Parts for Bosch HGS5053UC/07: Burners Assembly Parts

This valve assembly controls water flow inside the appliance and includes the mounting screw for secure installation. It replaces worn or leaking valves to restore proper water routing and help prevent drips or fill problems. What it does:

• Directs or stops water flow through an appliance's internal plumbing
• Replaces a valve that is cracked, stuck, or leaking
• Commonly fixes symptoms like visible leaks, no water flow, or continuous filling
• Ensures a secure mechanical mount where the valve attaches

• Disconnect power and shut off the water supply before starting work
• Inspect surrounding seals and hoses; replace any damaged gaskets or clamps
• Handle plastic fittings gently to avoid breakage; align valve before tightening

This cable harness connects and routes electrical wiring between components to restore reliable power and signal paths. It replaces a damaged or worn harness to help resolve intermittent power, no-start, or control communication issues. What it does:

• Provides pre-assembled wiring and connectors to restore factory electrical connections
• Replaces frayed, pinched, or broken wires that cause intermittent operation or failure to power
• Ensures correct connector fit for mating components and sensors
• Reduces risk of short circuits caused by damaged insulation or loose terminals

• One cable harness

• Recommended for technicians or experienced DIYers; disconnect power before servicing
• Compare connector colors and pin counts to the original harness before installation
• Route and secure harness away from sharp edges, moving parts, and heat sources
• Replace the harness rather than reusing terminals if any connector terminals are loose or damaged.

This ignition device controls spark generation for a gas range or cooktop, allowing reliable burner ignition for normal cooking. It replaces a worn or faulty module to restore consistent spark to the burners. What it does:

• Generates high-voltage spark to the burner electrodes so gas ignites when a burner is turned on
• Replaces a module that causes no spark, intermittent sparking, or multiple burners failing to light
• Works with the cooktop/range control system to time spark during ignition attempts
• Helps eliminate clicking or failure-to-ignite symptoms when the module itself is at fault

• One ignition device/spark module

• Requires basic disassembly of the cooktop/range top; disconnect power and gas supply before servicing
• Handle with care to avoid damage to wire terminals and spark electrode connections
• Verify correct part number and mounting orientation before installing; test ignition system after reassembly

This surface burner replaces a damaged or worn cooktop burner head to restore even heat distribution for cooking. Made to match OEM fit and function for compatible Bosch cooktops. What it does:

• Directs gas flow to produce and shape the cooking flame
• Helps maintain consistent heat under cookware for even cooking
• Commonly replaces burners that show uneven flame, poor ignition, or visible damage
• Works with the existing burner cap and base assembly when compatible

• Turn off gas supply and power to the appliance before starting any repair
• Handle carefully to avoid bending ports; inspect mating surfaces and burner cap for proper fit
• Use basic hand tools; tighten screws snugly but do not over-torque

This replacement surface burner restores proper heat delivery for compatible cooktops and ranges. It replaces a worn or damaged burner to help return consistent cooking performance and reliable ignition. What it does:

• Provides the cooking surface that spreads heat from the burner to cookware
• Replaces warped, cracked, or corroded burners that cause uneven heating
• Can resolve slow or inconsistent heating and visible damage to the burner head
• Works with the existing burner base and ignition system when installed correctly

• One surface burner

• Disconnect power (and gas, for gas ranges) before starting any work; follow all safety precautions
• Handle glass or ceramic cooktops carefully to avoid cracking or chipping during removal/installation
• Ensure the burner seats properly on the base and that any gaskets or retaining hardware are reinstalled
• After installation, restore power/gas and test the burner for proper flame/heat and stable ignition

This surface burner head directs gas to create a stable cooking flame for a gas cooktop. It restores correct flame pattern and even heating so burners light reliably and cookware heats predictably. What it does:

• Directs and shapes the gas flame for consistent, even heat across cookware
• Replaces a warped, clogged, or damaged burner that causes uneven cooking
• Helps resolve burners that flame irregularly, sputter, or fail to light
• Works with the burner cap and ignition system to maintain reliable ignition

• Turn off gas supply and power before beginning service; verify there is no gas flow
• Remove grates and burner cap, then lift out the old burner head; seat the replacement fully
• Check for debris or clogs in the burner ports; clean with a soft brush if needed
• After installation, reassemble components and test for proper ignition and flame shape; check for leaks before regular use

This mounting bracket secures the appliance to the cabinet or countertop to keep it stable and aligned during use. Replacing a broken or missing bracket restores proper mounting and prevents shifting or tilting. What it does:

• Provides a secure attachment point between the appliance and surrounding cabinetry or countertop
• Prevents the appliance from moving, rocking, or tilting during operation
• Restores proper alignment when an original bracket is cracked, bent, or missing
• Helps reduce stress on hinge and door assemblies caused by improper mounting

• Disconnect power and turn off the water supply before beginning work
• Use basic hand tools; fit and screw locations must match the appliance mounting points
• Confirm correct orientation and alignment before fully tightening fasteners
• Do not overtighten screws; replace damaged fasteners and hardware as needed

The Igniter is an OEM part for Bosch range ovens. It is responsible for providing the necessary spark to ignite the gas and initiate the heating cycle.

A bad igniter can occur due to normal wear and tear, electrical malfunctions, or damage from excessive heat. Signs of a faulty igniter include the oven failing to heat up, inconsistent heat levels, or a complete lack of ignition.

Symptoms of a bad igniter include:

• Oven not heating up
• Inconsistent heat levels
• Broken ceramic on the igniter

Replace your faulty igniter with this genuine OEM Bosch part to restore your range oven. This Bosch part can also be used on Thermador and Gaggenau appliances.


This ignition electrode provides the spark source for a gas burner, allowing reliable ignition of the burner for normal cooking. Replaces a cracked or worn electrode to restore consistent spark and burner lighting. What it does:

• Generates the spark needed to ignite the gas at the burner
• Commonly used when burners fail to light or spark is weak/intermittent
• Helps restore reliable ignition without replacing the entire burner assembly
• Fits behind the burner cap and works with the range's ignition system

• Disconnect power and shut off gas supply before attempting any service
• Handle carefully by the base; avoid touching the ceramic tip or electrode surface
• Make sure burner cap and surrounding parts are properly seated after installation

This electromechanical water inlet valve controls water flow into the dishwasher so cycles fill properly and stop when full. Replaces a failed inlet assembly to restore normal fill and prevent overfilling. What it does

• Opens and closes to let water into the wash tub when the cycle calls for it
• Stops water flow when the required level is reached
• Commonly replaces valves that cause no-fill, slow-fill, or continuous-fill symptoms
• Can stop leaks originating from a worn or cracked valve body or seals

• One water inlet valve assembly

• Disconnect power and shut off the water supply before starting work
• Verify inlet hose and fittings are free of debris before installation
• Inspect and replace any worn inlet hoses or clamps while accessible

A replacement cooktop surface burner that distributes the gas flame for efficient heating on gas ranges and cooktops. Restores proper flame placement so cookware heats evenly and safely. What it does:

• Provides the flame path for a single gas cooking zone
• Helps restore even heating when flames are misaligned or weak
• Replaces damaged, corroded, or warped burner components
• Works with the cooktop's ignition and valve to produce a steady flame

• One burner

• Turn off the gas supply and unplug the appliance before removing or installing the burner
• Replace only when the appliance is cool and no gas odor is present
• Hand-tighten or seat the burner per the appliance design; avoid forcing or bending parts
• If you detect a gas leak, or are unsure about installation,

This burner tip is the OEM-style nozzle that directs gas to the burner for reliable ignition and a steady flame. It restores proper fuel flow and flame shape so the appliance heats evenly and lights consistently. What it does:

• Directs gas flow from the valve to the burner for correct combustion
• Helps produce a consistent, even flame for reliable cooking or baking
• Can resolve ignition problems like weak or uneven flames
• Supports stable burner performance after a worn or damaged tip is replaced

• Turn off gas supply and power before starting any repair
• Replace with the exact part number and tighten to the manufacturer's recommended specifications
• Inspect surrounding fittings and gaskets; check for leaks after installation

The Nozzle Set is an OEM replacement part for Bosch LP gas ranges. It consists of precision-calibrated nozzles that regulate fuel flow to the burners, ensuring proper flame size and heat output. Accurate nozzle sizing is vital for safe, reliable cooking operations.

Causes of a bad nozzle set often relate to normal wear over extended usage periods. Exposure to heat cycling and food debris accumulation could cause clogging or damage nozzle openings.

Symptoms of a bad nozzle set include:

• Burner flames that blow out easily with pans in place
• Nozzles holes clogged or severely corroded/damaged
• Burners that emit excess smoke or soot at any setting
• Inability to achieve desired temperature ranges

This OEM Bosch part is also compatible with Thermador, Gaggenau, and some Kenmore models.
