fit replacement when the original fails. What it does:

• Senses vacuum/temperature conditions and opens or closes the control circuit as needed.
• Helps ensure proper defrost, evaporator, or control-system cycling when used in applicable systems.
• Commonly replaced if the appliance shows intermittent cycling, erratic temperature control, or related control failures.
• Matches OEM form and function to restore reliable operation when the original thermostat is faulty.

• One vacuum thermostat (single replacement unit)

• Disconnect power to the appliance before accessing electrical components to avoid shock.
• Handle carefully to avoid damage to terminals or the sensor element; avoid bending or stressing mounting tabs.

This part has been discontinued by the manufacturer and is no longer available.

This is a module cover that protects the appliance's control module and electronics from moisture, food soil, and accidental contact. It keeps the control area sealed and helps maintain reliable operation. What it does:

• Shields the control board and wiring from water, debris, and physical contact
• Helps prevent shorting, corrosion, and intermittent control faults due to contamination
• Reduces risk of visible damage to the module from bumps or cleaning
• Commonly replaced when cracked, warped, or missing after service

• One module cover

• Disconnect power to the appliance before starting service
• Remove outer panels or console as needed to access the control module; retain fasteners
• Handle the cover and underlying electronics carefully to avoid damage or ESD
• Secure all screws so the cover seals the module area

The Spark Module is an OEM part Bosch ranges and cooktops. This electronic part generates the high-voltage spark needed to reliably ignite the gas burners with the push of a button.

Causes can be issues like component failure over the thousands of ignitions it facilitates. Water ingress could also potentially cause problems.

Symptoms of a bad spark module include:

• Unreliable or intermittent burner ignition requiring multiple ignition button presses
• One or more burners that will not ignite at all
• Occasionally flashing or error codes relating to ignition issues

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.
