Parts for Lg LRE3083BD/00: Cavity Part Parts

This customized screw secures appliance components where a standard fastener won't fit, helping keep panels, brackets and small assemblies stable. It's a direct-fit replacement when the original specialized screw is missing or damaged. What it does:

• Fastens and holds appliance panels, brackets or small parts in place
• Prevents rattling, loose trim or misaligned components caused by a missing or stripped screw
• Matches the OEM fit and thread pattern for proper engagement and alignment
• Used in locations that require a non-standard or customized fastener

• Disconnect power and water before servicing the appliance
• Use the correct screwdriver or driver bit to avoid stripping the head
• Tighten securely but do not overtighten; overtightening can strip threads or crack parts
• Keep removed hardware organized so you can reinstall in the original location

This hardware washer helps distribute fastener load and maintain proper spacing in your LG appliance. Replacing a missing or worn washer restores secure mounting and alignment, reducing vibration and rattling from loose assemblies.

• Distributes the load of a screw or bolt and protects mating surfaces to maintain alignment
• Helps keep components secure and at the correct spacing
• A damaged or missing washer can lead to loosening, vibration, or rattling during operation
• Ensures correct hardware stack-up during reassembly after service

• Disconnect power and shut off water or gas before servicing
• Note the order and orientation of any washers/spacers; take a reference photo
• Use the correct driver or wrench and tighten snugly—do not overtighten
• Replace companion hardware if corroded, stripped, or damaged

The Common Nut is an OEM part for LG ranges. It secures the fan blade to the motor shaft. This nut maintains the fan's stability and preventing it from becoming dislodged during use.

Causes of a bad common nut can include loosening over time due to vibration, improper installation, or damage from impact or mishandling.

Symptoms of a bad common nut include:

• Excessive noise or vibration from the fan assembly
• The fan blade becoming loose or detached, causing poor air circulation
• Potential risk of the fan blade becoming a projectile if completely detached

This OEM LG part is also compatible with some Kenmore models.a

This factory-specified fastener secures designated panels and components, restoring a precise fit and helping keep your appliance solid and quiet. Replace a missing, stripped, or rusted original with the correct OEM match for the specified locations.

• Secures brackets, panels, and internal parts where this part number is called out
• Replaces damaged, stripped, corroded, or lost screws
• Helps reduce looseness and vibration that can cause rattling noises
• Exact OEM replacement for positions requiring this specific screw

• Disconnect power and shut off water/gas before servicing
• Match to the removed screw and install only in the locations specified for this part number
• Start threads by hand to avoid cross-threading; tighten snugly without overtightening, especially into plastic
• If multiple screws are involved, start all fasteners before final tightening to ensure alignment

The Screw is an OEM component specifically designed for LG ranges. It plays an important mounting and fastening role by securely attaching internal components together.

The screws utilized within the range cabinet ensure sturdy construction and reliable mechanical cohesion. They allow for simple assembly and proper alignment of inner parts.

Causes of bad screws can include wear and tear over time, or damage from overtightening leading to stripped threads or heads.

Symptoms of bad screws include:

• Loose, detached, or misaligned inner parts
• Hardware that does not fit or interface as designed
• Unintended noises or movement during the operation

This OEM LG replacement part is also compatible with Sears/Kenmore and some GE ranges utilizing similar fasteners. Replacement ensures the range remains mechanically sound.


This small, board-mounted tactile push-button switch is used on the control panel. It registers a momentary press so the control board can accept your selection. Replacing a worn switch restores reliable button response and consistent operation.

• Mounts to the user interface board and provides momentary contact when a button is pressed
• Sends a low-voltage signal to the control, enabling cycle or option selection
• Typical failure symptoms: unresponsive or intermittent buttons, needing extra force to register, stuck/always-on input, or unintended beeps/changes
• Helps restore consistent user-interface input when an individual button switch has failed

• Disconnect power to the appliance before servicing; shut off gas/water if applicable
• Access the control panel to reach the user interface board
• This is a board-level repair; note switch orientation. Replacement may require desoldering/soldering per OEM procedure
• Use ESD precautions and avoid overheating PCB pads; test button function before reassembly

The MOTOR, AC FAN is an OEM part for LG refrigerators, designed to circulate air efficiently throughout the unit. This vital component ensures that cool air is distributed evenly across the refrigerator and freezer compartments, aiding in maintaining consistent temperatures to keep food fresh and prevent spoilage.

Causes of a bad MOTOR, AC FAN can range from wear and tear over time, dust and debris accumulation impeding the motor's function, to electrical malfunctions preventing the motor from operating.

Symptoms of a bad MOTOR, AC FAN in a refrigerator include:

• Inconsistent or warming temperatures within the refrigerator or freezer compartments
• The refrigerator running longer than normal or working harder to maintain cool temperatures
• Unusual noises suggesting the fan motor is struggling to operate or has failed

This OEM LG part is also compatible with some Kenmore models.

A replacement bracket assembly that secures internal components and maintains correct alignment for reliable operation. Restores proper mounting and reduces noise or movement caused by loose or damaged supports. What it does:

• Provides a secure mounting point for internal appliance components to prevent shifting or sagging
• Restores alignment that can stop rattling, vibration, or intermittent contact issues
• Supports housings, panels or subassemblies to maintain proper clearance and function
• Replaces bent, cracked, or broken brackets that compromise component stability

• One bracket assembly as shown

• Recommend disconnecting power (and water, where applicable) before beginning any repair
• Remove panels or covers as needed to access the mounting location; keep fasteners organized
• Use appropriate hand tools; inspect adjacent parts and replace any damaged fasteners or clips

The Magnetron Thermostat is an OEM part for LG microwaves and built-in ranges. Its primary function is to monitor the temperature and ensure that it remains within a safe operating range. If the temperature exceeds the preset limit, the thermostat will interrupt the power supply to the magnetron, preventing overheating and potential damage.

Causes of a faulty magnetron thermostat can include electrical malfunctions, component failures, or physical damage. These factors can result in issues such as erratic heating, microwave not heating properly, or the appliance shutting off unexpectedly.

Symptoms of a bad magnetron thermostat may include:

• Microwave not heating food evenly or at all
• Inconsistent or weak heating performance
• Microwave shutting off or displaying error codes related to temperature issues

This OEM LG part can also be used on Kenmore/Sears appliances.

This replacement bar serves as the exterior door handle/trim that lets you open and close the appliance door smoothly while restoring the unit's original appearance. It's a direct-replacement style part designed to fit the factory mounting points. What it does:

• Provides a secure grip for opening and closing the appliance door
• Restores damaged, cracked, or cosmetically worn door trim/handle areas
• Helps maintain proper door alignment and fit when installed correctly
• Reduces draft and keeps the door sealing surface operating as intended

• One replacement bar

• Disconnect power (and for refrigerators, unplug the unit) before attempting removal/installation
• Remove any door shelves or trim blocking access; support the door during handle removal to avoid damage
• Reuse any required screws or brackets only if shown in OEM instructions; replace damaged fasteners

This incandescent oven lamp provides interior illumination so you can safely check food without opening the door. Direct replacement for a burned or dim oven/range light to restore cooking visibility. What it does

• Replaces a burned-out or flickering oven interior light bulb
• Restores clear visibility of the oven cavity for monitoring cooking progress
• Helps avoid opening the oven door unnecessarily, preserving oven temperature
• Fits the original lamp socket and installs in the oven light housing

• Disconnect power to the appliance before replacing the lamp to prevent electric shock
• Allow the oven and old bulb to cool completely before handling
• Use a cloth or gloves when installing the new lamp to avoid transferring oils from skin

This sheath heater is the electric element that delivers radiant heat for the unit's heating cycles, such as grill/broil or convection. Replacing a failed heater restores proper temperature performance and consistent results.

• Generates radiant heat when energized to help reach and maintain set temperature
• Supports grill/broil or convection functions for browning and even cooking
• Common failure signs: no heat in those modes, extended preheat times, uneven results, tripped breaker, or a visibly blistered/broken element
• Restores reliable heating performance when the original element is open or shorted

• Disconnect power and let components cool before servicing
• If servicing a microwave, remember high-voltage components can retain a dangerous charge; discharge the capacitor and consider service if you're not experienced
• Handle the element by its brackets; avoid bending the sheath or stressing terminals
• Move wires one at a time to the new part and verify element continuity with a multimeter before reassembly

AC synchronous motor assembly that turns the appliance's rotating components to restore normal operation. Replace this motor if the appliance fails to spin, spins intermittently, or produces unusual humming or grinding noises. What it does:

• Replaces the appliance's worn or failed AC synchronous motor to restore rotation and proper function.
• Helps address symptoms such as no rotation, intermittent spinning, humming, grinding, or failure to start.
• Connects to the existing motor mounting and electrical connectors as a direct replacement when the part numbers match.
• Matches OEM function and electrical type (AC synchronous) for compatible appliance platforms.

• Always disconnect the appliance from power before starting any repair.
• Remove the appropriate access panels to reach the motor; support any heavy components (drum/rotator) while you work.
• Verify that the motor's wiring connectors and mounting points match the original before final installation.

The Broil Element is an OEM replacement part for LG electric ranges. As a vital upper heating system, this broil element helps efficiently brown and crisp foods placed directly under or on the top rack of the oven.

Causes of a defective broil element may relate to normal wear and tear on the coils from repeated high-heat cooking. Food residues adhering over time can reduce performance.

Symptoms of a problematic broil element include:

• Inadequate or uneven browning from the top-level heating system
• Diminished functionality of the broil setting on the control panel
• Potential thermal damage or exposed wiring from a failed element

This OEM component fits some Kenmore/Sears electric range models as well.

The Bake Element is an OEM replacement part for LG wall ovens and ranges. It is responsible for providing heat during the bake functions.

Symptoms of a bad bake element include:

• Inconsistent or unreliable bake temperatures
• Hot/cold spots leading to uneven cooking results
• Premature failure of bake cycles or overload tripping

Causes can be normal wear over thousands of heating cycles. Improper cleaning allowing residue buildup may also degrade element performance prematurely. Accurate, dependable heat is required for successful baking.

This OEM LG part is also compatible with Kenmore and Frigidaire wall ovens and ranges.

This control panel assembly is the front user interface that holds the touchpad/buttons and display, restoring responsive controls and a finished look to the appliance. It replaces a cracked, faded, or unresponsive front control surface. What it does

• Provides the front-mounted buttons/touchpad and display lens used to select cycles and functions.
• Routes user input to the appliance's control electronics so commands register correctly.
• Restores a damaged, cracked, or scratched control surface that interferes with button use.
• Helps address symptoms such as unresponsive or stuck buttons, missing or obscured markings, and visible panel damage.

• One control panel assembly (front user interface)

• Disconnect power to the appliance before beginning work to avoid shock.
• Remove outer trim or screws as needed; handle the display lens and ribbon cables gently to avoid damage.
• Keep small screws and clips organized during disassembly; reconnect all cables securely before reassembly.

This door handle mounting anchor creates the fixed attachment point on the appliance door or drawer. Replacing a worn or missing anchor restores a solid, wobble-free handle and a consistent feel when opening and closing.

• Provides the secure mounting point that the handle fastens to
• Helps keep the handle aligned and rigid during use
• Replace if the anchor is cracked, stripped, or missing
• Resolve a loose/wobbly handle, a handle that won't tighten, or misalignment after service

• Disconnect power; turn off the water supply
• Protect the door/drawer finish and support the handle during removal
• Remove the handle per your model's instructions and take out the damaged anchor
• Install the new anchor using the existing mounting location/hardware, seat the handle fully, then tighten set screws evenly without overtightening
